ADLINK Technology AmITX-SL-G User manual

AmITX-SL-G
User’s Manual
Mini-ITX Embedded Motherboard with
6th and 7th Gen Intel® Core™ i7/i5/i3 Processors
and Intel® Q170/H110 Chipset
Manual Rev.: 1.1
Revision Date: September 17, 2018
Part Number: 50-1J070-1010

ii Preface
Preface
Copyright
Copyright 2017, 2018 ADLINK Technology, Inc. This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other
means in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in order to improve reliability, design, and
function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer
be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global environmental preservation
through compliance with the European Union's Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have enforced measures to ensure that our
products, manufacturing processes, components, and raw materials have as little impact on
the environment as possible. When products are at their end of life, our customers are
encouraged to dispose of them in accordance with the product disposal and/or recovery
programs prescribed by their nation or company.
Battery Labels (for products with battery)
廢電池請回收
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene,
cadmium, Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Dioxane, formaldehyde, lead, DEHP,
styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause
cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP,
DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
Trademarks
Product names mentioned herein are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective companies.
Revision History
Revision Description Date By
1.00 Initial Release 2016-04-11 JC
1.1
Added 7th Gen CPUs; added power consumption values; updated BIOS; updated
manual format 2018-09-17 DA

AmITX-SL-G
Preface iii
Table of Contents
Preface................................................................................................................................ii
List of Figures ....................................................................................................................v
List of Tables.....................................................................................................................vi
1. Introduction................................................................................................................1
1.1. Packing List.....................................................................................................................1
1.2. Optional Accessories ......................................................................................................1
2. Specifications ............................................................................................................3
2.1. Core System ...................................................................................................................3
2.2. Rear I/O Connectors.......................................................................................................3
2.3. Internal Headers and Connectors...................................................................................4
2.4. Form Factor.....................................................................................................................4
2.5. SEMA Board Controller...................................................................................................4
2.6. Debug Header.................................................................................................................4
2.7. Video...............................................................................................................................5
2.8. Audio...............................................................................................................................5
2.9. LAN.................................................................................................................................5
2.10. Trusted Platform Module (TPM)......................................................................................5
2.11. Power Specification.........................................................................................................5
2.12. Temperatures..................................................................................................................8
2.13. Environmental.................................................................................................................8
2.14. Operating Systems..........................................................................................................8
2.15. Functional Block Diagram...............................................................................................9
3. Mechanical Layout ..................................................................................................11
3.1. Connector Locations.....................................................................................................11
3.2. Mechanical Dimensions................................................................................................12
3.3. Thermal Solutions.........................................................................................................13
4. Connectors and Jumpers .......................................................................................15
4.1. Rear IO Connectors......................................................................................................15
4.2. Internal Connectors.......................................................................................................17
4.3. Jumper and Switch Settings..........................................................................................28
4.4. Onboard Connector Information....................................................................................31
5. Driver Installation ....................................................................................................33
6. Smart Embedded Management Agent (SEMA) .....................................................35
6.1. Board Specific SEMA Functions...................................................................................35
7. System Resources ..................................................................................................39
7.1. System Memory Map....................................................................................................39
7.2. I/O Map .........................................................................................................................39
7.3. Interrupt Request (IRQ) Lines.......................................................................................40
7.4. PCI Configuration Space Map.......................................................................................42

iv Preface
7.5. PCI Interrupt Routing Map ............................................................................................43
7.6. SMBus Slave Address ..................................................................................................43
8. BIOS Setup...............................................................................................................45
8.1. Menu Structure..............................................................................................................45
8.2. Main ..............................................................................................................................46
8.3. Advanced......................................................................................................................52
8.4. Security.........................................................................................................................68
8.5. Boot...............................................................................................................................68
8.6. Save & Exit ...................................................................................................................70
Safety Instructions...........................................................................................................71
Getting Service.................................................................................................................72

AmITX-SL-G
Preface v
List of Figures
Figure 1: AmITX-SL-G Functional Block Diagram..................................................................................9
Figure 2: AmITX-SL-G Rear I/O...........................................................................................................11
Figure 3: AmITX-SL-G Component-Side Connectors ..........................................................................11
Figure 4: AmITX-SL-G Mechanical Dimensions...................................................................................12
Figure 5: Jumper and Switch Locations...............................................................................................28

vi Preface
List of Tables
Table 1: AmITX-SL-G Processors..........................................................................................................1
Table 2: AmITX-SL-G Onboard Connector Information .......................................................................31
Table 3: SEMA Onboard Voltage Monitor............................................................................................35
Table 4: SEMA BMC Status.................................................................................................................36
Table 5: SEMA Exception Codes.........................................................................................................36
Table 6: SEMA BMC Flags..................................................................................................................37
Table 7: System Memory Map.............................................................................................................39
Table 8: I/O Map..................................................................................................................................39
Table 9: IRQ Lines PIC Mode..............................................................................................................40
Table 10: IRQ Lines APIC Mode..........................................................................................................41
Table 11: PCI Configuration Space Map..............................................................................................42
Table 12: PCI Interrupt Routing Map ...................................................................................................43
Table 13: SMBus Slave Address.........................................................................................................43

