Adam Equipment CRW Series User manual

@Adam Equipment Company 2004
Adam Equipment
CRW SERIES
CRANE SCALES
(P.N. 6085, Revision A2, December 2004)
Software revision: V 1.06

@Adam Equipment Company 2004

@Adam Equipment Company 2004
1
1.0 INTRODUCTION
1.1 INTRODUCTION
CRW Series offers heavy-duty scales used to weigh very large
masses. The main features include-
•Large LED display (30.5 mm)
•Rechargeable battery operated
•Selectable reading resolution
•Charger auto-off
•Battery protection
•Standard Remote Control Handset
1.2 TECHNICAL SPECIFICATIONS
Model
No.
Max.
Capacity
Over-
load
Capacity
Scale
Division
Net
weight
CRW-
1
1000kg 1500kg 0.5kg 15.5 kg
CRW-
3
3000kg 4500kg 1kg 15.5 kg
CRW-
5
5000kg 7500kg 2kg 24.0 kg
CRW-
7.5
7500kg 11250kg 2kg 37.6 kg
CRW-
10
10000kg 15000kg 5kg 37.6 kg

@Adam Equipment Company 2004
2
1.3 KEY DESCRIPTION
[ON/OFF] Power switch- use this key to turn on and turn off the scale.
[CHANGE] Division change key- use this key to change division.
When in setting mode, use this key to change parameter.
[LOCK] Reading lock key- use this key to lock reading.
When in setting mode, use this key to escape setting.
In calibrate mode, use this key to change the decimal point.
[ZERO] Re-zero key- use this key to return zero reading.
When in setting mode, use this key to store the setting.
1.4 DISPLAY





Lock indicator- when this indicator is on, scale is reading
data in lock mode.
Press the [LOCK] key to return to normal weighing mode.
    
        
     


Stable indicator- this indicator means the current data is
stable and you can read the data.
When in calibrate mode, make sure to proceed only when
this indicator is on.
   
      
   


Zero indicator- this indicates the scale is in zero point.

@Adam Equipment Company 2004
3
2.0 OPERATION
2.1 SAFETY INSTRUCTIONS
Read this manual carefully before you operate the Crane Scale.
•Unpack the Crane Scale carefully from the packing using suitable
lifting equipment as the weight of the Scale can be over the limit
for manual handling, particularly for the higher capacity model.
•Attach it to your Hoist or equivalent existing equipment securely in
the upright position. Make sure that the equipment to which the
scale is attached is in proper condition. The operator should be
trained for safe operation. It is recommended to fasten the hook
on the ground level and then to lift the scale to the desired height
rather than lifting the scale to the fastening hook.
•Do regular visual inspection for any damage or wearing out of
parts. Particularly the split pins at the end and the inner wall of the
hook and all joints should be checked regularly. If any damage or
wearing out has taken place, replace the parts at the earliest.
•Do all inspection and maintenance work when the scale is not in
use.
•Do not expose the scale to extreme temperatures. The operating
temperature range is 0°C to 40°C.
•Secure the sample to be weighed in the hook of the scale. Ensure
that the sprung Safety Lever returns to its resting position which
prevents the sample from slipping out of the hook.
•Do not exceed the maximum capacity of the Scale as mentioned
in section 1.2.
•Clean and protect your scale after use.

@Adam Equipment Company 2004
4
2.2 BATTERY OPERATION
When battery goes low, the reading will keep on flickering. It is the time
to charge the battery with the special charger. If the scale is being used
without proper charging, the display will flicker and after 30 minutes the
display will show “     
          
     ”. If you still don’t charge the battery, the scale
would be shut down automatically after 5 seconds of warning, in order to
protect the battery. Charge the battery immediately.
If you do not use the crane scale for a long time, you may need to
charge the battery every three months.
2.3 CHARGING BATTERY
Use the special charger to charge battery, using other type of charger
may cause harm to the battery.
Please ensure your AC power meets the required rating of power.
The LED on charger will turn on when battery is being charged and it will
be flickering when battery is fully charged.
After the full charging, the AC adapter will automatically switch over to
the low current charge process, so that it is not necessary to disconnect
the AC adapter immediately.
2.4 BASIC OPERATIONS
Power on and off- Press [ON/OFF] key to on and off the scale.
Zero the scale- When there is no item on the scale but the reading is not
zero, press the [ZERO] key to re-zero the reading.
Reading lock- When reading is not stable, you can use the [LOCK] key
to lock the reading, so that you can read easily. After you finish reading,
press [LOCK] again to return to normal weighing mode.
Change division- You can use the [CHANGE] key to change division, All
scales have been set for the middle division in the factory.
Overload Warning- Please do not add any item that exceeds the
maximum capacity of the scale. When the display shows



 
  
  



,

remove
the item to avoid damage to the load cell.

@Adam Equipment Company 2004
5
2.5 AUTO SLEEP
The crane scales have automatic sleep function. You can disable this
function, see section 4.0. When the scale weighs a sample below the
minimum capacity (20d) for more than the set time, it will automatically
enter the sleep mode. Only the last point will turn on at LED. Once you
press any key or add more weight on the hook, it will return to normal
weighing mode again. Please pull out the antenna before operating the
remote controller.
2.6 REMOTE CONTROLLER
The crane scales are supplied with remote control. You will find 4 keys
on the remote controller.
Key A: use as [ZERO] key
Key B: use as [CHANGE] key
Key C: use as [LOCK] key
3.0 CALIBRATION
Turn off the power if you are using the scale.
Then turn on the power, press [ZERO] and [CHANGE] key at the
same time during self-checking.
Display shows “”, asking for entering the password.
Input password, use [LOCK] key to move the active digit,
[CHANGE] key to increment a digit. Press the [ZERO] key to
confirm the password. The default password is “”.
Display will show “”, press [CHANGE] key until display shows
“”.
Press [ZERO] key to enter calibration, display shows “”.
Empty the hook, after STABLE indicator on, press [ZERO] key to
confirm, after few seconds, zero calibration is now complete.
After zero calibration, display shows a value of mass for span
calibration. You can change this weight by using the [LOCK] key
to move the active digit and [CHANGE] key to increment a digit.
After entering the value of the calibration mass, press the [ZERO]
key to confirm. When display shows “”, add the calibrate mass
on the hook after stable indicator on. Press the [ZERO] key again,
wait for few seconds, span calibration is now complete.

