ACU-RITE 00384 User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets: Sensor..... 2
Features & Benets: Display.... 3
Setup .................................... 4
Sensor Setup ......................... 4
Display Setup ........................ 5
Intelli-Time® Clock................... 6
Set the Time, Date & Units ...... 6
Backlight Settings................... 6
Placement Guidelines ............. 7
Using the Thermometer........... 8
Troubleshooting ..................... 9
Care & Maintenance.............10
Replace Intelli-Time
®
Battery ..10
Specications........................10
FCC Information ...................10
Customer Support .................11
Warranty..............................11
Thermometer
model 00384
Questions? Contact Customer Support at
www.AcuRite.com/support or email [e-mail]

2 3
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. Outdoor Sensor
3. Power Adapter
4. Instruction Manual
Features & Benets
4
3
2
1
5
OUTDOOR SENSOR
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being sent to the
display.
3. Battery Compartment
4. A-B-C Switch
ID code that must match display’s A-B-C
switch to ensure units synchronize.
5. Battery Compartment Cover
DISPLAY FRONT
1. Backlight Button
For momentary backlight and dimmer settings.
2. Current Outdoor Temperature
Arrow icon indicates direction temperature
is trending.
3. Sensor Signal Strength
4. HIGH Indicator
Indicates today’s HIGH records are being viewed.
5. LOW Indicator
Indicates today’s LOW records are being viewed.
6. AUTO DIM Icon
Indicates display is in auto-dimming brightness
mode. (see page 6)
7. Day of the Week
8. Date
9. Moon Phase
10. Current Indoor Temperature
Arrow icon indicates direction temperature
is trending.
11. Current Indoor Humidity
Arrow icon indicates direction humidity is trending.
12. Display Low Battery Indicator
13. Intelli-Time® Clock
Automatically updates itself for Daylight
Saving Time.
14. Current Outdoor Humidity
Arrow icon indicates direction humidity is trending.
15. Sensor Low Battery Indicator
DISPLAY BACK
1 6. In tegrated Hang Hole
For easy wall mounting.
17. A-B-C Switch
ID code that must match sensor’s A-B-C switch to
ensure units synchronize.
18. Battery Compartment
19. Intelli-Time Battery Compartment Cover
20. Plug-in for Power Adapter
21. Button
For setup preferences and viewing HIGH records.
22. SET Button
For setup preferences.
23. Button
For setup preferences and viewing LOW records.
24. Battery Compartment Cover
(not shown)
Features & Benets
16
18
17
19
23
21
20
22
5
6
7
8
9
10
511 4
12
13
15
14
4
3
2
1
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

4 5
SETUP
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
Sensor Setup
Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However,
you must select the same letter
choices for both the sensor and
the display in order for the units
to synchronize.
Install or Replace Batteries
AcuRite recommends high quality
alkaline or lithium batteries in
the outdoor sensor for the best
product performance. Heavy
duty or rechargeable batteries
are not recommended.
The sensor requires lithium
batteries in low temperature
conditions. Cold temperatures
can cause alkaline batteries
to function improperly. Use
lithium batteries in the sensor for
temperatures below -4ºF / -20ºC.
1. Slide off the battery
compartment cover. Take
note of the A-B-C switch
setting inside the battery
compartment for display
setup.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
2
1
1A-B-C Switch
set to match
display
Display Setup
Set the A-B-C Switch
Locate the A-B-C switch inside
the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display and
the sensor in order for the units
to synchronize.
Install or Replace Backup
Batteries
1. Remove the battery
compartment cover.
2. Insert 3 x AAA alkaline
batteries into the battery
compartment, as shown.
Follow the polarity (+/–)
diagram in the battery
compartment.
3. Replace the battery cover.
Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
1
2
2Install Batteries
2 AA batteries
A B C
IMPORTANT: Batteries are
a backup power source to
preserve records in the event of
a power outage. Power adapter
is recommended as the primary
power source to enjoy the full
functionality of this product.
2Install Batteries
3 AAA batteries
1A-B-C Switch
Set to match
sensor.
A B C
3
Plug in
Power Adapter
3

