ADLINK Technology NuPRO-E330 User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.01
Revision Date: January 6, 2011
Part No: 50-13066-1010
NuPRO-E330
Full-Size PICMG 1.3 Intel® Core™ i7/i5/i3
Q57 Express Chipset SHB
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 2010/05/28 Initial Release
2.01 2011/01/06
Update specifications: memory, temperature,
OS support; delete IDE, Turbo Boost; correct
dimensions, Floppy/Parallel connector layout,
graphics card driver path

Preface iii
NuPRO-E330
Preface
Copyright 2010-2011 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The NuPRO-E330 User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade single board computers.
Manual Organization
This manual is organized as follows:
Preface: Presents important copyright notifications, disclaimers,
trademarks, and associated information on the proper understand-
ing and usage of this document and its associated product(s).
Chapter 1, Introduction: Introduces the NuPRO-E330, its fea-
tures, applications, and specifications, including functional
descriptions and board layout.
Chapter 2, Hardware Information: Provides technical informa-
tion on connectors and jumpers for configuring the NuPRO-E330.
Chapter 3, Getting Started: Illustrates how to install components
on the NuPRO-E330 such as CPU, heatsink, and memory mod-
ules.
Chapter 4, Driver Installation: Provides information on how to
install the NuPRO-E330 device drivers.
Chapter 5, BIOS Setup: Describes basic navigation for the
AMIBIOS®8 BIOS setup utility.
Appendix A, Watchdog Timer: Presents information on imple-
menting the watchdog timer.
Appendix B, System Resources: Presents information on I/O
mapping, IRQ routing, and resource allocation.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
NuPRO-E330
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents vii
NuPRO-E330
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Specifications....................................................................... 3
1.4 Block Diagram ..................................................................... 5
1.5 Functional Description ......................................................... 6
1.6 Mechanical Drawing ............................................................ 9
1.7 I/O Connectivity ................................................................. 10
1.8 Power Consumption .......................................................... 11
1.9 Package Contents ............................................................. 14
2 Hardware Information...................................................... 15
2.1 Rear Panel I/O Ports.......................................................... 15
2.2 Board Layout ..................................................................... 18
2.3 Onboard Connectors ......................................................... 19
2.4 Jumpers............................................................................. 25
3 Getting Started ................................................................. 27
3.1 Installing the CPU.............................................................. 27
3.2 Installing the CPU Fan and Heatsink................................. 31
3.3 Installing Memory Modules................................................ 32
4 Driver Installation............................................................. 35
4.1 Intel® Q57 Express Chipset Driver.................................... 35

viii Table of Contents
4.2 Display Driver..................................................................... 36
4.3 Ethernet Driver................................................................... 37
4.4 Intel® Rapid Storage Technology...................................... 37
4.5 Intel® Active Management Technology............................. 37
4.6 TPM Driver......................................................................... 38
4.7 Audio Driver....................................................................... 38
5 BIOS Setup........................................................................ 39
5.1 Starting the BIOS............................................................... 39
5.2 Main Setup......................................................................... 43
5.3 Advanced BIOS Setup....................................................... 44
5.3.1 CPU Configuration.........................................................45
5.3.2 IDE Configuration ..........................................................47
5.3.3 Super IO Configuration..................................................48
5.3.4 Hardware Health Configuration .....................................49
5.3.5 ACPI Settings ................................................................52
5.3.6 AHCI Configuration........................................................53
5.3.7 Remote Access Configuration .......................................54
5.3.8 Trusted Computing ........................................................56
5.3.9 USB Configuration.........................................................57
5.4 PCI/PnP Settings............................................................... 59
5.4.1 IRQ/DMA .......................................................................59
5.5 Boot Settings ..................................................................... 60
5.5.1 Boot Settings Configuration...........................................60
5.5.2 Boot Device Priority.......................................................62
5.5.3 Boot Device Groups.......................................................62
5.6 Security Setup.................................................................... 63
5.7 Chipset Setup .................................................................... 65
5.7.1 Graphics and Memory Configuration.............................66
5.7.2 PCH Configuration.........................................................68
5.7.3 Management Engine Subsystem...................................69
5.8 Exit Menu........................................................................... 72

Table of Contents ix
NuPRO-E330
A Appendix: Watchdog Timer..............................................75
A.1 Sample Code..................................................................... 75
B Appendix: System Resources..........................................79
B.1 System Memory Map......................................................... 79
B.2 Direct Memory Access Channels....................................... 79
B.3 IO Map............................................................................... 80
B.4 Interrupt Request (IRQ) Lines............................................ 81
Important Safety Instructions.............................................. 87
Getting Service...................................................................... 89

xTableofContents
This page intentionally left blank.

