ActionTec ECB7250A KIT User manual

2.5 GbE / MoCA 2.5 Extender ECB7250A
©2022 Actiontec Electronics, Inc.
Actiontec, Creative Solutions for the Digital Life, and the Actiontec logo are
registered trademarks or trademarks of Actiontec Electronics, Inc., in the U.S. or
other countries. All other names are properties of their respective owners. Product
photo may differ from actual product. However, functionality remains as stated
above. Specifications are subject to change without notice.
This Quick Start Guide will walk you through the
easy steps to connectyour MoCA Extender.
Quick Start Guide
(2)MoCA Extender
(2)Ethernet Cables
(2) Power Adapters (2) Coaxial Cables
(2) Coaxial Splitters
Package Contents:
ECB7250AKIT
Congratulations! You’ve successfully connected
your device to the Internet.
Additional MoCAExtender may bepurchased and
connected toother devices needing anEthernet
connection and that are near a coaxial port.
Tech Support
For registration or access to user manuals, wall-mount
templates, software updates, etc. visit our webpage:
https://support.actiontec.com/ (External, 5V DC, 2A
made by APD,
Model #WB-10E05FU)
PN 0530-0852-000

Step 2 : Connect to your Modem/Router
Step 1: Connect to your Device
Get one MoCA 2.5 Extender.
Locate the device or access point (laptop, etc.) that
needs toconnect tothe Internet. Connect one Ethernet
Cable from the Extender to the Device.
Connect one Splitter to the Coax Cable coming from
the Coax Outlet on the wall.
Connect one Coax Cable from the Splitter to the Coax
In porton the Extender.
Connect one Power Adapter to the Extender and to a
Power Outlet.
Wait until the Power light on the front of the adapter
is GREEN.
IMPORTANT! If the Coax LED on the Extender
is already GREEN, you may have MoCA built in to your
modem/router. Check the device you just connected. If it
is connected to the Internet, you’re done*. If the device
does not connect to the Internet, continue to Step 2.
*You may use the 2nd adapter with another device or access point.
Get one MoCA 2.5 Extender.
Connect one Ethernet Cable from the Extender to the
Modem/Router.
Connect one Splitter to the Coax Cable coming from
the Coax Outlet on the wall.
Connect one Coax Cable from the Splitter to the Coax
In porton the Extender.
Note: If you have a TV or set top box near your modem/router,
connect a coax cable from the splitter to the TV or set top box.
Connect the second Power Adapter to the Extender
and to a Power Outlet.
Wait until the Power light on the front of the adapter
is GREEN.
When the Coax LED is GREEN on both adapters, your
adapters areworking.
a
a
b
b
c
c
d
d
e
e
f
f
g
g
g
Coax
OutletPower
Adapter
Power
Outlet
MoCA Extender
Laptop or other
access point
TV
Splitter
a
d
e
f
c
Ethernet Cable
b
(Coaxial wiring behind the wall)
Coax LEDPower LED
ECB7250
Ethernet
Power
Power
Coax
Coax In
ECB7250
MPS
Ethernet Port of Modem/Router
g
Coax
OutletPower
Adapter
Power
Outlet
MoCA Extender
TV
Splitter
a
d
e
f
c
Ethernet Cable
b
Coax LEDPower LED
ECB7250
Ethernet
Power
Power
Coax
Coax In
ECB7250
MPS
