Deployment Guide
Wireless Display
over LAN
Version 1.0

This document is copyright © 2018 Actiontec Electronics, Inc.. All rights reserved. Use of this document
is governed by the terms and conditions available at http://www.actiontec.com/terms-of-use/.
Actiontec products and associated software may contain and/or use open source software. Please see
http://opensource.actiontec.com/ for pertinent open source information.
Actiontec product warranty information may be found on the corresponding product webpages available at
http://www.actiontec.com.
Actiontec, ScreenBeam, ScreenBeam 960, the Actiontec logo and the ScreenBeam logo are either
trademarks or registered trademarks of Actiontec Electronics Inc. in the United States of America and/or
other countries. Miracast and Wi-Fi are either trademarks or registered trademarks of the Wi-Fi Alliance in
the United States of America and/or other countries. IEEE is either a trademark or registered trademark of
the Institute for Electrical and Electronics Engineers, Inc. in the United States of America and/or other
countries. Ethernet is either a trademark or registered trademark of Xerox Corp. in the United States of
America and/or other countries. Microsoft and Windows are either trademarks or registered trademarks of
Microsoft Corporation in the United States of America and/or other countries. macOS, iOS, Mac and OSX
are either trademarks or registered trademarks of Apple Inc. in the United States of America and/or other
countries. Android, Google and YouTube are either trademarks or registered trademarks of Alphabet, Inc.
and/or its subsidiaries in the United States of America and/or other countries. HDMI and the HDMI logo
are either trademarks or registered trademarks of HDMI Licensing, LLC in the United States of America
and/or other countries. Intel, Core, Core i3 and Core i5 are either trademarks or registered trademarks of
Intel Corp. in the United States of America and/or other countries. AMD is either a trademark or registered
trademark of Advanced Micro Devices, Inc. in the United States of America and/or other countries. All other
trade names, trademarks or registered trademarks in this document are used with reference to the entities
claiming those marks and/or the names of their products in the United States of America and/or other
countries, and Actiontec Electronics Inc. does not claim any proprietary interest in the rights or marks of
others.
Actiontec Electronics, Inc. is not responsible for nor makes any express or implied guarantee regarding the
accuracy of the contents of this document, nor any third-party products or standards referred to in this
document.

Table of Contents
Part I Introduction .............................................................................................................. 4
1.1 Key Features ....................................................................................................... 4
1.2 System Requirements for Display Devices......................................................... 5
1.3 ScreenBeam Network Requirements.................................................................. 5
1.4 ScreenBeam Display Requirements ................................................................... 6
1.5 Related Documents............................................................................................. 6
Part II Setting up ScreenBeam ........................................................................................... 7
Part III Configuring the Infrastructure Network.................................................................... 9
3.1 Wired Network ..................................................................................................... 9
3.2 Wireless Network............................................................................................... 10
3.3 Connecting Receiver to Infrastructure Network .................................................11
3.4 Connecting Client Device to Infrastructure Network ..........................................11
Part IV Setup Topology...................................................................................................... 12
4.1 Introduction........................................................................................................ 12
4.2 Meeting Room ................................................................................................... 12
4.3 Classroom ......................................................................................................... 13
Part V iOS/macOS Native Screen Mirroring..................................................................... 14
5.1 Introduction........................................................................................................ 14
5.2 macOS Native Screen Mirroring ....................................................................... 14
5.3 iOS Native Screen Mirroring.............................................................................. 16
Part VI Miracast Over Infrastructure ................................................................................. 19
6.1 Introduction........................................................................................................ 19
6.2 Windows 10 Miracast Over Infrastructure......................................................... 19
Part VII Installing Wireless Display over LAN Software ................................................. 22
7.1 Introduction........................................................................................................ 22
7.2 macOS Installation ............................................................................................ 22
7.2.1 Configure macOS for ScreenBeam application..................................... 22
7.2.2 Install macOS application ...................................................................... 23
7.3 Windows 7 Installation....................................................................................... 24
Part VIII Setting up Firewall............................................................................................. 25
8.1 macOS............................................................................................................... 25
8.2 Windows 7 ......................................................................................................... 26
Part IX Connecting to Receiver......................................................................................... 28
9.1 macOS............................................................................................................... 28
9.2 Windows 7 ......................................................................................................... 31

