Application Programming Interface V1.00
ACR1281U-C8
Contactless
Reader/Writer

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 2 of 52
Table of Contents
1.0. Introduction .............................................................................................................4
1.1. Features.................................................................................................................................4
2.0. USB Interface...........................................................................................................5
3.0. Reader Commands..................................................................................................6
3.1. ACR120_Open ......................................................................................................................6
3.2. ACR120_Close ......................................................................................................................7
3.3. ACR120_Reset ......................................................................................................................8
3.4. ACR120_Status .....................................................................................................................9
3.5. ACR120_ReadRC531Reg...................................................................................................11
3.6. ACR120_WriteRC531Reg ...................................................................................................12
3.7. ACR120_DirectSend ...........................................................................................................13
3.8. ACR120_DirectReceive.......................................................................................................14
3.9. ACR120_RequestDLLVersion .............................................................................................15
3.10. ACR120_ReadEEPROM .....................................................................................................16
3.11. ACR120_WriteEEPROM .....................................................................................................17
3.12. ACR120_ReadUserPort ......................................................................................................18
3.13. ACR120_WriteUserPort.......................................................................................................19
3.14. ACR120_Power ...................................................................................................................20
4.0. General Card Commands......................................................................................21
4.1. ACR120_Select ...................................................................................................................21
4.2. ACR120_ListTags................................................................................................................23
4.3. ACR120_MultiTagSelect .....................................................................................................25
4.4. ACR120_TxDataTelegram ..................................................................................................27
5.0. Card Commands for Mifare® 1K/4K Cards ..........................................................29
5.1. ACR120_Login ....................................................................................................................29
5.2. ACR120_Read.....................................................................................................................32
5.3. ACR120_ReadValue ...........................................................................................................33
5.4. ACR120_Write.....................................................................................................................34
5.5. ACR120_WriteValue............................................................................................................35
5.6. ACR120_WriteMasterKey....................................................................................................36
5.7. ACR120_Inc ........................................................................................................................37
5.8. ACR120_Dec .......................................................................................................................38
5.9. ACR120_Copy.....................................................................................................................39
6.0. Card Commands for ISO14443-4 Interface ..........................................................40
6.1. PICC_Xch_APDU ................................................................................................................40
6.2. Exchange ADPU Command ................................................................................................42
6.3. PICC_RATS.........................................................................................................................43
6.4. Auto-RATS...........................................................................................................................45
6.5. Firmware Upgrade Mode .....................................................................................................46
Appendix A. Error Codes returned by High Level APIs ...............................................47
Appendix B. Possible TAG Types .................................................................................49
Appendix C. USB ID and Drivers for ACR1281U-C8.....................................................50
Appendix D. Standard Program Flow............................................................................51
Appendix E. Physical and Logical Block/Sector Calculation ......................................52

