Addonics Technologies UDFH15-C User manual

Compact USB Duplicator controller user manual
Page 1 of 17
I. INTRODUCTION............................................................................................................ 3
1. Features............................................................................................................................................................. 3
2. Control Panel Overview................................................................................................................................. 4
3. Specifications.................................................................................................................................................. 5
II. WARNING ..................................................................................................................... 5
III. SYNCHRONOUS /ASYNCHRONOUS MODE .............................................................. 6
1. Synchronous Mode.......................................................................................................................................... 6
2. Asynchronous Mode ....................................................................................................................................... 6
IV. MENU OVERVIEW........................................................................................................ 8
1. Copy ................................................................................................................................................................... 8
2. Compare............................................................................................................................................................ 8
3. Copy + Compare.............................................................................................................................................. 8
4. Capacity Check................................................................................................................................................ 9
5. Utility.................................................................................................................................................................. 9
5.1. Format FAT32................................................................................................................................................... 9
5.2. Format exFAT................................................................................................................................................... 9
5.3. Measure Speed ............................................................................................................................................. 10
5.4. Quick Erase.................................................................................................................................................... 10
5.5. Full Erase........................................................................................................................................................ 10
5.6. DoD Erase ...................................................................................................................................................... 10
5.7. Change Disk Signatures............................................................................................................................. 11
5.8. Media Information......................................................................................................................................... 11
5.9. Device Model................................................................................................................................................. 11
5.10. System Information................................................................................................................................. 11
5.11. System Update.......................................................................................................................................... 12
6. Setup.................................................................................................................................................................12
6.1. Copy Area....................................................................................................................................................... 12
6.2. Asynchronous Mode .................................................................................................................................... 13
6.3. Smaller Target ............................................................................................................................................... 13
6.4. Unknown Format .......................................................................................................................................... 13
6.5. Check Before Copy...................................................................................................................................... 14
6.6. Set Slow Out Threshold.............................................................................................................................. 14
6.7. Display Mode................................................................................................................................................. 15
6.8. Start-up Menu ................................................................................................................................................ 15
6.9. Button Beep................................................................................................................................................... 16
6.10. Show Result Time .................................................................................................................................... 16
6.11. Boot Password......................................................................................................................................... 16
6.12. Setup Password....................................................................................................................................... 16

Compact USB Duplicator controller user manual
Page 2 of 17
6.13. Language.................................................................................................................................................... 17
6.14. Clear Setup ................................................................................................................................................ 17
6.15. Performance ............................................................................................................................................. 17

Compact USB Duplicator controller user manual
Page 3 of 17
I. Introduction
This duplicator controller is designed to process each channel with its own control unit. As a
result, the copying speed does not degrade with increasing number of targets loaded. The
controller supports fast copy with multiple file formats created by three major operating
systems (Windows/Linux/MAC), and makes mirror copies of data efficiently. Furthermore,
this duplicator has been fully tested with quality assurance before leaving our manufacturing
facility.
1. Features
a. Each processing channel has its own control unit and operates independently with
dedicated bandwidth of up to 35MBper second.
b. Standalone operation. No PC or software is required, minimizing possible computer
virus infection.
c. Instant power on and off, no warm-up or cool-down required.
d. Easy-to-use One-Touch copy operation.
e. Compare function available for verification of copy accuracy
f. Menu options are user-friendly and easily accessed through the 4-button control panel.
Use ▲or ▼ button to scroll through the options and view the operation status of each
channel on the 2-line backlit LCD display.
g. Support Synchronous and Asynchronous copy modes for best operation efficiency.
h. Powerful 32-bit CRC checksum to assure data integrity.
i. Unique source data analysis to copy data area only to achieve highest efficiency
j. Supports multiple file formats: Windows: FAT 16/32、exFAT、NTFS, Linux: Ext 2/3/4,
Mac: HFS/HFS+
k. Not only to do copy, but also test flash media capacity and reading/writing speed.

