Acroprint 125 Operating instructions

General Service Instructions
Models 125 and 150 Recorders
To Remove Case Cover
1) Turn key one quarter turn clockwise.
2) Lift case cover u then forward.
3) Reverse rocedure to re lace cover.
To Set Time and/or Date
NOTE: Unless your recorder is equi ed with
continental (0-23) hours, all PM hours on the time
card will be rinted underscored (Ex.: 1:00). To
change the time and/or date follow these ste s:
1) Un lug recorder and remove Case Cover.
2) To Set Day/Date
A) Make sure current time setting is between
midnight and noon (see note above).
B) Push down and release Yellow Lever (see
Figure 1) to set correct day/date.
C) Plug in recorder and unch card to verify correct
setting. Re eat ste s A-C if reading is incorrect
3) To Set Time
A) Push down and release Black Minute Lever
to set the correct time (see Figure 1). If
minute lever does not work, lug in recorder
and wait for minute hand to advance, then
un lug recorder and try lever again. DO NOT
MOVE CLOCK HANDS TO SET THE TIME.
4) To Set Month (if so equi ed)
A) Turn Month Knob (see Figure 1) counter-
clockwise to select correct month.
B) Plug in recorder and unch card to verify correct
setting. Re eat ste s A-B if reading is incorrect.
5) To Set ear (if so equi ed)
A) Insert oint of en into s oke on side of year
wheel and rotate counter-clockwise.
B) Plug in recorder and unch card to verify correct
setting. Re eat ste s A-B if reading is incorrect.
IMPORTANT NOTES
1) The date setting (if so equi ed) MUST
be manually reset to the first of the
month each month, following any month
with less than 31 days.
2) The month and year settings (if so
equi ed) MUST be manually reset
every month/year.
3) To reset your recorder after a ower
failure follow the ste s 1-5.
4) HINT: If clock is set slightly ahead of actual
time, you may un lug it until it matches the
correct time.
To Set Time and/or Date for Left Print Models
1) Un lug recorder and remove Case Cover.
2) To Set Day/Date
A) Follow the same ste s as for standard models,
but note the different location of Yellow Day/Date
lever in Figure 2.
3) To Set Time
A) Follow the same ste s as for standard models.
4) To Set Month (if so equi ed)
A) Move Month Lever (see Figure 2) to extreme
left osition then return slowly to right until an
audible "click" is heard.
B) Plug in recorder and unch card to verify correct
setting. Re eat ste s A-B if reading is incorrect.
5) To Set ear (if so equi ed)
A) Note that year set lever is located at the rear
of the ty ehead assembly. Follow the same
ste s as for setting the month on left rint
models.
Figure 2 (left print models)
Month Lever
I2 I2
3
4
5
6
7
8
9
I0 II
CR
O
PR
I
T
N
RALEIGH, N.C. USA
Black Minute
Lever
Yellow
Day/Date
Lever
Month Knob (turn counter-clockwise)
Figure 1
(cover removed)
I2 I2
3
4
5
6
7
8
9
I0 II
CR
O
PR
I
T
N
RALEIGH, N.C. USA
Black
Minute
Lever Yellow
Day/Date
Lever
Note: Day/Date & Month levers
are shown in cut-away views.
The levers are behind the clock
dial.

To Change Ribbon
A re lacement Acro rint Ribbon is su lied on two s ools. When ordering s ecify 20-106-002
for two-color right margin rint recorder, 20-106-000 for two-color left margin rint recorder, or
20-0106-003 for solid blue ribbon. To re lace the ribbon, erform the following ste s.
1) Note how ribbon is threaded. Pull right Ribbon Tension S ring (see Figure 3) forward and
remove s ool. Pull left Ribbon Tension S ring (see Figure 3) forward and remove s ool.
Remove and discard ribbon.
2) Insert new right Ribbon S ool with "hex" hole fitted on to "hex" shaft on the right ribbon feed
ratchet. Thread ribbon, as noted in ste 1. Insert new left Ribbon S ool with "hex" hole fitted
on to "hex" shaft on the left ribbon feed ratchet. Turn right Ribbon S ool counter-clockwise
to remove excess slack in ribbon.
Figure 3 (front view with cover removed)
I2 I2
3
4
5
6
7
8
9
I0 II
CR
O
PR
I
T
N
RALEIGH, N.C. USA
Ribbon S ool
Ribbon Tension S ring
Ribbon S ool
Ribbon Tension S ring

