ACME Invincibled LED-767RGBWII User manual

LED$767'RGBW'II!
!
!
''''''''''''''''''User' Manual!
Please!read!the!instructions!carefully!before!use

1
CONTENTS'
1.!Safety!Instructions....................................................................................................2!
2.!Technical!Specifications............................................................................................3!
3.!How!To!Set!The!Unit.................................................................................................4!
3.1!Control!Panel......................................................................................................4!
4.!How!To!Control!The!Unit..........................................................................................5!
4.1!Master/Slave!Built!In!Preprogrammed!Function................................................5!
4.2!Easy!CAJ8!Controller...........................................................................................5!
4.3!DMX!Controller...................................................................................................6!
5.!DMX!512!Configuration............................................................................................7!
6.!DMX!512!Connection................................................................................................8!
7.!Troubleshooting .......................................................................................................9!
8.!Fixture!Cleaning........................................................................................................9!

2
1.'Safety'Instructions' '
WARNING
Please!keep!this!User!Manual!for!future!consultation.!If!you!sell!the!unit!to!another!user,!be!sure!
that!they!also!receive!this!instruction!booklet.!
Unpack!and!check!carefully!there!is!no!transportation!damage!before!using!the!unit.!
Before!operating,!ensure!that!the!voltage!and!frequency!of!the!power!supply!match!the!power!
requirements!of!the!unit.! !
It’s!important!to!ground!the!yellow/green!conductor!to!earth!in!order!to!avoid!electric!shock.!
The!unit!is!for!indoor!use!only.!Use!only!in!a!dry!location.!
The!unit!must!be!installed!in!a!location!with!adequate!ventilation,!at!least!50cm!from!adjacent!
surfaces.!Be!sure!that!no!ventilation!slots!are!blocked.! !
Disconnect!main!power!before!replacement!or!servicing.! !
Make!sure!there!are!no!flammable!materials!close!to!the!unit!while!operating!as!it!is!fire!hazard.! !
Use!safety!cables!when!installing!this!unit.! !
Maximum!ambient!temperature!is!Ta:!40!degrees!C.!DO!NOT!operate!it!where!the!temperature!
is!higher!than!this.!
Turn!off!the!power!and!allow!about!5!minutes!for!the!unit!to!cool!down!before!servicing.!
In!the!event!of!a!serious!operating!problem,!stop!using!the!unit!immediately.!Never!try!to!repair!
the!unit!by!yourself.!Repairs!carried!out!by!unskilled!people!can!lead!to!damage!or!malfunction.!
Please! contact! the! nearest! authorized! technical! assistance! center.! Always! use! the! same! type!
spare!parts.!
DO!NOT!touch!any!cables!during!operation!as!high!voltage!may!cause!electric!shock.!
Warning:'
To! prevent! or! reduce! the! risk! of! electrical! shock! or! fire,! do! not! expose! the! unit! to! rain! or!
moisture.!
The!housing!and!lenses!must!be!replaced!if!they!are!visibly!damaged.!
Please!read!the!instructions!carefully!as!they!include!important!information!
about!installation,!usage!and!maintenance.!

3
Caution:'
There! are! no! user! serviceable! parts! inside! the! unit.! Do! not! open! the! housing! or! attempt! any!
repairs!yourself.!In!the!unlikely!event!your!unit!may!require!service,!please!contact!your!nearest!
dealer.'
Installation:'
The!unit!should!be!mounted! via! its!screw!holes!on!the! bracket.! Always!ensure!that!the! unit! is!
firmly! fixed! to! avoid! vibration! and! slipping! while! operating.! Make! sure! that! the! structure! to!
which! you! are! attaching! the! unit! is! secure! and! is! able! to! support! a! weight! of! 10! times! of! the!
unit’s! weight.! Also! always! use! a! safety! cable! that! can! hold! 12! times! of! the! weight! of! the! unit!
when!installing!the!fixture.! !
The!equipment!must!be!installed!by!professionals.!It!must!be!installed!in!a!place!where!is!out!of!
the!reach!of!people!and!no!one!can!pass!by!or!under!it.!
2.'Technical'Specifications' '
!3!DMX!channels:!Dimmer/Strobe,!Colour,!Rotation;!
!3!operation!modes:!DMX,!Master/Slave,!Sound!Active;!
!BuiltJin!programs!in!Master/Slave!operation!triggered!by!music;!
!Full!range!dimmer!and!variable!strobe!effects;!
!Optional!easy!controller!CAJ8!for!instant!lighting!shows;!
◇'Power'Voltage:!!!!!!!!!!!AC!100~240V,!50/60Hz!
◇'Power'Consumption:''''''23W!
!Power'Cable'Daisy'Chains:''24!Fixtures!Max.!(230V,!50Hz)!
!!!!!!!!!!!!!!!!!!!!!!!!!!16!Fixtures!Max.!(120V,!60Hz)'
◇'LED'Sources:!!!!!!!!!!!!!1!×!10W!CREE!QuadJColor!LED!
◇'Weight:' ' '''''''''''''''3.3Kgs!
◇'Dimension:''''''''''''''215!×!172!×!195mm!

