SERVER STORAGE DATA SHEET
The first-to-market Adaptec 29320LPE, PCI
Express (PCIe), single-channel Ultra320
SCSI HBA is a host bus adapter (HBA) card
ideal for attaching tape drives, tape libraries,
disk drives, JBODs, RAID arrays, and other
SCSI peripherals to workstations and
servers supporting the PCIe bus
architecture.
With support for PCIe x1, x4, x8, and x16
slots, the Adaptec 29320LPE provides
incredible compatibility with PCIe
workstations and servers. And through its
seamless backward compatibility with all
previous SCSI generations, the Adaptec
29320LPE protects your investment in
existing hardware, while delivering support
for the industry’s latest host connection.
The Adaptec 29320LPE is a low-profile card
ideal for rack-mount servers. It also has a
68-pin internal connector and a 68-pin
VHDCI external connector enabling
complete flexibility in configuration
options.
Adaptec Speedflex™
Exclusive Adaptec SpeedFlex (AIC-3860)
technology ensures that all devices
connected to an Ultra320 SCSI card will
deliver top performance, regardless of SCSI
generation. Your legacy technology
investments are protected, and the risks of
migrating to Ultra320 are eliminated. With
Ultra320, your devices can keep pace with
the ever-changing requirements of today ’ s
and tomorrow’s technologies.
Wide Range of OS and System
Support
The Adaptec 29320LPE supports 32-bit and
64-bit versions of Microsoft Windows,
Linux, NetWare, Solaris, SCO as well as the
x86, AMD64 and EM64T system
architectures with PCIe host connections.
With this broad base of OS and system
support, the Adaptec 29320LPE is the ideal
choice for attaching the most powerful SCSI
peripherals to your workstation or server.
Compatibility, Reliability, and Support
Adaptec has been delivering storage and I/O
solutions to the industry for more than 24
years. In fact, Adaptec is the undisputed
HBA leader, and no other vendor’s
technology is more proven. The Adaptec
29320LPE has been extensively tested with
third-party components to deliver the
utmost in compatibility. The cards are
backed by a 3-year warranty and legendary
Adaptec technical support.
Adaptec® SCSI Card 29320LPE
Product Highlights
PCI Express x1 host connectivity
Ultra320 SCSI single channel
Driver support for Windows®,
Linux, Novell NetWare®, Solaris
and SCO
Top performance with Adaptec
Speedflex™
Supports up to 15 SCSI bus IDs
Up to 12 meter cable lengths
RoHS compliant
Compatibility with SCSI and tape
hard drives
Low profile
Automatic termination
PCI Express x1, Single-Channel, Ultra320 SCSI
Host Adapter

Copyright 2007 Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, Snap Appliance, the Snap Appliance logo, Snap Server, Snap Disk, GuardianOS, SnapOS, and Snap Server Storage Manager are trademarks of Adaptec, Inc.,
which may be registered in some jurisdictions. Microsoft and Windows are registered trademarks of Microsoft Corporation, used under license. All other trademarks used are owned by their respective owners.
Information supplied by Adaptec, Inc., is believed to be accurate and reliable at the time of printing, but Adaptec, Inc., assumes no responsibility for any errors that may appear in this document. Adaptec, Inc., reserves the right, with-
out notice, to make changes in product design or specifcations. Information is subject to change without notice.
P/N: 987002-011 Printed in U.S.A. 02/07 4656_1.3
Adaptec SCSI Card 29320LPE
SERVER STORAGE DATA SHEET
Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, California 95035
Tel: [phone]
Fax: [phone]
Literature Requests:
US and Canada: 1 [phone] or [phone]
World Wide Web: http://www.adaptec.com
Pre-Sales Support: US and Canada: 1 [phone] or [phone]
Pre-Sales Support: Europe: Tel: [phone] or Fax: [phone]
Adaptec SCSI Card 29320LPE
Why to Buy? Industry’s first PCIe x1 Ultra320 SCSI controller that is ideal as a SCSI disk drive and SCSI tape drive connection
solution with unparalleled PCIe connectivity and industry standard compatibility.
Customer Needs Connect SCSI devices to a workstation or server with PCIe slots
System Environment x86, AMD64 and EM64T system architectures with PCIe host connections
Features
•PCIe x1 host connectivity
•Ultra320 SCSI single channel
•Adaptec Speedflex™
•Supports up to 15 SCSI bus IDs
•Up to 12 meter cable lengths
•RoHS compliant
Management Utilities •Adaptec BIOS Configuration Utility
Operating System
•Windows 2000, XP, Server 2003
•Linux
•Novell NetWare 6.5
•SCO OpenServer, UnixWare
•Sun Solaris 10 x86
Physical Dimensions 6.60” H x 2.54” L (168mm x 65mm)
Operating Temperature (incl. battery) 0°C to 55°C
Operating Voltage 12V+/-9%, 3.3V+/-9%
Regulatory Certification FCC, C-tick, CE, VCCI
Warranty 3 years
Package Contents
•Adaptec 29320LPE Controller with standard bracket
•Replacement low-profile bracket
•6-position SCSI cable (kits only)
•Quick Install Guide
•CD with drivers and documentation
Adaptec SCSI Card 29320LPE
Ordering Part Number: 2248700-R (Sgl)/2250300-R (Kit)