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 3 of 52
List of Tables
Table 1 : USB Interface Wiring ............................................................................................................... 5
Table 2 : ACR120_Open Command Description.................................................................................... 6
Table 3 : ACR120_Close Command Description ................................................................................... 7
Table 4 : ACR120_Reset Command Description ................................................................................... 8
Table 5 : ACR120_Status Command Description .................................................................................. 9
Table 6 : ACR120_ReadRC531Reg Command Description................................................................ 11
Table 7 : ACR120_WriteRC531Reg Command Description ................................................................ 12
Table 8 : ACR120_DirectSend Command Description ........................................................................ 13
Table 9 : ACR120_DirectReceive Command Description.................................................................... 14
Table 10 : ACR120_RequestDLLVersion............................................................................................. 15
Table 11 : ACR120_ReadEEPROM Command Description ................................................................ 16
Table 12 : ACR120_WriteEEPROM Command Description ................................................................ 17
Table 13 : ACR120_ReadUserPort Command Description ................................................................. 18
Table 14 : ACR120_WriteUserPort Command Description.................................................................. 19
Table 15 : ACR120_Power Command Description .............................................................................. 20
Table 16 : ACR120_Select Command Description .............................................................................. 21
Table 17 : ACR120_LIstTags Command Description .......................................................................... 23
Table 18 : ACR120_MultiTagSelect Command Description ................................................................ 25
Table 19 : ACR120_TxDataTelegram Command Description ............................................................. 27
Table 20 : ACR120_Login Command Description................................................................................ 29
Table 21 : ACR120_Read Command Description................................................................................ 32
Table 22 : ACR120_ReadValue Command Description ...................................................................... 33
Table 23 : ACR120_Write Command Description ................................................................................ 34
Table 24 : ACR120_WriteValue Command Description....................................................................... 35
Table 25 : ACR120_WriteMasterKey Command Description............................................................... 36
Table 26 : ACR120_Inc Command Description.................................................................................... 37
Table 27 : ACR120_Dec Command Description .................................................................................. 38
Table 28 : ACR120_Copy Command Description ................................................................................ 39
Table 29 : PICC_Xch_APDU Command Description ........................................................................... 40
Table 30 : PICC_RATS Command Description.................................................................................... 43
Table 31 : FSDI to (Frame Size for Proximity Coupling Device) FSD Conversion............................... 43
Table 32 : Possible TAG Types ............................................................................................................ 49

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 4 of 52
1.0. Introduction
The ACR1281U-C8 is the new version of ACS’s ACR120U Contactless Smart Card Reader. The
ACR1281U-C8 USB Protocol defines the interface between the PC and the reader, as well as the
communication channel between the PC and the supported contactless cards, including Mifare®, ISO
14443 Type A and B compatible cards. By using the High Level APIs, the users can develop
applications that involve the use of contactless cards with minimum effort. For example:
•Access control, Identification: Reading the serial numbers of all cards in the field
•Data Storage: Performing encrypted read and write operations
•Ticketing: Performing read, write, increment and decrement operations in an encrypted
environment
•Multi applications: Performing read, write, increment and decrement operations on various
sectors of the card
1.1. Features
•USB Full Speed (12 Mbps)
•Read and write functionality
•Smart Card Reader:
oBuilt-in antenna for contactless tag access, with card reading distance of up to 50 mm
oSupports for ISO 14443 Type A and B cards, Mifare®
oBuilt-in anti-collision feature (only one tag is accessed at any time)
oSelective card polling capability (especially useful when multiple cards are presented)
•Built-in Peripherals:
oLED
oBuzzer
•Firmware Upgradability
•Compliant with the following standards:
oCE
oFCC
oRoHS

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 5 of 52
2.0. USB Interface
The ACR1281U-C8 is connected to a computer through USB as specified in the USB Specification
2.0. The ACR1281U-C8 is working in full speed mode, i.e.12 Mbps.
The USB interface is used for firmware upgrade purpose.
Pin Signal Function
1 VCC +5V power supply for the reader
2 D- Differential signal transmits data between reader and PC
3 D+ Differential signal transmits data between reader and PC
4 GND Reference voltage level for power supply
Table 1: USB Interface Wiring
Note: In order for the ACR1281U-C8 to function properly through USB interface, ACS proprietary
device drive has to be installed.

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 6 of 52
3.0.Reader Commands
3.1. ACR120_Open
Opens a port (connection) to the reader.
High Level API:
DLLAPI INT16 AC_DECL ACR120_Open(INT16 ReaderPort);
Parameters Description
ReaderPort Port number. Available choices are “ACR120_USB1” to
“ACR120_USB8”.
Return Value INT16 Handle for further operations. Error Code < 0
Table 2: ACR120_Open Command Description
Low Level Frame Structure:
Command: From PC to Reader (5 bytes)
Command Code
(1 byte)
Command Data Length
(1 bytes)
Instruction Code
(1 byte)
Data Length
(1 byte)
E0h 02h 05h 00h
Response: From Reader to PC (5 bytes) << Success or Fail >>
Response Code
(1 byte)
Response Status
(2 bytes)
Response Data Length
(2 bytes)
E1h INT16 0000h

