Introduction 1
1 Introduction
In order to increase the available functions on the PCI-8154/58 4-
axis/8-axis pulse train output control channel carrier board,
ADLINK offers four daughter boards providing a variety of func-
tions. These DB-815x daughter boards can only be used with the
PCI-8154/58 carriers only. Additional functionality provided by the
DB-815x series includes high-speed triggering and distributed I/O
control. Daughter boards can be added based on application
requirements. The four daughter boards in the DB-815x series
are:
The DB-8151 offers an HSL (High Speed Link) system for distrib-
uted I/O on the PCI-8154/58. HSL is an innovative distributed I/O
Model Name Primary Function Description
DB-8150 High Speed Trigger Out
XHigh speed trigger pulse out
up to 1 MHz
XSimultaneous 8 differential
trigger output
X2 channels encoder input
(from external I/F or carrier.
FIFO/Linear function com-
pared trigger output
DB-8151 HSL Master Controller XHigh Speed Link for distrib-
uted I/O
DB-8152 ECAM Controller
X2 channel encoder input
(Master & slave)
XMaster/Slave controller
XEasytoimplement electronic
cam behavior
DB-8153 Motionnet Master Controller
XSerial single axis motion
control bus
XDoes not support I/O func-
tion
Table 1-1: DB-815x Series

2 Introduction
technology which allows thousands of I/O points to be scanned at
the millisecond-level in real time by using mater-slave architec-
ture. Commercial Ethernet cables with RJ45 connector are used
for simplified setup of the HSL slaves modules as close as possi-
ble to sensor devices, again, resulting in a dramatic reduction of
wiring. System integrators can benefit from HSL network because
it integrates discrete I/O, and analog I/O. This local network fea-
tures rapid response, real-time scanning. Integration of multi-axis
operations can also be accomplished with the DB-8151 module as
the HSL architecture is ready to use on a parallel multi-axis con-
troller.

Introduction 3
HSL is ideal for:
XDistributed solutions based on a multi-axis controller archi-
tecture
XDaughter board solutions making the motion system config-
uration more flexible and compact.
XSimpler wiring for remote I/O, including discrete I/O and
analog I/O modules
XA vast number of discrete I/O points (hundreds or more)
XReal-time and fast scanning
XHigh speed data acquisition
The block diagram of the DB-8151 is as follows.

4 Introduction
Figure 1-1: Block Diagram of the DB-8151
PCI-8154/58 Local bus
HSL Master
Transformer
TX
RX
HSL Potocol
FPGA

Introduction 5
1.1 Specifications
Interface
XFor use with the PCI-8154 and PCI-8158 PCI cards only
XThe DB-8151-RJ45 must also be used when using the DB-
8151
Master Controller
XHSL ASIC master control
X48 MHz external clock
Interface
XRS-485 with transformer isolation
XFull duplex communication
X3/6/12 Mbps transmission rate can be set by software (6
Mbps default)
Connector
XRJ45 connector x 2
Interrupt
XStatus read back
LED Indicator
XLink status
Dimension
X96.42 (L) x 62 (W) mm
Operating Temperature
X0 to 60°C
Storage Temperature
X-20 to 80°C
Power Consumption
X+3.3V @ 250 mA (typical)
X+5V @100 mA (typical)

6 Introduction
1.2 Supported Software
Program Library
ADLINK provides a Windows WDM driver and DLL function library
for the DB-8151. These function libraries are shipped with the
board and supports Windows 2000/XP.

Installation 7
2 Installation
This chapter describes how to install the DB-8151. Please follow
these steps below:
XCheck what you have (Section 2.1, page 7)
XCheck the PCB (Section 2.2, page 8)
XInstall the hardware (Section 2.3, page 10)
XInstall the software driver (Section 2.4, page 12)
XUnderstanding the I/O signal connections (Chapter 3, page
17) and their operations (Chapter 4, page 43)
2.1 Package Contents
In addition to this User’s Guide, the package also includes the fol-
lowing items:
XDB-8151: HSL Master control board x1
XDB-8151-RJ45: HSL interface board x1
XCopper Pillar x4
XScrews x8
X10 Pin Flat Cable x1
If any of these items are missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping materi-
als and carton to ship or store the product in the future.

8 Installation
2.2 DB-8151 and DB-8151-RJ45 Outline Drawing
Figure 2-1: DB-8151 PCB Layout
DB-8151:
XCN1, CN2: Daughter board connectors for the PCI-8154/58
XCN3: Main signal connector
CN2
CN1
CN3
62
96.42

Installation 9
Figure 2-2: DB-8151-RJ45 PCB Layout
DB-8151-RJ45:
XRJ1: Main HSL master controller connector
XCN1: Link to DB-8151
RJ1
CN1
106.68
46.42

10 Installation
2.3 DB-8151 Hardware Installation
2.3.1 Hardware configuration
DB-8151 must be installed on to a PCI-8154 or PCI-8158 only.
Please ensure correct orientation of the DB-8151 before it attach-
ing it to the PCI-8154 or PCI-8158.
2.3.2 Installation Procedures
Please follow installation procedure as follows.
Daughter Board Installation
1. Attach the DB-8151 on to the PCI-8154 or PCI-8158.
Please ensure correct orientation of the DB-8151 daugh-
ter board.
2. Screw the eight screws into the corresponding copper
pillars.
3. Connect the DB-8151 and DB-8151-RJ45 with the 10-
pin flat cable.
Figure 2-3: Board Configuration

Installation 11
Carrier Board Installation
4. Turn off the computer. Turn off all accessories (printer,
modem, monitor, etc.) connected to the computer.
Remove the cover from the computer.
5. Select one available 32-bit PCI expansion slot with a
neighboring open slot for the DB-8151-RJ45. PCI slots
are shorter than ISA or EISA slots and are usually white
or ivory.
6. Before handling the PCI-8154 or PCI-8158 with DB-8151
and DB-8151-RJ45, discharge any static buildup on your
body by touching the metal case of the computer. Hold
the edge of the card and do not touch the components.
7. Plug the PCI-8154/58 with DB series vertically down into
the PCI slot, and then secure the PCI-8154/58 bracket
and DB-8151-RJ45 bracket onto rear panel.
2.3.3 Troubleshooting:
If the system doesn’t boot or if any erratic behavior of the PCI
board is experience, it is most likely caused by an interrupt conflict
(possibly an incorrect ISA setup). The solution, once determined it
is not a simple oversight, is to consult the BIOS documentation
that comes with your system.
Check the control panel of the Windows system if the card is listed
by the system. If not, check the PCI settings in the BIOS or use
another PCI slot.

12 Installation
2.4 Software Driver Installation
Execute the following steps:
1. Auto-run the ADLINK All-In-One CD.
2. Follow the procedures of the installation wizard.
3. After setup installation has completed, reboot the sys-
tem.
