ADJ UB 6H User manual

User Manual
UB 6HUB 6H
Rev 03/2021

©2021 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying
product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be trade-
marks or registered trademarks of their respective companies and are hereby acknowledged. All
non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as
a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and opera-
tion of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment. Please turn o all electrical products when
they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power
when not in use. Thank you!
ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 2
DOCUMENT VERSION
Please check www.adj.com for the latest revision/update of this document.
Date Document
Version
Software
Version >
DMX Channel
Mode
Notes
08/04/17 1 1.01 6/10/12/18 Initial Release
03/12/21 2 1.03 N/C Update for Primary/Secondary Mode

UB 6H Introduction
ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 3
Unpacking: Thank you for purchasing the UB 6H by ADJ Products, LLC. Every UB 6H has been
thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the carton appears to be damaged,
carefully inspect your xture for any damage and be sure all accessories necessary to operate the unit
have arrived intact. In the event that damage has been found or parts are missing, please contact our
toll free customer support number for further instructions. Do not return this unit to your dealer without
rst contacting customer support.
Introduction: The ADJ UB 6H is a DMX intelligent, LED bar xture. This xture can be used in a stand
alone set up or connected in a Primary/Secondary set up. This xture has six operating modes: Sound
Active mode, Auto Run mode, Static Color mode, RGBWA+UV Dimmer mode, Built-In Program mode,
and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support line, to provide set up help and
to answer any questions that may arise during initial set up or operation. You may also visit us on the
web at www.adj.com for any comments or suggestions. Service Hours are Monday through Friday
8:00 a.m. to 4:30 p.m. Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [email protected]
Warning! To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or
moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, as
doing so will void your manufacturer’s warranty. In the unlikely event that your unit requires service,
please contact ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.

ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 4
UB 6H Features
• Multi-Colors
• Six Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 4 DMX Modes: 6 Channel Mode, 10 Channel Mode, 12 Channel Mode, & 18 Channel Mode.
• Magnetic Quick Align (See the Magnetic Quick Align section of this manual)
• ADJ UC IR compatible and Airstream IR compatible
• Multiple Unit Power Linking Capability (See the Multiple Unit Power Linking section of this man-
ual for details)
UB 6H Warranty Registration
The UB 6H carries a 2 year limited warranty. Please fill out the enclosed warranty card to validate your
purchase. All returned service items, whether under warranty or not, must be freight pre-paid and
accompanied by a return authorization (R.A.) number. The R.A. number must be clearly written on the
outside of the return package. A brief description of the problem as well as the R.A. number must also
be written down on a piece of paper included in the shipping carton. If the unit is under warranty, you
must provide a copy of your proof of purchase invoice. You may obtain an R.A. number by contact-
ing our customer support team on our customer support number. All packages returned to the service
department not displaying an R.A. number on the outside of the package will be returned to the ship-
per.
UB 6H Installation
The unit should be mounted using a mounting clamp (not provided), which should be attached to the
mounting bracket that is provided with the unit. Always ensure that the unit is firmly fixed to avoid
vibration and slipping while operating. Always ensure that the structure to which you are attaching
the unit is secure and is able to support at least 10 times the unit’s weight. Also, always use a safety
cable that can hold at least 12 times the weight of the unit.
The equipment must be installed by a professional, and it must be installed in a place where it is out
of the reach of people’s grasp.

ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 5
UB 6H Safety Precautions
• To reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord is frayed or broken.
• Do not attempt to remove or break off the ground prong from the electrical cord. This prong is
used to reduce the risk of electrical shock and fire in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover for any reason. There are no user serviceable parts inside.
• Never operate this unit with the cover removed.
• Never plug this unit in to a dimmer pack.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
(15cm) between this device and a wall.
• Do not attempt to operate this unit if it has been damanged in any way.
• This unit is intended for indoor use only. Use of this product outdoors voids all warranties.
• During long periods of non-use, disconnect the unit from the power outlet.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to the point at which they exit from
the unit.
• Cleaning - The fixture should be cleaned only as recommended by the manufacturer. See the
Cleaning section of this manual for cleaning details.
• Heat - The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen onto, or liquid has been spilled into, the fixture.
C. The fixture has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a marked change in performance.

UB 6H Safety Precautions
RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV) RADIATION!
FIXTURE EMITS HIGH INTENSITY ULTRAVIOLET (UV) LIGHT AT A WAVELENGTH OF 390NM -
410NM.
WEAR PROPER EYE AND SKIN PROTECTION.
AVOID PROLONGED PERIODS OF EXPOSURE.
AVOID WEARING WHITE COLOR CLOTHING AND/OR USING (UV) PAINTS ON SKIN.
AVOID DIRECT EYE AND/OR SKIN EXPOSURE AT DISTANCES OF LESS THAN 11 feet (3.3m).
DO NOT OPERATE FIXTURE WITH DAMAGED OR MISSING EXTERNAL COVER PROTECTIVE
LENS.
DO NOT LOOK DIRECTLY INTO THE (UV) LIGHT AND/OR VIEW (UV) LIGHT DIRECTLY WITH
OPTICAL INSTRUMENTS THAT MAY CONCENTRATE THE LIGHT/RADIATION OUTPUT.
INDIVIDUALS SUFFERING FROM A RANGE OF EYE CONDITIONS, SUNLIGHT EXPOSURE
DISORDERS, OR INDIVIDUALS USING PHOTOSENSITIVE MEDICATION MAY EXPERIENCE
DISCOMFORT IF EXPOSED TO THE ULTRAVIOLET (UV) LIGHT EMITTED FROM THIS FIXTURE.
ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 6

