RECOMMENDATIONS FOR PROPER PROTECTION
The Following Recommendations for the Location of Fire and Burglary Detection Devices
Help Provide Proper Coverage for the Protected Premises.
Recommendations for Smoke and Heat Detectors
With regard to the number and placement of smoke/heat detectors, we subscribe to the
recommendations contained in the National Fire Protection Association's (NFPA) Standard #72
noted below.
Early warning fire detection is best achieved by the installation of fire detection equipment in all
rooms and areas of the household as follows: For minimum protection, a smoke detector should
be installed outside of each separate sleeping area, and on each additional floor of a multi-floor
family living unit, including basements. The installation of smoke detectors in kitchens, attics
(finished or unfinished), or in garages is not normally recommended.
For maximum protection, the NFPA recommends that you install heat or smoke detectors in
the living room, dining room, bedroom(s), kitchen, hallway(s), attic, furnace room, utility and
storage rooms, basements and attached garages.
In addition, we recommend the following:
• Install a smoke detector inside every bedroom where a smoker sleeps.
• Install a smoke detector inside every bedroom where someone sleeps with the door partly or
completely closed. Smoke could be blocked by the closed door. Also, an alarm in the hallway
outside may not wake up the sleeper if the door is closed.
DINING KITCHEN
BEDROOM
BEDROOM
BEDROOM
BEDROOM
LIVING ROOM
BEDROOM
BDRM
BDRM
DINING
LIVING ROOM
TV ROOM KITCHEN
BEDROOM BEDROOM
TO
BR
LVNG RM
BASEMENT
KTCHN
.
CLOSED
DOOR GARAGE
Smoke Detectors for Minimum Protection
Smoke Detectors for Additional Protection
Heat-Activated Detectors
floor_plan-V0
• Install a smoke detector inside bedrooms where
electrical appliances (such as portable heaters, air
conditioners, or humidifiers) are used.
• Install a smoke detector at both ends of a hallway if
the hallway is more than 40 feet (12 meters) long.
• Install smoke detectors in any room where an alarm
control is located, or in any room where alarm control
connections to an AC source or phone lines are made. If
detectors are not so located, a fire within the room
could prevent the control from reporting a fire or an
intrusion.
THIS CONTROL COMPLIES WITH NFPA
REQUIREMENTS FOR TEMPORAL PULSE
SOUNDING FOR FIRE NOTIFICATION
APPLIANCES.
Recommendations for Proper Intrusion Protection
For proper intrusion coverage, sensors should be located at every possible point of entry to a
home or commercial premises. This would include any skylights that may be present, and the
upper windows in a multi-level building.
In addition, we recommend that radio backup be used in a security system so that alarm signals can
still be sent to the alarm monitoring station in the event that the telephone lines are out of order
(alarm signals are normally sent over the phone lines, if connected to an alarm monitoring station).

iii
Table of Contents
•••••••••••••••••••••••••••••••••••••••••••••••••
Conventions Used In This Manual.........................................................................................vi
Section 1 Introduction.......................................................................................................1–1
Features ............................................................................................................................................................1-1
Section 2 Installing the Control & Peripherals.................................................................2-1
Cabinet and Lock Installation .........................................................................................................................2-1
Mounting the PC Board Alone.........................................................................................................................2-1
Mounting Control with RF Receiver ...............................................................................................................2-2
Mounting the Keypads.....................................................................................................................................2-3
Wiring the Keypads..........................................................................................................................................2-3
Supplementary Power (Optional)......................................................................................................................2-3
Sounder (Bell) Connections..............................................................................................................................2-4
Wiring the AC Transformer.............................................................................................................................2-4
AC Powerup ......................................................................................................................................................2-5
Backup Battery.................................................................................................................................................2-5
Earth Ground Connections ..............................................................................................................................2-6
Installing the Hardwired Zones.......................................................................................................................2-6
Smoke Detectors...............................................................................................................................................2-6
Installing the 5881/5882 Receiver...................................................................................................................2-7
Installing Other 5800 Series Transmitters.....................................................................................................2-8
Installing the 4204 Relay Module....................................................................................................................2-9
Installing a 4285 or 4286 VIP Module ............................................................................................................2-9
Standard Phone Line Connections................................................................................................................2-10
Long-Range Radio Connections.....................................................................................................................2-11
Audio Alarm Verification (AAV) Connections ..............................................................................................2-11
Section 3 Programming Overview ....................................................................................3-1
About Programming.........................................................................................................................................3-1
Zone Response Type Definitions......................................................................................................................3-1
Mechanics of Programming..............................................................................................................................3-3
Data Field Programming Procedures..............................................................................................................3-3
Interactive Mode Programming (∗56, ∗58, ∗80, ∗81, and ∗82).......................................................................3-3
Loading Factory Defaults/Initializing for Download......................................................................................3-3
Exiting the Programming Mode ......................................................................................................................3-3
Section 4 Data Field Programming...................................................................................4-1
About Data Field Programming ......................................................................................................................4-1
Section 5 Zone Programming...........................................................................................5–1
About Zone Programming...............................................................................................................................5–1
✱56 Zone Programming Procedure.................................................................................................................5–1
✱58 Expert Programming Mode Procedures..................................................................................................5–5
Section 6 Output Device Programming...........................................................................6–1
