ADJ ACCU-STAND LTS2 AS User manual

LTS2 AS
User Manual

2
Date Document
Version
Software
Version DMX Channels Notes
07/25/2023 1.0 N/A N/A Initial release
©2023 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying product
names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes
all forms and matters of copyrightable materials and information now allowed by statutory or judicial
law or hereinafter granted. Product names used in this document may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged. All non-ADJ Products, LLC
brands and product names are trademarks or registered trademarks of their respective companies.
ADJ Products, LLC and all afliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as a
result of the improper, unsafe, insufcient and negligent assembly, installation, rigging, and operation
of this product.
ADJ PRODUCTS LLC World Headquarters
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
Tel: [phone] | Fax: [phone] | www.adj.com |[email protected]
ADJ Supply Europe B.V.
Junostraat 2 | 6468 EW Kerkrade | Netherlands
Tel: [phone] | Fax: [phone] | www.adj.eu | [email protected]
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the environment. Please turn off all electrical products
when they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment
from power when not in use. Thank you!
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of this
document may be available online.
Please check www.adj.com for the latest revision/update of this manual before
beginning installation and/or programming.

3
Gen Info 4
Limited Warranty (USA Only) 5
Safety Guidelines 6
Overview 7
Installation Instructions 8
Trouble Shooting | Frequently Asked Questions 11
Specifications | Optional Accessories 12
Dimensional Drawings 13
CONTENTS

4
GENERAL INFORMATION
INTRODUCTION
Please read and understand the instructions in this manual carefully and thoroughly before attempting
to operate this device. These instructions contain important safety and use information.
UNPACKING
The products in this kit have been thoroughly tested and have been shipped in perfect operating
condition. Carefully check the shipping carton for damage that may have occurred during shipping. If
the carton is damaged, carefully inspect the device for damage, and be sure all accessories necessary
to install and operate the device have arrived intact. In the event that damage has been found or parts
are missing, please contact our customer support team for further instructions. Please do not return
this device to your dealer without rst contacting customer support. Please do not discard the shipping
carton in the trash. Please recycle whenever possible.
WARRANTY RETURNS
All returned service items, whether under warranty or not, must be freight pre-paid and accompanied
by a return authorization (R.A.) number. The R.A. number must be clearly written on the outside of
the return package. A brief description of the problem as well as the R.A. number must also be written
down on a piece of paper and included in the shipping container. If the unit is under warranty, you must
provide a copy of your proof of purchase invoice. Items returned without an R.A. number clearly marked
on the outside of the package will be refused and returned at customer’s expense. You may obtain an
R.A. number by contacting customer support.
CUSTOMER SUPPORT
Contact ADJ Service for any product related service and support needs.
Also visit forums.adj.com with questions, comments or suggestions.
ADJ SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
323-582-2650 | Fax: [phone] | [email protected]
ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
[phone] | Fax: [phone] | [email protected]
REPLACEMENT PARTS please visit parts.adj.com
IMPORTANT NOTICE!
THIS UNIT CONTAINS NO USER SERVICEABLE COMPONENTS. DO NOTATTEMPT ANY REPAIRS
YOURSELF, AS DOING SO WILL VOID YOUR MANUFACTURER’S WARRANTY. DAMAGES
RESULTING FROM MODIFICATIONS TO THIS DEVICE AND/OR THE DISREGARD OF SAFETY
INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID THE MANUFACTURER’S WARRANTY
AND ARE NOT SUBJECT TO WARRANTY CLAIMS AND/OR REPAIRS.

