Adam Equipment 700660189 User manual

© Adam Equipment Company 2013
Adam Equipment
IHS/IHSa SERIES (EN)
SERIES IHS (FR)
IHS SERIE (DE)
SERIE IHS/IHSa (ES)
Serie IHS (IT)
(P.N. 700660189, Revision D1, Jul 2013)
Software version 1.0/A1.0

© Adam Equipment Company 2013
ENGLISH: P 1 - 13
FRANÇAIS: P 14 - 27
DEUTSCH: P 28 - 41
ESPAÑOL: P 42 - 56
ITALIANO: P 57 - 70
EU DECLARATION: P 71

EN
© Adam Equipment Company 2013
1700660189RevD1-Jul13
Easy Reference:
Model name of the scale:
Serial number of the unit:
Software revision number
(Displa ed when power is first turned on):
Date of Purchase:
Name of the supplier and place:

EN
© Adam Equipment Company 2013
1700660189RevD1-Jul13
1.0 CONTENTS
1.0 CONTENTS .............................................................................................. 1
2.0 INTRODUCTION ...................................................................................... 2
2.1 INTRODUCTION ................................................................................................ 2
2.2 TECHNICAL SPECIFICATIONS .......................................................................... 3
2.3 SAFETY NOTICE ................................................................................................ 4
2.4 KEY DESCRIPTION .............................................................................................. 5
2.5 DISPLAY ............................................................................................................ 5
3.0 OPERATION .............................................................................................. 7
3.1 SAFETY INSTRUCTIONS .................................................................................... 7
3.2 BATTERY OPERATION ...................................................................................... 8
3.3 CHARGING BATTERY ........................................................................................ 9
3.4 BASIC OPERATIONS ......................................................................................... 9
4.0 CALIBRATION ........................................................................................... 11
5.0 PARAMETER ............................................................................................. 12

EN
© Adam Equipment Company 2013
2700660189RevD1-Jul13
2.0 INTRODUCTION
2.1 INTRODUCTION
The IHS/IHSa Series is a range of heav -dut crane scales used to weigh
ver large masses.
The main features include:
•Eas Operation & Rugged construction
•30mm super big & bright red LED displa with view angle.
•360 degree rotar safet hook design, eas to use
•Hold feature
•Overload safet up to 200%
•One charge can last 150 hours
•Auto power off after 30 minutes of non use
•7.2Vdc 2 amp batter charger
•Aluminum die-casting housing
•Large remote control handset

EN
© Adam Equipment Company 2013
3700660189RevD1-Jul13
2.2 TECHNICAL SPECIFICATIONS
M
del N
Capacity
Divisi n
M
del N .
Capacity
Divisi n
IHS 1 1000kg 0.2kg/0.5kg IHS 2a 2000lb/1000kg 0.5lb/0.2kg
IHS 3 3000kg 0.5kg/1kg IHS 6a 6000lb/3000kg 1lb/0.5kg
IHS 5 5000kg 1kg/2kg IHS 10a 10000lb/5000kg 2lb/1kg
IHS 10 10000kg 2kg/5kg IHS 20a 20000lb/10000kg
5lb/2kg
M del A B C D E F G Weight
IHS
1/2a
260 203 47 30 628 76 214 12kg
IHS
3/6a
260 203 47 30 628 76 214 14kg
IHS
5/10a
260 203 60 40 723 80 214 19kg
IHS
10/20a
260 203 70 50 837 90 214 31kg

EN
© Adam Equipment Company 2013
4700660189RevD1-Jul13
2.3 SAFETY NOTICE
The limit stated below is the Ultimate Overload Limits of the scales.
Adam Equipment Co. Ltd. Its directors, owners and affiliated companies and
organisations cannot be held liable for an resulting damage or injur sustained as a
result of the machines being used in excess of their stated capacities or ultimate
overload limits.
M del NO. IHS 1/IHS 2a IHS 3/IHS 6a IHS 5/IHS 10a IHS 10/IHS 20a
Max
capacity
1000kg/2000lb 3000kg/6000lb 5000kg/10000lb 10000kg/20000lb
Overl ad
capacity
1500kg/3000lb 4500kg/9000lb 7500kg/15000lb 15000kg/30000lb
NOTICE:
Do not use the scales if an parts are bent or loose or show signs of damage or wear.
Refer to the user manual.