Compact USB Duplicator controller user manual
Page 4 of 17
2. Control Panel Overview
▲Button: Up, Backward: To navigate backward in the menu.
▼Button: Down, Forward: To navigate forward in the menu.
ENT Button: Enter, OK: Execute the function.
ESC Button: Escape, Cancel: Go back to the previous level in the menu.
▲Button
▼Button
ENT Button
ESC Button
LCD Screen

Compact USB Duplicator controller user manual
Page 5 of 17
3. Specifications
II. Warning
1. The duplicator tasks mentioned in this user’s manual are as following: Copy, Compare,
Copy + Compare, Capacity Check, and the functions under Utility sub menu, such as
Format FAT32, Format exFAT, Quick Erase, Full Erase and DOD Erase.
2. All the tasks can be executed in synchronous mode, and asynchronous mode (except
Copy + Compare function).
3. The Green LED flashes during the execution process of a task. After the task is done, the
Green LED will stay solid if the process is successful, otherwise the Red LED will be on if
the process is failed.
4. Press and hold ESC button during the execution process of a task will stop and exit the
execution of the task.
Operation
Standalone (No PC or Software is required)
Target
6 -118 depending on model
Copy Speed
Maximum 35 MB/s (actual speed depends on the media)
Copy Mode
Synchronous and Asynchronous
Copy Area
Whole Media, File and System(Fast Copy)
Supported
Media
USB 1.0/2.0/3.0/3.1
Supported File
System Format
(for Fast Copy)
Windows：FAT16/32, exFAT, NTFS
Linux：Ext2/3/4
MAC：HFS/HFS+
Display
2-line Backlit Monochrome LCD
Control Button
4 push-button control panel (ENT, ESC, UP, DOWN )
Memory
128MB DDR3

Compact USB Duplicator controller user manual
Page 6 of 17
5. DO NOT unplug USB drive from the duplicator during the execution process of a task. It
may cause damage to the duplicator system and media.
6. It is strongly recommended that the capacities of the source and target media are equal
or similar.
7. It is not recommended to use USB card reader to copy different media on the USB
duplicator, such as CF/SD/MS cards. It may cause damage to the duplicator system and
media.
8. DO NOT plug in USB or flash media until the duplicator boots up. It may cause abnormal
results if a USB or flash media with quality issue is plugged in before or during the boot
up process.
III. Synchronous /Asynchronous Mode
1. Synchronous Mode
Synchronous Mode (default) means that the duplicator will start to execute a task after the
source and target devices have been inserted and the ENT button is pressed. The task will
begin and end at the same timeforalltargetdevices. Any other target device plugged in during
the process of a task will not be executed with the task. Go to section 6.2 Asynchronous
Mode to enable or disable this function.
a. Insert source media into the source channel and blank media into the target channels
properly. The LCD display will show no source disk when source media is not plugged
in yet, and show the number of target media inserted when source media plugged in.
b. The green LED will be on if the target device is plugged in properly.
c. Select the task from menu, and press ENT button to execute it.
d. During the execution process, the status of each target device can be checked by
using the ▲and ▼buttons.
e. After the task is done, LCDdisplay will show the number of successful andfailed target(s),
and execution time. Go to section 6.10 Show Result Time to set up the display of time.
2. Asynchronous Mode
Asynchronous Mode means that the duplicator will read the data from source device into

Compact USB Duplicator controller user manual
Page 7 of 17
system memory buffer and start to execute a task immediately when target device(s)
inserted. Duplicator does not have to wait for all target device(s) inserted in order to
start the execution of the task at the same time. No matter the data size of the source
device, duplicator can asynchronously execute a task if Asynchronous Mode is
enabled. Go to 6.2 Asynchronous Mode to enable or disable this function.
a. Insert source media into the source channel, select the task to execute from the menu,
and press ENT button. Duplicator will start to execute the task now.
b. Target devices can be plugged in during the execution process, and will start to execute the
task immediately
c. Target device can be removed when it finishes the execution process and its green
LED is solid on. New target device can be plugged into the same channel for execution
of the task again.
d. LCD display will show the percentage of execution process, the number of successful and
failed target(s). Here the percentage of execution process displayed is only for the least
processed target device.
e. During the execution process, the status of each target device can be checked by
using the ▲and ▼buttons.
f. After the task is done for all target devices, press ESC button to exit from the task. LCD
display will show the total number of successful and failed target(s), and total execution
time. Go to 6.10 Show Result Time to set up the display of time.
g. Don’t need to wait for all target devices to be done. Each channel executes the task
asynchronously.