5
LIMITED WARRANTY (USA ONLY)
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing
defects in material and workmanship for a prescribed period from the date of purchase (see specic warranty period
on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including
possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service, you must obtain a Return Authorization number (RA#) before sending back the product-please
contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Products, LLC
factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are
within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within
the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be
shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability
whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void of the serial number has been altered or removed; if the product is modied in any manner which
ADJ Products, LLC concludes, after inspection, affects the reliability of the product, if the product has been repaired or
service by anyone other than ADJ Products, LLC factory unless prior written authorization was issued to purchaser by
ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contact, and this warranty does not include maintenance, cleaning or periodic check up. During
the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts,
and will absorb all expenses for warrant service and repair labor by reason of defects in material or workmanship. The
sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement
thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were
manufactured after August 15, 2012, and bear identifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products without any
obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products
described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC
in connection with this product, including warranties of merchantability or tness, are limited in duration to the warranty
period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or
tness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be
liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to ADJ Products, LLC Products and supersedes all prior warranties
and written descriptions of warranty terms and conditions heretofore published.
LIMITED WARRANTY PERIODS
• Non L.E.D. Lighting Products = 1-year (365 days) Limited Warranty (Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc.
excluding LED and lamps)
• Laser Products = 1 Year (365 Days) Limited Warranty (excludes laser diodes which have 6 month limited warranty)
• L.E.D. Products = 2-year (730 days) Limited Warranty (excluding batteries which have a 180 day limited warranty)
Note: 2 Year Warranty only applies to purchases within the United States.
• StarTec Series = 1 Year Limited Warranty (excluding batteries which have a 180 day limited warranty)
• ADJ DMX Controllers = 2 Year (730 Days) Limited Warranty

6
SAFETY GUIDELINES
To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. ADJ
PRODUCTS LLC is not responsible for injury and/or damages resulting from the misuse of these devices due
to the disregard of the information printed in this manual. Only qualied and/or certied personnel should per-
form installation of these devices and only the original rigging parts included with these devices should be used
for installation. Any modications to these devices and/or the included mounting hardware will void the original
manufacturer’s warranty and increase the risk of damage and/or personal injury.
THERE ARE NO USER SERVICEABLE PARTS INSIDE THESE DEVICES.
DO NOT ATTEMPT ANY REPAIRS YOURSELF, AS DOING SO WILL VOID YOUR MANUFAC-
TURER’S WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS TO THIS STAND
AND/OR THE DISREGARD OF SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL
VOID THE MANUFACTURER’S WARRANTY AND ARE NOT SUBJECT TO ANY WARRANTY
CLAIMS AND/OR REPAIRS.
NEVER SET UP OR INSTALL STAND ON UNEVEN SURFACE!
NEVER INSTALL OR MOUNT STAND IN UNSTABLE LOCATIONS!
SPREAD THE LEGS UNTIL THE STAYS EXTEND HORIZONTALLY!
NEVER REMOVE THE SAFETY PIN WHEN THE A KNOB IS LOOSE!
BE CAREFUL NOT TO OVEREXTEND THE INNER PIPE!
KEEP FLAMMABLE MATERIALS AWAY FROM THE STAND
MAX LOAD CAPACITY PER STAND IS 132.3 LBS. (60 KGS)
INDOOR / DRY LOCATIONS USE ONLY!
DO NOT EXPOSE DEVICES TO RAIN AND/OR MOISTURE!
WHEN USING STAND OUTSIDE UNDER STRONG WIND, TAKE APPROPRIATE MEASURES
TO AVOID TIPPING!
TIGHTEN EACH KNOB AND BOLT SECURELY!
AVOID USING BRUTE FORCE WHEN INSTALLING.
ONLY USE RECOMMENDED RIGGING HARDWARE AS DESCRIBED IN THIS GUIDE.
USE THE ORIGINAL PACKAGING AND MATERIALS TO TRANSPORT FOR SERVICE.
DO NOT POSITION STAND CLOSE TO ANY FLAMMABLE MATERIALS WHILE OPERATING.
DO NOT ATTEMPT INSTALLATION OF STAND IF YOU LACK THE RELEVANT KNOWLEDGE
OR EXPERTISE.

7
OVERVIEW
INCLUDED ITEMS
• LTS2 AS stand (x1)
• T-Bar (x1)
• Support Bar (x2)
1. Knob A
2. Knob B
3. Knob C
4. Knob D
5. Stay
6. Leg
7. Outer Pipe
8. Inner Pipe
9. Inlet Pipe
10.Support Bar
11. T-Bar
1
2
8
4
7
10
9
3
5
6
11

