ScreenBeam 1100
Wireless Display Receiver
Quick Start Guide
This Quick Start Guide provides the instructions on how to install the ScreenBeam
1100 receiver, connect client devices, and setup for deployment.
Before Beginning Deployment
Before deploying Actiontec ScreenBeam products, check for the latest firmware,
release documentation and tech tips.
zFor ScreenBeam receiver’s deployment guide, firmware upgrades, and release
notes, go to: https://support.screenbeam.com/1100
zFor Miracast™or native macOS/iOS wireless display connection tutorial, go to:
https://www.screenbeam.com/setup
zFor ScreenBeam Central Management System (CMS) software, go to:
https://support.screenbeam.com/cms
zFor Open Source information, go to: https://opensource.actiontec.com
Package Contents
zScreenBeam 1100 receiver
zPower supply
zHDMI cable
zQuick Start Guide (this document)
zRegulatory documents
Documentation
For FAQs, troubleshooting tips
and support, visit:
https://support.screenbeam.com
Need Help?
To open a ticket for support, visit:
https://support.screenbeam.com/ticket
1 | screenbeam.com
quick start guide

quick start guide
Introduction
The ScreenBeam 1100 allows presenters with Windows 10,
macOS, iOS, or Android device to wirelessly display without
requiring any apps. ScreenBeam 1100 offers a variety of
secured network modes to support connection from the
internal users on different subnets and external guest users.
Overview of Network Modes
ScreenBeam 1100 supports local Wi-Fi, Wi-Fi Miracast, and
wireless display over existing infrastructure network. Two or more
modes can operate concurrently to support various scenarios
where both internal and guest users could simply connect and
project.
2 | screenbeam.com
Local Wi-Fi
The ScreenBeam Wi-Fi mode provides the simplest form
of network for client devices to connect and project. In this
mode, user needs to connect the client device Wi-Fi to the
ScreenBeam Wi-Fi and then select the receiver to mirror. This
mode is ideal for guest client devices that needs wireless
display and or Internet access. Internet is available if the
ScreenBeam receiver is connected to the existing network,
wired or wireless if bridge mode is enabled. Mobile device with
cellular service can access the Internet and wireless display if
bridge mode is disabled.
Windows 10, iOS, macOS
SSID/Receiver Name:
ScreenBeam XYZ0
Optional
Bridge
Wireless
Wired
A
P
In-Room Display
Windows 10, iOS, macOS ScreenBeam 1100
Wi-Fi
In-Room Display
Figure 1 Client device wireless display by connecting to
ScreenBeam’s local Wi-Fi
Note: ScreenBeam Wi-Fi is fully secured and manageable
via ScreenBeam CMS with options to tune the wireless
power transmission, channel and encryption type.

ScreenBeam
™
|
1100
screenbeam.com | 3
Wi-Fi Miracast
The Wi-Fi Miracast mode allows compatible Wi-Fi Miracast
devices to connect directly to ScreenBeam, even when
connected to an infrastructure wireless network. Miracast is
commonly available on Windows 10/8.1 and Android 4.4 (and
later) devices since 2015. Users can enjoy wireless display and
Internet access if the client device is already connected to Wi-Fi.
Windows 10/8.1 or Android
SSID/Receiver Name:
ScreenBeam XYZ0
Optional
Bridge
Miracast
WFD
WAP X
In-Room Display
Windows 10/8.1 or Android ScreenBeam 1100
Miracast
WFD
In-Room Display
Figure 2 Miracast client device wireless display by
connecting to ScreenBeam’s Wi-Fi Miracast network
Wireless Display over existing LAN
ScreenBeam 1100 can be connected to the existing wireless or
wired network and supports wireless display for client devices
on either network. This is a common setup to support client
devices that needs access to network resources. Additional
port and network configurations may be required for this mode
to work seamlessly.
Windows 10, iOS, macOS
Organization Network
Optional
Bridge
Receiver Name:
ScreenBeam XYZ0
SSID-Staff
VLAN1 / subnet 10.1.1.x
10.1.1.x
www
WAP X
In-Room Display
Organization Network www
Wi-Fi
AP
Over
Existing
LAN Wired/
Wireless
Windows 10, iOS, macOS ScreenBeam 1100
In-Room Display
Figure 3 Client device wireless display over existing
infrastructure network
ScreenBeam 1100 can be connected to two different networks
concurrently. This dual-network feature allows the flexibility of
supporting wireless display for either staff (on internal network)
or visitors (on guest network). Refer to the deployment guide
for more details.

