2.0 INTRODU TION
2.1 INTRODUCTION
The IHS/IHSa Series is a range of heav -dut crane scales used to weigh ver large
masses.
The main features include:
•Eas Operation & Rugged construction
•30mm super big & bright red LED displa with view angle.
•360 degree rotar safet hook design, eas to use
•Hold feature
•Overload safet up to 125%
•One charge can last 150 hours
•Auto power off after 30 minutes of non use
•7.2Vdc 2 amp batter charger
•Aluminum die-casting housing
•Large remote control handset

© Adam Equipment 2017 5
2.2 TECHNICAL SPECIFICATIONS
Model No apacity Division Model No. apacity Division
IHS
1
1000kg
0.2kg/0.5kg
IHS
2a
2000lb/
1000kg
0.5lb/
0.2kg
IHS
3
3000kg
0.5kg/1kg
IHS 6a
6000l
b/
3000kg
1lb/
0.5kg
IHS 5
5000kg
1kg/2kg
IHS 10a
10000lb/
5000kg
2lb/
1kg
IHS
10
10000kg
2kg/5kg
IHS 20a
20000lb/
10000kg
5lb/
2kg
Model
A
B
D
E
F
G
Weight
IHS 1/2a 260 203 47 30 628 76 214 12kg
IHS 3/6a 260 203 47 30 628 76 214 14kg
IHS 5/10a 260 203 60 40 723 80 214 19kg
HIS 10/20a 260 203 70 50 837 90 214 31kg

© Adam Equipment 2017 6
2.3 SAFETY NOTICE
The limit stated below is the Ultimate Overload Limits of the scales.
Adam Equipment Co. Ltd. Its directors, owners and affiliated companies and organisations cannot
be held liable for an resulting damage or injur sustained as a result of the machines being used
in excess of their stated capacities or ultimate overload limits.
Model
NO.
IHS 1
/IHS 2a
IHS 3
/IHS 6a
IHS 5
/IHS 10a
IHS 10
/IHS 20a
Max
capacity
1000kg/2000lb 3000kg/6000lb 5000kg/10000lb 10000kg/20000lb
Overload capacity 1250kg/2500lb 3750kg/7500lb 6250kg/1250lb 12500kg/25000lb
NOTI E:
Do not use the scales if an parts are bent or loose or show signs of damage or wear. Refer to the
user manual.
2.4 KEY DESCRIPTION IHS VERSION

© Adam Equipment 2017 7
[On/Off]
Power switch
-
use this ke to turn on and turn off the scale.
[
hange
]
Division change ke
-
use this ke to change division.
When in setting
mode, use this ke to change parameter.
[Hold]
Hold
function;
use this ke to lock the displa .
There is a LED indication
light on the bottom of the displa . Press the [Hold] ke again, to cancel
HOLD function.
[Zero]
Re
-
zero ke
-
use this ke to return
to
zero reading.
2.5 DISPLAY
P
ower
Power on mode
harge
C
har
ging mode
L
ow batter
H
old
H
old mode
Z
ero
Zero indicator
2.4 KEY DESCRIPTION IHSA VERSION

© Adam Equipment 2017 8
[On/Off]
Power switch
-
use this ke to turn on and turn off the scale.
[lb/kg]
Unit
change ke
-
use this ke to
select the weighing unit of lb or kg
.
When in setting mode, use this ke to change parameter.
[Hold]
Hold function, use this ke to lock the displa .
There is a LED indication
light on the bottom of the displa . Press the [Hold] ke again, to cancel
HOLD function.
[Zero]
Re
-
zero ke
-
use this
ke to return to zero reading.
2.5 DISPLAY
Z
ero
Zero indicator
harge
C
harging mode
Low batter
H
old
H
old mode
lb
LB weighing mode
kg
KG weighing mode
3.0 OPERATION
3.1 SAFETY INSTRUCTIONS
Read this manual carefull before ou operate the IHS Crane Scale.
•Unpack the Crane Scale carefull from the packing.
•Attach it to our hoist or equivalent existing equipment securel at the ground
level, in the upright position. Make sure that the equipment to which the scale is
attached is in proper condition. The operator should be trained for its safe
operation.
• Carr out regular visual inspection for an damage or wear and teat on parts.
Particularl the split pins at the hook and e ebolts and the inner wall of the hook
and all joints should be checked regularl . If an damage or wear has taken place,
replace the parts.