EN
© Adam Equipment Company 2013
5700660189RevD1-Jul13
2.4 KEY DESCRIPTION IHS VERSION
[On/Off] Power switch- use this ke to turn on and turn off the scale.
[Change] Division change ke - use this ke to change division. When in
setting mode, use this ke to change parameter.
[H ld] Hold function; use this ke to lock the displa . There is a LED
indication light on the bottom of the displa . Press the [H ld] ke
again, to cancel HOLD function.
[Zer ] Re-zero ke - use this ke to return to zero reading.
2.5 DISPLAY
P wer Power on mode
Charge Charging mode
Low batter
H ld Hold mode
Zer Zero indicator

EN
© Adam Equipment Company 2013
6700660189RevD1-Jul13
2.4 KEY DESCRIPTION IHSA VERSION
[On/Off] Power switch- use this ke to turn on and turn off the scale.
[lb/kg] Unit change ke -use this ke to select the weighing unit of lb or
kg. When in setting mode, use this ke to change parameter.
[H ld] Hold function, use this ke to lock the displa . There is a LED
indication light on the bottom of the displa . Press the [H ld] ke
again, to cancel HOLD function.
[Zer ] Re-zero ke - use this ke to return to zero reading.
2.5 DISPLAY
Zer Zero indicator
Charge Charging mode
Low batter
H ld Hold mode
lb LB weighing mode

EN
© Adam Equipment Company 2013
7700660189RevD1-Jul13
kg KG weighing mode
3.0 OPERATION
3.1 SAFETY INSTRUCTIONS
Read this manual carefull before ou operate the IHS Crane Scale.
•Unpack the Crane Scale carefull from the packing.
•Attach it to our hoist or equivalent existing equipment securel at the
ground level, in the upright position. Make sure that the equipment to
which the scale is attached is in proper condition. The operator should
be trained for its safe operation.
• Carr out regular visual inspection for an damage or wear and teat on
parts. Particularl the split pins at the hook and e ebolts and the inner
wall of the hook and all joints should be checked regularl . If an
damage or wear has taken place, replace the parts.
•Do all inspection and maintenance work when the scale is not in use.
•Do not expose the scale to extreme temperatures. The operating
temperature range is 0° C to 40° C.
•Secure the sample to be weighed in the hook of the scale. Ensure that
the sprung Safet Lever returns to its resting position which prevents
the sample from slipping out of the hook.
•Do not exceed the maximum capacit of the Scale .
•Clean and protect our scale after use.

EN
© Adam Equipment Company 2013
8700660189RevD1-Jul13
3.2 BATTERY OPERATION
•The batter will operate continuousl for 150 hours before requiring
recharging. The scale will alert ou when the batter is within 10 hours
of requiring recharging b the indicator lamp above the low batter
s mbol to indicate that the batter is low voltage.
•When the batter requires charging, the scale will turn off to prevent
batter damage. If the button is depressed at this point, the indicator
lamp will reappear and then the scale will again deactivate
automaticall .
•Charging time for a completel discharged batter is approximatel 16
hours. A full batter pack is recommended to keep the scale
continuousl operational.
•The scale will automaticall power down after 30 minutes of non use to
further protect the batter .
N te: More frequent charging of the batter prolongs its life.

EN
© Adam Equipment Company 2013
9700660189RevD1-Jul13
3.3 CHARGING BATTERY
•Plug the power suppl into the mains power, then into the back of the
IHS scale.
•The red indicator lamp will illuminate to indicate that the batter
charger is functioning properl .
•The green indicator lamp will illuminate to indicate that the batter
full charged.
3.4 BASIC OPERATIONS
Power on and off- Press [On/Off] ke to turn on the scale . Then the displa on
the scale will show [88888]. Press again to turn off the scale.
Zero the scale-Depress the [Zer ] to re-zero the reading.
Change division- ou can use the [Change/lb/kg] ke to change division.
Lb/kg- ou use this to select either lb or kg weighing units
Hold -when required, such as when the reading is not stable or ou cannot pause
to record a reading, ou can use the [H ld] ke to lock the reading, so that ou
can read it easil later, after ou finish reading, press [H ld] again to return to
normal weighing mode.
N te: The [H ld] ke has no affect if the Hold parameter has been disabled. See
section 5.1

EN
© Adam Equipment Company 2013 10700660189RevD1-Jul13
Overload Warning-: please do not add an item that exceeds the maximum
capacit of the scale. When the buzzer is sounded and the displa shows”-----”,
remove the item to avoid damage to the load cell and scale.
3.5 REMOTE CONTROLLER
A: Determine increments in which the weight displa
B: Hold the settled values
C: Zero the scale
D: Backlight (onl used on scales with LCD displa )

EN
© Adam Equipment Company 2013 11700660189RevD1-Jul13
4.0 CALIBRATION
•Hold [Zer ] when the scale is powered on.
• The displa on the scale will show “SPAN”. Make sure the hook is
empt or has the slings or chains to be used in place. See Below.
•Depress the [Zer ] button, the displa on the scale will show “Set” then
“0” and then “0000.0” after few seconds. Zero calibration is now
complete.
•Enter the weight to calibrate with b using [H ld] ke to increment a
digit then the [Change/lb/kg] ke to move it across the screen left.
•For example, the displa on the IHS will displa “3000.0” for a 3 ton
calibration mass.
•Add the calibrated mass on the hook, it the best that the mass is close
to the capacit where possible.
•When the scale is stable, press the [Zer ]. The displa shows ‘HOLd’.
•After a few seconds, the calibration is complete.
** To calibrate in pounds (lb) make sure that the scale is lb mode before
commencing, to calibrate in kilograms (kg) make sure the scale is in kg mode before
commencing.
When using slings, chains or other material to support the calibration mass, these
items should be hung from the scale before setting the zero point so that when the
calibration mass is added, onl the weight of the calibration mass is measured b
the scale.
If an error is detected when calibrating an error message will be shown.
Err 3 is when wrong data is entered for the mass, i.e. too small or wrong division.
Err-5 means the calibration has failed.