quick start guide
Minimum Requirements
System Requirements
Client device from 2015 or newer with one of the following
operating systems:
zWindows 10 build 1709 (and later)
zmacOS X 10.10 (and later)
ziOS 11 (and later)
zAndroid 4.4 (and later) with Miracast
Network Requirements
For wireless display over the existing wireless network or LAN:
zEthernet: 100BASE-T 10/100 connection
(1 Gbps is recommended)
zWireless: 802.11ac (5GHz is strongly recommended)
zMulticast DNS (mDNS) support is required for iOS
and macOS native screen mirroring to auto-discover
ScreenBeam
zRequired ports
z5353 (UDP) for Multicast DNS (mDNS) discovery
z7100 (TCP and UDP) for macOS, iOS and
Windows 10 mirroring
z7250 (TCP) for Miracast over LAN data stream
z18000-18009 (TCP) for macOS and iOS AV data
Note: Additional network configuration is not required for
Wi-Fi Miracast enabled device to connect. Verify Group
Policy and firewall settings to allow Wi-Fi Direct groups or
hosted networks.
Setup Requirements
zScreenBeam 1100 receiver
zDisplay with an available HDMI input
z(Optional) Touchscreen with USB touch cable
zAn ethernet network connection with DHCP IP or a
Wi-Fi router
Note: This is used for wireless display over LAN and
management.
zScreenBeam wireless display app
Note: Not required for Windows 10/8.1, macOS, and iOS
with native screen mirroring support.
4 | screenbeam.com

ScreenBeam
™
|
1100
A. Setting up
ScreenBeam 1100 Receiver
Power
HDMI
Display
Optional USB
Figure 4 ScreenBeam 1100 setup
1. Place the receiver next to the display.
2. Connect one end of the provided HDMI cable to the
receiver’s HDMI port and the other end to an available HDMI
port on the display.
Note: For VGA connection details, refer to the
ScreenBeam 1100 User Guide.
3. Optional: If the display has USB HID touch capability, insert
the HID USB connector into a USB port of the ScreenBeam
receiver. (USB cable is not included)
4. Connect the receiver’s power supply to the receiver’s power
port, then to an electrical outlet.
5. Optional: Connect one end of the Ethernet cable to the
receiver’s Ethernet port and connect the other end to the
network switch with DHCP IP. (Ethernet cable is not included).
Note: Refer to section B for more information on setting
up a network connection.
6. Turn on the display and switch to the corresponding input
connected to the receiver.
7. Wait for the Ready to Connect screen to appear on the
display.
B. Set Up Network Connection
ScreenBeam requires network connection for various
purposes, such as wireless display over LAN support and
management of the receiver. ScreenBeam can be connected to
the network via wired or Wi-Fi connection.
Wired Connection
If ScreenBeam is connected to a DHCP-enabled network, the
Ready to Connect screen will show the IP address assigned
to the ScreenBeam.
Wireless Connection or Static IP Address
This requires additional steps to configure the receiver with the
proper network credentials. Refer to Section D for instructions
on how to setup the ScreenBeam receiver.
Using a wired connection with DHCP IP is recommended for
initial testing.
screenbeam.com | 5

quick start guide
C. Connect Client Device
This section provides the instructions on how to connect to
ScreenBeam using the native screen mirroring from the most
common operating systems.
Refer to www.screenbeam.com/setup for details and
instructions for all other operating systems.
Note: The web page will display the instructions based
on the client-device OS. Use the links at the bottom of the
web page to select OS-specific instructions.
Connect Using Local Wi-Fi
1. Connect the client device’s Wi-Fi to the wireless network
(AP SSID) as shown on the TV display. Windows 10/8.1
or Android with Miracast can skip to Connect Using Wi-Fi
Miracast section.
2. Enter the password for the wireless network.
screenbeam is the default password.
3. Select the ScreenBeam receiver name as shown on the
TV display.
zFor Windows 10
Select Connect from the Action Center by swiping from
right or simultaneously pressing the Windows key and K.
zFor iOS or macOS
Connect with from the menu bar or control center.
4. Enter in the PIN if required. If the PIN code is not displayed,
try the hidden PIN 1234.
5. Select duplicate or extended screen mode if prompted.
6 | screenbeam.com
6. If the display has touch functionality, Windows 10 devices
can take advantage of the touch and inking feature by
selecting Allow touch…. (Refer to section F for more
details.)
Note: To disconnect, return to the screen mirroring
menu and select mirroring off.
Connect Using Wi-Fi Miracast
1. Select the ScreenBeam receiver name as shown on the
TV display.
zFor Windows 10
Select Connect from the Action Center by swiping from
right or simultaneously pressing the Windows key and K.
zFor Android
Select the Screen Mirroring option from the quick
access menu and follow the connection instructions.
2. Enter in the PIN if required. If the PIN code is not displayed,
try the hidden PIN 1234.
3. Select duplicate or extended screen mode if prompted.
4. If the display has touch functionality, Windows 10 devices
can take advantage of the touch and inking feature by
selecting Allow touch…. (Refer to section F for more
details.)
Note: Some Android devices do not support PIN and will
fail to connect. Refer to section D below for instructions
on how to configure ScreenBeam and disable PIN
enforcement.

