2.0INTRODUCTION
2.1 FEATURES

TheLHS/LHSaSeriesarearangeofheavy‐dutylowercapacitycranescales
Themainfeaturesinclude:
 EasyOperation&Ruggedconstruction
 25mmbrightredLEDdisplayenablingagoodviewingangle.
 360degreerotarysafetyhookandsupportringdesign
 Overloadsafetyupto125%ofmodelcapacity
 Selectableweighingunitsofkg,LbsandNewtons(Newtonsnotavailablefor“a”
models)
 StandardandPeakHoldfeature
 Internalrechargeablebatteryfittedasstandard
 Autopoweroffafter30minutesofnonuse
 6Vdc600mabatterycharger
 StrongDiecastAlluminiumhousing
 Infraredremotecontrol



© Adam Equipment Company 2017 3
2.2 TECHNICALSPECIFICATIONS

ModelNo Capacity Division ModelNo Capacity Division
LHS‐500 500kg 0.1kg LHS‐1000a 1000lb/500kg 0.2lb/0.1kg
LHS‐1500 1500kg 0.2kg LHS‐3000a 3000lb/1500kg 0.5lb/0.2kg
LHS‐2000 2000kg 0.5kg LHS‐ 4000a 4000lb/2000kg 1lb/0.5kg




© Adam Equipment Company 2017 4
2.3 SAFETYNOTICE

ThelimitstatedbelowistheUltimateOverloadLimitsofthescales.
AdamEquipmentCo.Ltd.Itsdirectors,ownersandaffiliatedcompaniesandorganisationscannot
beheldliableforanyresultingdamageorinjurysustainedasaresultofthemachinesbeingusedin
excessoftheirstatedcapacitiesorultimateoverloadlimits.

ModelNo. LHS500/1000a LHS1500/3000a LHS2000/4000a
Max
capacity  500kg/1000lb 1500kg/3000lb 2000kg/4000lb
Overload
capacity 625kg/1250lb 1875kg/3750lb 2500kg/5000lb
NOTICE:
Donotusethescalesifanypartsarebentorlooseorshowsignsofdamageorwear.Refertothe
usermanual.
2.4 KEYANDPANELDESCRIPTION




© Adam Equipment Company 2017 5

[ON/OFF] Thepowerswitch islocatedontherearhousing.Usethiskeytoturn
thescaleONandOFF.
[Zero] Pressthe[Zero] keytoreturnthereadingtozero.
[Unit] Press the [Unit] key to change the weighing unit being displayed
betweenKg,LbsandNewtons(Newtonsnotavailablefor“a”models)
[Hold]
Usethiskeytoactivate standard Hold.WhenpressedtheHold LEDwill
lightatthetopleftsideofthedisplayandthereadingonthedisplay
will lock and flash. Press the [Hold] key again to cancel the [Hold]
function.
*WhenPeakholdisselectedfromtheparametersectionthepressof
theHoldkeywillactivatePeakHold.TheHoldLEDwillflashandthe
display will also flash and lock showing the maximum weight
registeredofasingleweighingprocess.
Pressthe[Hold]keyagaintocancelthe[Hold]function.

2.5 DISPLAYINDICATIONSWITHLED
KglbN TheLEDwilllightupintheweighingunitthatisbeingusedto
indicatewhentheweightisstable.
Hold HoldIndicator
3.0 OPERATION
3.1 SAFETYINSTRUCTIONS
ReadthismanualcarefullybeforeyouoperatetheSHSCraneScale.
 UnpacktheCraneScalecarefullyfromthepackaging.
 Attachittoyourhoistorequivalentexistingequipmentsecurelyatthegroundlevel
tothesupportringintheuprightposition.Makesurethattheequipmenttowhich
thescaleisattachedisinpropercondition.Theoperatorshouldbetrainedforits
safeoperation.
 Carryoutregularvisualinspectionforanydamageorwearandtearonparts.The
splitpinsinparticularatthehookandeyebolts,aswellastheinnerwallofthehook