About Output Device Programming...............................................................................................................6–1
Programming Output Devices ........................................................................................................................6–2
Section 7 Zone Lists..........................................................................................................7–1
About Zone Lists..............................................................................................................................................7–1
Zone List Programming...................................................................................................................................7–1

VISTA-10SE Installation and Setup Guide
iv
Section 8 Alpha Descriptor Programming (✱82 Menu Mode)........................................8-1
About Alpha Descriptor Programming............................................................................................................8-1
Programming Zone Descriptors.......................................................................................................................8-1
Adding Custom Words......................................................................................................................................8-3
Section 9 System Communication....................................................................................9-1
Panel Communication with Central Station ..................................................................................................9-1
Report Code Formats........................................................................................................................................9-1
System Communication Programming ...........................................................................................................9-3
Section 10 System Operation...........................................................................................10-1
Security Codes ................................................................................................................................................10-1
Keypad Functions...........................................................................................................................................10-1
Panic Keys.......................................................................................................................................................10-2
4285/4286 VIP Module (if used).....................................................................................................................10-2
Relay Outputs (if used)....................................................................................................................................10-2
Exit Error Alarm Displays (if programmed) ...................................................................................................10-2
Section 11 Testing the System.........................................................................................11-1
Local Tests ......................................................................................................................................................11-1
Communication Tests.....................................................................................................................................11-1
Transmitter Sniffer Mode ..............................................................................................................................11-1
Go/No Go Test Mode.......................................................................................................................................11-2
Automatic Standby Battery Tests.................................................................................................................11-2
Trouble Conditions .........................................................................................................................................11-2
Power Problems ..............................................................................................................................................11-2
Other Displays (fixed-word keypad displays are in parentheses)...............................................................11-3
Troubleshooting Guide...................................................................................................................................11-3
Section 12 Remote Programming and Control (Downloading) .....................................12-1
About Remote Programming..........................................................................................................................12-1
Equipment Required ......................................................................................................................................12-1
Remote Programming Information ...............................................................................................................12-1
Section 13 Specifications and Accessories....................................................................13-1
APPENDIX A Regulatory Agency Statements...................................................................A-1
APPENDIX B Limitations and Warranties..........................................................................B-1
INDEX .............................................................................................................................Index-1
Summary of Connections (SOC).................................................................Inside back cover
Programming Form..........................................................................................................Insert

v
List of Figures
•••••••••••••••••••••••••••••••••••••••••••••••••
Figure 2-1 Installing the Cabinet Lock ...............................................................................................................2-1
Figure 2-2 Mounting the PC Board....................................................................................................................2-1
Figure 2-3 Mounting the PC Board and RF Receiver........................................................................................2-2
Figure 2-4 Keypad Connections to the Control Board.......................................................................................2-3
Figure 2-5 Using a Supplementary Power Supply for Keypads ........................................................................2-4
Figure 2-6 Typical Sounder Wiring ....................................................................................................................2-4
Figure 2-7 Sounder Wiring (Supervised) ...........................................................................................................2-4
Figure 2-8 4-wire Smoke Detector Connections (Zone 5).................................................................................2-6
Figure 2-9 5881/5882 RF Receiver....................................................................................................................2-7
Figure 2-10 4204 Connections to Control............................................................................................................2-9
Figure 2-11 4285/4286 VIP Module Wiring Connections...................................................................................2-10
Figure 2-12 Standard Telephone Line Connections..........................................................................................2-11
Figure 2-13 Connection of AAV Unit When Not Using a 4285/4286 VIP Module .............................................2-12
Figure 2-14 Connection of AAV Unit When Using a 4285/4286 VIP Module....................................................2-12
Figure 5-1 5800 Series Wireless Devices.........................................................................................................5–4
Figure 5-2 5804 Wireless Key Transmitter .......................................................................................................5–9
Figure 5-3 5804BD 2-Way Wireless Key Transmitter.......................................................................................5–9
VISTA-10SE SUMMARY OF CONNECTIONS DIAGRAM..............................................................Inside back cover

vi
Conventions Used In This Manual
•••••••••••••••••••••••••••••••••••••••••••••••••
Before you begin using this manual, it is important that you understand the meaning of the
following symbols:
ULA UL note that includes specific information that must be followed if you are installing this system
in a UL Listed application.