6 7
Intelli-Time®Clock
Intelli-Time products are pre-programmed with the correct time and date.
Intelli-Time technology instructs the time and date to set themselves. All you
need to do is select your Time Zone and Daylight Saving Time preferences. The
clock will then automatically set itself and change for Daylight Saving Time.
Set the Time, Date & Units
Press and release the “SET” button, located on the back of the display, to enter
SET MODE. Once in SET MODE, the preference you are currently setting will
blink on the display.
To adjust the currently selected (ashing) item, press and release the “ “ or
“ “ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “SET” button again to adjust
the next preference. The preference set order is as follows:
DST (Daylight Saving Time ON or OFF)*
TIME ZONE (CST MST PST AKT HAT NST AST EST)
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
*If you live in an area that observes DST, DST should be set to ON, even if it is
not currently Daylight Saving Time.
You will automatically exit SET MODE if no buttons are pressed for 8 seconds.
Enter SET MODE at any time by pressing the “SET” button.
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and outdoor sensor are critical to the accuracy
and performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. Display stands
upright for tabletop use or is wall-mountable
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions. Sensor
is water resistant and is designed for general outdoor use, however,
to extend its life place the sensor in an area protected from direct
weather elements.
Hang the sensor using the integrated hang hole or hanger, or by
using string (not included) to hang it from a suitable location, like a
well covered tree branch. The best location is 4 to 8 feet above the
ground with permanent shade and plenty of fresh air to circulate
around the sensor.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct
sunlight and away from any heat sources or vents.
• Display and outdoor sensor must be within 330 ft (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place both units at least 3 ft (.9 m) away
from electronic devices (TV, computer, microwave, radio, etc.).
(100 meters)
(330 feet maximum)
Setup is Complete
The sensor will now synchronize with the display. It may take a few minutes for
synchronization to complete. Please refer to the troubleshooting section of this
manual if anything appears to be functioning improperly.
Display Backlight Settings
This weather station’s color display features three different lighting settings:
High (100%) brightness, Medium (60%) brightness and Low (30%) brightness.
Using battery power alone, the backlight is available momentarily for 10
seconds by pressing the “BACKLIGHT” button.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press “BACKLIGHT” button once to dim to 60% brightness;
press again to dim to 30%, press a 3rd time to enter “AUTO DIM” mode.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day & year.
MARCH 11- NOVEMBER 4 6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 30% brightness
NOVEMBER 5 - MARCH 10 7:30 a.m. - 7:00 p.m.= 100% brightness
7:01 p.m. - 7:29 a.m. = 30% brightness

8 9
Using the Thermometer
High & Low Records
Today’s high and low records are displayed for indoor and outdoor
temperature and humidity. Today’s records automatically clear at 12:00am
midnight every day. View today’s high or low records by pressing the “ “ or
“ “ buttons. Press and release again to view current readings.
To manually clear all of today’s LOW recorded values, press and release the
“ “ button to view low records, then press and HOLD the “ “ button for
2 seconds. Dashes will display to conrm you have cleared the LOW records.
To manually clear all of today’s HIGH recorded values, press and release the
“ “ button to view high records, then press and HOLD the “ “ button for
2 seconds. Dashes will display to conrm you have cleared the HIGH records.
Moon Phase
Track the phases of the moon, conveyed through simple lunar phase icons:
OPERATION
Troubleshooting
No outdoor sensor
reception
no bars
If the wireless signal indicator shows no bars:
• Relocate the display and/or the outdoor sensor. The
units must be within 330 ft (100 m) of each other.
• Make sure both units are placed at least 3 feet
(.9 m) away from electronics that may interfere with
the wireless communication (such as TVs, microwaves,
computers, etc).
• Use standard alkaline batteries (or lithium batteries in
sensor when temperature is below -4ºF/-20ºC). Do not
use heavy duty or rechargeable batteries. NOTE: It
may take up to a few minutes for display and sensor
to synchronize after batteries are replaced.
Display screen
not working
• Check that the batteries are installed correctly.
Batteries may need to be replaced.
Outdoor
temperature
is ashing or
showing dashes
Flashing of the outdoor temperature is generally an
indication of wireless interference.
1. Bring both the sensor and display indoors and
remove at least one battery from each.
2. Make sure the A-B-C switch on both units match.
3. Reinstall the batteries in the outdoor sensor.
4. Reinstall the batteries in the display.
5. Let the units sit within a couple feet of each other
for a few minutes to gain a strong connection.
Inaccurate
temperature
or humidity
• Make sure both the display and sensor are placed out
of direct sunlight and away from any heat sources or
vents (see page 7).
• Make sure both units are positioned away from
moisture sources (see page 7).
If your AcuRite product does not operate properly after trying
the troubleshooting steps, visit www.AcuRite.com or email
[e-mail] for assistance.