EN
© Adam Equipment Company 2013 12700660189RevD1-Jul13
5.0 PARAMETER
5.1 ENTER SETTING MODE
Turn off the power of the scale and then turn the power on again.
Press the [Change/lb/kg] ke during self-checking, displa shows “Bee0“, indicating
the scale has entered the setting mode, press the [H ld] or [Change/lb/kg] ke to
shift the parameter items. Use [Zer ] ke confirm and escape from setting the
current item.
5.2 PARAMETER SETTING TABLE
FUNCTION DESCRIPTION DEFAULT
bEE Sets buzzer
0: Disable
1: Enable
0
H d Sets hold function
0: Disable
1: Enable
0
Stb Sets zero function
STb0: zeroing allowed when unstable
STb1: zeroing not allowed when unstable
0
Aut
Sets auto backlight: (Onl applies when the scale has
an LCD displa )
AUT0: manual
AUT1：auto
0
CHt Sets units
0: lb
1: kg
1
YES Sets save:
0: not saved
1: save
0

EN
© Adam Equipment Company 2013 13700660189RevD1-Jul13
WARRANTY STATEMENT
Adam Equipment offers Limited Warranty (Parts and Labour) for any components that fail due to defects in
materials or workmanship. Warranty starts from the date of delivery.
During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam
Equipment Company. The company or its authorised Technician reserves the right to repair or replace the
components at any of its workshops at no additional cost, depending on the severity of the problems. However,
any freight involved in sending the faulty units or parts to the Service Centre should be borne by the purchaser.
The warranty will cease to operate if the equipment is not returned in the original packaging and with correct
documentation for a claim to be processed. All claims are at the sole discretion ofAdam Equipment.
This warranty does not cover equipment where defects or poor performance is due to misuse, accidental damage,
exposure to radioactive or corrosive materials, negligence, faulty installation, unauthorised modifications or
attempted repair, or failure to observe the requirements and recommendations as given in this User Manual.
This product may include a rechargeable battery that is designed to be removed and replaced by the user. Adam
Equipment warrants that it will provide a replacement battery if the battery manifests a defect in materials or
workmanship during the initial period of use of the product in which the battery is installed.
As with all batteries, the maximum capacity of any battery included in the product will decrease with time or use,
and battery cycle life will vary depending on product model, configuration, features, use, and power management
settings. A decrease in maximum battery capacity or battery cycle life is not a defect in materials or workmanship,
and is not covered by this Limited Warranty.
Repairs carried out under the warranty do not extend the warranty period. Components removed during warranty
repairs become company property.
The statutory rights of the purchaser are not affected by this warranty. The terms of this warranty is governed by
the UK law. For complete details on Warranty Information, see the terms and conditions of sale available on our
web-site.

FR
© Adam Equipment Company 2013 14700660189RevD1-Jul13
Adam Equipment
SERIES IHS
(P.N. 9520, Révision B3, Jul 2010)

FR
© Adam Equipment Company 2013 15700660189RevD1-Jul13
Référence simple:
Nom du modèle de la balance:
Numéro de série:
Numéro de révision du logiciel
(Affiché lors de la première mise en
marche):
Date d’achat:
Nom et adresse du fournisseur:

FR
© Adam Equipment Company 2013 16700660189RevD1-Jul13
1.0 SOMMAIRE
1.0SOMMAIRE..........................................................................................16
2.0 INTRODUCTION..................................................................................17
2.1 INTRODUCTION..................................................................................17
2.2 CARACTERISTIQUES TECHNIQUES................................................18
2.3 NOTICE DE SECURITE......................................................................19
2.4 DESCRIPTION DES TOUCHES...........................................................20
2.5 ECRAN................................................................................................20
3.0 FONCTIONNEMENT.............................................................................21
3.1 INSTRUCTIONS DE SECURITE...........................................................21
3.3 CHARGEMENT DE LA BATTERIE ...................................................23
3.4 FONCTIONNEMENT DE BASE..........................................................23
4.0 CALIBRAGE.........................................................................................25
5.0 PARAMETRES........................................................................................25

FR
© Adam Equipment Company 2013 17700660189RevD1-Jul13
2.0 INTRODUCTION
2.1 INTRODUCTION
La série IHS offre des crochets résistants utilisés pour peser des masses
importantes.
Les caractéristiques principales incluent:
•Utilisation facile & construction robuste
•Affichage lumineux LED (22mm)
•Conception sécurisée du crochet lui assurant une rotation de 360
degrés
•Marge sécuritaire de surcharge supérieure à 200%
•Une charge peut durer 150 heures
•Carter en métal moulé sous pression
•Télécommande de contrôle à distance.