4
3.'How'To'Set'The'Unit' '
3.1'Control'Panel' '
1.'MICROPHONE:'Receives!music!signals!for!sound!active!mode;'
2.'ONLY'FOR'REMOTE'CONTROL:'Connects!with!the!optional!CAJ8!to!control!the!unit;! !
3.'DMX'IN:!DMX!512!link,!use!a!3Jpin!XLR!cable!to!link!the!unit!to!the!DMX!controller;' '
4.'DMX'OUT:!DMX!512!link,!use!a!3Jpin!XLR!cable!to!link!to!the!next!unit;' '
5.'DIP'SWITCH:'Manually!selects!the!start!address;!

5
6.'FUSE'(T!6.3A):'Protects!the!unit!from!overJvoltage!or!short!circuit;'
7.'POWER'OUT:'Connects!to!the!next!unit;'
8.'POWER'IN:'Connects!to!power!supply;'
'
4.'How'To'Control'The'Unit' '
You!can!operate!the!unit!in!three!ways:!
'1.!Master/slave!builtJin!preJprogram!function!
!2.!Easy!controller!(optional!CAJ8)!
3.!Universal!DMX!controller!
You!do!not!need!to!turn!the!unit!off!when!you!change!the!DMX!address,!the!new!DMX!address!
setting!will!take!effect!immediately.! !
4.1'Master/Slave'Built'In'Preprogrammed'Function' '
The!unit!can!be!linked!together!in!a!daisy!chain!using!as!many!units!as!you!need!in!master/slave!
mode!to!perform!great!builtJin!preJprogrammed!lighting!shows!triggered!by!music.!
In'Master/Slave'mode'refer'to'the'DMX'settings'below:' '
Master'unit:'DMX'start'address'MUST'be'set'to'001.'(First'DIP'switch'='ON,'all'other'are'OFF)'
Slave'units:'DMX'start'address'may'have'any'value'but'NOT'001'(example:'set'the'first'3'DIP'
switches'to'ON)'
﹡Dipswitch!2!“ON”!has!two!functions:! !
1. Performs!the!builtJin!preJprograms!to!the!music.!
2. Auto!mode:!Eight!Chase(In!this!mode!press!dip!switch!3!and!this!will!change!the!direction!of!
rotation,!press!dip!switch!4,5,6!to!change!the!speed)!
﹡2$light'show'
Dipswitch!10”off”!means!the!unit!works!normally!and!“on”!means!inversion.!In!order!to!create!a!
great!light!show,!you!can!set!dip!switch!10!”on”!on!any!unit!that!is!linked!to!the!master!unit!to!get!
contrast!movement!to!the!master!unit!even!if!you!only!have!two!units.!Dipswitch!10!on!the!first!
(Master)!unit!is!no!use!for!the!2Jlight!show!as!it!is!the!master!unit!that!operates!the!light!show.!

6
4.2'Easy'Controller' '
The!CAJ8!remote!control!is!used!only!in!master/slave!mode.!By!connecting!to!the!1/4”!
jack!socket!to!the!first!unit!you!will!find!that!the!remote!control!will!control!all!the!
other!units!in!Stand!by,!Function!and!Mode!selection.!
!
4.3'DMX'Controller' '
When!using!a!universal!DMX!controller!to!control!the!chain!of!units!you!have!to!set!a!DMX!
address!with!Dip!switches!1!to!9.!Dip!switch!10!is!used!to!select!channel!mode,!it’s!ON!means!1!
channel!mode!and!OFF!means!3!channel!mode.!Please!refer!to!the!following!diagram!to!address!
your!DMX!512!system!using!binary!code.!
DMX'512'Address'Chart:' '
DipJswitches!
#!1!
#!2!
#!3!
#!4!
#!5!
#!6!
#!7!
#!8!
#!9!
#10!
Value!
1!
2!
4!
8!
16!
32!
64!
128!
256!
CH!mode!
!
•!Examples:!
1JCH!mode:!(Dip!switch!10!ON)!
Channel!1:!dip!/!on:!#1!(=1)!
Channel!2:!dip!/!on:!#2!(=2)!
Channel!3:!dip!/!on:!#1,!#2!(1+2=3)!
Channel!4:!dip!/!on:!#3!(=4)!
!
!
!
Stand!by!
Blackout!the!unit!
Function!
1.!Synchronous!Strobe!
2.!Two!light!Strobe!
3.!Sound!Strobe!
Rotation!Speed!
1J8!
Mode!
Strobe!(LED!OFF)!
Rotation!(LED!ON)!

