Ace Plus EX-G037 User manual

EX-G037
VGA/YPbPr & Audio to HDMI Converter
User Manual
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 1 of 9

Safety and Notice
The EX-G037 VGA/YPbPr & Audio to HDMI Converter has been tested for
conformance to safety regulations and requirements, and has been certified for
international use. However, like all electronic equipments, EX-G037 should be used with
care. Please read and follow the safety instructions to protect yourself from possible
injury and to minimize the risk of damage to the unit.
zFollow all instructions and warnings marked on this unit.
zDo not attempt to service this unit yourself, except where explained in this manual.
zProvide proper ventilation and air circulation and do not use near water.
zKeep objects that might damage the device and assure that the placement of this
unit is on a stable surface.
zUse only the power adapter, power cords and connection cables designed for this
unit.
zDo not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 2of 9

Introduction
This EX-G037 offers an easy and instant approach for converting analog PC video
(VGA) and component video (YPbPr) with either digital audio (S/PDIF) or analog stereo
audio to digital HDMI. With this module, VGA based devices such as PC with S/PDIF or
analog stereo audio can readily connect to your HDMI TV. With such a convenience,
presentations, demonstrations, or digital signage become easier and more cost effective.
DVI PC
HDT
HDMI
E
X
-G037
Audio cable
VGA cable HDMI display/projector
Features
zHDMI 1.2a Compliant
zPC video supports up to UXGA (1600x1200) or WUXGA (1920x1200)
zSupport HD (1080i / 720p) component video
zCoaxial S/PDIF audio input
zStereo analog audio input
zFront panel LED indicators
zEasy installation
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 3of 9

Package Content
z1x EX-G037
z1x VGA to YPbPr breakout cable
z1x 5V 4A power adapter
z1x User Manual
Technical Specifications
zVideo Bandwidth: 165 MHz
zInput Video Signal: 1.2 volts p-p
zOutput DDC Signal: 5 volts p-p (TTL)
zInput resolution up to UXGA (1600x1200) / WUXGA (1920x1200)
zHDMI Connector: 19 pin type female connector
zDSUB Connector: 15 pin female
zRCA Connector: Coaxial S/PDIF (PCM 48k)
zPhone Jack: Analog stereo audio
zPower Supply: 5V DC
zPower Consumption: 15 Watts (max)
zDimensions: 127mm x 105mm x 27mm (5”x4.1”x1”) (L x W x H)
zWeight: 430g (15oz)
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 4of 9

Resolution Support
PC video (VGA)
VESA 640x400 @85Hz VESA 1024x768 @60Hz VESA 1280x960
@85Hz
VESA 720x400 @85Hz VESA 1024x768 @75Hz VESA 1280x1024
@60Hz
VESA 640x480 @72Hz VESA 1024x768 @85Hz VESA 1280x1024
@85Hz
VESA 640x480 @75Hz VESA 1152x864 @60Hz VESA 1360x768
@60Hz
VESA 640x480 @85Hz VESA 1152x864 @75Hz VESA 1400x1050
@75Hz
VESA 800x600 @60Hz VESA 1280x768 @60Hz VESA 1920x1200
@60Hz
VESA 800x600 @72Hz VESA 1280x768 @75Hz VESA 1600x1200
@60Hz
VESA 800x600 @75Hz VESA 1280x768 @85Hz
VESA 800x600 @85Hz VESA 1280x960 @60Hz
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 5of 9

DIP Switch
Mode
2: Off Analog audio input
2: On S/PDIF audio input
1: Off Write back default factory EDID into flash
1: On Learn monitor’s EDID and save into flash
Component Video (YPbPr)
EIA 720x480p @59.94(60)Hz
EIA 720x576p @50Hz
EIA 1280x720p
@59.94(60)Hz
EIA 1920x1080i
@59.94(60)Hz
EIA 1920x1080p
@59.94(60)Hz
712x484 (NTSC)
702x574 (PAL)
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 6of 9

Panel Descriptions
Front Panel
1. S/PDIF Input
2. Audio Input
3. VGA/YPbPr Input
4. YPbPr/VGA Switch Button
Rear Panel
5. Mode Switch
4
3
2
1
9
8
6
5
7
+5
V
D
C
6. HDMI Detection
7. HDMI Output
8. Power Indicator
9. 5V DC
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 7of 9

1. Connect VGA or YPbPr source to the video input.
2. Connect S/PDIF or stereo audio source to RCA jack or 3.5mm jack.
3. Connect HDMI TV to the HDMI output connector
4. Power up the EX-G037.
Hardware Installation
EDID Learning
1. Power up the EX-G037. Connect display to HDMI Output.
2. To learn EDID from HDMI display, pull down the DIP switch 1 to ON, the green light
will be dark and bright to indicate the EDID learning process is complete. You DON’T
NEED to pull up the DIP switch again unless you want to learn another EDID by
pulling DIP switch 1 up and down.
Notice
1. Only HDMI enabled TV sets with underscan/overscan* support, the full active video
can be accurately displayed. Some HDMI equipped TV sets may not support this
feature. If underscan/overscan* is NOT supported, the top, bottom, left and right
border of the active video may be screened, and the S/PDIF audio may not sound
right.
2. Analog stereo audio can merely support 2-channel audio. This version does NOT
support 8-channel analog audio applications.
3. S/PDIF audio input supports the main 2-channel audio input
4. S/PDIF supports only 48KHz audio sample rate. Other than this rate, the input digital
audio should be adjusted to 48KHz in order to get audio signal correctly sent.
* The underscan mode displays the full video frame, which reveals content on the edge that is
recorded. In overscan, the field monitor zooms in to the area that would be visible on most
televisions. Set the field monitor to underscan if your video will be viewed on a computer
monitor or shown with a projector and also to look for light stands, microphones, and other
unwanted objects on the edges of your shot. Set it to overscan to see how the video will look on
a television.