@Adam Equipment Company 2004
6
4.0 PARAMETER
4.1 Enter setting mode
Turn off the power of the scale and
then turn the power on again.
Press the [ZERO] and [CHANGE]
key at the same time during self-
checking. Display shows “”,
asking for the password. Input the
password using the [LOCK] key to
move the active digit and the
[CHANGE] key to increment a
digit. Press [ZERO] to confirm.
The default password is “”,
Display shows “ ”, indicating
the scale has entered the setting
mode. Press the [CHANGE] key to
shift the parameter items, use
[ZERO] key to confirm and the
[LOCK] key to escape from setting
the current item.
4.2 PARAMETER SETTING TABLE
FUNCTION DESCRIPTION DEFAULT

Sets division
 : high resolution
 : standard resolution
 : low resolution


Sets zero tracking range




Sets baud rate (RS-232 is an optional function)
 : 600bps,
 : 1200bps
 :2400bps,
 : 4800bps
 : 9600bps


@Adam Equipment Company 2004
7

Sets ADC speed
 : 7.5 times/second
 : 15 times/second
 : 30 times/second
 : 60 times/second


Shows internal counts. Press [LOCK] to escape from
this parameter.
 
Sets weighing unit
! : kg, ! : ! :

"
Sets auto sleep mode
 : no auto sleep
 : auto sleep after scale empty for 5 minutes
 : auto sleep after scale empty for 10 minutes
 : auto sleep after scale empty for 20 minutes
 : auto sleep after scale empty for 30 minutes
"
# Sets parameter setting password 


"
Calibration
"$% (calibration mass) "$% (complete)
For details see SECTION 3.

@Adam Equipment Company 2004
8
5.0 ERROR CODES
ERROR
CODES
DESCRIPTION SUGGESTIONS
$"
Over range Remove the weight from the scale.
If the problem persists contact your dealer or Adam
Equipment for assistance.
&''
Zero Setting Error The scale was outside the normal auto-zero setting
range (4% of capacity),
Check the hook is empty or
Calibrate zero point again.


&''
A/D out of range The values from the A/D converter are outside the
normal range.
Remove weight from the scale if overloaded.
The load cell or the electronics may be faulty.
If the problem persists, contact your dealer or Adam
Equipment for assistance.
$
Battery low Charge the battery immediately.

@Adam Equipment Company 2004
Manufacturer’s Declaration of Conformity
This product has been manufactured in accordance with the harmonised European
standards, following the provisions of the below stated directives:
Electro Magnetic Compatibility Directive 89/336/EEC
Low Voltage Directive 73/23/EEC
Adam Equipment Co. Ltd.
Bond Avenue
Denbigh East Estate
Milton Keynes, MK1 1SW
United Kingdom
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. The equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Shielded interconnect cables must be employed with this equipment to insure compliance
with the pertinent RF emission limits governing this device.
Changes or modifications not expressly approved by Adam Equipment could void the user's
authority to operate the equipment.

@Adam Equipment Company 2004
ADAM EQUIPMENT is an ISO 9001:2000 certified global organisation with more
than 30 years experience in the production and sale of electronic weighing
equipments. Products are sold through a world wide distributor network -supported
from our company locations in the UK, USA and SOUTH AFRICA. The company and
their distributors offer a full range of Technical Services such as on site and
workshop repair, preventative maintenance and calibration facilities.
ADAM’s products are predominantly designed for the Laboratory, Educational,
Medical and Industrial Segments. The product range can be classified as follows:
-Analytical and Precision Laboratory Balances
-Top Loading Scales for Educational establishments
-Counting Scales for Industrial and Warehouse applications
-Digital Weighing/Check-weighing Scales
-High performance Platform Scales with extensive software
features including parts counting, percent weighing etc.
-Digital Electronic Scales for Medical use
-Retail Scales for price computing
Adam Equipment Co. Ltd.
Bond Avenue
Milton Keynes
MK1 1SW
UK
Phone:[phone]
Fax: [phone]
e-mail:
[email protected].uk
Adam Equipment Inc.
26, Commerce Drive
Danbury, CT
06810
USA
Phone: [phone]
Fax: [phone]
e-mail:
[email protected]m
Adam Equipment S.A. (Pty) Ltd.
P.O. Box 1422
Kempton Park 1620
Johannesburg
Republic of South Africa
Phone [phone]
Fax: [phone]
e-mail:
[email protected].za
© Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication
may be reprinted or translated in any form or by any means without the prior permission
of Adam Equipment.
Adam Equipment reserves the right to make changes to the technology, features,
specifications and design of the equipment without notice.
All information contained within this publication was to the best of our knowledge timely,
complete and accurate when issued. However, we are not responsible for
misimpressions which may result form the reading of this material.
The latest version of this publication can be found on our Website.
Visit us at www.adamequipment.com