7
3JCH!mode:!(Dip!switch!10!OFF)!
Channel!1:!dip!/!on:!#1!(=1)!
Channel!4:!dip!/!on:!#3!(=4)!
Channel!7:!dip!/!on:!#1,!#2,!#3!(1+2+4=7)!
Channel!10:!dip!/!on:!#2,!#4!(2+8=10)!
5.'DMX'512'Configuration' '
1/3'Channels'Mode:'

8
6.'DMX512'Connection' '
1. The!last!units!DMX!has!to!be!terminated.!Use!a!120!ohm!1/4W!resistor!between!pin!2(DMXJ)!
and!pin!3(DMX+)!of!a!3Jpin!XLRJplug!and!plug!it!in!the!DMX!output!of!the!last!unit.!
2. Connect!the!units!together!in!a!`daisy!chain`!with!an!XLR!cable!from!the!output!of!the!unit!to!
the!input!of!the!next!unit.!The!cable!can!not!branched!or!split!to!a!`Y`!cable.! !
3. The! DMX! output! and! input! connectors! are! passJthrough! type! to! maintain! the! DMX! circuit!
even!when!one!of!the!units’!power!is!disconnected.!
4. Each!fixture!unit!needs!to!have!an!address!set!to!receive!the!data!sent!by!the!controller.!The!
address!number!is!between!0J512!(usually!0!&!1!are!equal!to!1).!
5. DMX!cabling!configuration!is!as!follows:!
3!pin!XLR:!Pin!1:!GND,!Pin!2:!Negative!signal!(J),!Pin!3:!Positive!signal!(+)! !

9
7.'Troubleshooting' '
Following!are!a!few!common!problems!that!may!occur!during!operation.!Here!are!some!
suggestions!for!easy!troubleshooting:!
A.'The'unit'does'not'work,'no'light'and'the'fan'does'not'work'
1. Check!the!connection!of!power!and!main!fuse.!
B.'Not'responding'to'DMX'controller'
1. DMX!LED!should!be!on.!If!not,!check!DMX!connectors!and!cables!to!see!if!linked!properly.!
2. If!the!DMX!LED!is!on!but!no!response!check!the!address!settings!and!DMX!polarity.!
3. If!you!have!intermittent!DMX!signal!problems!check!the!cables!and!connectors.!
4. !Try!another!DMX!controller.! ! !
C.'No'response'to'the'sound'
1. Make!sure!the!unit!is!set!into!the!correct!mode.!
2. Check!the!microphone!by!tapping!it.!
3. Make!sure!the!fixture!is!not!set!into!Blackout!mode!
8.'Fixture'Cleaning' '
Cleaning!must!be!carried!out!periodically!to!optimize!light!output.!Cleaning!frequency!depends!on!
the!environment!in!which!the!fixture!operates:!damp,!smoky!or!particularly!dirty!surrounding!can!
cause!a!greater!accumulation!of!dirt!on!the!unit’s!optics.!
Clean!with!soft!cloth!using!normal!glass!cleaning!fluid!or!mild!soapy!water.!
Always!dry!the!parts!carefully.!
Clean!the!external!optics!at!least!every!30!days.
!
!
!
!
!
!
!

10
Declaration'of'Conformity'
!
We!declare!that!our!products!(lighting!equipments)!comply!with!the!
following!specification!and!bears!CE!mark!in!accordance!with!the!
provision!of!the!Electromagnetic!Compatibility!(EMC)!Directive!
89/336/EEC.!
!
EN55103J1:!2009!;!EN55103J2:!2009;!EN62471:!2008;!
EN61000J3J2:!2006!+!A1:2009!+!A2:2009;!EN61000J3J3:!2008.!
!
&'
Harmonized'Standard'
!
EN!60598J1:2008!+!All:2009;!EN!60598J2J17:1989!+!A2:1991;! !
EN!62471:2008;!EN!62493:!2010!
Safety!of!household!and!similar!electrical!appliances!
Part!1:!General!requirements!
!
'
