AddPac AP-IPNext SMT User manual

AddPac Technology OSTS
2010 AddPac, All Right reserved. AddPac Technology and AddPac logo are trademarks of AddPac Technology
intellectual property.
AP-IPNext SMT Manual

Contents
1. Introduction of IP-Next Series
2. Initial Settings
3. User’s Registration
4. Setup for Supplementary Service (IPNext)
5. Setup for Supplementary Service (External Servers)
6. Appendix
A. IPNext HDD setup (Fdisk / format / Raid)
B. IPNext Initialize
C. IPNext Redundant Configuration
AddPac Technology
2

IPNext Exterior (Front View)
AddPac Technology
3
Front View
1) POWER LED
2) LAN 0,1 LED
3) FXO LED
Parts of Rear Side
1) Power Switch
1) Power, 2) FastEthernet(Lan) 3) USB 4) FXO 1
Rear Side
1) FastEthernet(Wan), 2) Console. 3) FXO 0
1) POWER LED, 3) FXO LED
2) LAN0,1 LED

AddPac Technology Proprietary &
Documentation
Features Contents
Telephony and
Service
&
Features
•Voice Mail
•Call Parking
•Call Pickup
•Call Forwarding
•AutoAttendant
•Calling Number and Name Identification
•Call Transfer –Blind, Consult by Softkey
•Call Waiting Indication Call Swapping by Softkey
•Call Hold by Softkey
•Conference Control (internal/external MCU)
Major Features of IP-Next
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Features Contents
Advanced
Features
with AddPac IP
phone,
Video Phone, etc
•with AddPac IP phone, Video Phone, etc
•Plug and Play with Auto Discovery Function (SSCP)
•Softkey Map Download and Control (SSCP)
•Time and Date Setting
IP-PBX
Signaling
Protocols
•SIPApplication Server, Proxy, Registrar and Location Server(RFC3261)
•Multiple ITSP Trunk with SIP & H.323Account Support
- IP UA Client Role for Registering to ITSP SIP Server
- H.323 Gatekeeper Client Role for Registering to ITSP H.323
Gatekeeper Server
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Features Contents
IVR(Interactiv
e Voice
Response)
&
Auto
Attendant
•DefaultAutoAttendant Support
•IVR Function
- Provides with GUI-based Smart IVR Scenario Editor
- Upload/Download Scenario by Smart IVR Scenario Editor
- Supports Multiple Concurrent Scenarios
- Support Recordable IVR Prompts
Voice Mail •Support Voice Mail with IVR
•Access from Remote Site via Trunk Support
•Voice Mail Notification Support
Conference
•Ad-Hoc Conference
•Dial-Out Conference
•Meet-me Conference
•Multiple External MCU Support (Video,Audio, etc) : AP-MC1000
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Features Contents
Music &
Announcement
•Music on Hold
•ReplaceableAnnouncements
•Dialing Music/Tone Service
IP-PBX User
&
Device
Management
•Auto Discovery of IP Phones & IP Video Phones
•Monitoring Status of Phones
IP-PBX
Miscellaneous
Function
•Auto Config & Upgrade
•Personal Directory (Smart Messenger)
Basic Routing
•IPv4/IPv6 Dual Stack
•Management Routing
- Telnet, FTP, TFTP, SNMP, Syslog support
- Packet filtering (Access-list)
- Static Routing
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Features Contents
Network
Management
•Standard SNMP Agent (MIB v2) Support
•Traffic Queuing
•Remote Management using Console, Telnet.
Security
Functions
•Standard & Extended IPAccess List
•Enable/Disable for Specific Protocols
•Auto-disconnect for Telnet/Console Sessions
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Features Contents
Operation
&
Management
•System PerformanceAnalysis for Process, CPU, Connection I/F
•Configuration Backup & Restore forAPOS Managements
•System Booting andAuto-rebooting with Watchdog Feature
•System Managements with Data Logging
•IP Traffic Statistics with Accounting
•Debugging command
Other
Scalability
Features
•DHCP Server/Client
•Network Address Translation (NAT) Function
•Port Address Translation (PAT) Function
•Cisco Style Command Line Interface(CLI)
•Network time Protocol(NTP) Support
Major Features of IPNext