AmITX-SL-G
Introduction 1
1. Introduction
The AmITX-SL-G is a Mini-ITX motherboard supporting the Desktop 6th and 7th Generation Intel® Core™ i7/i5/i3
and Pentium®/Celeron® Processor with Intel® Q170/H110 Chipset. The AmITX-SL-G is specifically designed for
customers who need high-level processing and graphics performance with a long product life solution.
The AmITX-SL-G features three DisplayPorts, dual Gigabit Ethernet ports, USB 3.0 ports, USB 2.0 ports, SATA 6
Gb/s ports, and High Definition Audio with 7.1 channels. Expansion is provided by one PCIe x16, one PCIe x1, and
two mini-PCIe slots. The onboard feature connector provides GPIO, SMBus, and I2C support. The board is
equipped with SPI AMI EFI BIOS, supporting embedded features such as hardware monitor and watchdog timer
Table 1: AmITX-SL-G Processors
Model Number Chipset
AmITX-SL-G-Q170 Q170
AmITX-SL-G-H110 H110
Latest revision of the datasheet, user’s manual, BIOS, drivers, and board support packages, can be downloaded
from the product webpage on the ADLINK web site: www.adlinktech.com
1.1. Packing List
•AmITX-SL-G Mini-ITX motherboard
•ATX/AT power cable (P/N: 30-20872-1000)
•SATA dual power cable (P/N: 30-20875-0000)
•SATA cable (P/N: 30-10057-0600)
•Rear I/O shield (P/N: 34-25314-0000 )
1.2. Optional Accessories
•COM port cable, 1 port (P/N: 30-20876-0000)
•PS/2 KB/MS cable (P/N: 30-20873-0000)
•USB 2.0 cable, 2 ports for AmITX-SL-G-H110 (P/N: 30-20874-1000)
•USB 3.0 cable, 2 ports for AmITX-SL-G-Q170 (P/N: 30-20963-0000)

2 Introduction
This page intentionally left blank.

AmITX-SL-G
Specifications 3
2. Specifications
2.1. Core System
CPU Desktop 6th Generation Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151socket
Intel® Core™ i7-6700 Processor, 4C, 3.4/4.0 GHz, 8M, 65W
Intel® Core™ i7-6700TE Processor, 4C, 2.4/3.4 GHz, 8M, 35W
Intel® Core™ i5-6500 Processor, 4C , 3.2/3.6 GHz 6M, 65W
Intel® Core™ i5-6500TE Processor, 4C, 2.3/3.3 GHz, 6M, 35W
Intel® Core™ i3-6100 Processor, 2C, 3.7 GHz, 3M, 51W
Intel® Core™ i3-6100TE Processor, 2C, 2.7 GHz, 4M, 35W
Intel® Pentium® G4400 Processor, 2C, 3.3 GHz, 3M, 54W
Intel® Pentium® G4400TE Processor, 2C, 2.4 GHz, 3M, 35W
Intel® Celeron® G3900 Processor, 2C, 2.8 GHz, 2M, 51W
Intel® Celeron® G3900TE Processor, 2C, 2.3 GHz, 2M, 35W
Desktop 7th Generation Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151socket
Intel® Core™ i7-7700 Processor, 4C, 3.6/4.2 GHz, 8M, 65W
Intel® Core™ i7-7700T Processor, 4C, 2.9/3.8 GHz, 8M, 35W
Intel® Core™ i5-7500 Processor, 4C, 3.4/3.8 GHz, 6M, 65W
Intel® Core™ i5-7500T Processor, 4C, 2.7/3.3 GHz, 6M, 35W
Intel® Core™ i3-7101E Processor, 2C, 3.9 GHz, 3M, 54W
Intel® Core™ i3-7101TE Processor, 2C, 3.4GHz, 3M, 35W
Notes:
Availability of features may vary between processor SKUs and operating
systems
Chipset Intel® Q170/H110 Chipset
Memory Dual channel non-ECC 2133/2400 MHz DDR4 memory up to 32GB in dual SODIMMsockets
Embedded BIOS AMI EFI in 16MB SPI BIOS
2.2. Rear I/O Connectors
Display 3x DisplayPort (Q170) , 2x DisplayPort (H110)
LAN Dual GbE RJ-45
USB 4x USB 3.0; 4x USB 2.0
Audio 7.1 channel audio via 5 jacks and S/PDIF output on rear I/O