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 7 of 52
3.2. ACR120_Close
Closes the port (connection) to the reader.
High Level API:
DLLAPI INT16 AC_DECL ACR120_Close(UINT16 hReader);
Parameters Description
hReader Handle to the Reader returned by AC_Open()
Return Value INT16 0 = success; Error Code < 0
Table 3: ACR120_Close Command Description
Low Level Frame Structure:
Command: From PC to Reader (0 Bytes) <<No Frame will be sent to Reader>>
Response: From Reader to PC (0 Bytes) <<No Frame will be sent to PC>>

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 8 of 52
3.3. ACR120_Reset
Resets the Mifare Chip of the reader, then restores the factory settings.
High Level API:
DLLAPI INT16 AC_DECL ACR120_Reset(UINT16 hReader);
Parameters Description
hReader Handle to the Reader returned by AC_Open()
Return Value INT16 0 = success; Error Code < 0
Table 4: ACR120_Reset Command Description
Low Level Frame Structure:
Command: From PC to Reader (5 Bytes)
Command Code
(1 byte)
Command Data Length
(1 bytes)
Instruction Code
(1 bytes)
Data Length
(1 byte)
E0h 02h 05h 00h
Response: From Reader to PC (5 Bytes) << Success or Fail >>
Response Code
(1 Byte)
Response Status
(2 bytes)
Response Data Length
(2 bytes)
E1h INT16 0000h

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 9 of 52
3.4. ACR120_Status
Returns the firmware version and the reader status.
High Level API:
DLLAPI INT16 AC_DECL
ACR120_Status(UINT16 hReader,
UINT8 pFirmwareVersion[20],
STRUCT_STATUS pReaderStatus);
Parameters Description
hReader Handle to the Reader returned by AC_Open()
pFirmwareVersion Firmware version will be returned (20 bytes)
pReaderStatus Reader status
Return Value INT16 0 = success; Error Code < 0
Table 5: ACR120_Status Command Description
Low Level Frame Structure:
Command: From PC to Reader (5 Bytes)
Command Code
(1 Byte)
Command Data Length
(1bytes)
Instruction Code
(1 byte)
Data Length
(1 byte)
E0h 02h 18h 00h
Response: From Reader to PC (35 Bytes) << Success or Fail >>
Response
Code
(1 byte)
Response
Status
(2 bytes)
Response Data
Length
(2 bytes)
Response Data
(20 bytes) (10 bytes)
E1h INT16 01Eh pFirmwareVersion pReaderStatus
Struct STRUCT_STATUS
{
// 0x01 = Type A; 0x02 = Type B; 0x03 = Type A + Type B
UINT8 MifareInterfaceType;
// Bit 0 = Mifare Light; Bit 1 = Mifare1K; Bit 2 = Mifare 4K; Bit 3 =
Mifare DESFire
// Bit 4 = Mifare UltraLight; Bit 5 = JCOP30; Bit 6 = Shanghai Transport
// Bit 7 = MPCOS Combi; Bit 8 = ISO type B, Calypso
// Bit 9 – Bit 31 = To be defined
UINT32 CardsSupported;
UINT8 CardOpMode; // 0x00 = Type A; 0x01 = Type B TAG is being processed
// 0xFF = No TAG is being processed.
UINT8 FWI; // the current FWI value (time out value)
UINT8 RFU; // to be defined
UINT16 RFU; // to be defined
} ReaderStatus;

ACR1281U-C8 – Application Programming Interface [e-mail]
Version 1.00 www.acs.com.hk
Page 10 of 52
Remark:
1. For UINT32 CardSupported, the LSB is transmitted first.
e.g. Byte 0(LSB), Byte 1, Byte 2 & Byte 3(MSB)
