BACnet OUTSIDE SERIES
Installation & Operation Instructions
Version 1.0
I0000806
GENERAL INFORMATION
The BACnet Outside Series sensor is designed for use with
electronic controllers in commercial heating and cooling
building management systems. The ACI BACnet Immersion
Series sensor can be ordered to monitor temperature, RH,
or temp/RH of outside environments. It uses BACnet MS/TP
forphysicalconnection toaBASorcontroller,has dipswitch-
es to set addresses and baud rate, and has on board
end-of-line termination. There is no analog output.
WIRING INSTRUCTIONS
The BACnet Outside Series temperature sensor has a
depluggable terminal block located on the front of the
PCB. For ease of wiring, we recommend removing the
block, wiring, and reattaching before before
mounting. 16 to 22 AWG two conductor shielded
cable is recommended for powering the sensors.
ACI recommends using Belden 3105 or compatible
cable for RS-485 communication wiring. This wire has
120 ohm input impendence. The terminal blocks allow
for (1) or (2) wires to be connected in each position for
daisy chaining. Daisy chain the RS-485 wiring and do
not use “Star” or “T” wiring.
Avoid running communication wires next to AC line
voltage wires. These can be sources of noise that can
aect signal quality.
PRECAUTIONS
•DO NOT RUN THE WIRING IN ANY CONDUITWITH
LINE VOLTAGE (24/120/230 VAC).
•Remove power before wiring. Never connect or
disconnect wiring with power applied.
•It is recommended you use an isolated UL-listed
class 2 transformer when powering the unit with
24 VAC. Failure to wire the devices with the correct
polarity when sharing transformers may result in
damage to any device powered by the shared
transformer.
FIGURE 1: ENCLOSURE DIMENSIONS
EURO (-EH) ENCLOSURE
PROBE 4.70”: TEMP. ONLY
PROBE 3.00”: RH and RH/TEMP.
1.90"
(48.28 mm)
4.30"
(109.22 mm)
3.80"
(96.56 mm)
2.12"
(53.72 mm)
4.70"
(119.46 mm)
2.12"
(53.72 mm)
3.00"
(76.20 mm)

Page 2
PRECAUTIONS (Continued)
• If the 24 VDC or 24VAC power is shared with devices
that have coils such as relays, solenoids, or other
inductors, each coil must have an MOV, DC/ACTransorb,
Transient Voltage Suppressor (ACI Part: 142583), or
diode placed across the coil or inductor. The cathode, or
banded side of the DC Transorb or diode, connects to
the positive side of the power supply. Without these
snubbers, coils produce very large voltage spikes when
de-energizing that can cause malfunction or
destruction of electronic circuits.
MOUNTING INSTRUCTIONS
For optimal readings, follow these tips:
•Mount in shade on North side of the structure to
minimize sun exposure. In the Southern hemisphere
the South side of the building is where the sensor
should be mounted.
•Mount at least 1’-2’ (0.3-0.6 m) below eave to prevent
thermal radiation from aecting performance – see
FIGURE 2.
•Mount at least 4’ (1.22 m) above ground to prevent
thermal radiation rising up aecting performance.
•The plastic tube that houses the sensor must be
pointed down to avoid debris, water, or ice
potentially aecting sensor performance.
•Avoid mounting to chimney walls, above windows,
above vents, near doors, or dampers.
Remove the cover from the housing by turrning counter
clockwise. Attach the base directly to the wall. Mounting
holes are located at the bottom of the housing – see
FIGURE 1. Drill pilot holes for the mounting screws. Use the
enclosure mounting holes as a guide, or use the dimensions
listed above to measure out.
Install the PG11 watertight tting supplied with the sensor if not
using conduit. The outer knockout ring (PG 11/16) on housing
should not be removed when using a ½”NPT conduit tting.Take
care when mounting. Sensors should not be placed in
direct sunlight, or any other potential heating or cooling sources that could aect temperature being sensed.
Refer to the wiring instructions below to make necessary connections. After wiring, tighten the -EH cover clockwise onto the enclosure.
Conrm gasketed cover is fastened securely in order to prevent any moisture being introduced into housing.
