Adexa CW-52FD User manual

U S E R ‘ S M A N A U L - E N
CW-70FD
Service Cellar
CW-52FD

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
...............................................
1
INSTALLATION INSTRUCTIONS
.........................................................
4
CLEANING AND MAINTENANCE.
......................................................
5
PRODUCT DESCRIPTION
.....................................................................
6
TECHNICAL SPECIFICATIONS
............................................................
7
USE YOUR SEVICE CELLAR
.................................................................
8
BREAKDOWNS AND SOLUTIONS
....................................................
10

- -
1
THIS PRODUCT IS FOR HOUSEHOLD
USE ONLY!
Please read these instructions carefully
before the first use of this product and
save this manual for your future
reference.
IMPORTANT SAFETY INSTRUCTIONS
This warning is only for EUROPEAN market only!
When using an electrical appliance, basic precautions
should always be followed, including the following:
1. WARNING: When positioning the appliance, ensure
the supply cord is not trapped or damaged.
2. WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
3. Children aged from 3to8 years are allowed to load
and unload refrigerating appliances.
4. WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
5. This appliance is intended to be used in household
and similar applications such as
- Staff kitchen areas in shops,offices and other
working environments;
- Farm houses and by clients in hotel, motels and
other residential type environments;

- -
2
6. Please keep the products away from the fire or similar
glowing substance before you dispose the refrigerator.
7. Please remove the door before you dispose your
refrigerator.
8. The appliance shall not be installed in the laundry.
9. The appliance must be positioned so that the plug is
accessible.
10. The appliance shall be installed in accordance with
national wiring regulations.
11. Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
12. This appliance can be used by children aged from
8years and persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and use maintenance shall not be made by children
without supervision.
13. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
14. To avoid contamination of food, please respect the
following instructions:
-Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.

- -
3
.
-If the refrigerating appliance was left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance
15. DISPOSAL: Do not dispose this product as unsorted
municipal waste.Collection of such waste separately
for special treatment is necessary.
16. This refrigerating appliance is not intended to be used
as a built-in appliance.
17. This refrigerating appliance is not suitable for freezing
foodstuffs.
18. WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear
of obstruction.
19. WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
20. WARNING: Do not damage the refrigerant circuit.
21. Warning: Risk of fire / flammable materials. There
are flammable materials at the back of appliance, please
keep the product far away fire source.

-4-
INSTALLATION INSTRUCTIONS
Before putting your service cellar into service
● Remove all inner and outer packaging components.
● Check that none of the following parts are missing:
- 3 removable shelves
- 1 operating manual
● Before connecting your device to a power supply,
allow it to stand upright for about 2 hours. This
reduces the risk of malfunction of the refrigeration
system due to handling during transport.
● Clean the inner surfaces of the unit with a soft cloth
and warm water.
● Place your unit on a floor strong enough to support
the weight of the fully filled unit.
● Make sure the unit is level by adjusting the front feet
underneath the unit. Make sure that the cellar rests
on its feet in a stable manner.
● Install the appliance away from direct sunlight and
heat sources (radiator, hot plate, etc.). Direct sunlight
can damage the unit’s coating and heat can increase
its power consumption. If the ambient temperature is
extremely cold or hot, this may prevent the unit from
operating properly.
● The unit is not designed to be installed in a basement
or cellar.
● This unit is designed exclusively for indoor use.
Caution: Make sure that the unit is kept away from any
substance that may cause combustion.
● Check that the water tank is in place before
connecting the unit.

-5-
CLEANING AND MAINTENANCE
Cleaning your service cellar
● Unplug your service cellar and take out all the bottles.
● Clean the outside of the unit with hot water and a
mild detergent.
● Remove the water tank at the bottom of the unit, then
was hit.
Moving your service cellar
● Remove all bottles and disconnect the service cellar.
● Tape all loose parts inside your service cellar.
● Turnthe feet to adjust their height to the minimum to
avoid damage.
● Tighten the door to keep it closed.
● Be sure to keep the service cellar upright during
transport.

