SECTION SCP-FLC706-011-03H
Model List CLEI Code
FLC-706 1A VACHEGPC~~
4 CHANNEL ISDN
CENTRAL OFFICE CHANNEL UNIT
FLC 706
PG-FLEX
LIST
FAULT
A
C
T
I
V
E
1
2
3
4

SCP-FLC706-011-03H
January 6, 2003 FLC-706 List 1A
Revision History of This Practice
©Copyright 2003 ADC DSL Systems, Inc. All Rights Reserved.
ADC is a registered trademark of ADC Technologies, Inc. PG-Flex is a registered trademark of ADC DSL Systems, Inc. No right,
license, or interest to such trademarks is granted hereunder, and you agree that you shall assert no such right, license, or interest
with respect to such trademarks. Other product names mentioned in this document are used for identification purposes only and
may be trademarks or registered trademarks of their respective companies.
Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified, used, copied,
reproduced or disclosed in whole or in part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to change specifications at any time without notice.
Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting
from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special,
consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and
after the warranty period.
Revision Release Date Revisions Made
01 July 29, 1999 Initial Release
02 January 24, 2002 Release to rebrand document to comply with ADC standards
03 January 6, 2003 Updated Product Support Information

SCP-FLC706-011-03H Using This Practice
FLC-706 List 1A January 6, 2003
USING THIS PRACTICE
Three types of messages, identified by icons, appear in the text.
INSPECTING YOUR SHIPMENT
Upon receipt of the equipment:
•Unpack each container and visually inspect the contents for signs of damage. If the equipment has been
damaged in transit, immediately report the extent of damage to the transportation company and to ADC.
Order replacement equipment, if necessary.
•Check the packing list to ensure complete and accurate shipment of each listed item. If the shipment is short
or irregular, contact ADC as described in “Returns” on page 8. If you must store the equipment for a
prolonged period, store the equipment in its original container.
Notes indicate information about special circumstances.
Cautions indicate the possibility of equipment damage or the possibility of personal injury.
Electrostatic Discharge (ESD) susceptibility symbols indicate that a device or assembly is
susceptible to damage from electrostatic discharge.You must wear an antistatic wrist strap
connected to the appropriate ground connection prior to performing installation procedures.
You must also observe normal ESD precautions when handling electronic equipment. Do not
hold electronic plugs by their edges. Do not touch components or circuitry.

Inspecting Your Shipment SCP-FLC706-011-03H
January 6, 2003 FLC-706 List 1A

SCP-FLC706-011-03H
FLC-706 List 1A January 6, 2003 i
TABLE OF CONTENTS
Overview ____________________________________________________________________________ 1
Description and Features....................................................................................................................1
Operational Capabilities ......................................................................................................1
Applications.........................................................................................................................2
Front Panel .........................................................................................................................................3
Specifications .....................................................................................................................................4
Installation And Test ___________________________________________________________________ 4
Integration Parameters .......................................................................................................................4
Installing the FLC-706 in the COT Shelf...........................................................................................5
Provisioning the FLC-706 ...................................................................................................5
Verify operation...................................................................................................................5
Outgoing calls......................................................................................................................5
lncoming calls......................................................................................................................6
Troubleshooting _______________________________________________________________________ 7
Product Support ______________________________________________________________________ 8
Technical Support ..............................................................................................................................8
Limited Warranty...............................................................................................................................8
Returns ...............................................................................................................................................8
FCC Class A Compliance ................................................................................................................10
Modifications ...................................................................................................................................10
Acronyms___________________________________________________________________________ 11

SCP-FLC706-011-03H
ii January 6, 2003 FLC-706 List 1A

SCP-FLC706-011-03H
FLC-706 List 1A January 6, 2003 iii
LIST OF FIGURES
1. Typical ISDN Configuration ...........................................................................................................................2
2. FLC-706 ISDN Channel Unit Front Panel ......................................................................................................3

SCP-FLC706-011-03H
iv January 6, 2003 FLC-706 List 1A

SCP-FLC706-011-03H
FLC-706 List 1A January 6, 2003 v
LIST OF TABLES
1. FLC-706 Front Panel LEDs..............................................................................................................................3
2. COT Channel Unit Troubleshooting ................................................................................................................7