A checked note includes information you should be aware of before continuing with the
installation, and which, if not observed, could result in operational difficulties.
This symbol warns of conditions that could seriously affect the operation of the system, or cause
damage to the system. Please read each warning carefully. This symbol also denotes warnings
about physical harm to the user.
Enter Zone Num.
(00 = Quit) You may program many system options by responding to alpha keypad display
prompts. These prompts appear as shown at left in a double-line box, for example.
✴20 When programming the system, data fields are indicated by a “star”(✱), followed by the
data field number.
PRODUCT MODEL NUMBERS: Unless noted otherwise, references to specific model
numbers represent ADEMCO products.

1–1
SECTION 1
Introduction
•••••••••••••••••••••••••••••••••••••••••••••••••
The VISTA–10SE is a control that supports up to 22 hardwired and wireless zones, plus remote keypads.
Features
Basic Hardwired Zones
Provides 6 basic hardwired zones having the following
characteristics:
• Zones 1-6 response time is 300–500 milliseconds.
• Zone 3 programmable fast response time is 10–15
milliseconds.
• EOLR supervision supporting N.O. or N.C. sensors
• Zone 5 supports as many 4-wire smoke or heat
detectors as can be powered from the control).
• Zones 7, 95, and 96 are keypad Panics.
• Zone 8 is Duress.
• Zone 9 is Tamper.
Wireless Expansion
• Supports up to 16 wireless zones.
• Requires the use of a 5881 (5882 in Canada) type RF
receiver (with 5800 Series wireless transmitters), as
shown below.
Receiver Model No. of Zones Transmitter Type
5881L (5882L*) Up to 8 5800
5881M (5881M*) Up to 16 5800
5881H (5882H*) Up to 16 5800
* Used in Canada
ULWireless may not be used in UL Commercial
Burglary installations.
Remote Keypads
Up to 4 of any of the following keypads may be used:
Fixed-Word Keypads:
6127*, 6128, and 6137.
* This keypad cannot be used if a 4285/4286 VIP
Module is being used.
Alpha Keypads: 6139 (2-line alphanumeric display).
6138 (1-line alphanumeric display).
When programming from a keypad, a 6139 2-
line alpha keypad must be connected (but
need not stay in the system).
Security Codes
• Installer code is User 1
• One Master code for entire system (User 2).
• 4 secondary user codes (Users 3–6)
• One duress code (User 8).
Duress Code: An emergency code that, when
used to disarm or arm the system, will send a
silent duress message to the central station.
Keypad Panic Keys
• Up to 3 programmable panic key functions are
provided.
• Designated as Zones 7, 95, 96.
• Activated by wired and wireless keypads
• Reported separately.
Paging Feature
If the paging feature is to be included in this system,
(refer to Split/Dual Reporting field in SECTION 4: Data
Field Programming), the pager will respond to certain
conditions as they occur in the system by displaying a
7-digit system status code that indicates the type of
condition that has occurred.