4
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
Part I Introduction
Actiontec’s ScreenBeam 960 receiver brings wireless display capability to a variety of
devices and operating systems, both with native screen mirroring capability and those that
do not. ScreenBeam 960 allows for an optimal experience in installation, deployment,
management and end-user satisfaction. Native P2P screen mirroring with direct connection
via Miracast is built into ScreenBeam 960 for Windows 10/8.1 and Android 4.2 and later
Miracast devices. The information contained in this document outlines the general features,
requirements and recommendations for all other presentation scenarios for ScreenBeam 960,
including streaming over LAN using apps and native macOS/iOS screen mirroring. For
instructions on connection via native mirroring for Windows 10/8.1 and Android, please visit
https://www.screenbeam.com/setup.
1.1 Key Features
Key features of ScreenBeam 960 include:
•Native wireless display support without apps for modern operating systems
•Wireless display on legacy devices and operating systems over LAN
•Fast, responsive and stable wireless display connection
•Secured user connection with PIN to limit access to authorized display sources
•Video and audio streaming support for responsive screen mirroring
•USB HID support for front-of-room touch screen collaboration
•Analog line audio out for external audio amplification or capture
•VGA pass-through input for wired connection to sources for display
•VGA video out for projectors and legacy display devices
•HDMI video out with HDCP for modern display devices

5
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
1.2 System Requirements for Display Devices
The minimum system requirements of devices used to connect to ScreenBeam 960 with
firmware 9.15.39.0 (or later) are:
•OS: MS Windows 7 with SP2 or later, macOS 10.10 or later, and Android 4.2 or later
with Miracast
•CPU: 4th Gen Intel Core i3 or AMD equivalent
•Wi-Fi: 802.11n or 802.11ac Dual-Band 2x2
•RAM: 4GB
•HDD free space: 50GB
The recommended system requirements of devices used to connect to ScreenBeam 960
with firmware 9.15.39.0 (or later) are:
•OS: MS Windows 8.1 or later, or 2012 and later Macs running macOS 10.10 or later
•CPU: 5th Gen Intel Core i5 or AMD equivalent, or later
•Wi-Fi: Intel Dual-Band Wireless AC 726x (or later)
•RAM: 8GB
•HDD free space: 50GB (or more)
1.3 ScreenBeam Network Requirements
The minimum network requirements for ScreenBeam 960 Ethernet connection for Wireless
Display over LAN are:
•IEEE 802.3u / 100BASE-TX compliant 100Mbps Ethernet connection for ScreenBeam
receiver connection
Note: IEEE 802.3ab / 1000BASE-T 1Gbps Ethernet connection is recommended
•RJ-45-terminated shielded Cat 5e or better Ethernet cable from switch to ScreenBeam
receiver
•802.11n/ac Wi-Fi connectivity for client devices (5GHz strongly recommended)
•Network ports:
omacOS: 8554 (TCP), 24030 (UDP), 35507 (TCP)
omacOS native mirroring: 5353 (UDP), 7000 (UDP), 7100 (TCP), 47000 (TCP),
32768 to 60000 (UDP)
oWin 7: 7236 (TCP), 24030 (UDP), 35507 (TCP)
Note: VLAN routing may be required if ScreenBeam and Client devices are connected to
different VLAN networks.

6
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
1.4 ScreenBeam Display Requirements
ScreenBeam 960 requires a display with available HDMI or VGA port supporting 720p/WXGA
resolution or higher. 1080p or higher is recommended.
1.5 Related Documents
To better understand the deployment of ScreenBeam Wireless Display, and its display
capabilities over LAN, the following documents are recommended for review prior to
ScreenBeam deployment:
•ScreenBeam Receiver (ScreenBeam 960) user guide
•ScreenBeam Central Management System user guide
Note: ScreenBeam Central Management System (CMS) is not required for ScreenBeam
Wireless Display over LAN, but it is highly recommended for managing ScreenBeam
receivers. See https://www.screenbeam.com/products/screenbeam-cms/ for details.