Compact USB Duplicator controller user manual
Page 8 of 17
IV. Menu Overview
1. Copy
To copy from source device to target device(s), please go to 6.1 Copy Area to select the
setting first before this step.
No source device Source and target devices inserted Display copy progress
Final result
The process of all tasks are
displayed in the same format
2. Compare
This command allows to compare the copied target devices against the source for
accuracy.
Source and target devices inserted Display compare progress Final result
3. Copy + Compare
This command allows duplicator to start Copy process first, then follow with Compare
process immediately.
Source and target devices inserted Display copy progress Display compare progress
Final result
Result:
Pass：7 Fail：0
Copy：7
7.8G
P：0 F：0 10%
1. Copy
Source Not Ready
1. Copy
Ready device: 7
Copy: 7 number of targets
7.8G: data to be copied
P: number of passed
F: number of failed
10%: rate of progress
ENT
Result:
Pass：6Fail：1
2. Compare
Ready device: 7
COMP：7
7.8G
P：0 F：0
ENT
Result:
Pass：6Fail：1
3. Copy+Compare
Ready device: 7
Copy&：7 7.8G
P：0 F：0 10%
10％
&COMP：7 7.8G
P：0 F：0 10%
10％
ENT

Compact USB Duplicator controller user manual
Page 9 of 17
4. Capacity Check
This command allows to verify the device capacity. It can detect the actual capacity of
devices within 3 seconds.
Source and target devices inserted Display progress status Final result
5. Utility
5.1. Format FAT32
This option allows to format the target device to FAT32 file format. It will not format the
source device, avoiding accidently erasing the original data content. User will be asked if it is
sure to format the target devices before the Format process starts.
Use ▲or ▼ to select option Display progress status
Final Result
5.2. Format exFAT
This option allows to format the target device to exFAT file format. It will not format the
source device, avoiding accidently erasing the original data content. User will be asked if it is
sure to format the target devices before the Format process starts.
Use ▲or ▼to select option Display progress status
Final result
ENT
4. Capacity Check
Ready device: 8
Check：8
P：0 F：0
％
Result:
Pass：8Fail：0
ENT
ENT
Result:
Pass：7Fail：0
Format：7
P：0 F：
0 0%
[Utility]
1. Format FAT32
Sure to format?
Yes
Result:
Pass：7Fail：0
Format：7
P：0 F：0 0%
[Utility]
1. Format exFAT
Sure to format?
Yes

Compact USB Duplicator controller user manual
Page 10 of 17
5.3. Measure Speed
This option allows to measure the actual Read and Write spe ed of the target device. This
option will NOT alter or erase existing data on the target device.
Display read/write speed Use ▲or ▼to select device
5.4. Quick Erase
This option erases the table of content of file system of the target device, so it is fast to do
Quick Erase. There is chance that some files can be retrieved by software.
Use ▲or ▼to select option Display progress status
Final result
5.5. Full Erase
This option completely erases the content of target device. It takes longer time to erase and
the content will not be retrieved by software.
Use ▲or ▼to select option Display progress status
Final result
5.6. DoD Erase
This is to comply with the U.S.A. Department of Defense (DoD 5220) standard to fully erase
themedia by rewriting bitby bitthree times to guarantee the data to be permanently deleted.
It takes the longest time to erase, and the content will not be retrieved by software.
[# 1] Read 20M
1sec Write 16.6M
[Utility]
3. Measure Speed
[# 0] Read 20M
1sec Write 16.5M
ENT
Result:
Pass：7Fail：0
Q_Erase：7
P：0 F：0
[Utility]
4. Quick Erase
Sure to erase?
Yes
ENT
ENT
Result:
Pass：7Fail：0
F_Erase：7
P：0 F：0
[Utility]
5. Full Erase
Sure to erase?
Yes
ENT
ENT

Compact USB Duplicator controller user manual
Page 11 of 17
Use ▲or ▼to select option Display progress status
Final result
5.7. Change Disk Signatures
Duplicator generates the same disk signatures after copy which may cause computer unable
to read the disk correctly when two disks with identical disk signatures are presented, or shut
down the computer. This function allows to change disk signature.
Attention: it will cause error (data mismatch) if compare the disks after execution of
this function.
Display progress status Final result
5.8. Media Information
This option displays the information of selected device media, such as total capacity, file
format and the size of data content.
Use ▲or ▼to select device
5.9. Device Model
This option displays the model information of selected device, such as device model, serial
information and firmware version
Use ▲or ▼to select device
5.10. System Information
This option displays general information of the duplicator, including controller model,
system memory size, firmware version and number of targets.
Result:
Pass：7Fail：0
DoD Erase：7
P：0 F：0
[Utility]
6. DoD Erase
Sure to erase?
Yes
ENT
ENT
Result:
Pass：7Fail：0
[Utility]
7. Change Disk Signatures
D_Signatures: 0
P：0 F：0
ENT
ENT
ENT
Port # Total
Capacity
File Format Data
[Utility]
8. Media Information
[# 0]
60.0G
FAT32
[# 1] P: 1
Model information
[Utility]
9. Device Model
[# 0] P: 0
Model information
ENT
ENT