© Adam Equipment Company 2017 6
andalljointsshouldbecheckedregularly.Ifanydamageorwearhastakenplace,
stopusingthescaleandreplacetheparts.
 Doallinspectionandmaintenanceworkwhenthescaleisnotinuse.
 Donotexposethescaletoextremetemperatures.Theoperatingtemperaturerange
is0°Cto40°C.
 Securethesampletobeweighedinthehookofthescale.Ensurethatthesprung
SafetyLeverreturnstoitsrestingpositionwhichpreventsthesamplefromslipping
outofthehook.
 DonotexceedthemaximumcapacityoftheScale.
 Cleanandprotectyourscaleafteruse.
OverloadWarning
Pleasedonotaddanyitemthatexceedsthemaximumcapacityofthescale.Whenthedisplay
shows”-----”removetheitemtoavoiddamagetotheloadcellandscale.
3.2 BATTERYOPERATION

 The rechargeable battery will operate continuously for between 20 and 30 hours
beforerequiringrecharging.
 Tochargethebattery,plugthechargerunitintothesocketasmarkedontherearof
thescale.PlugthechargerintothemainspowersupplyandwaituntiltheLEDonthe
chargershowsgreen.Thebatteryisnowfullycharged.
 Chargingtimeforacompletelydischargedbatteryisapproximately16hours.Afull
batterypackisrecommendedtokeepthescalecontinuouslyoperational.
 Onlyusethechargerassuppliedwiththeunit.
 The scale will automatically power down after 30 minutes of nonusetofurther
protectthebattery.
 To replace the battery, turn the locking screw on the battery cover 90 degrees
clockwiseandliftopenthecover.Disconnectandremovetheoldbatteryandreplace
withanewone.
 Contactyourdealerforareplacementbattery.

© Adam Equipment Company 2017 7
BASICOPERATIONS
Poweronandoff
Pressthe[ON/OFF]buttontoturnthescaleonoroff.Thedisplayonthescalewillshowthe
modelcapacitythencountdownfrom9to0beforedisplayingzeroweight.

Zerothescale
Pressthe[Zero]keysothatthedisplayshowszero.

ChangetheweighingUnit
Pressthe[Unit]keytochangetheweighingunit

StandardHold(setting1)
Whenthereadingmaynotbeperfectlystableoryoucannotviewareadingeasilyyoucanpress
the[Hold]keytolockit.Thereadingwillbelockedandalsoflashatthepointyoupressthe
[Hold]buttonenablingyoutoviewitwhenyoucan.TheHoldLEDwillalsolightupandonce
youhavenotedthereadingapressofthe[Hold]keywillreturnthescaletothenormalweighing
mode.

PeakHold(setting0)
PeakHoldisthehighestweightreadingregisteredbythescalewhenaweighingtakesplace.
Pressthe[Hold]keywhenthedisplayisatzeroandtheHoldLEDwillflashwhichdenotesPeak
Holdhasbeenactivated.Whenweight/forceisappliedtothescalethedisplaywillalsoflash
andlockthehighestrecordedweightofthatweighingprocess.ThisvalueandtheHoldLEDwill
remainflashingonthedisplayuntilthe[Hold]keyispressedagainatwhichpointthescalewill
returntonormalweighingmodedisplayingthecurrentweightonthescale.
Press[Hold]againtoperformanotherPeakHoldweighingatanytime.


© Adam Equipment Company 2017 8

3.3 REMOTECONTROLUNIT

TheremotecontrolworksviainfraredandcanbeusedtooperatetheLHSfromlongdistances.
Itoperatesusing2xAAAbatteriesandthesecanbeexchangedbyunclippingacoverontherear
oftheremotecontrolunit.
3.5 USERPARAMETERS
FiveUSERparametersareontheSHS,toaccessthesepowerupthescaleandwhilstthedisplay
iscountingdownpressandthenreleasethe[Unit]button.Thedisplaywillshow00000.Usethe
[Hold]and[Unit]buttonstoenterthecode11111andthenpress[Zero].bEE1willbedisplayed.
Press the [Hold] button to change the setting and the [Zero] button to move to the next
parameter.