7
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment G ide
Part II Setting up ScreenBeam
Ens re the ScreenBeam 960 receiver is pdated to the latest firmware version. The firmware
version is indicated on the Ready to Connect screen at the bottom left corner. In the
example below, the receiver has o tdated firmware that will need to be pdated to the latest
firmware prior to proceeding.
The latest firmware and pdate instr ctions may be obtained from the ScreenBeam s pport
webpage in the ScreenBeam 960 section.
Confirm that the s pport for Wireless display over LAN is enabled on yo r receiver. Follow
the proced res below to enable the s pport for Wireless display over LAN:
1. Go to the ScreenBeam s pport webpage and click on the ScreenBeam 960, scroll
down to the Freq ently asked q estions category, and click on the link for ‘How Do I
Log In To The Local Management Web GUI (No SSID)’
2. Follow the steps to connect to the local management page for the ScreenBeam 960.
3. In the Feat res Tab, check that ‘Wireless display over LAN’ is enabled for the desired
scenarios. To save any changes scroll to the bottom of the page and press ‘Apply’
then press ‘Ok’ in the pop- p message.

8
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
Note: The “Wireless display over LAN” feature is required to support Windows 7 and pre-
2012 macOS 10.10 and later devices, as well as iOS 11 and later devices with the optional
ScreenBeam app. This does not affect iOS 9 and later or macOS 10.10 and later native
screen mirroring devices. Refer to the receiver’s user manual or Quick Start Guide for details
on how to access the receiver’s Local Management Interface.
Note: Actiontec recommends reboot of the receiver after settings changes whenever
possible.

9
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
Part III Configuring the
Infrastructure Network
Wireless display over LAN can allow ScreenBeam to stream video over both wireless and
Ethernet networks. While all devices are normally connected wirelessly, those connecting
over LAN rather than P2P directly to the ScreenBeam receiver rely upon properly-configured
wireless access points and a wired Ethernet connection for enhanced stability and throughput.
Since the stream quality and user experience heavily relies on the network’s performance,
consider adjusting your network and Wireless APs for optimal performance as recommended
below.
3.1 Wired Network
A ScreenBeam connection to a wired 1Gbps Ethernet complying with IEEE 802.3ab /
1000BASE-T using shielded Cat5e or better cable is strongly preferred. A 100Mbps IEEE
802.3u / 100BASE-TX compliant connection is the minimum requirement.
Whenever possible, use the following guidelines to assist in successful ScreenBeam receiver
deployment:
•Use non-blocking switches/routers to avoid intermittent connection issues over
infrastructure.
•Use Quality-of-Service features on switches and routers to prioritize ScreenBeam port
traffic.
•Employ policies for managed devices to prevent CPU-intensive or high-bandwidth tasks
such as online backups during times when wireless presentations may occur.
•Use virtual LANs (VLANs) with routing to sequester traffic on subnets wherever
possible.
For iOS/macOS native screen mirroring and wireless mirroring over LAN, the multicast
DNS (mDNS) protocol is required on port 5353 UDP. Since this protocol broadcasts the
ScreenBeam receiver’s presence to all IP addresses on a subnet, some network switches
may be configured to block traffic on this port to prevent excessive use of network
bandwidth by such traffic. It is important to configure switches to pass mDNS traffic to all
stations on a network so they become visible to user devices. If this cannot be done,
solutions exist that can cache mDNS broadcast requests and send them out of band to all
WAPs in a network without the corresponding bandwidth burden. Consult the
documentation from the WAP manufacturer or network vendor on how to deploy such
solutions.

10
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
3.2 Wireless Network
802.11ac wireless access points (WAPs) networking is strongly recommended. 802.11n
WAPs are the minimum required for ScreenBeam to work correctly. Dual-band
2.4GHz/5GHz support for WAPs is strongly recommended.
ScreenBeam 960 does not support Dynamic Frequency Selection (DFS) channel for wireless
connectivity. Dynamic Frequency Selection is required in the 5GHz band so that wireless
connection on DFS channels automatically switches when in use by other applications such
as radar. Ensure wireless APs are configured to support non-DFS 5GHz (recommended)
and/or 2.4GHz band as follows:
•2.4GHz – Channels 1, 6, 11 only
•5GHz (non-DFS, 20MHz wide channels) – Channels 36, 40, 44, 48, 149, 153, 157,
161 only
•5GHz (non-DFS, 40MHz wide channels) – Channels 36, 44, 149, 157 only
To avoid connectivity issues, the following practices are strongly recommended:
•Do not use overlapping channels for WAPs in adjacent rooms, including between
floors. Alternating channels used helps ensure reliable connectivity.
•Use 5GHz whenever possible versus 2.4GHz, as 5GHz signals cannot penetrate
through walls to adjacent rooms as well as 2.4GHz signals can, 5GHz channels
have better separation, and 2.4GHz is used by more devices.
•Minimize use of unauthorized or unmanaged wireless devices by policy (e.g.
Bluetooth, wireless game controllers, wireless video cameras), especially those
using the 2.4GHz band.
•Avoid use of 802.11n for clients and WAPs whenever possible, as 802.11ac is more
spectrum efficient than 802.11n and will give a better presentation experience.
If connectivity issues persist, contact a qualified IT professional to conduct a wireless
survey for recommendations on improving Wi-Fi connectivity.
As discussed above, network switches may not pass mDNS traffic across the network and
block that traffic at switches and routers. If unblocking the port is infeasible, solutions exist
that can cache mDNS broadcast requests and send them out of band to all WAPs in a
network without the corresponding bandwidth burden. Consult the documentation from
the WAP manufacturer or network vendor on how to deploy such solutions.