Compact USB Duplicator controller user manual
Page 12 of 17
Display system information
5.11. System Update
This option allows user to update the firmware of duplicator when necessary. Please obtain
the proper firmware file from manufacturer, and save the unzipped file under home folder on
the flash device (DO NOT save the file under sub folder). Insert the flash device containing
the firmware into the source port of duplicator and press ENT. It will update the system,
reboot the duplicator after update, active and operate under the new firmware.
Looking for firmware
6. Setup
6.1. Copy Area
This option allows to select the area on the source device to copy onto the target devices.
You may select either “System And Files” to skip all the unoccupied area on the source device
or “Whole Media”. By default, the copy area is set up as System And Files.
System And Files
The duplicator first analyzes the file format of source device. You may copy only the system and files
area to save overall copy time if the file format is FAT16, FAT32, exFAT, NTFS (Windows), EXT2,
EXT3, EXT4 (Linux), and HFS/HFS+ (Mac). Otherwise, the duplicator will copy the entire source
device content to the target devices including unoccupied space. For instance, the source device has
8GB capacity but with only 50MB of data in FAT32 file format. The duplicator will copy only the 50MB
of data area to the target device, hence shortening overall copy time.
Whole Media
When selected, the duplicator copies the entire content on the source device, including both the data
and empty spaces. This option is used when you have a source device with unknown file format.
For instance a source device has 8GB capacity and 50MB of data with unknown file format, the
ENT
Controller Model
Memory
[Utility]
10. System Info.
F0107V
128MB
Update BIOS
Complete! Reboot!
[Utility]
11. System Update
Update BIOS
Identify disc…
ENT
ENT

Compact USB Duplicator controller user manual
Page 13 of 17
duplicator will copy the whole 8GB of content to target device.
6.2. Asynchronous Mode
This option allows to enable or disable Asynchronous Mode. By default the
Asynchronous Mode is disabled. Please refer to Chapter III for the detail of
operation on Synchronous and Asynchronous Mode.
Use ▲or ▼ to select
6.3. Smaller Target
If the capacity of the target device is smaller than the source device, the duplicator will
partly copy or cannot copy. Partly Copy is the default setting.
Use ▲or ▼ to select
6.4. Unknown Format
This option allows you to Copy or Skip unknown format. If option Skip is selected here, the
unknown format from source will not be copied during copy process. Copy unknown format
is the default setting.
Use ▲or ▼ to select
[Setup]
2. Asynchronous Mode
[Asynchronous Mode
]
Disable
ENT
[Setup]
3. Smaller Target
[Smaller Target]
Partly Copy
ENT
[Setup]
4. Unknown Format
[Unknown Format]
Copy
ENT
Use▲▼to change option
▼
ENT
Sub menu
Copy Area menu
ENT
Main menu
[Copy Area]
System And Files
7. Setup [Setup]
1. Copy Area
[Copy Area]
Whole Media

Compact USB Duplicator controller user manual
Page 14 of 17
6.5. Check Before Copy
This option allows to check device real capacity before copying. By default this option is
disabled.
Use ▲or ▼ to select
6.6. Set Slow Out Threshold
This function allows to set up read/write speed threshold for target devices. When the target
device is causing the copy or compare process delay due to its lower read/write speed and
the rest of the devices in the same batch have to wait for it, the Slow Out Threshold strategy
will be applied as the following: the system will stop the copy or compare process for that
particular target device when its read/write speed is below the threshold for continuing
number of seconds based on the setting, and its red LED will flash to give warning. There are
3 settings to set up.
Read: set up the lowest read speed，and options are OFF, 1MB/s~25MB/s. The default
setting is OFF.
Write: set up the lowest write speed, and options are OFF, 1MB/s~25MB/s. The default
setting is OFF.
Duration: set up the period when read or write speed is lower than the threshold for
continuing number of time, and options are 1~20second. The default is 5second.
[Setup]
5. Check Before Copy
[Check Before Copy]
Disable
ENT
Use▲▼to change option
ENT
ENT
[Set Slow Out Thresh>]
Read: OFF
6.Setup [Setup]
6. Set Slow Out Thresh>
[Set Slow Out Thresh>]
Duration: 5sec
Setup Complete!
ENT
ENT
[Set Slow Out Thresh>]
Write: OFF
ENT
Use▲▼to change option
Use▲▼to change option