Installing the Time Recorder
Unpacking and Inspection
Carefully un ack your recorder and ins ect it for
any damage. Verify that the following accessories
are included: three mounting screws, a case lock
key, and the General Service Instructions. Re ort
damage or shortages to the com any from which
the unit was urchased.
Site Requirements
The recorder should be mounted on a sturdy wall,
shelf, or other su ort area. Do not use the recorder
under the following conditions:
 extremely high or low tem erature
[o erating range: 0° to 50° C (32° to 122° F)]
 extremely high or low humidity
[o erating range: 0 to 90% RH non-condensing]
 areas of high dust concentration
 areas with extreme vibration or when laced on
an unstable or unlevel surface
Mounting the Recorder and Card Racks
The recorder requires an uninterru ted AC ower
su ly, and should be mounted within 6 feet of a
ower rece tacle to accommodate the unit's ower
cord. The suggested wall mounting layout for the
recorder and o tional card racks is shown in Figure
4. Suggestions for mounting on s ecific wall and
shelf surfaces follow.
Wooden/Plywood Walls
You may use the three screws included with the
recorder to mount the recorder. Install a screw in
the wall 53" above the floor. Leave enough of the
screw rotruding so the recorder will hang flat
against the wall through the "keyhole" on back of
the clock. Hang and level the recorder. Insert and
tighten screws through the lower left and right
mounting holes.
Masonry Walls
You may use lastic masonry anchors and screws
available at your local hardware store to mount the
recorder. Mark a location on the wall 53" above
the floor. Drill a hole with a 1/4" masonry bit and
insert a lastic anchor. Tighten a screw at this
location, leaving enough of the screw rotruding
so the recorder will hang flat against the wall through
the "keyhole" on back of the clock. Hang and level
the recorder. Mark the location of the lower left and
right mounting holes. Remove the recorder, drill
holes, and insert anchors. Re lace the recorder,
insert and tighten screws through the lower left
and right mounting holes, and fully tighten the
"keyhole" screw.
Sheetrock/Hollow Core Walls
You may use "molly" fasteners available at your
local hardware store to mount the recorder. Follow
the rocedure for masonry walls, using the "molly"
fasteners instead. Alternatively, you may use longer
wood screws to attach the recorder to a stud behind
the sheetrock, using the "keyhole" and the lower
center mounting hole on the recorder.
Figure 4 (suggested mounting layout)
NOTE: Always consult with a rofessional
contractor/car enter and obey all local
building and fire codes when installing your
recorder.
32"
45"
40"
RECEPTACLE

We declare under our sole res onsibility that the magnetic stri e and/or bar code reading and/or data
recording equi ment Model 125/150/P150 Recorders to which this declaration relates are in conformity
with the following standards: EN 60950-1:1992. I, the undersigned, hereby declare that the equi ment
s ecified above conforms to the above directive and standards.
Raleigh, North Carolina USA
December 6, 2001 W. Glenn Robbins
All Rights Reserved. © COPYRIGHT 1996
Acro rint Time Recorder Com any
Maintenance
To obtain the best results from your recorder, we recommend eriodic ins ection, cleaning, and oiling
throughout each year by an authorized dealer. For further information, contact your dealer or Acro rint
Time Recorder Co., 5640 De arture Dr., Raleigh, NC 27616, U.S.A. IN USA 800.334.7190
Part No: 06-0104-000 Rev. Q
Declaration Of Conformity According To EMC Directive 73/23/EEC
0 .000 30.550
1 .002 31.552
2 .004 32.554
3 .005 33.555
4 .006 34.556
5 .008 35.558
6 .110 36.660
7 .112 37.662
8 .114 38.664
9 .115 39.665
10 .1 16 40 .6 66
11 .1 18 41 .6 68
12 .2 20 42 .7 70
13 .2 22 43 .7 72
14 .2 24 44 .7 74
15 .2 25 45 .7 75
16 .2 26 46 .7 76
17 .2 28 47 .7 78
18 .3 30 48 .8 80
19 .3 32 49 .8 82
20 .3 34 50 .8 84
21 .3 35 51 .8 85
22 .3 36 52 .8 86
23 .3 38 53 .8 88
24 .4 40 54 .9 90
25 .4 42 55 .9 92
26 .4 44 56 .9 94
27 .4 45 57 .9 95
28 .4 46 58 .9 96
Minutes Tenths Hundredths Minutes Tenths Hundredths
DECIMAL EQUIVALENTS OF MINUTE T PE WHEELS
MIDNIGHT
12 0
11
22
33
44
55
66
77
88
99
10 10
11 11
NOON
12 12
113
214
315
416
517
618
719
820
921
10 22
1123
REGULAR
CONTINENTAL
A.M.
P.M.
Conversion Chart
If your recorder is equi ed with a continental hour, tenths or hundredths wheel, lease see the minute
conversion chart below.