11
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
3.3 Connecting Receiver to Infrastructure Network
ScreenBeam receivers can be connected to the network over wireless or Ethernet. Ethernet
is strongly recommended for stability and optimal experience. ScreenBeam receivers can
also be deployed on separate VLANs from clients provided the 2 VLANs are configured for
the client device to communicate with the receiver.
Note: Receivers behind a Network Address Translated (NATed) router will not work. Traffic
must be explicitly routed between networks.
If total isolation from a wired network is required, such as a guest network / room in a
business, ScreenBeam with Miracast is the ideal solution for most modern Windows and
Android devices and requires no Ethernet or WAP connection. If iOS/macOS native
screen mirroring or legacy device support (e.g. Windows 7) is required with isolation, a
sequestered WAP and router will be required on the Ethernet connection, and those users
will need to connect to the WAP prior to presenting to the ScreenBeam.
3.4 Connecting Client Device to Infrastructure Network
Connect the client device to the same network where the receiver is connected. This means
the WAP, LAN/VLAN and ScreenBeam must be able to see each other. Ensure the source
device gets a good connection to the AP. The recommended connection signal strength
should be good to excellent, i.e. beyond -50dBm (RSSI level).
Ensure the client device and receiver have a low latency by pinging the ScreenBeam from a
device in the desired connection scenario. A network ping response time under 20ms is
desirable to ensure excellent end-user wireless presentation experiences.
The IP address of ScreenBeam 960 receiver is displayed by default on the Ready to Connect
screen on the attached display. For older firmware revisions, or when this has been
switched off previously in the management console or through CMS, the IP address can be
displayed by going to the receiver’s management console and setting the “Show network
information on the TV screen” option to “Firmware and Network Info” or “All Info”.

12
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
Part IV Setup Topology
4.1 Introduction
ScreenBeam 960 can be set up in different room types. This section outlines the most
common setup topologies for ScreenBeam deployments.
4.2 Meeting Room
The recommended setup for an office/meeting room is placing ScreenBeam 960 receiver on
the guest network/VLAN. This solution allows both the employee and guest to present.
Additional considerations include the following:
•If the client system is connected to the Guest’s Wi-Fi, the assumption is both are on the
same VLAN and no additional configuration required.
•If the client system is connected to the Employee/Internal Wi-Fi, then it’s likely both
devices are on different VLANs. The network may need to be configured to allow traffic
on the required ports for the Employee client system to communicate and stream to
ScreenBeam receiver.
•If sequestration of guest access to the network in the room is required, and Windows
10/8.1 or Android Miracast for guest presentation is desired, ScreenBeam connections
via P2P Miracast are ideal. For guest presentation by Windows 7, macOS or iOS
devices, the ScreenBeam and its network will need to be run with Ethernet connected to
its own router/switch and WAP.

13
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
4.3 Classroom
The recommended setup for a classroom environment is to place the ScreenBeam 960
receiver on a LAN/VLAN dedicated to the ScreenBeam. This will allow the teacher/staff
member to present directly.
In this scenario, the network administrator must configure the required ports for the staff client
system to communicate and stream to ScreenBeam receiver.

