ActionTec WCB3000N Installation guide

AG tting Start d BInstalling FiOS N twork Ext nd r
Flip this Installation Guide over to continue NEXT
If your coaxial cabl is alr ady conn ct d to a s t top box
you will n d to us th Coaxial Splitt r that is includ d in
your kit box.
V rizon FiOS N twork Ext nd r
uThe Verizon FiOS Network Extender works as a Wireless
Network Adapter to extend your existing Wi-Fi network.
uIt uses the same Wi-Fi network name (SSID) and wireless
credentials as your Verizon FiOS Router.
uYou can surf the Internet wirelessly from different locations
within your home or business without having to change from
one wireless network to another.
Your Verizon FiOS Network Extender Kit Includes –
• One WCB3000N FiOS Network Extender
• One ower Adapter
(External, 5V DC, 2A made by Actiontec, Model #WA-10 05FU)
• One Ethernet Cable
• Two Coaxial Cables
• One Coaxial Splitter
S tting up th FiOS N twork Ext nd r
art No: 0530-0689-002 QS1201/0913
Step1lace the FiOS Network
Extender in a room of your home or
business where the Wi-Fi signal is
weak.
Step2Locate the Coaxial Cabl
connected to the wall outlet in the
room where you want to install the
FiOS Network Extender. Connect the
coaxial cable from the Wall Outl t to
the Coax In Port on the back of the
FiOS Network Extender.
a.Disconnect the Coaxial Cabl
from the wall outlet and connect
it to one of the two OUT Ports on
the Coaxial Splitter.
b.Remove one of the two Coaxial
Cabl s from the box. lug one
end of the Coaxial Cable into the
IN Port on the Splitter and the other
end into the Coaxial Wall Outl t.
c.Remove the 2nd Coaxial Cabl
from the box. lug one end into
the OUT Port on the Splitter and
the other end into the Coax In
Port on the back of the FiOS
Network Extender.
Veriz nWCB3000N_QS12_Veriz n l k WBR QS 10/1/14 2:23 PM Page 1

FiOS
N twork
Ext nd r
Basic Instructions
G tting Start d
Installing FiOS N twork Ext nd r
A
B
WCB3000N
©2014 Verizon. All Rights Reserved
©2014 Actiontec Electronics, Inc, Actiontec, and the Actiontec logo are registered trademarks or
trademarks of Actiontec Electronics, Inc. in the US or other countries. All other names are properties
of their respective owners.
This product has a 1-year Limited Warranty
from the date of purchase. Go to
http://www.actiont c.com/products/warranty.php
for more information.
Step3lug one end of the
ower Adapter into the Pow r
Port on the back of the FiOS
Network Extender. lug the
other end of the ower
Adapter into a nearby
El ctrical Pow r Outl t.
Step4Wait until the Coax
Light on the front of the FiOS
Network Extender is Gr n.
This may take a couple of
minutes.
Step5Connect a Wi-Fi device and surf the Internet wirelessly.
Congratulations!
You have successfully extended your Wi-Fi network.
For additional information go to
www.v rizon.com/quickguid s