PARAMETERSETTINGTABLE
FUNCTION DESCRIPTION DEFAULT
BEE Setsbuzzer
0:Disable1:Enable 1
HODSetstheHoldfunction
0:Peak1:Standard
1
STBSetstheStablefunction
0:Disable1:Enable
1
CHT
Setsweighingunitonpowerup
0:kg1:Lb’s
2:Newtons(Newtonsnotavailablefor“a”
models)
0
YES Setssave:
0:Notsaved1:Savenewsettings
0


© Adam Equipment Company 2017 9
4.0CALIBRATION

 Pressthe[Zero]keyandpowerupthescaleusingtheon/offbutton.
 Release the [Zero] key and the display will show “SPAN”. Make sure the hook is
emptyunlessyouintendtouseanychains,slingsetctoholdthecalibrationmass.
Addanyitemssuchasthesetothehookbeforecontinuing.
 Press the [Zero] button and the display will show “SET” then “00000” when the
readingatzeroisstable.Thiscompletesthezerocalibration.
 Following zero calibrationthe valueof the massbeing used to calibratethescale
shouldbeentered.Usethe[Hold]buttontoincrementtherighthanddigit,andthe
[Unit]buttontomovethisdigittotheleft.Proceedbyenteringanumberforthenext
digit if required, until the value of your chosen calibration weight is displayed
correctly.
 Loadthismassontothehookandwhenthescaleisstablepressthe[Zero]key.The
displayshows‘HOLD’.
 After a few seconds, the calibration is complete and the scale returns to normal
weighingshowingthevalueofthecalibrationmassasused.

**TocalibrateinLbsmakesurethatthescaleisLbsmodebeforecommencing,tocalibrate
inKgmakesurethescaleisinKgmodebeforecommencing.



© Adam Equipment Company 2017 10
5.0PARTSLIST

LHS/LHSa
Part number Description Item No
7.00.1.2.0005 LHS COMPLETE HOUSING – 500kg/1000lb, 1500kg/3000lb 1, 2, 3
7.00.1.2.0012 LHS COMPLETE HOUSING – 2000kg/4000lb 1, 2, 3
7.00.4.0.0083 LHS ON/OFF SWITCH 4
7.00.4.0.0086 LHS POWER CONNECTOR SOCKET 5
7.00.4.0.0084 LHS LEAD ACID BATTERY 6Vdc 3.2ah 6
7.00.1.0.0279 LHS RING SUPPORT 7
7.00.1.0.0273 LHS LOAD CELL - 500kg/1000lb 8
7.00.1.0.0274 LHS LOAD CELL - 1500kg/3000lb 8
7.00.1.0.0275 LHS LOAD CELL - 2000kg/4000lb 8
7.00.1.0.0276 LHS HOOK 9
7.00.4.0.0085 LHS MAIN PCB 10
7.00.5.6.0045 LHS FASCIA PANEL - 500kg 11
7.00.5.6.0046 LHS FASCIA PANEL - 1500kg 11
7.00.5.6.0047 LHS FASCIA PANEL - 2000kg 11
7.00.2.0.0081 LHSa FASCIA PANEL - 1000lb 11
7.00.2.0.0082 LHSa FASCIA PANEL - 3000lb 11
7.00.2.0.0083 LHSa FASCIA PANEL - 4000lb 11
7.00.4.0.0094 LHS KEYBOARD PUSHBUTTON
7.00.3.0.0025 LHS COMPLETE PACKAGING SET
7.00.4.0.0109 LHS 6VDC @ 600ma POWER/CHARGER UNIT USA
7.00.4.0.0110 LHS 6VDC @ 600ma POWER/CHARGER UNIT
A
USTRALIA
7.00.4.0.0111 LHS 6VDC @ 600ma POWER/CHARGER UNIT SA
7.00.4.0.0087 LHS 6VDC @ 600ma POWER/CHARGER UNIT UK
7.00.4.0.0088 LHS 6VDC @ 600ma POWER/CHARGER UNIT EU
7.00.4.0.0090 LHS REMOTE CONTROL UNIT


