Adams SAXOPHONE PLAYING STAND User manual

ADAMS SAXOPHONE PLAYING STAND
TENOR AND BARITONE SAXOPHONE
ADAMS MUSIC CENTRE
ADAMS-MUSIC.COM

Take the playing stand out of
the carrying bag.
In some occasions the top point
screw of the low C#-key has to
be loosened to mount the clamp
on the saxophone. Please use
a well-tting screwdriver and
pay attention that the spring is
placed back carefully.
Unscrew the two parts of the
clamp with the hex key.
Place the second part of the
clamp over the saxophone and
turn the hexagonal socket screw
xed in the clamp.
Slide the rst half with the
extending pin over the
reinforced ring of the bell
(Connection part of low C#
and B-key).
Tighten the clamp securely with
the hex key until the clamp can
no longer move.
1 2
3
4 5
Tenor
Tenor
Baritone
Baritone
Tenor Baritone

After the legs have fallen down,
tighten the wing nut rmly.
Place the stand next to your
chair and grab the support by
the rod at the bottom.
ATTENTION! Never move the
saxophone itself to try to
change the position of the rest.
This might cause damages
Pull the support at the bot-
tom of the rod towards your
chair and then back into ‘2nd
gear’. This is the base position.
Some force is required for
this, but this ensures that the
saxophone will remain rm and
stable.
Take a relaxed position, with a
straight back. When needed,
adjust the stand by pulling the
stand (not the saxophone)
into the right position.
This is necessary to guarantee
stability.
Place the stand on the oor, make sure all plastic nuts are ‘open’ and
slide the saxophone into the stand with the clamping strap.
Tighten the 2 plastic nuts, one
on the clamp and one on the
stand (height adjustment).
Now take the playing stand and loosen the large wing nut at the bottom
of the stand with the wing nut pointing upwards.
ATTENTION! The legs of the
stand are very heavy, so hold
the standard up with wing nut
on top to prevent the legs falling
down on your hands! Now turn
the wing nut up which enables
the legs to move freely.
Turn the stand arround.
ATTENTION! The heavy legs will
fall down, so watch your hands!
6
7 8
9
Tenor
Tenor
Baritone
Baritone

ADAMS MUSIC CENTRE
ADAMS-MUSIC.COM
DON’TS
DO’S
While setting up the stand, make sure you have a relaxed and straight back posture.
Be careful with the heavy legs of the stand during setup.
Never move the sax when it is in the stand. This could damage the cup part.
The large swivel of the stand must not be loosened. This makes the
standard unstable and can cause damage to your saxophone.
ADAMS ITTERVOORT (NL)
Aziëstraat 17-19
NL-6014 DA Ittervoort
[email protected]
[phone]
ADAMS LUMMEN (B)
Bosstraat 73
B-3560 Lummen
[email protected]
[phone]
Set the correct height by adjusting the lower
plastic wing nut and raise the support to the
prefered position.
If necessary, turn the mouthpiece or the neck
into the preferable playing position.
Now you are ready to play!