AddPac Technology Proprietary &
Documentation
Hardware Features of IPNext
Details Contents
CPU •High Performance RISC Integrated Host Processor
Memory Main Memory •128Mbyte SDRAM
Flash Memory •512Mbyte
SDRAM Memory •512Kbyte Flash Memory
LAN Interface LAN0 Port •One(1) Ethernet 10/100Mbps Fast Ethernet
LAN1 Port •One(1) Ethernet 10/100Mbps Fast Ethernet
Console Port •One(1) RS-232C Interface for CLI
PSTN Interface FXO Port •None (ModelA)
•2-Port FXO Voice Interface (2 * RJ11)(Model B)
Power &
Operation
Environments
•Power Requirement: Power VAC 110~220 VAC, 50/60Hz, 5V 3A
•Operating Temperature: 0°C ~ 50°C (32°~ 122°F)
•Storage Temperature: -40°C ~ +85°C (-40°~ +185°F)
•Relative Humidity: 5% ~ 95% (Non-condensing)
Dimensions •38(H) * 182(W) * 182(D)
Weight •0.46 Kg

Private
Private
AddPac Technology Proprietary &
Documentation
IPNext
200
300
201 202
301
302
Function of Signaling / Media Proxy
( RTP Proxy)
NAT router
NAT router
PSTN

AddPac Technology Proprietary &
Documentation
SMM
addpac propriety
SMM message
Major Functions
•IP-Next Registration all setups related to user.
•IP-Next all setups related to service
•IP-Next status review
•IP-Next message trace
SMM
Smart Multimedia Manager
IPNext
101
Local Area
103
102
100
200
300
201 202
301
302
PSTN
Smart Multimedia Manager

AddPac Technology Proprietary & Documentation
Category Sub-Category Description of Functions
Administration
Mode Advanced mode Display Mode for setting up all the functions of IP-PBX
Easy mode Mode for Setting up only Basic Functions of IP PBX
Event
monitoring Real Time Monitoring for the
Call being Processed Monitoring Function for Enabled Calls at the present time
Real Time message Trace Real Time Message Tracing Function for Calls Being Processed at the Present
Time
Message logging Storing and restoring Functions for Calls being Processed (filtering function)
Redundancy Active-Active The structure allowing Two IP-PBX’s to provision service simultaneously
Active-Standby The structure allowing one of two IP PBX’s become master and the other one
become disbled
Terminal
Registration SSCP The terminal using AddPac Specific Terminal Control Protocol. AP-IP-XXX, AP-
VP-XXX series come under this sub- category
Generic SIP terminal Supporting linking protocol of SSCP and general SIP terminal or SIP gateway with
Multiple Ports
SIP Trunk Trunk Gateway or Service Provider’s SIP server for interoperability with PSTN
network outside
IP V6 IP Version 4
V4 IP Version 6
Smart Multimedia Manager
Smart Multimedia Manager

AddPac Technology Proprietary & Documentation
Category Sub-Category Functional Description
Codec Class codec list by group Each codec class can be set to each group
Device Profile In case of SSCP terminal,
Reference can be made for SSCP terminal after common options
are grouped and a profile is created
Account Administrator Account/password
register/delete admin account which can access to SMM
Subscriber account/password register/
delete access account for Smart Messenger or voice mail
Device
Management Phone User assigning telephone numbers to subscribers
user General Detailed information on telephone subscriber (one’s real name,
subscriber id, password and others)
Terminal General Setup and binding of profile/partition/VoIP Protocol for telephone
subscribers
Trunk Gateway General Setup and binding of location/device profile/partition/VoIP Protocol
for Trunk gateway
routing pattern Routing pattern input(Digit map)
Call Control Call priority / authority / MRBT/CID…
SIP Proxy Server General location/device profile/partition/RTP Proxy/Network domain/SIP
ID/password/DTMF relay method and other setups
Register (option) Register Phone number
Smart Multimedia Manager