© Adam Equipment 2017 9
•Do all inspection and maintenance work when the scale is not in use.
•Do not expose the scale to extreme temperatures. The operating temperature
range is 0° C to 40° C.
•Secure the sample to be weighed in the hook of the scale. Ensure that the sprung
Safet Lever returns to its resting position which prevents the sample from slipping
out of the hook.
•Do not exceed the maximum capacit of the Scale.
•Clean and protect our scale after use.
3.2 BATTERY OPERATION
•The batter will operate continuousl for 150 hours before requiring recharging.
The scale will alert ou when the batter is within 10 hours of requiring recharging
b the indicator lamp above the low batter s mbol to indicate that the batter is
low voltage.
•When the batter requires charging, the scale will turn off to prevent batter
damage. If the button is depressed at this point, the indicator lamp will reappear
and then the scale will again deactivate automaticall .
•Charging time for a completel discharged batter is approximatel 16 hours. A full
batter pack is recommended to keep the scale continuousl operational.
•The scale will automaticall power down after 30 minutes of non use to further
protect the batter .
Note: More frequent charging of the batter prolongs its life.
3.3 CHARGING BATTERY
•Plug the power suppl into the mains power, then into the back of the IHS scale.
•The red indicator lamp will illuminate to indicate that the batter charger is
functioning properl .
•The green indicator lamp will illuminate to indicate that the batter full charged.

© Adam Equipment 2017 10
3.4 BASIC OPERATIONS
Power on and off- Press [On/Off] ke to turn on the scale. Then the displa on the scale will
show [88888]. Press again to turn off the scale.
Zero the scale-Depress the [Zero] to re-zero the reading.
Change division- ou can use the [ hange/lb/kg] ke to change division.
Lb/kg- ou use this to select either lb or kg weighing units
Hold -when required, such as when the reading is not stable or ou cannot pause to record a
reading, ou can use the [Hold] ke to lock the reading, so that ou can read it easil later,
after ou finish reading, press [Hold] again to return to normal weighing mode.
Note: The [Hold] ke has no affect if the Hold parameter has been disabled. See section 5.1
Overload Warning-: please do not add an item that exceeds the maximum capacit of the scale.
When the buzzer is sounded and the displa shows”-----”, remove the item to avoid damage to the
load cell and scale.
3.5 REMOTE CONTROLLER
A: Determine increments in which the weight displa
B: Hold the settled values
C: Zero the scale
D: Backlight (onl used on scales with LCD displa )

© Adam Equipment 2017 11
4.0 ALIBRATION
•Hold [Zero] when the scale is powered on.
• The displa on the scale will show “SPAN”. Make sure the hook is empt or has the
slings or chains to be used in place. See Below.
•Depress the [Zero] button, the displa on the scale will show “Set” then “0” and
then“0000.0” after few seconds. Zero calibration is now complete.
•Enter the weight to calibrate with b using [Hold] ke to increment a digit then the
[ hange/lb/kg] ke to move it across the screen left.
•For example, the displa on the IHS will displa “3000.0” for a 3 ton calibration
mass.
•Add the calibrated mass on the hook, it the best that the mass is close to the
capacit where possible.
•When the scale is stable, press the [Zero]. The displa shows ‘HOLd’.
•After a few seconds, the calibration is complete.
** To calibrate in pounds (lb) make sure that the scale is lb mode before commencing, to calibrate
in kilograms (kg) make sure the scale is in kg mode before commencing.
When using slings, chains or other material to support the calibration mass, these items should be
hung from the scale before setting the zero point so that when the calibration mass is added, onl
the weight of the calibration mass is measured b the scale.
If an error is detected when calibrating an error message will be shown.
Err 3 is when wrong data is entered for the mass, i.e. too small or wrong division.
Err-5 means the calibration has failed.
5.0 PARAMETER
5.1 ENTER SETTING MODE
Turn off the power of the scale and then turn the power on again.
Press the [ hange/lb/kg] ke during self-checking, displa shows “Bee0“, indicating the scale has
entered the setting mode, press the [Hold] or [ hange/lb/kg] ke to shift the parameter items.
Use [Zero] ke confirm and escape from setting the current item.