4 Specifications
2.3. Internal Headers and Connectors
PCI Express Slots PCIe x16 (Gen3)
PCIe x1 (Gen2)
1x Mini-PCIe card (default half size, full size optional), supports PCIe x1(Gen 2)/USB2.0 (top
side)
1x Mini-PCIe card (default full size, half size optional): supports PCIex1(Gen 2) or
mSATA/USB2.0 (bottom side)
USB 2x USB 3.0 onboard header (Q170)
2x USB 2.0 onboard header (H110)
1x USB 3.0 vertical connector (H110 only supports USB2.0)
SATA 3x SATA 6 Gbps ports (Jumper select NA/3.3V/5V for SATA1 and SATA2 to deliver power by
SATA pin7; Default is NA)
2x SATA power connector
Serial 3x RS-232 headers, 1x RS-232/422/485 headers (supports NC/5V/12V power by jumper selection)
LVDS (optional) Build option
eDP (optional) Build option
Other Front Panel Header
Audio Header
Feature Connector Header
PS/2 KB/MS Connector
SPI Header
ATX Power Connector (14-pin)
2.4. Form Factor
Mini-ITX: 170mm x 170mm
2.5. SEMA Board Controller
ADLINK Smart Embedded Management Agent (SEMA)
•Voltage/Current monitoring
•Power sequence debug support
•AT/ATX mode control
•Logistics and Forensic information
•Flat Panel Control
•General Purpose I2C
•Failsafe BIOS (dual BIOS )
•Watchdog Timer and Fan Control
2.6. Debug Header
40-pin Multipurpose Flat Cable Connector:used in combination with DB-40 debug module providing BIOS
POST code LED, BMC access, SPI BIOS flashing, Power Testpoints, Debug LEDs

AmITX-SL-G
Specifications 5
2.7. Video
GPU Feature Support Intel® 9th generation LP graphics core architecture with up to 18 execution units
supporting DirectX 11/12, OGL4.3/4.4, and up to three independent, simultaneous
displays
Display Interface Support •3x DisplayPort v1.2 with resolution up to 4096 x 2160 @ 24Hz (3x DisplayPort(Q170) ,
2x DisplayPort (H110))
•LVDS (optional): Single/dual channel 24-bit LVDS up to 1920x1080 @ 60 Hz (from
eDP-to-LVDSconverter)
•eDP (optional): Supports 3840x2160 resolution @ 60Hz, 24bpp (not available
concurrently withLVDS)
2.8. Audio
Integrated Intel® HD Audio on chipset
Audio Codec Realtek ALC886
Interfaces •7.1 channel audio via 5 jacks and S/PDIF output on rear I/O
•7.1 channel audio signals and S/PDIF output via internal header
2.9. LAN
Intel PHY Intel® i219-LM (PHY) Ethernet controller (H110: i219-V)
•Supports Intel® AMT 11.0 (Q170 only)
•Supports Intel® vPro™ (Q170 only)
Intel MAC/PHY Intel® i211AT (MAC/PHY) Ethernet controller
Interface 10/100/1000 GbE connection
2.10. Trusted Platform Module (TPM)
Chipset Atmel AT97SC3204 (optional)
Type TPM1.2
2.11. Power Specification
Power Modes AT and ATX mode (AT mode start controlled by BMC)
Standard Voltage Input ATX = 12VDC ±5%, 5Vsb ±5% or AT = 12V ±5%
Power Management ACPI 4.0 compliant
Power States Supports C1-C6, S0, S1, S4, S3, S5, (Wake-on-USB S3/S4, WoL S3/S4/S5)