ScreenBeam
™
|
1100
Connect Using the
Existing Wireless Network or LAN
1. Connect the ScreenBeam receiver to a known network
where your client device can communicate over Wi-Fi.
2. Verify the receiver obtained an IP address (shown on the
Ready to Connect screen).
3. Connect the client device to the same network as
ScreenBeam receiver
4. Select the ScreenBeam receiver name as shown on the
TV display.
zFor Windows 10
Select Connect from the Action Center by swiping from
right or simultaneously pressing the Windows key and K.
zFor iOS or macOS
Connect with from the menu bar or control center.
5. Enter in the PIN if required. If the PIN code is not displayed,
try the hidden PIN 1234.
6. Select duplicate or extended screen mode if prompted.
7. If the display has touch functionality, Windows 10 devices
can take advantage of the touch and inking feature by
selecting Allow touch…. (Refer to section F for more
details.)
Congratulations!
The display is now enabled for wireless screen mirroring.
D. Configure ScreenBeam Receiver
ScreenBeam 1100 can be configured by using the
ScreenBeam CMS software or accessing the ScreenBeam’s
local management interface (LMI).
Using ScreenBeam CMS Software
ScreenBeam Central Management System (CMS) is a highly
recommended complimentary tool for multi-unit deployment,
configuration and administration.
1. To obtain CMS software and the CMS User Guide, go to:
https://support.screenbeam.com/cms.
2. Refer to the CMS User Guide for setup instructions.
Note: Access to the LMI is prohibited by default if
ScreenBeam 1100 is connected to ScreenBeam CMS
for management. This option can be changed in the
receiver’s settings.
ScreenBeam™CMS Wired / Wireless
Infrastructure Network
Figure 5 Receivers managed by ScreenBeam CMS
screenbeam.com | 7

quick start guide ScreenBeam
™
|
1100
Using Local Management on ScreenBeam
The Local Management Interface can configure and update a
single ScreenBeam. There are three methods to access the LMI:
Method 1: ScreenBeam Local Wi-Fi Network
1. Connect the client device’s Wi-Fi to the wireless network
(AP SSID) as shown on the TV display.
2. Enter the password for the wireless network.
screenbeam is the default password.
3. The Ready to Connect screen on the display will show the
assigned IP address of the ScreenBeam.
4. Enter the assigned IP address into the web browser of a PC
or Apple device.
zIf the receiver is not connected to an existing wireless
network or LAN, its IP address is 192.168.26.1.
zIf the receiver is connected a network, the IP address can
be identified on the Ready to Connect screen.
5. The browser may give an error stating “The connection
or site is not secure or private.” Manually accept the
connection as follows:
Chrome browser: click Advanced, then click Proceed.
Edge/IE browser: click Details, then Go on to the
webpage (not recommended).
Firefox browser: click Advanced, then click Add
Exception, then click Confirm Security Exception.
6. When the ScreenBeam management page appears, enter
the Username Administrator and Password Actiontec (both
case-sensitive).
Method 2: Network Connection via DHCP
1. Using a shielded RJ-45-terminated Cat5e or better Ethernet
cable, connect the ScreenBeam Ethernet port to a DHCP-
enabled network.
2. The Ready to Connect screen on the display will show the
assigned IP address of the ScreenBeam. Enter this address
into the web browser of a PC or Apple device on the same
network as the ScreenBeam.
3. Follow the directions from Method 1 from Step 5 on.
Method 3: Wireless P2P Direct Connection
1. Using a Windows 10/8.1 device, connect the device to the
ScreenBeam per section B above.
2. Once connected, use a web browser and enter
https://192.168.16.1 to access the LMI.
3. Follow the directions from Method 1 from Step 5 on.
8 | screenbeam.com