List of Figures xi
NuPRO-E330
List of Figures
Figure 1-1: NuPRO-E330 Block Diagram ..........................................5
Figure 1-2: NuPRO-E330 Board Dimensions ....................................9
Figure 2-1: Rear Panel I/O Ports......................................................15
Figure 2-2: Connectors and Jumpers...............................................18

xii List of Figures
This page intentionally left blank.

List of Tables xiii
NuPRO-E330
List of Tables
Table 1-1: NuPRO-E330 General Specifications..............................4
Table 1-2: NuPRO-E330 I/O Connectivity ......................................10
Table 1-3: Core™ i7-860 Processor Power Consumption..............11
Table 1-4: Core™ i3-540 Processor Power Consumption..............12
Table 1-5: Pentium® G6950 Processor Power Consumption ........13
Table B-1: System Memory Map.....................................................79
Table B-2: Direct Memory Access Channels...................................79
Table B-3: IO Map...........................................................................80
Table B-4: IRQ Lines PIC Mode......................................................81
Table B-5: IRQ Lines APIC Mode...................................................83
Table B-6: PCI Configuration Space Map.......................................85
Table B-7: PCI Interrupt Routing Map.............................................86

xiv List of Tables
This page intentionally left blank.

Introduction 1
NuPRO-E330
1 Introduction
1.1 Overview
The ADLINK NuPRO-E330 is a PICMG 1.3 System Host Board
(SHB) supporting the next-generation Intel® Core™ i7/i5/i3 and
Pentium® processors in LGA1156 package to deliver a scalable
high performance platform for a wide array of industrial
applications. The NuPRO-E330 supports 32nm and 45nm process
CPUs at up to 3.33GHz with integrated graphics and memory
controllers, Direct Media Interface (DMI) and Flexible Display
Interface (FDI) connectivity to the Intel® Q57 Express Chipset.
Dual-channel DDR3 1066/1333 MHz memory is supported up to a
maximum of 8 GB in two DIMM slots.
These advanced features, coupled with PCI Express® x16 expan-
sion capability, dual PCI Express®-based Gigabit Ethernet, PCI
Express Mini Card slot and diverse I/O and storage make the
NuPRO-E330 ideal for instrumentation and automation control
applications.

2Introduction
1.2 Features
XSupports Intel® Core™ i7/i5/i3 and Pentium® processors in
LGA1156 package
XIntegrated Intel® HD Graphics on dual core 32nm (Clarkdale)
processors
XPCI Express® x16 expansion capability via backplane
XPCI Express Mini Card slot
XDual Gigabit Ethernet
X9x USB 2.0 ports (1x on bracket, 4x onboard, 4x on backplane)
X6x SATA 3 Gb/s ports (4x onboard, 2x on backplane)
X6x COM ports (including 1x RS-232/422/485/485+)
XWatchdog Timer, Hardware Monitor
XOptional HD audio kit (DB-Audio2 daughter board)
XTPM hardware security chip
XRoHS compliant
NOTE:
NOTE:
To purchase the optional DB-Audio2 daughter board, please
contact your ADLINK sales representative.

Introduction 3
NuPRO-E330
1.3 Specifications
System
CPU
Intel® Core™ i7/i5/i3 and Pentium® Dual Core processors
in LGA1156 package:
• Intel® Core™ i7-860 Processor, 2.80 GHz, 8M Cache,
45nm, 95W, 4 cores/8 threads
• Intel® Core™ i5-750 Processor, 2.66 GHz, 8M Cache,
45nm, 95W, 4 cores/4 threads
• Intel® Core™ i5-660 Processor, 3.33 GHz, 4M Cache,
32nm, 73W, 2 cores/4 threads, HD Graphics
• Intel® Core™ i3-540 Processor, 3.06 GHz, 4M Cache,
32nm, 73W, 2 cores/4 threads, HD Graphics
• Intel® Pentium® G6950 Processor, 2.80 GHz,
3M Cache, 32nm, 73W, 2 cores/2 threads, HD Graphics
Chipset • Intel® Q57 Platform Controller Hub
Memory • Two 240-pin DIMM sockets support dual-channel
1066MHz DDR3 (up to 8 GB)
BIOS • AMI BIOS in 32-Mbit SPI Flash
Audio • Intel® High Definition Audio support via DB-Audio2
daughter board
Watch Dog Timer • 1-255 second or 1-255 minute programmable and can
generate system reset.
Hardware
Monitor • CPU/System temperature, fan speed and onboard DC voltage
TPM • Infineon SLB 9635 TT 1.2
Operating
Systems • Windows® XP, Vista 32/64-bit, 7 32/64-bit,Server 2008; Fedora™ 10

