ACT ACT1020 - WIRING FOR ENTRYEXIT User manual

Card/Prox Reader
The +5V reader supply on ACT controllers is normally rated
at 100mA. Typically this is sufficient to power 2 ACT readers.
Note however that readers from other manufacturers may need
to be powered separately if their current requirements exceed
this or if they require 12V.
The standard wiring colours for
ACT1020 reader is shown above.
Readers should be a maximum of 30m
from the controller when powered
from +5V and a maximum of 100m
when powered from +12V.