SCP-FLC706-011-03H
vi January 6, 2003 FLC-706 List 1A

SCP-FLC706-011-03H Description and Features
FLC-706 List 1A January 6, 2003 1
OVERVIEW
The ADC®PG-Flex®FLC-706 List 1A ISDN Basic Rate Interface Central Office Channel Unit provides an
interface to North American ISDN Basic Access services through a PG-Flex COT shelf. The FLC-706
accommodates four ISDN channels and provides ISDN Line Unit Network Termination (LUNT) at the COT shelf.
The FLC-706 installs into a single slot of a PG-Flex COT shelf.
DESCRIPTION AND FEATURES
The FLC-706 features are:
•four ISDN U-interfaces
•MLT compatible and metallic test access
•Vdc resistive test signature
•mp/pp-eoc slave mode in 3-DS0 format
•segmented path performance monitoring
•interim path performance monitoring
•software provisioning
•loopbacks
•Pair Gain Test Controller (PGTC) compatible
Operational Capabilities
The FLC-706 supports two-wire DSL 2B+D data or subsets of that rate. The B1 and B2 channels carry digitized
voice and data. The D channel communicates control signalling and low-speed, packet-switched data.
Segmented path performance monitoring collects the error rates for each DSL loop individually. Interim path
performance monitoring collects the end-to-end error rate for the entire transport path.
For system isolation and system tests, the FLC-706 provides:
•a hybrid transformer that isolates the equipment from the facility and provides coupling and impedance
matching at 135 Ω
•metallic test access through the FPI-729 PGTC Interface Unit
•MLT compatibility
•a DC resistive test signature of 120 kΩfor out-of-service system tests

Description and Features SCP-FLC706-011-03H
2 January 6, 2003 FLC-706 List 1A
Applications
ISDN is a networking standard that provides end-to-end, simultaneous handling of digitized voice and data traffic
on the same link. Figure 1 shows a typical ISDN configuration. The FLC-706 connects an ISDN Digital
Subscriber Line (DSL) to the Central Office (CO). Line Termination (LT) in the CO occurs at the ISDN switch.
The DSL loops are U-interface. The FRC-756 provides Line Unit Line Termination (LULT) at the RT. The
subscriber site has the Network Termination (NT1).
Figure 1. Typical ISDN Configuration
Set all options for the FLC-706 through the PG-Flex COLU or PGTC unit RS-232 maintenance port. Disable
ISDN by means of the maintenance port to prevent time slots from being assigned when they are not in use. The
FLC-706 must be plugged into a COT shelf before any ISDN provisioning screens can be displayed.
To provide clocking to the FLC-706, ensure the following conditions exist:
•a composite clock on the PG-Flex COT shelf is connected and correctly terminated
•an FPI-729 or an FAU-728 List 2 card is installed
DSL
Loop
HDSL
Facility
DSL Loop
<18kft to 1300
ISDN
Switch PG-Flex PG-Flex
COT RT
L
TNT1
L
U
N
T
L
U
L
T

SCP-FLC706-011-03H Front Panel
FLC-706 List 1A January 6, 2003 3
FRONT PANEL
The front panel LEDs indicate the state of the FLC-706 (see Figure 2).
Figure 2. FLC-706 ISDN Channel Unit Front Panel
Each LED for the four channels has the same states and indications.
Table 1. FLC-706 Front Panel LEDs
LEDs State Indicates
ACTIVE
(1 through 4)
Solid green Channel is in SYNC
Fast-flashing green Channel is attempting to SYNC
Slow-flashing green Channel is in a maintenance state which is either loopback or
subscriber circuit testing
FAULT Solid red A fault has been detected on the unit during powerup
Off No faults have been detected on the unit during powerup
FLC 706
PG-FLEX
LIST
FAULT
A
C
T
I
V
E
1
2
3
4
Status LEDs
Retaining Latch