10 11
CR2032
3V
Care & Maintenance
Display Care
Outdoor Sensor Care
Replace Intelli-Time Battery
remove the compartment cover.
FCC Information
-
TEMPERATURE RANGE ºF to 158º ºC to 70ºC
ºF to 122º ºC to 50ºC
HUMIDITY RANGE
WIRELESS RANGE
POWER
DATA REPORTING
Customer Support
AcuRite customer support is committed to providing you with best-in-
class service. For assistance, please have the model number of this
product available and contact us in any of the following ways:
[e-mail]
Visit us at www.AcuRite.com
►Installation Videos ►Register your Product
►Instruction Manuals ►Support User Forum
►Replacement Parts ►Submit Feedback & Ideas
Limited 1-Year Warranty
AcuRite is a wholly owned subsidiary of Chaney
Instrument Company. For purchases of AcuRite
products, AcuRite provides the benefits and services set
forth herein. For purchases of Chaney products, Chaney
provides the benefits and services set forth herein.
Remedy for breach of this warranty is limited to repair or
replacement of the defective item(s). If we determine that repair
or replacement is not feasible, we may, at our option, refund
the amount of the original purchase price.
We expressly disclaim all liability for special, consequential,
or incidental damages, whether arising in tort or by contract
from any breach of this warranty. Some states do not allow the
exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you.
We further disclaim liability from personal injury relating to
our products to the extent permitted by law. By acceptance of
any of our products, the purchaser assumes all liability for the
consequences arising from their use or misuse. No person, firm
or corporation is authorized to bind us to any other obligation
or liability in connection with the sale of our products.
Furthermore, no person, firm or corporation is authorized
to modify or waive the terms of this warranty unless done in
writing and signed by a duly authorized agent of ours.
In no case shall our liability for any claim relating to our
products, your purchase or your use thereof, exceed the
original purchase price paid for the product.
Applicability of Policy
This Return, Refund, and Warranty Policy applies only to
purchases made in the United States and Canada. For
purchases made in a country other than the United States or
Canada, please consult the policies applicable to the country in
which you made your purchase.
Additionally, this Policy applies only to the original purchaser
of our products. We cannot and do not offer any return,
refund, or warranty services if you buy products used or from
resale sites such as eBay or Craigslist.
Governing Law
This Return, Refund, and Warranty Policy is governed by the
laws of the United States and the State of Wisconsin. Any
dispute relating to this Policy shall be brought exclusively in the
federal or State courts having jurisdiction in Walworth County,
Wisconsin; and purchaser consents to jurisdiction within the
State of Wisconsin.
THE ABOVE-DESCRIBED WARRANTY IS THE SOLE WARRANTY
FOR THE PRODUCTS AND IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ALL OTHER WARRANTIES
OTHER THAN THE EXPRESS WARRANTY SET FORTH HEREIN
ARE HEREBY EXPRESSLY DISCLAIMED, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTY OF MERCHANTABILITY
AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR
PURPOSE.
We warrant that all products we manufacture under this
warranty are of good material and workmanship and, when
properly installed and operated, will be free of defects for a
period of one year from the date of purchase.
Any product which, under normal use and service, is proven
to breach the warranty contained herein within ONE YEAR
from date of sale will, upon examination by us, and at our sole
option, be repaired or replaced by us. Transportation costs and
charges for returned goods shall be paid for by the purchaser.
We hereby disclaim all responsibility for such transportation
costs and charges. This warranty will not be breached, and we
will give no credit for products which have received normal
wear and tear not affecting the functionality of the product,
been damaged (including by acts of nature), tampered,
abused, improperly installed, or repaired or altered by others
than our authorized representatives.
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the
Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copyrights
are the property of their respective owners. AcuRite uses patented technology.
Visit www.AcuRite.com/patents for details.
Printed in China
00384 INST 092319
Weather
Stations Temperature & Humidity
Weather
Alert Radio
Kitchen
Thermometers
& Timers
Clocks
It’s more than accurate, it’s
AcuRite offers an extensive assortment of precision instruments,
designed to provide you with information you can depend on to
Plan your day with confidence™.
www.AcuRite.com