AddPac Technology Proprietary & Documentation
Category Subcategory Functional Description
MCU Local MCU Registering Local MCU
Remote MCU Registering Remote MCU
Auto Upgrade Auto Upgrade Server Assigning auto upgrade server outside or IP PBX
Option Auto upgrade group/URL/server position/ access information (id/password) and
others.
Call Policy pick-up Setup for enabling direct pickup in the same group only for pick-up group
partition Used for setting ranks for outgoing calls of each group/ subscriber
Partition access list Used for setting ranks of outgoing calls of each group/ subscriber
Number Translation Rule Registering patter list of change in number
Routing group Routing Tag for Trunk interface
Routing List Routing pattern list to be applied to Routing Group
Smart Multimedia Manager

Initial Setting
1. Basic configuration(CLI)
2. LdapClient set up(CLI)
AddPac Technology
16

Console and Telnet Login
AddPac Technology
17
Telnet
console
Serial port
ethernet
Baud rate 9600
No parity
1 stop bit
No flow control
Default login account/password : root/router
COM port
FastEthernet 0/0
Command of change Root account password
IP-PBX> enable
IP-PBX# config t
IP-PBX(config)# no username root
IP-PBX(config)# username root password addpac administrator
% Caution: After no username is set and rebooted, the root account disappears and remote access
becomes impossible. The only way to access is automatic login, the authority at this time is
administrator
% Must save after setup.
IPNext

Installation guide for IPNext
•Booting messages in IPNext(via console)
AddPac Technology
18
System Bootstrap, Version 1.2
Decompressing the image:
##########################[OK]
?System Boot Loader, Version 5.1.6
Copyright (c) by AddPac Technology Co., Ltd. Since 1999.
[DUAL-BOOT] Start application (0xbd000000)...
System Bootstrap, Version 1.2
Decompressing the image:
#################################################
AddPac IP-PBX Series (IPNext_G2)
32BIT RISC Processor With 125MHz Clock
128 Mbytes System Memory.
512 Kbytes System Boot Flash Memory
32 Mbytes System Flash Memory
1 RS232 Serial Console Interface
…
Press RETURN to get started.

Basic configuration
•Connect IPNext
•Set hostname
•Set Server Clock
AddPac Technology
19
Welcome,APOS(tm) Kernel Version 8.xx.xxx.
Copyright (c) 1999-2008AddPac Technology Co., Ltd.
Login: root (Login ID)
Password:****** (Default login Password : router)
IP-PBX>
IP-PBX> enable
IP-PBX# configure terminal
IP-PBX(config)# hostname <Name> (set Hostname )
IP-PBX(config)#
IP-PBX> enable
IP-PBX# configure terminal
IP-PBX(config)# clock time <Year><Month><Day><Hour><Minute><Second> (set clock)
IP-PBX(config)# clock time 2010 03 15 15 28 45
IP-PBX(config)#

Basic configuration
•Set Interface IP
•Set Gateway
AddPac Technology
20
IP-PBX> enable
IP-PBX# configure terminal
IP-PBX(config)# interface FastEthernet 0/0
IP-PBX(config)# ip address <IP Address> <Subnetmask> (Set ip address)
Example)
IP-PBX(config)# ip address 172.17.109.200 255.255.0.0
IP-PBX> enable
IP-PBX# configure terminal
IP-PBX(config)# ip route <Destination Network IP> <Wildcard Mask><Gateway IP> (set Gateway ‘s ip)
IP-PBX(config)#
Example)
IP-PBX(config)# ip route 0.0.0.0 0.0.0.0 172.17.1.1
