User Guide
1:1 HDD Duplicator PRO
(HDUSI325)
T E C H N O L O G I E S
www.addonics.com
Duplicator Panel
Source Drive Bay
Target Drive Bay
Power Switch

Table Of Contents
Basic Instructions
Functions
Copy HDD
Compare HDD
PreScan Source
ReScan Bus
Source Size
Overwrite
Setup
USB Mode
Advanced Setup
Basic Troubleshooting
Error Messages List
Firmware Update Procedure
............. Page 3
............. Page 5
............. Page 6
............. Page 6
............. Page 7
............. Page 7
............. Page 8
............. Page 8
............. Page 8
............. Page 11
............. Page 11
............. Page 15
............. Page 16
............. Page 17

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/
I. Installing drive into the HDD Duplicator
Note: Make sure that the capacity of the target hard disk is equal
or larger than the source hard disk.
For example, on the label of the hard drives, it might identify both
drives as 80GB but the actual size differs. And when this type of
drives are used on the HDD duplicator, when you start
duplicating, you will receive a “Target Not Ready” error. To
resolve this issue, you need to decrease the drive size of the
source drive. To do this, navigate to: 6.Setup > 6.2Copy Size and
use the button arrows to decrease the drive size of the source
drive by increments of 1%.
For installing ahard drive on the various enclosures that
come with the HDD duplicator, refer to the bundled
enclosure installation guides.
Step 1
Once the hard drive is installed on the drive enclosure, slide in
theSource drive into the drive bay. Push down the handle and
using the key provided, turn the key lock to the Lock position.
This will secure the drive and turn on the power to the hard drive.
Step 2
Slide in the Target drive into the drive bay. Push down the
handle and using the key provided, turn the key lock to the Lock
position. This will secure the drive and turn on the power to the
hard drive.
II. Connecting the power cable and poweringon
a. Connect the power cord provided from the wall outlet to the
back of the tower.
b. A main power switch is located at the back of the tower. Turn
the switch on. Another auxiliary switch is located on the front
of the tower.
c. Push the auxiliary switch button to turn on the HDD
duplicator.
Basic Instructions

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/
III. The Duplicator Panel
There are four buttons and an LCD on the panel of HDD
Duplicator.
1 – LCD shows a function or a message.
2 – it is used to scroll up function menus.
3 – it is used to scroll down function menus.
4 – it is used to execute a function.
5 – it is used to cancel a function.
IV. Duplicating a drive
When the duplicator powers on, it initializes and goes through the
steps below
Shows the firmware version Initialize SDRAM's status..
Detect Drives' status. Shows the first function:
Copy HDD copies data directly from the source hard disk to the
target hard disk.
Press ENT button to begin copy. The system will auto-detect the
hard disks and show the following info on the LCD.
The LCD will show the following info during the copying process:
remaining time, completed percentage. The copy speed, capacity
and time will vary depending on the source hard disk. Once the
copying process is complete the LCD will display the following
results.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/
Functions
The copy controller has 8 functions in total, with the th (Adv Setup) being a hidden system
function that onlyappears when the ESC key is pressed for 2 seconds untilthere is a beep.These
are shown below.
8-01. Language
8-03. Startup Menu
8-04.Auto Compare
8-05. Copy With Size
8-06. Button Sound
8-07. Device Info
8-08. System Info
8. Setup
8-02. Copy Size
10.AdvSetup
10-01. Detect HDD Delay
10-02. Read Error Skip
10-03. Update Firmware
10-04. Compare Firmware
10-05. Quick Erase HDD
10-06.H/W Diagnostic
10-07.Load Default
10-08.Link Option
10-09.USBAuto-Link
10-10.Copy HPA
Duplicator Controller
1. Copy HDD
2. Compare HDD
3. PreScan Source
4. ReScan BUS
5. Source Size
6. Secure Erase
7. Overwrite
8. Setup
9. USB Mode
10.AdvSetup
8-09. Fast Copy