Version 1.0
I0000806
FIGURE 2: MOUNTING LOCATIONS
FIGURE 3: LAYOUT
TERMINAL BLOCKS
RESET BUTTON
DIP SWITCH
END OF LINE
TERMINATION
LED
POWER
ADDRESS BAUD
D+
EN DIS
BACNET
VD-GN
4
62
36 18421421
Recommended 1-2 ft
(0.3-0.6 m) Below Eave
Install Sensor
Downward
Roof
Ground
TABLE 1: WIRING CONNECTIONS
TERMINAL BLOCKS
+V
GN
D-
D+
CONNECTIONS
Power Supply Positive 12-36VDC / 24 VAC
Power Supply Common or Ground
EIA-485 Data Negative
EIA-485 Data Positive

Page 3
Version 1.0
I0000806
BACnet MS/TP INTERFACE
The BACnet Master-Slave/Token-Passing (MS/TP) data link protocol uses EIA-485 as a two-wire, daisy chain network. A branch is a
discrete chain of devices connected to a controller. The max number of devices per segment is (32), as per the BACnet
specications. 4000 ft (1219.2 m) is the maximum recommended length for a segment, which includes all devices from the
controller to the last device in the daisy chain. ACI’s BACnet sensors are master devices. Only master nodes are allowed to send
and receive tokens on the MSTP network.
Each branch must have all devices connected with (+) connected to (+) and (-) connected to (-). If a shielded cable is used, this is
not to be connected to the devices. The shield cable should only be connected on one end to earth ground, usually at the
controller. The start and end of each branch should have a termination resistor at the device level or at the controller.
Each device must be congured for the correct baud rate and have a unique address in each branch.The baud rate for the branch
is set by the controller. This product has auto-baud for ease of network conguration but setting the baud rate using the DIP
switches is recommended.
ADDRESS SELECTION
Switches 1-7 are used to set the BACnet address. Refer to TABLE 2 for switch settings. Each device in a network branch must
have a unique address. The value of each position is printed on the board. By default, the address is (0). If the device is
powered when a change is made, the device must be power cycled or reset for changes in address to be made.
ADDRESS
0
1
12
SW 1 (64)
0
0
0
SW 2 (32)
0
0
0
SW 3 (16)
0
0
0
SW 4 (8)
0
0
1
SW 5 (4)
0
0
1
SW 6 (2)
0
0
0
SW 7 (1)
0
1
0
TABLE 2: ADDRESS SELECTION
BAUD RATE
Auto-Baud
9600
19200
38400
57600
76800
115200
SW 8
0
0
0
0
1
1
1
SW 9
0
0
1
1
0
0
1
SW 10
0
1
0
1
0
1
0
BAUD RATE SELECTION
Switches 8-10 are used to set the BACnet baud rate.
Refer to TABLE 3 for switch settings. Where (0) is low
and (1) is high. By default, the device is in auto-baud. If
the system’s baud rate is known, it is recommended to
set the specic baud rate to match the system. If the
device is powered when a change is made, the device
must be power cycled or reset for changes in baud rate
to be made.
TABLE 3: BAUD RATE SELECTION
EOL TERMINATION RESISTANCE
SELECTION
RS-485 requires that the last device in a chain have a
termination resistor. This is controlled using a jumper
in the EN (enabled) position marked on FIGURE 4.
When the jumper is set to EN (enabled), a 120 Ω
resistance is added in parallel to the data line. When
the jumper is set to DIS (disabled), the resistance is not added. By default, the jumper is placed the DIS (disabled) position.
FIGURE 4: EOL TERMINATION JUMPERS
END OF LINE
TERMINATION ENABLED END OF LINE TERMINATION DISABLED
EN DIS EN DIS

Page 4
DEVICE CONFIGURATION THROUGH BACnet
DEVICE INSTANCE
The Device Instance, by default, is 1035000 plus the Address. For example, an Address of 21 results in a default address
of 1035021. This can be changed once the device is connected to the network, but each device instance must be unique
within the network. The device instance must be unique throughout the entire BACnet network, not just this segment.
DEVICE LOCATION
The device location is optional but is intended to allow for further denition of the device’s location. The device location can
be a character string up to 64 characters in length.
DEVICE NAME
By default, the device name is based on the type of device and the address. The device name can be a character string up to
(32) characters in length. This can be changed once the device is connected to the network. For example: Temperature
Sensor - 034. The device name must be unique throughout the entire BACnet network, not just this segment.
DEVICE DESCRIPTION
By default, the device name is based on the type of device and the address. The
device name can be a character string up to (32) characters in length. This can be
changed once the device is connected to the network. For example: Temperature
Sensor - 034. The device name must be unique throughout the entire BACnet
network, not just this segment.
LED INFORMATION
One LED indicates three statuses. Solid green shows that power is good, but no data is transmitting. A solid Amber indicates that
auto-baud is set and no data has been received to set a baud rate. Green/Amber ashing indicates data is being transmitted or
received. Solid Red LED status indicates an error state, usually loss of communication on the network. If this status remains for
(10) times the APDU timeout, the device will automatically reset. If this state remains longer than that, reset the device.