4Introduction
Table 1-1: NuPRO-E330 General Specifications
I/O Interfaces
Serial ATA • 6x SATA 3 Gb/s ports (4x onboard, 2x on backplane)
I/O Ports
• 1x USB 2.0 port on rear panel, 4x via onboard header, 4x
via backplane
• 6x serial ports via onboard pin-header
(5x RS-232, 1x RS-232/422/485/485+)
• 2x Gigabit Ethernet RJ45 ports
• 1 VGA port (Dsub-15)
• PS/2 Keyboard/Mouse (Mini-DIN 6-pin)
• 1 Parallel port
• 1 Floppy port
PCIe/PCI • PCIe-x16, PCIe-x4 and PCI 32bit/33MHz via golden fingers
• PCI Express Mini Card slot
Display
Integrated
Graphics • Integrated Intel® HD Graphics on dual core 32nm (Clarkdale) processors
External
Graphics • PCI Express x16 or onboard PCI Express Mini Card slot for optional mPCIe-8770
Ethernet
Controller
• Dual Gigabit Ethernet (Intel® 82578DM Gigabit Ethernet
PHY, Intel® 82574L Gigabit Ethernet Controller)
• Supports Preboot Execution Environment (PXE),
Wake-On-LAN, and Intel® AMT 6.0 on LAN1 (82578DM)
Ports • Two RJ-45 Ethernet ports
Mechanical and Environment
Form Factor • Standard full-size PICMG 1.3 SHB
Dimensions • 338 x 126 mm (L x W)
Operating Temp. • 0ºC to 60ºC
Storage Temp. • -20ºC to 80ºC
Relative Humidity • 10% to 90% non-condensing
Safety • CE, FCC Class A

Introduction 5
NuPRO-E330
1.4 Block Diagram
Figure 1-1: NuPRO-E330 Block Diagram
BIOS
PCH
Q57
CPU
Core i7/i5/i3
Pentium G6950
FDI
SPI
PCIe
Controller
SATA
DDR3
Memory
Controller
PCIe x16
PCI
Controller
USB
2.0
HDA Audio
TPM
LPC
DMI
VGA
DDR3 DIMM
1066/1333
Channel A
Integrated
HD Graphics
DDR3 DIMM
1066/1333
Channel B
PCIe x16
CRT
DB-15 PCI
32-bit/33MHz
KB/Mouse
LPT/FDD
RS-232
RS-232/
422/485/485+
ITE IT8783F
Super I/O
4x PCIe x1
to backplane
PCIe
Mini Card
PCIe x1
PCIex1
Intel 82578DM
Intel 82574L
Header for
DB-Audio2
USB 2.0
(1x bracket, 4x onboard,
4x backplane)
SATA ports
(4x onboard, 2x backplane)
LPC

6Introduction
1.5 Functional Description
Processor Support
The NuPRO-E330 is a single processor design for the latest Intel
Clarkdale (32nm) and Lynnfield (45nm) processors in LGA1156
socket (Intel® Core™ i7/i5/i3, Pentium® G6950). An integrated
memory controller supports dual channel 1066/1333 MHz DDR3
and integrated Intel® HD Graphics is supported on dual core
32nm (Clarkdale) processors. The CPU provides a PCI Express
x16 for external graphics or expansion. Direct Media Interface
(DMI) and Flexible Display Interface (FDI) provide connectivity to
the Intel® Q57 Express Chipset.
Intel® Q57 Express Chipset
The Intel® BD82Q57 Platform Controller Hub (PCH) combines
with the processor to provide a compact yet powerful 2-chip solu-
tion. Direct Media Interface (DMI) is the chip-to-chip connection
between the processor and PCH. Intel® Flexible Display Interface
carries display traffic from the integrated graphics in the processor
to the legacy display connectors in the PCH. The PCH supports all
other required interfaces including PCI Express, Serial ATA, USB
2.0, PCI, LPC, and SPI.
Dual-Channel DDR3 Memory
To meet the requirements of memory-intensive applications, the
NuPRO-E330 has a dual-channel memory architecture supporting
DDR3 1066/1333 MHz DIMMs. The key advantages of DDR3 are
the higher bandwidth and the increase in performance at lower
power than DDR2. DDR3 memory technology meets the require-
ments of the latest 3D graphics, multimedia, and network applica-
tion, and boosts system performance by eliminating bottlenecks.
Gigabit Ethernet
The NuPRO-E330 utilizes an Intel® 82578DM Gigabit Ethernet
PHY and Intel® 82574L Gigabit Ethernet Controller connected to
the PCI-E bus of the Q57 PCH. Intel® AMT 6.0 (82578DM on
LAN1), Wake-on-LAN and PXE are supported.