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/
CopyHDD
Copy HDD copies data directly from the source hard disk to the target hard disk. Please make
sure that the capacity of the target hard disk is equal or larger than the source hard disk.
Choose option 1 from the menu:
Press ENT to begin copy. The system will auto-detect the hard disks and show the following
copyinginfo on the LCD.
The LCD will show the following info during the copying process: elapsed time, completed
percentage. The copyspeed, capacity and time willvary depending on the source hard disk. Once
the copyingprocess is complete the LCD willdisplaythe following results.
Copy-36MB/s 0%
232.9GB 00:00:00
Copy HDD
OK: 1 Fail: 0
1. Copy HDD
HDD:1 232.9GB
Compare
Compare HDDisused to seeif the dataon a sourcehard disk is identical to the target hard disk
after the Copy HDoperation.
Choose option 2 from the menu:
2. Compare HDD
HDD: 1 232.9GB
Press ENT to begin the comparison. The LCD will display the following info.
Comp-23MB/s 0%
232.9GB 00:00:00
Once the comparison is complete the LCD will display the following info as well asthe amount of
data on the source harddisk.
Compare OK:1
Fail: 0 Di: 0

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/
PreScan Source
PreScan HDD is used to check if the source hard disk can be accessed properly.
It also tests the read speed.
Choose option 3 from the menu:
3. PreScan Source
HDD : 1 232.9GB
Press ENTto begin scan. The LCD will display the following info
Scan-90MB/s 1%
230.6GB 00:00:27
Once the scan is complete, the LCD will display the corresponding results
PreScan OK!
4. ReScan BUS
ReScanBus
Chooseoption 4from themenu:
Press ENT to re-scan hardware. The LCD will displaythe following info.
Re-Scan BUS NOW?
Yes
When the scan is completethe LCD will display the following info.
Bus re- scan OK!
ReScan Bus allows swapping the source or target in and out without having to
reboot the system.

8.Setup
Setup
Setup allows various system settings to be changed. There are 12 sub-options:
Language, Copy Size, Startup Menu, Auto Compare, Button Sound, Device Info,
System Info, Fast Copy, Auto Start Drive, Auto Start Timer, Tolerance Size and
Boot Time Delay.
Choose option 8 from the menu:
InProcess
Elapsed 01:00
7. Overwrite
Overwrite
Overwrite is used to overwrite the data of the hard disk, it will erase all HDDs connected to the duplicator
(including Source HDD). There are 3 sub-options: One pass,3 pass and 7 pass.
Choose option 7 from the menu:
Press ENT to access option. Bydefault it is One pass Use the Up and Down arrowkeys to choose
otheroptions.
7-01. Overwrite
One pass
Press ENT to access option. Bydefault it is set to No. Use the Up and Down arrowkeys to choose
Yes.
Wipe all data.
Continue? No
Press ENT and theLCD will show the following info.
In Process
Elapsed 01:00
Language
This option is used to select the system's language support. By default this is set to English. Press
ENT to change the Language settings.
Language
English
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

8-02.Setup
CopySize
Press ENT and the LCD will displaya detailed list of optionsasshownbelow
Use the Up and Down arrow keys to choose dierent copy sizes. The system will oer their
corresponding percentages so the user can specify the amount to copy from the source hard disk.
Press ENT to conrm and save the changes.
Copy Size
100%~1% (*MB)
Startup Menu
This option allows you to set an option other than "Se tup" to be displayed as the rst available
option on the menu every time you start the system.
Startup Menu
1. Copy HDD
Press ENT then use the Up and Down arrow keys to choose other options. By default the rst
menu option is Copy HDD.
8-03.Setup
Startup Menu
Auto Compare
This option automaticallycompares the source hard disk with the target hard disk after a copy
operation is completed.
Press ENT to access option. Bydefault it isset to O. Use the Up andDown arrow keys to choose
On.
Auto Compare
O
8-04.Setup
Auto Compare
CopySize
This option is used to specifythe size of thesource harddisk forsimplifyingfurthercopying
operations.
CopyWithSize
This option is used toset the source hard disk withthe target hard disk the same capacityafter a
copyoperation.
8-05.Setup
Copy With Size
Press ENT to enter the following gure. The default is O. Use the Up and Down arrow keysto
choose On.
Copy with Size
O
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

Device Info
This option is used to display the detailsof all hard disks connected to the copy controller.
8-07.Setup
Device Info
Press ENT and the LCD will displayeach hard disk' information in order as shown below.
0 Source CH: 0
Hitachi 232.9GB
System Info
This optiondisplays system information.
8-08.Setup
System Info
Fast Copy
This option displays Fast Copy. Fast Copy only copies data on the source drive
to the target drives. Currently only supports FAT, FAT32, NTFS, HFS, Ext2 and
Ext3 partitions. 8-09. Setup
Fast Copy
Press ENT and the LCD will display the following info. Use the Up and Down arrowkeys to choose
whether fast copy is on or o. (Thisfunction currently only eective in FAT, FAT32, NTFS, HFS,
Ext2 and Ext3 partitions.)
FastCopy
On
USB Mode
Not Available
Button Sound
This option isused to controlthe sound of a button when you press it.
8-06.Setup
Button Sound
Press ENT and the LCD will display the following info. Use the Up and Down arrow keys to choose
whether button sound is on or o.
ButtonSound
On
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

