Firmware Version
Note:This is a read only menu option that will display the con-
trollers current software version.
1. Press the SET-UP button for two seconds to enter the main
menu.
2. Turn the DIAL/ENTER dial to menu option 16 (Firmware Ver-
sion). Press the DIAL/ENTER dial to enter. Press the ESC/PAGE
button to exit.
Fixture Control, Saving, & Playing Memories
Note: Although the generic proles may work for you, it is rec-
ommended that you load and use the custom proles that were
provided on the USB sitck that was included with your control-
ler. The custom proles may oer you additional control and
features that the generic proles do not include. If you wish to
use the custom proles, please refer to the LOADING FIXTURE
PROFILES section of this user manual and load them before
proceeding. After you have patched your xtures, you can con-
trol and save memories using the following steps.
1. Press the FIXTURE button then select the xtures, using the
FUNCTION 1-12 buttons, that you want to control. If you are
using multiple xtures of the same type and want to control
them at the same time, you can press the rst and last buttons
so all xtures in between are selected at the same time. For ex-
ample, I have patched 6 xtures on buttons 1-6, to select them
all quickly, I would simultaneously press buttons 1 & 6 so all 6
xtures are selected.
2. Press the COLOR button and add a color by using the
FUNCTION 1-12 buttons. Turn the DIAL/ENTER dial to switch
between two pages of preset colors (Note: your xture must
support this feature to function).
3. Press the GOBO button and add a gobo by using the FUNC-
TION 1-12 buttons. Turn the DIAL/ENTER dial to switch be-
ADJ Products, LLC www.adj.com - WiFly NE1 Page 16 ADJ Products, LLC www.adj.com - WiFly NE1 Page 17
WiFly NE1 Operation
tween two pages of preset gobos (Note: your xture must sup-
port this feature to function).
4. Press the EFFECT button and add an eect by using the
FUNCTION 1-12 buttons. Turn the DIAL/ENTER dial to switch
between three pages of eects. In the display, you will see ML
EFFECT (for moving lights) and RGB EFFECT 1 and RGB EF-
FECT 2 (for RGBWA+UV LED’s) plus the speed, phase, size,
and direction settings, which can be controlled from the four
EFFECT rotary dials. You can pause an eect at any time by
pressing the PAUSE button. (Note: your xture must support
this feature to function).
5. Press the SHOW button and enable a show by using the
FUNCTION 1-12 buttons. (Note: your xture must support this
feature to function).
6. You can also set all channel values manually. If you have
already set your scene and want to store it. please see step 7
now. To make manual channel adjustments, press the FIXTURE
button, then press the DIAL/ENTER dial for two seconds, the
display will list channels 1-4 along with their current values.
Use the four EFFECT dials to adjust each channel listed in the
display. Channels are displayed four at a time. To access ad-
ditional channels, turn the DIAL/ENTER dial clockwise and
counter-clockwise.
7. To save your current output, press and hold down any of the
six MEMORY buttons until the display reads “Operation Com-
plete!”. Press that same MEMORY button a second time to
playback from that memory location, it should illuminate solid
green. Repeat steps 1-6 to store additional memories. There
are two memory banks. To access the secondary memory bank
press the ESC/PAGE button. If there is a memory running, that
MEMORY button will ash letting you know that is actively run-
ning in the other bank. If your memory includes an “EFFECT”,
you can pause the eect by pressing the PAUSE button.