Compact USB Duplicator controller user manual
Page 15 of 17
6.7. Display Mode
There are three display modes: Basic, Show Timer, and Expert. Basic Mode shows the
copy progress in general; Show Timer Mode displays the time used for the task; Expert
Mode shows the devices with highest copy speed and lowest copy speed and their copy
progress respectively. By default it is Basic Mode.
Use ▲or ▼ to select
Basic Mode
Show Timer Mode
Expert Mode
6.8. Start-up Menu
Choose one of the following as the default start-up function: Copy, Compare,
Copy+Compare, Capacity Check, Utility and Setup. The default start-up function is Copy.
Use ▲or ▼ to select
[Setup]
6. Display Mode
[Display Mode]
Basic
ENT
Copy：1 2.5G
P
：
0 F：0 10%
Copy
：
1 number of target
2.5G：data to be copied
P：
number of passed copies
F：number of failed copies
10%：rate of progress
Copy：1 2.5G
03:45 10%
Copy
：
1 number of target
2.5G：data to be copied
03:45 : copy time used
10%：rate of progress
A：10 4 = 2303M
P：0 1 = 2183M
A: 10
：
number of targets in copy process
P: 0：number of targets passed copy
4 = 2303M：
the port with highest copy
speed and data copied so far
1 = 2183M：
the port with lowest copy
speed and data copied so far
[Setup]
7. Start-up Menu
[Start-up Menu]
Copy
ENT

Compact USB Duplicator controller user manual
Page 16 of 17
6.9. Button Beep
This option allows to setup button sound from the following options: Button & Warning,
OFF, Warning only. The default setting is Button & Warning.
Use ▲or ▼ to select
6.10.Show Result Time
This option allows to enable or disable the display of copy time afterfinishing the copy
process. The default setting is disable.
Use ▲or ▼ to select
6.11.Boot Password
This option allows to set up password for system boot up to prevent from the
unauthorized use of the duplicator. The password must be 6 characters.
Use ▲or ▼ to select Use ▲or ▼ to select,
Press ENT to confirm
6.12.Setup Password
This option allows to set up password for Setup function to prevent from the change of
system settings on the duplicator. The password must be 6 characters.
Use ▲or ▼ to select Use ▲or ▼ to select,
Press ENT to confirm
[Setup]
8. Button Beep
[Button Beep]
Button & Warning
ENT
[Setup]
9. Show Result Time
[Show Result Time]
Disable
ENT
ENT
[Setup]
10. Boot Password
Boot Password
Enable
[Boot Password]
===> _ _ _ _ _ _
ENT
[Setup]
11. Setup Password
Setup Password
Enable
[Setup Password]
===> _ _ _ _ _ _
ENT
ENT

Compact USB Duplicator controller user manual
Page 17 of 17
6.13.Language
This option allows to choose the language for display: English, Spanish, Portuguese, and
Japanese. English is the default language.
Use ▲or ▼ to select
6.14.Clear Setup
This option resets the duplicator back to factory default settings.
Use ▲or ▼ to select
6.15.Performance
This option allows to set up the performance for Copy function based on the following modes:
Speed, Balance, and Compatibility. Speed mode is to execute the Copy function at the fastest
speed, but may have compatibility issue with certain brands flash media. Balance mode is to
execute the Copy function at stable speed, and have less compatibility issue with certain
brands flash media. Compatibility mode is to execute the Copy function at the most stable
speed, and almost have no compatible issue with flash media. The default mode is Speed.
Use ▲or ▼ to select
Copyright © 2018. All rights reserved
[Setup]
12. Language
[Language]
English
ENT
[Setup]
13. Clear Setup
Clear Parameter To Default?
Yes
Clear Parameter To Default?
All Parameters were cleared!
ENT
ENT
[Setup]
14. Performance
[Performance]
Speed
ENT