AdvSetup
Adv Setup oers expert users access to more advanced system settings.
To access this option, hold down the ESC key for two seconds until it appears.
10.Adv Setup
Detect HDD Delay
This function is used to set the time interval betweenthe system'sre-scansof all connectedHDD
devices.
Press ENT and the LCD willshowthe following info.
10-01.AdvSetup
Detect HDD Delay
Detect HDD Delay
1Sec
Press ENT then use the Up and Down buttons to choose dierent time settings (1~60 sec)
Read Error Skip
This function sets the system to ignore anyerrors during the copying process. Normally if there is
an error during copying a warning is displayed on theLCD. By using this function, users can also
copy a HDD with errors.
10-02.AdvSetup
Read Error Skip
Read Error Skip
O
Press ENT to enter the following screen. By default this option is set to OFF. Use the up and down
buttons to enable or disable this option.
Update Firmware
This function is used to update the system's rmware. Download the latest version of the rmware
from the Internet at www.addonics.com. For the complete instructions, visit the rmware update
webpage or view the instructions found later in this manual.
10-03.Adv Setup
Update Firmware
Compare Firmware
This function is used to comparethe current system rmware version with the newversionthe user
is upgrading to.This ensures that the downloaded rmware is the latest version.Themessage
"Last update F/W" indicates that it is the latest version.
11-04.Adv Setup
Compare Firmware SearchingF/W ... Please Wait ... Last update F/W
OK!
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

All data will be
lost,Erase? No
Press ENT again and the LCD willprompt you to conrm the erase operation.
Test IDE 0/1
OK
LCD Test Start ButtonTest ?SDRAM Test:
8192Kbytes OK
FlashTest: OK Testnished
Once the system diagnostics have been completed the "Test finished" message will appear on the
LCD.
Press ENT and the system will begin the tests as shown below.
H/W Diagnostic
Press ENT to enter the following screen. This function is used to checkthat the system is
operatingnormally.
11-06.AdvSetup
H/W Diagnostic
Press ENT again to enter the following screen.The LCD will cycle through the test categories as
they are performed.The LCD display istested rst, the control panel is tested next (requires
manual operation), then followed by the system's internal diagnostics, hardware connection test
then the RAM and SD Flash test.All test results are shown on the LCD. This is a simple way to
verifythat the system is operating normally.
Quick Erase HDD
This function is used to quickly erase all data on the HDD. Please backup anyimportant data
before using this function.
10-05.Adv Setup
Quick Erase HDD
Quick Erase HDD
ALL/Target CH:*
Press ENT to enter the following screen. Use the Up and Down buttons to select theHDD to
erase.
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

5. Source Size
Source Size
Source Size is used to show the capacity of the source.
Choose option 5 from the menu:
Press ENT andthe LCD will show the following info.
HDD:Hitachi
Size:232.9GB
Then press ENT and the LCD will show the data's size info.
HDD:Hitachi
Data:200.9GB
6. Secure Erase
Secure Erase
Secure Erase is used to wipe the data of the hard disk, it will erase all of HDD of duplicator
(included Source HDD).
Choose option 6 from the menu:
Press ENT to access option. By default it is set to No. Use the Up and Down arrow keys to choose
Yes.
Wipe all data.
Continue? No
Press ENT andthe LCD will show the following info.
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

Press ENT to enter the followingscreen. Use the Up and Down bu
defaults.
Load Default
Load Default
Ok
If Load Default OK, this will be displayed on the LCD as shown below.
Load Default
Press ESC to return to the main menu then use the ENT button to select. This function resets all
settings to their factory default. This function helps the system recover from errors caused by an
illegal operation.
10-07.Adv Setup
Load Default
CopyHPA
If this function is set to "ON", the system will completely copythe data in a source HDD's host
protected area.
10-10.AdvSetup
CopyHPA
The default is "OFF". Use the ENT , Up and Down buttons to change this to "On".
USBAuto-Link
NOT AVAILABLE
Link Option
NOT AVAILABLE
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