Specifications SCP-FLC706-011-03H
4 January 6, 2003 FLC-706 List 1A
SPECIFICATIONS
INSTALLATION AND TEST
INTEGRATION PARAMETERS
Install the FLC-706 into PG-Flex systems with:
•List 3 or higher PG-Flex CO Line Unit
•List 3 or higher PG-Flex RT Line Unit
•an FPI-729 or FAU-728 List 2 card (used for clocking) in the COT shelf
Transmission
Code 2B1Q, 2 binary, one quaternary, at 160 kbps
Network Interface 3DS0 format
Basic Rate Interface 2B+D; 2 B channels at 64 kbps, one D channel at 16 kbps
dc Resistive Test Signature 120 kΩ
Terminal Impedance 135 Ω
Environmental
Temperature Range -40º F to +150º F (-40º C to +65º C)
Altitude -200 ft. to 13,000 ft. (-60 m to 4,000 m)
Dimensions
Height 6.75 in. (17.1 cm.)
Depth 10.5 in. (26.7 cm.)
Width 1.0 in. (2.54 cm.)
Weight 0.8 lb. (0.4 kg.)
Standards
ANSI T1.601-1992 Layer 1
TR-NWT-000397 ISDN Basic Access Transport System Requirements
TR-NWT-000393 ISDN Basic Access Digital Subscriber Lines
TR-TSY-000829 Embedded Operations Channels
Observe normal ESD precautions when handling electronic equipment. Do not hold electronic plug-ins by
their edge. Take care not to touch components or circuitry.

SCP-FLC706-011-03H Installing the FLC-706 in the COT Shelf
FLC-706 List 1A January 6, 2003 5
INSTALLING THE FLC-706 IN THE COT SHELF
Insert the FLC-706 into the COT shelf. Ensure the LEDs go through the following sequencing:
•turn ON for about 2 seconds
•turn OFF for about 2 seconds
•scan ON from top to bottom
•turn OFF
If the LEDs do not follow the above sequence, see Table 2 on page 7.
Provisioning the FLC-706
Provision the FLC-706 using a List 3 or higher COLU practice. Access the ISDN Channel Setup menu and select
the appropriate options.
Verify operation
Verify incoming and outgoing calls for both B channels, where B1 is the digitized voice channel and B2 is the
data channel:
Outgoing calls
Verify outgoing calls for both B channels, for example, calls from the NT1 to the LT (refer to Figure 1 on page 2):
1Originate an outgoing B1 voice call and make sure that:
adial tone is present
bthe number you called is displayed (when answered)
the number from which you called is displayed as the originating number
2Hold up the B1 voice circuit, then switch to the B2 data circuit.
3Originate an outgoing B2 data call to the data loopback (LPBK) test line and perform the BER test (after the
data call is established).
4After the B2 data test is completed, drop the B2 data line, then drop the B1 voice line.
5Return all circuits to normal.
When verifying the B1 and B2 channels, only the B channel used for digitized voice has dial tone. The data
channel does not have dial tone.
To verify the operation steps, use a Tektronix Craftec CT-100 ISDN type test set (or equivalent) that can
generate a PRBS/2047 pattern to perform a data Bit Error Rate Test (BERT) when the circuit connects
to the far end. This is the most stressful pattern for ISDN circuits. A test result that does not exceed 10-7
BER must be demonstrated.

Installing the FLC-706 in the COT Shelf SCP-FLC706-011-03H
6 January 6, 2003 FLC-706 List 1A
lncoming calls
Verify incoming calls for both B channels, for example, calls from the LT to the NT1 (refer to Figure 1 on page 2):
1To test an incoming B1 voice call:
adraw dial tone from another ISDN or POTS circuit
bdial the ISDN B1 voice circuit number
cverify that the number you called is displayed (when answered)
verify that the number from which you called is displayed as the originating number
2Hold up the B1 voice circuit, then switch to the B2 data circuit.
3Originate an outgoing call on the B2 data circuit using another ISDN data circuit and call the B2 data circuit
under test. Then, perform the BER test.
4Drop the B2 data line after the B2 test is completed. Then drop the B1 voice line.
5Return all circuits to normal.