TEMPERATURE CONFIGURATION
One LED indicates three statuses. Solid green shows that power is good, but no data is transmitting. A solid Amber indicates that
auto-baud is set and no data has been received to set a baud rate. Green/Amber ashing indicates data is being transmitted or
received. Solid Red LED status indicates an error state, usually loss of communication on the network. If this status remains for
(10) times the APDU timeout, the device will automatically reset. If this state remains longer than that, reset the device.
TEMPERATURE AND RH OFFSET
This device allows for a temperature oset of +/-5 °C (9 °F) and an RH oset of +/-10%. By default, these values are set to 0,
meaning no oset is added. These are set by writing to the present value of the Temperature Calibration Oset (AV0) or RH
Calibration Oset (AV1). The value written must be within the specied range or an error will be returned. To set these back
to factory settings, write any changed values to (0).
TEST MODE
For the Sensor objects (AI0 and AI1), a test mode can be set by writing the Boolean value true to the “out-of-service”
property. Then the present-value can be set to any valid test value the user requires. This allows a user to test reactions to
specic values returned by this device.
RESET
The reset button can be used to reset the device without disconnecting power.The location of this button is shown in FIGURE 3 (p. 2).
Version 1.0
I0000806
TABLE 4: UNIT SETTING
UNITS
°F
K
°C
VALUE
64
63
62

W.E.E.E. DIRECTIVE
At the end of their useful life the packaging and product should be disposed of via a suitable recycling centre.
Do not dispose of with household waste. Do not burn.
TABLE 5: BACnet OBJECT TABLE
Page 5
Version 1.0
I0000806
OBJECT TYPE
Device
Analog
Inputs
Analog
Values
BACnet ENGINEERING UNITS
- - - - - - - - - - - - - - - - - - - - - - - - - - -
degrees-Fahrenheit (64) - default
percent-relative-humidity (29)
delta-degrees-Fahrenheit (120)
percent-relative-humidity (29)
RANGE
0-4194302
-40.0 - 176.0
0.0 - 100
-9.0 - 9.0
-10.0 -10.0
OBJECT NAME
BN11x0
Temperature Sensor
RH Sensor
Temperature
Calibration Oset
RH Calibration Oset
OBJECT ID
- - - - - - - - - - -
AI-0
AI-1
AV-0
AV-1
PRODUCT SPECIFICATIONS
12 to 36 VDC / 24 VAC +/- 10%, 50/60 Hz (Reverse Polarity Protected)
25 mA maximum (0.67 VA)
-40 to 176°F (-40 to 80°C)
@ 77°F (25°C): +/- 1.0°F (+/- 0.5°C)
+/- 9°F (+/- 5°C) (Field Congurable)
0 to 100%
@ 77°F (25°C): +/- 2% from 10 to 90% RH
+/- 10% RH (Field Congurable)
4 seconds
BACnet MS/TP; EIA RS-485
0 to 127 (0 (Default); Field Selectable)
Auto Baud (Default), 9600, 19200, 38400, 57600, 76800, 115200 (Field Selectable)
1035000 + Address (example: Address 127 = 1035127; Field Congurable)
Screw Terminal Blocks / 16 AWG (1.31 mm2) to 22 AWG (0.33 mm2)
0.45 lbf-in (0.5 Nm) nominal
-40 to 176°F (-40 to 80°C)
-40 to 185°F (-40 to 85°C)
10 to 95% RH, non-condensing
Aluminum, diameter: 1.125”(28.58 mm) | “EH”Enclosure: ABS Plastic, UL94-V0
Supply Voltage:
Current Consumption:
Temperature Measurement Range:
Temperature Measurement Accuracy:
Temperature Calibration Oset:
RH Measurement Range:
RH Measurement Accuracy:
RH Calibration Oset:
Temperature / RH Update Rate:
Communication Protocol:
Sensor Addresses:
Supported Baud Rates:
Device Instance Number:
Connections / Wire Size:
Terminal Block Torque Rating:
Operating Temperature Range:
Storage Temperature Range:
Operating Humidity Range:
Sensing and Enclosure Material:
BACnet is a registered trademark of ASHRAE. ASHRAE does not endorse, approve or test products for compliance with ASHRAE standards. Compliance of listed products to the requirements of ASHRAE
Standard 135 is the responsibility of BACnet International (BI). BTL is a registered trademark of BACnet International.
