ACS ACM1252U-Z2 User manual

Subject to change without prior notice
[email protected]
www.acs.com.hk
ACM1252U-Z2 User Manual V1.00
User Manual
ACM1252U-Z2
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 2 of 13
Version History
Date By Changes Version
2016-09-19 Keith Mo ● Initial Version 1.00
●
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 3 of 13
Table of Contents
1.0. INTRODUCTION .................................................................................................................................... 4
2.0. FEATURES ............................................................................................................................................. 5
3.0. ARCHITECTURE ..................................................................................................................................... 6
4.0. ACM1252U-Z2 OPERATING PROCEDURE .............................................................................................. 7
4.1. DRIVER INSTALLATION PROCEDURE ................................................................................................................ 7
4.2. OPERATION EXAMPLE ................................................................................................................................ 10
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 4 of 13
1.0. Introduction
The ACM1252U-Z2 is a reader (IFD and PCD) module that support contactless (PICC) smart cards.
The ACM1252U-Z2 is an NFC reader module developed based on the 13.56 MHz
contactless technology. This NFC Reader Module supports all three NFC modes
namely card reader/writer, card emulation, and peer-to-peer communication.
The ACM1252U-Z2 supports ISO 14443 Type A and B cards, MIFARE®, FeliCa,
and ISO 18092–compliant NFC tags. It also supports other NFC devices with an
access speed of up to 424 Kbps and proximity operating distance of up to 30 mm
(depending on tag type used).
It is PC/SC–compliant for interoperability across different applications and platforms
and provides high-speed communication ability for contactless cards and NFC
tags/devices. Post-deployment firmware upgrade is also supported, eliminating the
need for additional hardware modification.
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 5 of 13
2.0. Features
 ISO 14443 Parts 1-4 Compliant for Contactless Smart Card Interface.
 ISO 18092 Compliant for Contactless Smart Card Interface.
 An external antenna for PICC contactless access applications.

The ACM1252U-Z2 supports the following Tag Types:
o
MIFARE Classic. E.g. MIFARE 1K, 4K, MINI and Ultralight.
o
ISO14443-4 Type A and B.
o
ISO18092 FeliCa, NFC tag
 T=CL emulation for MIFare 1K/4K PICCs
 High Speed (424 kbps) Communication for PICCs
 Energy saving modes for turning off the antenna field whenever the PICC is inactive,
or no PICC is found. It prevents the PICC from exposing to the field all the time.
 User-Controllable Peripherals. E.g. LED.
 PCSC Compliant for Contact and Contactless Interfaces.
 USB V2.0 Interface. (12M bps)

Device Firmware Upgradeable through the USB Interface.
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 6 of 13
3.0. Architecture
NXP’s LPC11U37 is for main processor for communication with PC, and control the contactless chip
and peripherals. PN512 act as a contactless chip to perform the communication between contactless
tags and LPC11U37
For communication architecture, the protocol between ACM1252U-Z2 and PC is using CCID protocol.
All the communication between PICC is PCSC Compliant
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 7 of 13
4.0. ACM1252U-Z2 Operating Procedure
4.1. Driver installation Procedure
Hardware requires:
 ACM1252U-Z2
 PC with OS window XP or above
Software requires:
 Driver installer “ACS_Unified_PCSC_Driver_Installer_bin-4.0.6.0-20141114_all.zip”
Steps:
1. Extract the file “ACS_Unified_PCSC_Driver_Installer_bin-4.0.6.0-20141114_all.zip”
2. Execute “Setup.exe”
3. Below screen will be shown
Select the language, then Click “OK”
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 8 of 13
4. Below screen will be shown, “Next” to continue
5. Below screen will be shown, configure the installation path, then “Next” to continue
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 9 of 13
6. Below screen will be shown, “Install” to continue
7. Waiting until below screen shown
Click “Finish”
8. Driver Installation Complete
AdvancedCardSystemsLimited

ACM1252U-Z2 User Manual
[email protected]
Version 1.00
www.acs.com.hk
Page 10 of 13
4.2. Operation Example
Hardware requires:
 ACM1252U-Z2
 PC with OS window XP or above
 Test card x 1 (provided by ACS)
Software requires:
 APDU.exe (for example)
Steps:
1. Plug in the reader into the PC
2. Place the Test Card on the top of the reader about 5cm
3. Open “APDU.exe”
4. Click “1. Select reader”, Chose “ACS ACR1252 CL Reader PICC 0”, then click “OK”