Basic Troubleshooting
LCD
If the LCD blank afterthedevice is turned on, check that the power cable is properly connected
and that the power supply is on.
Error Message
When the system is running a copyoperation or hardwarediagnostics, if the operation is manually
terminated by pressing ESC an error message will be shown by the LCD. This may lead to an
illegal operation and cause the device to stop reminding. If this happens, the device must be
restarted.
Hard Disk
If unable to read the hard disk please check that the data and powercables are properly
connected.
Keys
If pressing the keys on the front panel produces no response from the system, the keys may have
malfunctioned. Please check the control panel to see if the wiring has come loose.
Firmware Upgrade
may cause the duplicator to become inoperable. If the system is working normally, do not attempt
this operation. If the system is already experiencing problems, please contact yourdistributorfor
repairs.
Startup/Shutdown
down normally, wait a moment (usuallyaround 2 seconds) before starting the system again so it
can run its self-diagnostics.
About CopyHPA
usually accessible to software. The SATAHDD Duplicate Controller supports the copying of data
from this hidden area.
Drive is locked (cannot be initialized after the SECURE ERASE or OVERWRITE)
1. Place drive in the source slot
2. Execute "PreScan" function for 1 minute
3. Press "ESC" key until you see "User Abort" on the LCD screen
4. Now remove the drive from the duplicator and connect it to your system, the HDD should be
recognized and be able to initialize again
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

ErrorMessagesList
NO# Error Messages Description Applied to
1 Source Drive Not Exist! duringoperating Copy,Async Copy, Compare,
Async Compare, PreScan
Source, Source Size, Copy
Size,Tolerance Size
2 UserAbort! Canceloperating
3 No Drive Exist operating Device Info
4 X Space Not Enough
Target Drive Space Not
Enough
When source capacity is
small than target Copy, Compare
5 X Space Not Enough
Target Drive Fail! When source capacity is small than target AsyncCopy,Async Compare
6 PreScan Fail during copy or bad sector
on HDD
PreScan Source
7 Source Drive Read Fail! connection on source port
during copy or bad sector
on source HDD
Copy,Async Copy, Compare
8 Target Drive Write Fail! connection on target port
duringcopy
Copy
9 Target Drive Read Fail! connection on target port
duringcomparing
Compare
10 Target Drive Fail connection on target port
duringasynccomparing
AsyncCopy,Async Compare
11 Target Drive Not Exist! operating Overwrite
12 One pass
One pass failed Lose SATAconnection on SATAportduring Overwrite Overwrite
13 3 pass
pass 1 failed Lose SATAconnection on SATAportduring Overwrite Overwrite
14 7 pass 5220.22-M
pass 1 failed Lose SATAconnection on SATAportduring Overwrite Overwrite
If you hear the warning signalwhile the copying function is executing (a beep every 5 seconds),
the LCD screen will displaythe problem status; you maypress any button to return to the copy
progress screen.
Lose target SATA
Lose target SATA
Lose target SATA
Lose target SATA
Lose SATAconnection
No HDD exist during
Any function and anytime
No source HDD exist
No HDD exist during
www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: [phone] Email: www.addonics.com/support/query/

www.addonics.com
Phone: [phone]
Fax: [phone]
Email: http://www.addonics.com/sales/query/
CONTACT US
FirmwareUpdateProcedure
(Requires one hard drive containing the rmware le):
1. Create a 50MB HDD partition with FAT/FAT32 or NTFS les system on any SATA hard drive
2. Download the rmware and unzip the le to .BIN le format
3. Copy the .BIN le onto the 50 MB partition of the HDD
4. Insert this drive to the Source slot of the duplicator. For subsystem, connect the drive to the
Source SATA port
5. Select "Firmware Update" function under the "Setup" or "Advanced Setup" menu and press
ENT to do the update. To access the "Advanced Setup", hold onto the ESC button for 5 seconds.
The new option will appear
6. Once completed, it will reboot and show you the new rmware versioQ


1RWHV
SECURE ERASE - HDD duplicator sends a WIPE
command to the hard drive. This command lls 00 string to entire HDD
OVERWRITE - There are three options: One pass, 3 passes and 7 passes 5220.22-M. The duplicator
writes a string of pattern over the entire disk one time, three times or seven times. (5220.22-M is
the DoD standard for drive sanitization)
Please note that some drives may become locked and cannot be initialized after the SECURE ERASE
or OVERWRITE. Should this happen, use the following procedures to unlock the drive:
1. Place drive in the source slot
2. Execute "PreScan" function for 1 minute
3. Press "ESC" key until you see "User Abort" on the LCD screen
4. Now remove the drive from the duplicator and connect it to your system, the HDD should be
recognized and be able to initialize again