© Adam Equipment 2017 12
5.2 PARAMETER SETTING TABLE
FUN TION DES RIPTION DEFAULT
bEE
S
ets buzzer
0: Disable
1: Enable
0
Hod
S
ets hold function
0: Disable
1: Enable
0
Stb
S
ets zero function
STb0: zeroing allowed when unstable
STb1: zeroing not allowed when unstable
0
Aut
S
ets auto backlight:
(Onl applies when the scale has an
LCD displa )
AUT0: manual
AUT1：auto
0
Ht
S
ets units
0: lb
1: kg
1
YES
S
ets save:
0: not saved
1: save
0

© Adam Equipment 2017 13
A
AD DA AM M E EQ QU UI IP PM ME EN NT T, , M MA AI ID DS ST TO ON NE E R RO OA AD D, , K KI IN NG GS ST TO ON N, ,
M
MI IL LT TO ON N K KE EY YN NE ES S, , M MK K1 10 0 0 0B BD D, U.K.
Tel: [phone] Fax: [phone]
E-Mail Address: [e-mail]
CRANE SCALES
SAFE-LOAD STATEMENT
We hereby state that our Crane Scales are tested and inspected prior to dispatch. The safe-
loads for the crane scales are listed below:
Model no Max. capacity Max ultimate overload limit
LHS 500 / LHS 1000a 500 kg / 1000 lb 625 kg / 1250 lb
LHS 1500 / LHS 3000a 1500 kg / 3000 lb 1875 kg / 3750 lb
LHS 2000 / LHS 4000a 2000 kg / 4000 lb 2500 kg / 5000 lb
SHS 50 / SHS 100a 50 kg / 100 lb 62.5 kg / 125 lb
SHS 150 / SHS 300a 150 kg / 300 lb 187.5 kg / 375 lb
SHS 300 / SHS 600a 300 kg / 600 lb 375 kg / 750 lb
IHS 1/ IHS 2a 1000 kg / 2000 lb 1250 kg / 2500 lb
IHS 3 / IHS 6a 3000 kg / 6000 lb 3750 kg / 7500 lb
IHS 5 / IHS 10a 5000 kg / 10000 lb 6250 kg / 1250 lb
IHS 10 / IHS 20a 10000 kg / 20000 lb 12500 kg / 25000 lb
The limits stated above are the ultimate overload limits of the scales. Adam Equipment
Co. Ltd. its directors, owners and affiliated companies and organizations cannot be held
liable for any resulting damage or injury sustained as a result of the machines being used
in excess of their stated maximum capacity, capabilities and ultimate overload limits. To
avoid possible injury or death, read all instructions stated in the Manual before using.