© Adam Equipment Company 2017 11
























































































































































12

ADAM EQUIPMENT, MAIDSTONE ROAD, KINGSTON,
MILTON KEYNES, MK10 0BD , U.K.
Tel: [phone] Fax: [phone]
E-Mail Address: [e-mail]
CRANE SCALES
SAFE-LOAD STATEMENT
We hereby state that our Crane Scales are tested and inspected prior to
dispatch. The safe-loads for the crane scales are listed below:
Model no Max. capacity Max ultimate overload limit
LHS 500 / LHS 1000a 500 kg / 1000 lb 625 kg / 1250 lb
LHS 1500 / LHS 3000a 1500 kg / 3000 lb 1875 kg / 3750 lb
LHS 2000 / LHS 4000a 2000 kg / 4000 lb 2500 kg / 5000 lb
SHS 50 / SHS 100a 50 kg / 100 lb 62.5 kg / 125 lb
SHS 150 / SHS 300a 150 kg / 300 lb 187.5 kg / 375 lb
SHS 300 / SHS 600a 300 kg / 600 lb 375 kg / 750 lb
IHS 1/ IHS 2a 1000 kg / 2000 lb 1250 kg / 2500 lb
IHS 3 / IHS 6a 3000 kg / 6000 lb 3750 kg / 7500 lb
IHS 5 / IHS 10a 5000 kg / 10000 lb 6250 kg / 1250 lb
IHS 10 / IHS 20a 10000 kg / 20000 lb 12500 kg / 25000 lb
The limits stated above are the ultimate overload limits of the scales. Adam Equipment Co. Ltd. its
directors, owners and affiliated companies and organizations cannot be held liable for any resulting
damage or injury sustained as a result of the machines being used in excess of their stated maximum
capacity, capabilities and ultimate overload limits. To avoid possible injury or death, read all instructions
stated in the Manual before using.



13

WARRANTYINFORMATION
AdamEquipmentoffersLimitedWarranty(PartsandLabour)forthecomponentsfailedduetodefects
inmaterialsorworkmanship.Warrantystartsfromthedateofdelivery.

Duringthewarrantyperiod,shouldanyrepairsbenecessary,thepurchasermustinformitssupplieror
AdamEquipmentCompany.The companyorits authorisedTechnicianreservestherighttorepairor
replacethecomponentsatanyofitsworkshopsdependingontheseverityoftheproblems.However,
anyfreight involvedin sending thefaultyunits orparts totheservice centreshouldbebornebythe
purchaser.

Thewarrantywillceasetooperateiftheequipmentisnotreturnedintheoriginalpackagingandwith
correct documentation for a claim to be processed. All claims are at the sole discretion of Adam
Equipment.

Thiswarrantydoesnotcoverequipmentwheredefectsorpoorperformanceisduetomisuse,accidental
damage, exposure to radioactive or corrosive materials, negligence, faulty installation, unauthorised
modificationsorattemptedrepairorfailuretoobservetherequirementsandrecommendationsasgiven
in this User Manual. Additionally rechargeable batteries (where supplied) are not covered under
warranty.

Repairs carried out under the warranty does not extend the warranty period. Components removed
duringthewarrantyrepairsbecomethecompanyproperty.

Thestatutoryrightofthepurchaserisnotaffectedbythiswarranty.Thetermsofthiswarrantyis
governedbytheUKlaw.ForcompletedetailsonWarrantyInformation,seethetermsandconditions
ofsaleavailableonourweb‐site.



© Adam Equipment Company 2017
WEEE2012/19/EU

Thisdevicemaynotbedisposedofindomesticwaste.Thisalsoappliestocountriesoutsidethe
EU,pertheirspecificrequirements.Disposalofbatteries(iffitted)mustconformtolocallaws
andrestrictions.
Cetappareilnepeutêtreéliminéaveclesdéchetsménagers.L’éliminationdelabatteriedoitêtre
effectuéeconformémentauxloisetrestrictionslocales.
DiesesGerätnichtmitdemHausmüllentsorgt.
Dispositivonopuedeserdesechadojuntoconlosresiduosdomésticos
Dispositivononpuòesseresmaltitoneirifiutidomestici.