8
INSTALLATION INSTRUCTIONS
AVOID INSTALLING OR MOUNTING THE STAND IN UNSTABLE LOCATIONS, SUCH AS AN UN-
EVEN SURFACE OR MOVING TABLE. DOING SO MAY CAUSE THE STAND TO TIP OVER AND
CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE.
WHEN USING THE STAND OUTSIDE UNDER STRONG WIND, TAKE APPROPRIATE MEASURES
TO PREVENT THE STAND FROM TIPPING OVER.
TIGHTEN EACH KNOB AND BOLT SECURELY. ENSURE THAT THE BRACKET HAS NO LOOSE
KNOBS OR JOINTS AFTER INSTALLATION TO PREVENT ACCIDENTS AND/OR INJURY.
AVOID PLACING THE STAND IN A DOORWAY OR OTHER HIGH TRAFFIC AREAS AS PEOPLE
MAY TRIP ON THE EQUIPMENT AND CORDS, OR BE INJURED BY FALLING OBJECTS.
TAKE CARE NOT TO PINCH YOUR FINGERS OR HANDS BETWEEN THE STAND LEGS.
NEVER STAND DIRECTLY BELOW THE DEVICES WHEN MOUNTING, REMOVING OR SERVIC-
ING.
DEVICES MUST ALL BE INSTALLED FOLLOWING ALL LOCAL, NATIONAL, AND COUNTRY
COMMERICAL ELECTRICAL AND CONTRUCTION CODES AND REGULATIONS.
DO NOT EXCEED WEIGHT CAPACITY OF 132.3 LBS (60 KGS) PER STAND (WHEN EVENLY
DISTRIBUTED).
FLAMMABLE MATERIAL WARNING
Keep stand minimum 5.0 feet (1.5m) away from ammable materials and/or pyrotechnics.
DO NOT INSTALL/HANG DEVICES ON STAND IF YOU ARE NOT QUALIFIED TO DO SO!

9
INSTALLATION INSTRUCTIONS
SETUP
Loosen Knob D by turning it counter clockwise. Spread the legs by pulling up on the outer pipe until
the stays extend horizontally.
Loosen Knob C by turning it counter clockwise. Extend the inner pipe to the desired height and insert
the safety pin through the stopper holes in the inner pipe. Secure and tighten Knob C by turning it
clockwise. Repeat this process to set the desired height for inlet pipe as well.

10
INSTALLATION INSTRUCTIONS
MOUNTING THE T-BAR
The stand comes with a T-Bar for mounting optional lighting and other equipment. To install the T-Bar,
vertically align the Support Bars with the T-Bar connection. Lower the T-Bar onto the inner pipe and
tighten Knob A to secure T-Bar to stand.
MOUNTING OPTIONAL LIGHTING AND OTHER ACCESSORIES
Lighting and other optional accessories may be mounted to the T-Bar. For installation instructions,
please refer to the mounting instructions provided with the unit that is to be installed.
Note: The stand has a maximum capacity of 132.3 lbs. (60 kg)
*Lights not
included.

11
TROUBLE SHOOTING
The stand is unstable.
• Check to ensure that all knobs and hardware are tight and secure.
• Reposition the stand if it is located in an unsuitable location (uneven or unstable surface).
• Additional measures (i.e. sandbags or security cables) may be needed to secure the stand.
The T-Bar does not stay at the desired height.
• Check to ensure that all knobs and hardware are tight and secure.
• Check to ensure that the safety pin is installed and set in place.
FREQUENTLY ASKED QUESTIONS
What is the diameter of the inner pipe?
The pipe diameter is 1.5 in (38 mm).
What is weight capacity of the stand?
The sand has a capacity of stand is 132.3 lbs. (60 kg).
What is the diameter of the T-Bar?
The T-Bar has an outer diameter of 1.5” (38 mm).
What is the maximum height of the stand?
The maximum height of the stand is 128” (3,250 mm).
Are additional stands, clamps or accessories available?
Yes. A variety of stands and accessories are available at www.adj.com.

12
SPECIFICATIONS
• Black high quality aluminum tripod stand
• Single T-bar with mounting hardware
• Tripod extends to 12 ft. (includes support bars)
• Collapses down for easy transport
• Ideal for mobile DJs and bands
• T-Bar Diameter: 1.5-inch
• Maximum load capacity 80 lbs. evenly distributed
• Weight: 12 lbs
OPTIONAL ACCESSORIES
ORDER CODE DESCRIPTION
LTS200 LTS2 AS
OSL587 O Slim 2 Clamp (Pearl)
OSL150 O Slam 1.5 Clamp 80 lbs. / 36 kg

13
DIMENSIONAL DRAWINGS
Specifications subject to change without any prior written notice.
128”
3,250 mm
Ø 70”
Ø 1,778.2 mm
73.3”
1,861.2 mm
47.2”
1,200 mm
