Adam Equipment AQ Series User manual

© Adam Equipment Company 2014
A
DAM EQUIPMEN
T
AQ MECHANICAL
PLATFORM SCALE
MODELS: AQ 100K, AQ 300K, AQ 500K
USER MANUAL
©ADAM EQUIPMENT SA (Pty) LTD.
Rev. D, Jul 2014

© Adam Equipment Company 2014
OPERATION INSTRUCTIONS
Read the following precautions and instructions before you begin assembly or using.
Preparation
 Please check carefully the spare parts according to the breakdown of parts list
before assembly, list found in the box.
 Please put the scale on the level ground to get the correct weight, and keep the
scale pan horizontally.
 Please move the Sliding Poise to the zero position of the weigh beam, and then
turn the adjusting screw bolt of the adjusting Poise until the weigh beam can
swing normally.
Operation
 Do not place the object on the scale pan suddenly to avoid any damage. The
object should be put in the middle of the scale pan to get correct weight.
 Please add relevant Slotted Weight to the Hanger when the object is over the
weighing range of the weighbeam.
 Do not weigh any objects over the range of the scale.
Maintenance
 Keep the scale in dry and clean place.
 In case of any problem, please contact the manufacturer for help.
Table 1: Basic Parameters of scale
Model Scale Interval Platform Size Dimension Dead Weight
100 KG 50g 400 x 300 650 x 320 x 600 26 kg
300 KG 100/200g 600 x 450 960 x 550 x 1150 75 kg
500 KG 100/200g 600 x 450 960 x 550 x 1150 78 kg
Table 2: Range of Permissible Error
Model
Test
Weight
100 KG 300 KG 500 KG Permissible Error (d)
0 ~
500d 0-25kg 0- 100kg 0-100kg +/- 1d
>500d –
2000d 25-100kg 100kg- 300kg 100kg-400kg +/- 2d
>2000d n.a. n.a. 400kg-500kg +/- 3d
d = Scale Interval
Table 3: Number of Slotted Weights supplied
Specification
Amount
Model
5kg 10kg 20kg 25kg 50kg 100kg 200kg
100 kg 1 2 1 1
300 kg 1 1 2
500 kg 1 1 2 1