FCC/ICCLASSADIGITALDEVICEEMCVERIFICATIONSTATEMENT
NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigital
device,pursuanttoPart15oftheFCCrulesandCanadianICES‐003/NMB‐003regulation.These
limits are designed to provide reasonable protection against harmful interference when the
equipmentisoperatedinacommercialenvironment.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstruction
manual,maycauseharmfulinterferencetoradiocommunications.Operationofthisequipment
inaresidentialareaislikelytocauseharmfulinterferenceinwhichcasetheuserwillberequired
tocorrecttheinterferenceathisownexpense.
CALIFORNIAPROPOSITION65‐MANDATORYSTATEMENT
WARNING:Thisproductincludesasealedlead‐acidbatterywhichcontainschemicalsknownto
theStateofCaliforniatocausecancerandbirthdefectsorotherreproductiveharm.




AdamEquipmentproductshavebeentestedwith,andarealwayssuppliedwith
mains power adaptors which meet all legal requirements for the intended
country or region of operation, including electrical safety, interference and
energy efficiency. As we often update adaptor products to meet changing
legislationitisnotpossibletorefertotheexactmodelinthismanual.Please
contactusifyouneedspecificationsorsafetyinformationforyourparticular
item.Donotattempttoconnectoruseanadaptornotsuppliedbyus.










© Adam Equipment Company 2017

ADAMEQUIPMENTisanISO9001:2008certifiedglobalcompanywithmorethan40years’experienceinthe
productionandsaleofelectronicweighingequipment.

AdamproductsarepredominantlydesignedfortheLaboratory,Educational,HealthandFitness,Retailand
IndustrialSegments.Theproductrangecanbedescribedasfollows:

‐AnalyticalandPrecisionLaboratoryBalances
‐CompactandPortableBalances
‐HighCapacityBalances
‐Moistureanalysers/balances
‐MechanicalScales
‐CountingScales
‐DigitalWeighing/Check‐weighingScales
‐HighperformancePlatformScales
‐Cranescales
‐MechanicalandDigitalElectronicHealthandFitnessScales
‐RetailScalesforPricecomputing
ForacompletelistingofallAdamproductsvisitourwebsiteat
www.adamequipment.com



AdamEquipmentCo.Ltd.
MaidstoneRoad,Kingston
MiltonKeynes
MK100BD
UK
Phone:+44(0)1908274545
Fax:+44(0)1908641339
e‐mail:
[email protected]
AdamEquipmentInc.
1,FoxHollowRd.,
OxfordCT
06478
USA
Phone:+12037904774
Fax:+12037923406
e‐mail:
[email protected]

AEAdamGmbH.
Instenkamp4
D‐24242Felde

Germany
Phone+49(0)4340403000
Fax:+49(0)43404030020
e‐mail:
[email protected]

AdamEquipmentS.A.(Pty)Ltd.
7MegawattRoad,
SpartanEXT22
KemptonPark,
Johannesburg,
RepublicofSouthAfrica


Phone+27(0)119749745
Fax:+27(0)113922587
e‐mail:
[email protected]

AdamEquipment(S.E.ASIA)PTY
Ltd
2/71TacomaCircuit
CANNINGVALE6155
Perth
WesternAustralia


Phone:+61(0)864616236
Fax+61(0)894564462
e‐mail:
[email protected]


AdamEquipment(Wuhan)Co.Ltd.
ABuildingEastJianhua
PrivateIndustrialPark
ZhuanyangAvenue
WuhanEconomic&Technological
DevelopmentZone
430056Wuhan
P.R.China
Phone:+86(27)59420391
Fax+86(27)59420388
e‐mail:
[email protected]

©CopyrightbyAdamEquipmentCo.Allrightsreserved.Nopartofthispublicationmaybereprintedortranslatedin
anyformorbyanymeanswithoutthepriorpermissionofAdamEquipment.

Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the
equipmentwithoutnotice.

Allinformationcontainedwithinthispublicationistothebestofourknowledgetimely,completeandaccuratewhen
issued.However,wearenotresponsibleformisinterpretationswhichmayresultfromthereadingofthismaterial.

ThelatestversionofthispublicationcanbefoundonourWebsite.

www.adamequipment.com

