Adam Equipment MDW-250L User manual

Adam Equipment
MDW-250L
DIGITAL PHYSICIAN SCALE
(P.N. 4302, Rev. B4, January 2006)
© Adam Equipment Company 2006

1.0 INTRODUCTION
•The MDW 250L scale is a
Digital Physician Scale.
•It is an accurate
electronic device with
advanced design and
stable performance.
•It is designed to measure
both the weight and the
height of a person.
2.0 TECHNICAL SPECIFICATIONS
Maximum capacity 250 kg
Minimum capacity 2 kg
Scale division 100 g
Height range 80 cm-210 cm
Division of measurement 0.5 cm
Accuracy class
Display LCD
Size of platform 372 X 272 mm
Overall dimension 535 X 275 X 940 mm
Deadweight 13 kg
Environment for Use Temperature: 5ºC-40ºC;
Humidity: <85℅RH
Power AC 220V through an adapter
Battery Internal, re-chargeable
6V, 5 hours approx.
© Adam Equipment Company 2006
1

3.0 DISPLAY AND KEY DESCRIPTIONS
KEYS FUNCTIONS
[On/Off] To turn the scale on or off.
[Hold] To lock the reading even if the person to be weighed is moving.
[Tare/Zero]
To zero the scale if the display drifts from zero.
To tare the scale, if necessary.
[Func] To set up the service parameters
[kg/ lb] To switch the weighing unit between Kg and lb
DISPLAY DESCRIPTIONS
Zero The arrow above Zero will be displayed when the scale reaches zero.
Stab To indicate that the weighing result is stable
Tare To indicate the scale is tared
Hold This indicates the Hold function is enabled
lb To indicate the reading is in lb
kg To indicate the reading is in kg
The arrow indicator will point at kg, lb, Hold, Tare, Stab or/and Zero
marked below the LCD panel, as on when they are chosen.
AC When the adapter is connected to recharge the battery, it will show a
red indicator.
© Adam Equipment Company 2006
2

© Adam Equipment Company 2006
3
4.0 SETTING UP THE SCALE
•Take the Physician scale out of the box.
•Remove the three screws from the bottom of the pillar.
•Place and rotate the pillar and secure it to an upright position
using the three screws and connect the cable by fixing the
connector.
•Slide the pole cover to the bottom.
•Remove the screw at the top of the pillar and turn the
indicator panel to 180 degree. Tighten the screw until the
indicator panel is secured.
•Position the height measuring rod and secure it by fixing its
threaded end.
•Connect the adapter power supply to the main power supply
and put the switch at the rear of the scale to ON.
5.0 WEIGHING
•Place the Physician Scale on an even floor and press the
[On/Off] key.
•The instrument performs a self-test after which it is ready for
operation. The display will show “
0.0 ” with an arrow symbol,
above kg or lb, indicating the last chosen unit.
•The arrow above Stab will be on when the reading is stable.
•Press the [On/Off] key to switch off the scale. If the scale is
not to be used for a long time, the main power switch should
be turned off to save the battery life.
•To start weighing, press [On/Off], the scale will show “0.0”.

© Adam Equipment Company 2006
4
•If the scale is still displaying a small weight when there is no
load on the platform, it needs to be zeroed. Press the
[Tare/Zero] key to zero the display. The arrow above Zero
will be on. If the zero display is not achieved then the scale
may need to be re-calibrated.
•If the weighing value is to be tared to obtain the net value,
press [Tare/Zero] again. The arrow above Tare will be on.
•The person to be weighed can step on to the platform now.
The weight will be displayed in Kg or lb depending on the
units chosen by the user.
•Units: Press the [kg/lb] key for changing the weighing unit to
kg or lb. An arrow will indicate towards the chosen unit.
•Backlight: The scale has an automatic back-light which is
switched on whenever time the scale is in use.
•Overload display: When “OL” appears on the display, it
shows that the load on the platform is over the maximum
capacity. It is necessary to reduce the load otherwise the
sensor or the platform may be damaged.
•Hold Function: To lock the weighing result, press the [Hold]
key. The arrow indicator will point towards Hold and it will
show a steady reading even if the person on the platform is
moving or goes away from the scale and will not allow the
next weighing. To release the function, press [Hold] again.
•Do not press the [On/Off] key if you do not want to weigh as
pressing the [On/Off] key will switch the scale to ON.
6.0 MEASURING HEIGHT
•While measuring the height, it is necessary to pull up the
measuring board at a right angle with the inside tube.
•When the tube is pulled out straight, it is sufficient to
measure the height from 80 to 126 cm. The number can be
obtained upon the conjoint place where the upper part of
middle tube screw meets with the inside tube scale.

© Adam Equipment Company 2006
5
•Further, if the middle tube is pulled out straight, it is possible
to measure the height from 126-190 cm. The reading can be
obtained at the conjoint place where the upper part of outside
tube screw meets with the middle tube scale.
7.0 MAINTENANCE
•Do not dismantle the weighing machine without following the
necessary instructions.
•Do not jump while standing on the load-bearing board. This
may damage the sensor inside.
•Do not move the weighing machine violently and abruptly. It is
recommended to move and put down the weighing machine
gently.
•It is suggested to wipe the stains with soft cloth soaked with
detergent and to wipe later with soft cloth too. Do not use
organic solutions and boiled water to wipe the stains. Do not
use water for cleaning.
•Keep the weighing machine in a dry and clean environment. Do
not expose it outdoor or use it in locations near fire, under
direct sunshine or with high temperature.
•When lifting the height meter, it is suggested to pull it straight
along the pipe without using excessive force.
•The [On/Off] key on the screen board only switches off the
screen power instead of the entire power to the weighing
machine. Therefore, it is necessary to switch off the main
power supply when the weighing machine is not in use for a
long time. Otherwise the battery may be damaged as a result of
over-discharge.

Manufacturer’s Declaration of Conformity
This product has been manufactured in accordance with the harmonised European
standards, following the provisions of the below stated directives:
Electro Magnetic Compatibility Directive 89/336/EEC
Low Voltage Directive 73/23/EEC
Adam Equipment Co. Ltd.
Bond Avenue
Denbigh East Estate
Milton Keynes, MK1 1SW
United Kingdom
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. The equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Shielded interconnect cables must be employed with this equipment to insure compliance
with the pertinent RF emission limits governing this device.
Changes or modifications not expressly approved by Adam Equipment could void the
user's authority to operate the equipment.