UB 6H DMX Set Up
ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 7
Power Supply: The ADJ UB 6H contains an automatic voltage switch, which will automatically sense
the voltage when it is plugged into the power source. With this switch, there is no need to worry about
the correct power voltage, and this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal protocol that is used as a form
of communication between intelligent fixtures and controllers. A DMX controller sends DMX data
instructions from the controller to the fixture. DMX data is sent as serial data that travels from fixture
to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most control-
lers only have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of different manufacturers to be
linked together and operate from a single controller, as long as all fixtures and the controller are DMX
compliant. To ensure proper DMX data transmission, try to use the shortest cable path possible
when linking several DMX fixtures. The order in which fixtures are connected in a DMX line does not
influence the DMX addressing. For example, a fixture assigned a DMX address of 1 may be placed
anywhere in a DMX line: at the beginning, at the end, or anywhere in the middle. When a fixture is
assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that
unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation): The UB 6H can be controlled via
DMX-512 protocol. The UB 6H has 4 DMX channel modes; please see the Channel Mode sections of
this manual for the different modes. Your unit and your DMX controller require a standard 3-pin XLR
connector for data input and data output (Figure 1). We recommend Accu-Cable DMX cables. If you
are making your own cables, be sure to use standard 110-120 Ohm shielded cable (This cable may
be purchased at almost all pro lighting stores). Your cables should be made with a male XLR connec-
tor at one end of the cable and a female XLR connector at the other. Also remember that DMX cable
must be daisy chained and cannot be split.

ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 8
Notice: Be sure to follow figures two and three when making your own cables. Do not use the ground
lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug or allow the
shield conductor to come into contact with the XLR cable’s outer casing. Grounding the shield could
cause a short circuit and result in erratic behavior.
Special Note: Line Termination. When longer runs of cable are used, you may need to use a ter-
minator on the last unit to avoid erratic behavior. A terminator is a 110-120 ohm 1/4 watt resistor
which is connected between pins 2 and 3 of a male XLR connector (DATA + and DATA -). This unit is
inserted in the female XLR connector of the last unit in your daisy chain to terminate the line. Using a
cable terminator (ADJ part number Z-DMX/T) will decrease the chances of erratic behavior.
5-Pin XLR DMX Connectors. Some manufacturers use 5-pin DMX-512 data cables for DATA trans-
mission in place of 3-pin. 5-pin DMX fixtures may be implemented in a 3-pin DMX line. When insert-
ing standard 5-pin data cables into a 3-pin line, a cable adaptor must be used. These adaptors are
readily available at most electronics stores. The chart below details a proper cable conversion.
UB 6H DMX Set Up

ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 9
UB 6H Operating Instructions
LED Display On/Off:
To set the LED display to turn off after 10 seconds of inactivity, press the MODE button until “don” is
displayed, then press the UP button until “doff” is displayed on the screen. Now the display will turn
off after 10s. Press any button to turn the display on again.
LED Display Inversion:
Follow these instructions to flip the display 180° so that the display can be read when the unit is
mounted upside down.
1. Plug the fixture in and press the MODE button until “dXX” is displayed. “XX” represents either
“on” or “oFF”.
2. Press the SET UP button until “Stnd” is displayed.
3. Press the UP or DOWN buttons to “flip” the display 180°.
Operating Modes:
The UB 6H has six operating modes:
• Static Color Mode - There are 63 colors to choose from.
• RGBWA+UV Dimmer Mode - Choose one of the 6 colors to remain static, or adjust the intensity
of each color to create a custom color.
• Built-In Program - There are 22 built-in programs to choose from with multiple adjustments.
• Auto Run - An auto program will run with adjustable fade speed and strobe.
• Sound-Active mode - The unit will react to sound, chasing through the built in programs.
• DMX control mode - This function will allow you to control each DMX trait with a standard DMX
512 controller.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLXX” is displayed.
2. There are 63 colors to choose from. Select your desired color by pressing the UP and DOWN
buttons. After you have selected your desired color you can activate strobing by pressing the
SET UP button to enter the Flash (strobe) mode.
3. “FS.XX” will now be displayed, indicating that the device is now in Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).

ADJ Products, LLC - www.adj.com - UB 6H User Manual Page 10
UB 6H Operating Instructions
RGBWA & UV Dimmer Mode:
1. Plug the fixture in and press the MODE button until “r.XXX” is displayed. You are in Red dimming
mode.
2. Press the UP and DOWN buttons to adjust intensity. After you have finished adjusting the inten-
sity, or if you would like to skip to the next color, press the SET UP button.
3. When “G.XXX” is displayed you are in Green dimming mode. Press the UP and DOWN buttons to
adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press the UP and DOWN buttons to
adjust intensity.
5. When “U.XXX” is displayed you are in White dimming mode. Press the UP and DOWN buttons to
adjust intensity.
6. When “A.XXX” is displayed you are in Amber dimming mode. Press the UP and DOWN buttons to
adjust intensity.
7. When “u.XXX” is displayed you are in UV dimming mode. Press the UP and DOWN buttons to
adjust intensity.
8. After you have adjusted the colors to make your desired color you can then activate strobing by
pressing the SET UP button to enter the strobe mode.
9. “FSXX” will be displayed, indicating that the device is now in strobe mode. The strobe can be
adjusted between “00” (flash off) to “15” (fastest flash).
Auto Run Mode:
In this mode the fixture will run an auto program.
1. Plug the fixture in and press the MODE button until “AUTO” is displayed.
2. After you have activated Auto Run mode, press the SET UP button to adjust the fade time.
3. Once you press SET UP “Fd.XX” should be displayed. Use the UP or DOWN buttons to set the
fade speed to either “Fd.00” (fade off) or between “Fd.01” (fastest speed) and “Fd.99” (slowest
speed). After adjusting the fade speed, press SET UP if you wish to activate the Flash mode.
4. “FS.XX” will now be displayed, indicating that the device is now in Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