SCP-FLC706-011-03H Installing the FLC-706 in the COT Shelf
FLC-706 List 1A January 6, 2003 7
TROUBLESHOOTING
Table 2 provides troubleshooting procedures using the front panel LEDs and customer reports. The FLC-706
supports CO initiated loopbacks.
Table 2. COT Channel Unit Troubleshooting
LEDs State Indicates Action
FAULT On Fault detected in the PG-Flex
system
Replace channel unit.
FAULT +
ACTIVE 1
On Internal fault on the FLC-706 Replace channel unit.
FAULT +
ACTIVE 2
On Internal fault on the FLC-706 Replace channel unit.
FAULT +
ACTIVE 3
On Internal fault on the FLC-706 Replace channel unit.
FAULT +
ACTIVE 4
On Internal fault on the FLC-706 Replace channel unit.
ACTIVE Slow-Flash Circuit is in either Loopback
or PGTC test setup state
Access the circuit by means of the PG-Flex Line Unit
maintenance port and release the circuit or wait for the test
originator to complete testing.
ACTIVE Fast-Flash ISDN circuit lost sync Check loop or for NT1 removal by customer.
Problem Reported Condition Action
Customer reports no dial tone Off-hook not extended to CO Check status LEDs. Clear any indicated trouble. Use
PG-Flex Line Unit maintenance port as required.
Customer reports data
transmission errors
Customer experiencing
errors
Perform Step 3 on page 6. Check performance monitoring
record.
Technician establishes loopback Loopback customer circuit at
various points
Use loopback portion of PG-Flex Line Unit maintenance
port to select and activate loopbacks.

Technical Support SCP-FLC706-011-03H
8 January 6, 2003 FLC-706 List 1A
PRODUCT SUPPORT
TECHNICAL SUPPORT
Technical Assistance is available 24 hours a day, 7 days a week by the contacting Customer Service Engineering
group at:
LIMITED WARRANTY
Product warranty is determined by your service agreement. Refer to the ADC Warranty/Software Handbook for
additional information, or contact your sales representative or Customer Service for details.
RETURNS
To return equipment to ADC:
1Locate the number of the purchase order under which the equipment was purchased. To obtain a return
authorization number, you need to provide the original purchase order number to ADC’s Return Material
Authorization (RMA) Department.
2Call or write ADC’s RMA Department to ask for an RMA number and any additional instructions. Use the
telephone number, fax number or email address listed below:
•Telephone: [phone]
•Email Address: [email protected]
3Include the following information, in writing, along with the equipment you are returning:
•Company name and address.
•Contact name and telephone number.
•The shipping address to which ADC should return the repaired equipment.
•The original purchase order number.
•A description of the equipment that includes the model and part number of each unit being returned, as
well as the number of units that you are returning.
•The reason for the return. For example:
–The equipment needs an ECO/ECN upgrade.
–The equipment is defective.
Telephone: [phone]
The 800 telephone support line is toll-free in the U.S. and Canada.
Email: [email protected]
Knowledge
Base:
http://adc.com/Knowledge_Base/index.jsp
Web: www.adc.com

SCP-FLC706-011-03H Returns
FLC-706 List 1A January 6, 2003 9
If there is another reason for returning the equipment, please let us know so we can determine how
best to help you.
4Pack the equipment in a shipping carton.
5Write ADC’s address and the RMA Number you received from the RMA Department clearly on the outside
of the carton and return to:
ADC DSL Systems, Inc.
14352 Franklin Ave.
Tustin, CA 92780-7013
Attention: RMA (Number)
If the equipment is defective, please tell us what you observed just before the equipment
malfunctioned. Be as detailed in your description as possible.
All shipments are to be returned prepaid. ADC will not accept any collect shipments.

FCC Class A Compliance SCP-FLC706-011-03H
10 January 6, 2003 FLC-706 List 1A
FCC CLASS A COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the use will be required to correct the interference at his own expense.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are not
expressly approved by ADC Technologies, Inc. voids the user's warranty.
All wiring external to the product(s) should follow the provisions of the current edition of the National Electrical
Code.