The 7-digit status code can be preceded by up to 16
digits (programmed in a separate field), which can
consist of a PIN number, Subscriber account number, or
any additional data that may be required to be sent to
the pager.
Quick Arm Feature
“Quick Arm”may be programmed, allowing use of the
[#] key in place of the security code for arming (Quick
Arm will not work unless the Master code has been
programmed into the system).
Optional Bell Supervision
This is a hardware-enabled option, achieved by cutting
a red jumper on the PC board. If the “Alarm Output”
loop connected to an external sounder is then opened or
shorted, a “bell trouble”message will be displayed at
the keypads, accompanied by a trouble sound. A trouble
report will also be sent to the central station.
Optional RF Jam Detection
If RF jam detection is programmed for a 5800 RF
system, the RF receiver will detect a condition that may
impede proper RF reception (i.e., jamming or other RF
interference). Such a condition will produce a message
display, and a report will be sent to the central
monitoring station (if trouble reporting is enabled).
Optional Output Relays
• Up to 4 relays using one 4204 Relay Module.
• Actions programmable to respond to zone activity or
manual keypad entries.

VISTA-10SE Installation and Setup Guide
1-2
Optional VIP Module
• Supports the ADEMCO 4285/4286 VIP Module.
• Provides access to the system via on-premises or off-
premises phones for arming, disarming, etc., plus
control of relay outputs.
Optional Long-Range Radio
Allows all messages that have been programmed to go
to the primary telephone number to be reported
additionally to a 7720 PLUS, 7820 or 7835C radio.
Alarm Output
• Provides a 12VDC, 2 AMP output that can drive the
compatible sounders listed in SECTION 13:
Specifications and Accessories (assumes a fully
charged battery is connected).
• Steady output for burglary/panic, or temporal pulse
sounding output for fire notification, as required by
UL.
• Uses current-limiting circuitry for protection.
Auxiliary Power Output
• Provides 12VDC, 500mA maximum. Uses current
limiting circuitry for protection.
• This output interrupts for smoke detector reset if 4-
wire smoke detectors are used.
Programming
• Programmed options are stored in electrically
erasable, nonvolatile EEPROM memory
(information can be reprogrammed at any time and
will not be lost in the event of a power loss).
• The system can be uploaded, downloaded, or
controlled via an IBM-compatible computer, using
ADEMCO's Compass Windows downloading
software, and a modem specified by ADEMCO.
Keypad programming consists of:
• Data field programming.
• Interactive (menu) mode programming.
For programming from a keypad, a 6139 2-line
alpha keypad must be connected (but need
not stay in the system).
Communication Formats Supported
• ADEMCO Low Speed (Standard or Expanded)
• Sescoa/Radionics (Standard or Expanded)
• ADEMCO Express
• ADEMCO Contact ID®
Zone Descriptors
You can assign alpha descriptors to all zones (useful
only when using alpha keypads and/or the 4285/4286
VIP Module).
AC Power Supply
Uses No. 1321, 120VAC plug-in transformer with
16.5VAC 25VA output (1321CN in Canada).
Backup Battery
Rechargeable (Sealed Lead Acid) 12VDC, 4AH
minimum.

2-1
SECTION 2
Installing the Control & Peripherals
•••••••••••••••••••••••••••••••••••••••••••••••••
Cabinet and Lock Installation
ULFor Residential Fire and/or Burglary installa-
tions, use the ADEMCO RES-UL cabinet.
For Commercial Burglary installations, use the
ADEMCO COM-UL cabinet.
Before installing the cabinet's contents,
remove the metal cabinet knockouts required
for wiring entry. Do not attempt to remove the
knockouts after the circuit board has been
installed.
1. Mount the control cabinet to a sturdy wall in a
clean, dry area that is not readily accessible to the
general public using fasteners or anchors (not
supplied), in the four cabinet mounting holes.
2. Remove cabinet door, then remove the lock knockout
from the door. Insert the key into the lock.
3. Position the lock in the hole, making certain that the
latch will make contact with the latch bracket when
the door is closed.
4. When correctly positioned, push the lock until it is
held securely by its snap tabs.
Notes:
•Use an ADEMCO No. N4445 Lock.