-6-
PRODUCT DESCRIPTION
1.Lighting 5.Upper Hinge
2.Aluminum Plate 6.Door Gasket
3.Shelf 7.Recessed Handle
4.Feet 8.Glass Door
9. Lighting Switch 12.Temperature up switch
10. Temperature selector switch
11.Temperature Display 13.Temperature down switch

-7-
TECHNICALSPECIFICATIONS
Reference : CW-52FD
Rated voltage : 220-240V~
Ampere : 0.55A
Rated frequency : 50Hz
Climate class : N
Rated frequency : R600a (31g)
Protection against electrical
shock :
I
Insulation foam : CYCLOPENTANE
Climate class:
- Extended temperate(SN): 'this refrigerating appliance is
intended to be used at ambient temperatures ranging
from 10 °C to 32 °C';
- Temperate(N): 'this refrigerating appliance is intended to
be used at ambient temperatures ranging from 16 °C to
32 °C';
- Subtropical(ST): 'this refrigerating appliance is intended to
be used at ambient temperatures ranging from 16 °C to
38 °C';

-8-
- Tropical(T): 'this refrigerating appliance is intended to be
used at ambient temperatures ranging from 16 °C to43 °C';
Note: More data information, please scan the QR code on
the energy label.
USE YOUR SERVICE CELLAR
The temperature setting allows you to adjust it according
to your needs:
Setting temperature before tasting red wines:
Temperature recommended 16-17°C.
If the ambient temperature is higher or lower than the
recommended temperatures, this will have a negative
impact on its performance. For example, placing the unit
in an extremely cold or hot place can cause variations in
the internal temperature of the unit.
The internal temperature may vary depending on the
location of the bottles, at the top, middle or bottom.
Adjustment may be necessary depending on the ambient
temperature.
Do not hesitate to leave a thermometer inside the cellar in
order to carry out regular monitoring.
This service cellar is designed for the maximum storage
of 18 standard size (75cl) bottles of wine.
Temperature setting:

-9-
● The keys ‹▲› and ‹▼› allow you to increase or decrease
the temperature in increments of 1°C (the
temperature range is11~18°C)
● The button ‹ › allows you to switch the interior
lighting on and off.
To
minimize
energy
consumption,
be sure to respect the filling
capacity of your service cellar–18 «
Bordeaux 75cl » size.
The combination of drawers,
baskets and shelves that result in
the most efficient use of energy for
the appliance.
The chart indicates the ideal storage temperatures for
different types of wines:
Red wines 15°C ~ 18
±1
°C
Dry/White Wines 10°C ~ 15°C
Vintage Wines 13°C

-10-
BREAKDOWNS AND SOLUTIONS
Some malfunctions can be easily resolved. Before
calling customer service or a repairer, please consult
the following table:
PROBLEM POSSIBLE CAUSES & SOLUTIONS
The service cellar
does not work. Not connected.
The circuit-breaker is tripped or the
fuse is damaged.
Check if the outlet is powered by
connecting another electrical device.
The service cellar is
not cold enough Check the temperature setting.
High ambient temperature may
require setting the service cellar to a
colder temperature.
The door is being opened too often.
The door is not completely closed.
The door seal is not properly
positioned.
Not enough space around the service
cellar to allow ventilation.

-
11
-
The device
operates
continuously
The room temperature is higher than
the maximum supported.
A large number of bottles inside the
service cellar.
The door is being opened too often.
The door is not completely closed.
Temperature control is not calibrated
correctly.
The door seal is not properly
positioned.
The light doesn’t
work. The service cellar is not plugged in.
The circuit-breaker has been tripped
or a fuse is damaged.
The LED lighting is out of order.
The light button is set to «OFF».
Vibrations. Check to make sure the service cellar
is level.
The service cellar
seems to be
making too much
noise.
The service cellar is not level, or a foot
is incorrectly adjusted.

-12-
The door does not
close properly. The service cellar is not level.
The shelves are out of position and
blocking the door closure.
Water under the
device Water is being collected incorrectly in the water tank on the back of the unit.
Check that the water tank is in place.
Empty the water tank.

-13-
We decline liability for any damage or accident derived
from any use of this product which is not in conformity
with the instructions contained in this booklet.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product
should not be disposed with other household
wastes throughout the EU.Toprevent possible
harm to the environment or human health
from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse
of material resources. Toreturn your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environment safe recycling.