© Adam Equipment 2017 14
WARRANTY STATEMENT
Adam Equipment offers Limited Warrant (Parts and Labour) for an components that fail due to
defects in materials or workmanship. Warrant starts from the date of deliver .
During the warrant period, should an repairs be necessar , the purchaser must inform its supplier
or Adam Equipment Compan . The compan or its authorised Technician reserves the right to repair
or replace the components at an of its workshops at no additional cost, depending on the severit of
the problems. However, an freight involved in sending the fault units or parts to the Service Centre
should be borne b the purchaser.
The warrant will cease to operate if the equipment is not returned in the original packaging and with
correct documentation for a claim to be processed. All claims are at the sole discretion of Adam
Equipment.
This warrant does not cover equipment where defects or poor performance is due to misuse,
accidental damage, exposure to radioactive or corrosive materials, negligence, fault installation,
unauthorised modifications or attempted repair, or failure to observe the requirements and
recommendations as given in this User Manual.
This product ma include a rechargeable batter that is designed to be removed and replaced b the
user. Adam Equipment warrants that it will provide a replacement batter if the batter manifests a
defect in materials or workmanship during the initial period of use of the product in which the
batter is installed.
As with all batteries, the maximum capacit of an batter included in the product will decrease with
time or use, and batter c cle life will var depending on product model, configuration, features, use,
and power management settings. A decrease in maximum batter capacit or batter c cle life is not
a defect in materials or workmanship, and is not covered b this Limited Warrant .
Repairs carried out under the warrant do not extend the warrant period. Components removed
during warrant repairs become compan propert .
The statutor rights of the purchaser are not affected b this warrant . The terms of this warrant is
governed b the UK law. For complete details on Warrant Information, see the terms and conditions
of sale available on our web-site.

© Adam Equipment 2017 15
WEEE 2012/19/EU
This device ma not be disposed of in domestic waste. This also applies to countries outside the EU, per
their specific requirements. Disposal of batteries (if fitted) must conform to local laws and restrictions.
Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit être
effectuée conformément aux lois et restrictions locales.
Dieses Gerät nicht mit dem Hausmüll entsorgt.
Dispositivo no puede ser desechado junto con los residuos domésticos
Dispositivo non può essere smaltito nei rifiuti domestici.
F / I LASS A DIGITAL DEVI E EM VERIFI ATION STATEMENT
NOTE: This equipment has been tested and found to compl with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules and Canadian ICES-003/NMB-003 regulation. These limits are
designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can radiate radio
frequenc energ and, if not installed and used in accordance with the instruction manual, ma cause
harmful interference to radio communications. Operation of this equipment in a residential area is
likel to cause harmful interference in which case the user will be required to correct the interference at
his own expense.
ALIFORNIA PROPOSITION 65 - MANDATORY STATEMENT
WARNING: This product includes a sealed lead-acid batter which contains chemicals known to the State
of California to cause cancer and birth defects or other reproductive harm.
Adam Equipment products have been tested with, and are alwa s supplied with
mains power adaptors which meet all legal requirements for the intended countr or
region of operation, including electrical safet , interference and energ efficienc . As
we often update adaptor products to meet changing legislation it is not possible to
refer to the exact model in this manual. Please contact us if ou need specifications or
safet information for our particular item. Do not attempt to connect or use an
adaptor not supplied b us.

© Adam Equipment 2017
ADAM EQUIPMENT is an ISO 9001:2008 certified global compan with more than 40 ears’ experience in the
production and sale of electronic weighing equipment.
Adam products are predominantl designed for the Laborator , Educational, Health and Fitness, Retail and Industrial
Segments. The product range can be described as follows:
-Anal tical and Precision Laborator Balances
-Compact and Portable Balances
-High Capacit Balances
-Moisture anal sers / balances
-Mechanical Scales
-Counting Scales
-Digital Weighing/Check-weighing Scales
-High performance Platform Scales
-Crane scales
-Mechanical and Digital Electronic Health and Fitness Scales
-Retail Scales for Price computing
© Cop right b Adam Equipment Co. All rights reserved. No part of this publication ma be reprinted or translated in an form or
b an means without the prior permission of Adam Equipment.
Adam Equipment reserves the right to make changes to the technolog , features, specifications and design of the equipment
without notice.
All information contained within this publication is to the best of our knowledge timel , complete and accurate when issued.
However, we are not responsible for misinterpretations which ma result from the reading of this material.
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