•The cabinet can be closed and secured without a lock
by using 2 screws in the cover's edge.
CABINET DOOR
BOTTOM
LOCKED
UNLOCKED
cab_lock_snap-001-V0
ADEMCO ADEMCO
PUSH
SNAP
TAB
SNAP
TAB
PUSH
ON LOCK
UNTIL IT
IS SEATED
SECURELY
STEP 2STEP 1
CHECK
POSITION
Figure 2-1. Installing the Cabinet Lock
Mounting the PC Board Alone
(no RF Receiver)
1. Hang two mounting clips (provided) on the raised cabinet tabs (see Detail B in Figure 2-2).
2. a. Insert the top of the circuit board into the slots at the top of the cabinet. Make sure that the board
rests on the correct row (see Detail A below).
b. Swing the base of the board into the mounting clips and secure the board to the cabinet with the accompanying
screws (see Detail B).
+
+
CIRCUIT
BOARD
DETAIL B
SIDE VIEW
OF MOUNTING
CLIPS
DETAIL A
SIDE VIEW
OF BOARD
SUPPORTING
SLOTS
CIRCUIT
BOARD
cb_mount-V0
CABINET
CABINET
Figure 2-2. Mounting the PC Board

VISTA-10SE Installation and Setup Guide
2-2
Mounting Control with RF Receiver
To mount the control panel and RF receiver boards
together in the cabinet, do the following:
1. Hang two mounting clips (provided with receiver) on
the raised cabinet tabs, as indicated in the upper left
diagram in Figure 2-3.
2. Insert the top of the receiver board (removed from
its own case as described in its instructions) between
the rows of slots at the top of the cabinet, as shown
in Detail A.
3. Position the base of the receiver board onto the
mounting clips and secure both to the cabinet with
the supplied screws.
4. Hang two mounting clips (supplied with the control
board), on the raised cabinet tabs as shown in
Figure 2-3.
5. Insert the top of the control board into the slots of
the mounting clips secured in step 3 above.
6. Position the lower end of the control board into place
on the mounting clips and secure both to the cabinet
with the two supplied screws.
7. Insert both grounding lugs (supplied with the
receiver) through the top of the cabinet into the left-
hand terminals of the antenna blocks (located at the
upper edge of the receiver board), and secure them
to the cabinet with the screws provided, as shown in
Detail B.
8. Insert the receiver's antennas through the top of the
cabinet, into the blocks' right-hand terminals, and
tighten the screws.
Refer to setup and wiring instructions for the receiver
in the Installing the 5881/5882 Receiver paragraph
later in this section.
NOTES
•Do not mount the cabinet on or near metal objects.
This will decrease RF range and/or block RF
transmissions from wireless transmitters.
•Do not locate the cabinet in an area of high RF
interference (revealed by frequent or prolonged
lighting of the LED in the receiver after it is
operational (random flicker is OK)
ANTENNA
MOUNT
(2 PLACES)
ANTENNA
(2)
SCREW
(2)
BLACK
MOUNTING
CLIP
RED
MOUNTING
CLIP
WHITE
MOUNTING
CLIP
GROUNDING
LUG
(2)
NOTE
A COMBINATION OFTHESE MOUNTING CLIPS HAS BEEN
INCLUDED INYOUR INSTALLATION KIT.
USE THE APPROPRIATE CLIPS FOR MOUNTING.
IF NO RF RECEIVER IS USED, MOUNT THE PC BOARD USING
EITHER THE WHITE OR BLACK CLIPS,WHICHEVER ARE
INCLUDED IN THE CONTROL PANEL'S HARDWARE KIT.
DETAIL A
SIDE VIEW
OF BOARD -
SUPPORTING SLOTS
CIRCUIT
BOARD
CABINET
MOUNTING
CLIP
CABINET
MOUNTING
CLIP
CONTROL
CIRCUIT
BOARD
BOARD
SUPPORTING
SLOTS
RECEIVER CIRCUIT BOARD
++
AB
pc_mount-001-V1
DETAIL B
ANTENNA AND GROUNDING
LUG INSTALLATION
INSTALLATION WITH RECEIVER CIRCUIT BOARD
Figure 2-3. Mounting the PC Board and RF Receiver