14
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment G ide
Part V iOS macOS Native Screen
Mirroring
5.1 Introduction
ScreenBeam 960 now offers iOS/macOS native screen mirroring. This feat re allows iOS
9 and later devices, and macOS 10.10 and later devices prod ced from 2012 onward, to
have wireless screen display. Unlike Windows 10/8.1 native screen mirroring sing
Miracast P2P mode direct connections, iOS/macOS native screen mirroring req ires the se
of existing WAPs and other network infrastr ct re to mirror the ser device on the
front-of-room display.
Please note the req irements for mDNS broadcast as o tlined in section on Infrastr ct re
Network Config ration above, as well as the need for the iOS or macOS device to be on the
same network as the ScreenBeam device. If mDNS broadcast traffic is blocked on a
network, or if the ScreenBeam device is inaccessible from the network that the iOS or macOS
device is on, iOS/macOS native screen mirroring will not work.
5.2 macOS Native Screen Mirroring
To initiate macOS native screen mirroring:
1. On the Men bar, click on the screen mirroring icon, which is a small sq are with a
triangle at the bottom. A men will pop p with a list of available receivers.
2. Click on the name of the ScreenBeam receiver at the front of the room from the list
of receivers to connect to the receiver.
3. If the PIN option is enabled on the ScreenBeam, another dialog box will appear
asking for the PIN as follows:

15
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment G ide
Enter the corresponding PIN and click Ok.
4. The macOS device sho ld now be mirroring to the front-of-room display.
5. The defa lt option is to mirror the screen directly, b t extended desktop can be
chosen by clicking the “Use as Separate Display” option:
6. To disconnect from the ScreenBeam, click on the screen mirroring icon again and
click on Off to t rn native screen mirroring off. The macOS device will stop mirroring
to the front-of-room display.
Note: DRM-protected content from apps or browsers cannot be displayed from a macOS
device to the ScreenBeam front-of-room display.

16
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
5.3 iOS Native Screen Mirroring
To initiate iOS native screen mirroring:
1. Swipe upward from the bottom of the iOS device screen to bring up the Control
Center, or inward from the top-right corner on newer versions of iOS, then tap on the
Screen Mirroring button:
2. A list of receivers will pop up on the screen. Select the ScreenBeam receiver to
present to by tapping on the receiver name:

17
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
3. If the PIN option is enabled on the ScreenBeam, another dialog box will appear
asking for the PIN as follows:
Enter the corresponding PIN and tap Ok.
4. The iOS device should now be mirroring to the front-of-room display.
5. To disconnect the iOS device from the front-of-room display, swipe upward from the
bottom of the iOS device screen, or inward from the top-right corner on newer
versions of iOS, to bring up the Control Center. Tap on Screen Mirroring, then tap
on Stop Mirroring.

18
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
The iOS device will stop mirroring to the front-of-room display.
Note: When playing videos from YouTube or similar apps, the receiver may enter a mode
that plays the video directly on the receiver rather than mirror the screen. In such cases,
only the video controls may be present on the screen.
Note: Occasionally, during updates of video streaming apps, this mode may work erratically.
In such cases, the app itself will need to be updated.
Note: DRM-protected content from apps or browsers cannot be displayed from an iOS
device to the ScreenBeam front-of-room display.

19
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
Part VI Miracast Over Infrastructure
6.1 Introduction
The ScreenBeam 960 supports native Miracast using peer-to-peer (P2P) connection. In
some circumstances, it may be desirable to carry Miracast traffic over the existing network
infrastructure into the ScreenBeam’s Ethernet port. Cases requiring this type of connection
include having limited available wireless spectrum due to the number of devices on the same
wireless band, and policies requiring exclusive use of managed WAPs for wireless network
traffic. This section describes the requirements for Miracast over Infrastructure. The
connection procedure is identical to the procedure for P2P connection.
Miracast over infrastructure must be enabled in the Wireless Display over LAN section of the
device configuration or CMS, and both the ScreenBeam and the Windows device must be
on the same network. Only Windows 10 devices with build 1703 or later can display to a
ScreenBeam via Miracast over infrastructure. Although the display connection uses
network infrastructure to transmit to the display, the Windows 10 device must have Wi-Fi
enabled to detect the presence of the receiver.
6.2 Windows 10 Miracast Over Infrastructure
To initiate Windows 10 Miracast over infrastructure screen mirroring:
1. Click on the Action Center icon in the notification area of the taskbar.
2. Click on the Connect button:

20
© 2018 Actiontec Electronics Inc. All rights reserved. ScreenBeam Deployment Guide
3. Find the name of the ScreenBeam receiver on the “Ready to Connect” screen on the
front-of-room display, and click to connect:
4. If a PIN is requested, enter the number displayed on the front-of-room display:
Note: If no PIN number is displayed on the front-of-room screen, use the PIN
provided by the device administrator or, if none, use 12345670.