ScreenBeam
™
|
1100
E. Customize ScreenBeam Settings
Under the Device Configuration Page
Assign new Device Name
1. From the Device Name Access option, select Enable.
2. Select the Device Name text box, then enter a new name
(example: Conference TV).
Note: Each receiver should have a unique name; this
makes it easier for users to identify and connect to the
correct display. Supported naming characters are
A-Z, a-z, 0-9, -, _.
Change the Administrator’s Password
1. Select the Administrator Password text box and enter
the new password.
2. Select Apply/Save button to save any changes.
Under the Features Page
Configure Force PIN Pairing Option
By default, the Force PIN Pairing option is Enabled and the PIN
code is generated randomly. A unique PIN is will be generated
each time a new user/device attempts to connect. To change
the PIN pairing type or PIN code:
1. Select either ON to force PIN or OFF to not force PIN upon
connection.
2. If Force PIN Pairing is ON, select either Each connection
or First connection only.
3. Select Random or Static for PIN code generation.
4. If Static, then enter PIN of choice. Keep note of the new
PIN for user distribution.
Note: For eight-digit PIN option, only the first seven digits
of the PIN can be set in configuration; the eighth digit
will be automatically chosen by the ScreenBeam and
appended to the first seven.
5. Select Apply/Save button to save any changes.
Configure HDMI/VGA Port
Power Management
By default, ScreenBeam is designed to display the Ready to
Connect screen continuously. To extend display life and/or
reduce power consumption:
1. Select either Screen Saver or Display Off.
2. Enter a desired time for setting to take effect.
3. Optional: Select a Wake up mode.
4. Select Apply/Save button to save any changes.
screenbeam.com | 9

quick start guide ScreenBeam
™
|
1100
F. Using Interactive Touch Display
ScreenBeam 1100 supports wireless inking and touch with
Windows 10 Miracast for collaboration using a touchscreen
display. Users can project their preferred Windows 10 application
and take notes on the touchscreen; the notes appear directly on
the client device.
System Requirements
OS: Windows 10 build version 1709 (or later)
CPU: 5th Gen Intel Core i-Series 5xxx or AMD equivalent
(or better)
RAM: 4 GB or more
Setup Requirements
zInteractive touch display or projector
zUSB Type-A to Type-B/A cable
(depending on the touchscreen type)
Supported Features
zSupport USB HID display, projector, or whiteboard
zUp to 20-point touch
zUp to four simultaneous passive pens
zUp to two simultaneous active pens
Supported features may require compatible touchscreen and
or application. Works best with InGlass™Technology enabled
display. Refer to the online compatibility list at:
https://support.screenbeam.com/touch/compatibility
Setup and Instructions
1. Connect the USB Type-A end to the ScreenBeam 1100
receiver’s USB port.
2. Connect the USB Type-B/A end to the USB Touch input on
the display or projector.
Note: If the display provides more than one touch output,
make sure the USB Type-B/A end is connected to the
same touch output as the HDMI input.
3. Connect Windows 10 device to ScreenBeam 1100 (see
instructions in section C).
4. Start using the display by touching the screen. Launch an
app and draw using finger or pen.
10 | screenbeam.com

ScreenBeam
™
|
1100
G. Deploying ScreenBeam Receiver
Please read the deployment guide for best practices and tips
before placing the ScreenBeam 1100 to the site for users.
1. Unplug the power supply and HDMI cable from
ScreenBeam 1100 receiver.
2. Move the receiver to its permanent location.
Note: Access to a wired or wireless LAN connection is
required.
3. Plug the HDMI cable to the receiver and the display.
4. Plug in the receiver’s power supply.
5. Switch the display to the correct input and verify the Ready
to Connect screen appears.
6. Verify the ScreenBeam 1100 obtains a valid IP address.
Note: By default, ScreenBeam shows all of the receiver’s
information on screen for ease of troubleshooting. The
information can be configured to be hidden from the
management interface or via CMS.
H. Expectations and Known Issues
zWi-Fi Internet is limited when connecting to ScreenBeam
local Wi-Fi unless ScreenBeam is connected to the network
and bridge mode is enabled.
zIf ScreenBeam is connected to the existing network, some
existing access points and or controllers (i.e. Meraki or
Cisco) may flag it as a rogue AP and restrict the client from
connecting. Consult with the network administrator to flag
ScreenBeam as a friendly access point.
zWindows 10 build 1803 (and earlier) do not support wireless
display PIN on Miracast over LAN. The connection will fall
back to establishing the Miracast over Wi-Fi Direct path.
Support Information
For FAQs, troubleshooting tips and support, visit:
https://support.screenbeam.com
To open a ticket for support, visit:
https://support.screenbeam.com/ticket
Website: www.screenbeam.com
This product is intended to be supplied by a Listed Direct
Plug-In Power Unit marked “Class 2”, Listed Power Adapter
or DC power source marked “L.P.S.” (or “Limited Power
Source”) and rated 12Vdc, 3A minimum.
US SKU: Model # CDS036-W120U.
International SKU: Model # ATS036T-W120V.
Made by Actiontec.
screenbeam.com | 11

quick start guide ScreenBeam
™
|
1100
PN: 0530-0838-000
© 2019 All rights reserved. Actiontec and the Actiontec logo are registered trademarks, and
ScreenBeam is a trademark of Actiontec Electronics, Inc. All other names are properties of
their respective owners. Specifications subject to change without notice. 031119