6 Specifications
2.11.1. Power Consumption
Processor Intel® Core™
i7-7700
3.60Ghz
Intel® Core™
i7-6700 3.40
GHz
Intel® Core™
i3-7101E 3.90
GHz
Intel® Core™
i7-7700T 2.90
GHz
Intel® Core™
i5-7500T
2.70Ghz
Intel® Core™
i3-7101TE
3.40Ghz
Chipset H110 H110 H110 H110 H110 H110
Memory Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Transcend
TS512MSH64
V4H 4GB
DDR4 2400
SO-DIMM
1Rx8
Graphics Intel® HD
Graphics 630 Intel® HD Graphics 630 Intel® HD Graphics 630 Intel® HD Graphics 630 Intel® HD Graphics 630 Intel® HD Graphics 630
HDD Intesl 545S
256GB SATA3 Intesl 545S 256GB SATA3 Intesl 545S 256GB SATA3 Intesl 545S 256GB SATA3 Intesl 545S 256GB SATA3 Intesl 545S 256GB
SATA3
OS Window 10
Enterprise x64
v1709
Window 10
Enterprise x64
v1709
Window 10
Enterprise x64
v1709
Window 10
Enterprise x64
v1709
Window 10
Enterprise x64
v1709
Window 10
Enterprise
x64 v1709
Windows Idle mode/Enable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 0.66 0.66 0.65 0.63 0.65 0.66
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 7.92 7.92 7.8 7.56 7.8 7.92
Windows Idle mode/Disable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 0.66 0.67 0.66 0.64 0.66 0.65
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 7.92 8.04 7.92 7.68 7.92 7.8
Windows typical mode/Enable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 7.25 6.48 4.68 4.59 3.84 3.52
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 87 77.76 56.16 55.08 46.08 42.24
Windows typical mode/Disable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0

AmITX-SL-G
Specifications 7
Processor Intel® Core™
i7-7700
3.60Ghz
Intel® Core™
i7-6700 3.40
GHz
Intel® Core™
i3-7101E 3.90
GHz
Intel® Core™
i7-7700T 2.90
GHz
Intel® Core™
i5-7500T
2.70Ghz
Intel® Core™
i3-7101TE
3.40Ghz
12V(A) 6.65 5.75 4.58 4.25 3.34 3.32
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 79.8 69 54.96 51 40.08 39.84
Windows MAX mode/Enable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 10.25 8.92 6.66 8.5 5.35 4.56
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 123 107.04 79.92 102 64.2 54.72
Windows MAX mode/Disable EIST
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 9.85 7.58 6.45 4.58 4.36 4.35
5VSB(A) 0 0 0 0 0 0
Power
consumption(W) 118.2 90.96 77.4 54.96 52.32 52.2
System S1 mode
3.3V(A) No support No support No support No support No support No support
5V(A) No support No support No support No support No support No support
12V(A) No support No support No support No support No support No support
5VSB(A) No support No support No support No support No support No support
Power
consumption(W) Not Applicable Not Applicable Not Applicable Not Applicable Not Applicable Not Applicable
System S3 mode
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 0 0 0 0 0 0
5VSB(A) 0.09 0.09 0.09 0.09 0.09 0.09
Power
consumption(W) 0.45 0.45 0.45 0.45 0.45 0.45
System S4 mode
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 0 0 0 0 0 0
5VSB(A) 0.06 0.06 0.07 0.06 0.06 0.07

8 Specifications
Processor Intel® Core™
i7-7700
3.60Ghz
Intel® Core™
i7-6700 3.40
GHz
Intel® Core™
i3-7101E 3.90
GHz
Intel® Core™
i7-7700T 2.90
GHz
Intel® Core™
i5-7500T
2.70Ghz
Intel® Core™
i3-7101TE
3.40Ghz
Power
consumption(W) 0.3 0.3 0.35 0.3 0.3 0.35
S5 Mode with ECO Disable
3.3V(A) 0 0 0 0 0 0
5V(A) 0 0 0 0 0 0
12V(A) 0 0 0 0 0 0
5VSB(A) 0.06 0.06 0.07 0.06 0.06 0.07
Power
consumption(W) 0.3 0.3 0.35 0.3 0.3 0.35
S5 Mode with ECO Enable
3.3V(A) No support No support No support No support No support No support
5V(A) No support No support No support No support No support No support
12V(A) No support No support No support No support No support No support
5VSB(A) No support No support No support No support No support No support
Power
consumption(W) Not Applicable Not Applicable Not Applicable Not Applicable Not Applicable Not Applicable
2.12. Temperatures
Standard Operating
Temperature 0°C to 60°C
Storage Temperature -20°C to 80°C
2.13. Environmental
Humidity 40° C @ 95% RH non-condensing
Shock and Vibration IEC 60068-2-64 and IEC-60068-2-27
Vibration: 1Grms(5~500 Hz)/OP. 3Grms(5~500 Hz)/NON-OP
Shock: 20G (with 11 ms duration, half sine wave) operating, 20G(with 11 ms duration, half
sine wave) non-operating
HALT Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
2.14. Operating Systems
Standard Support Windows 7 32/64-bit (6th Generation Intel® Core™ i7/i5/i3 and Pentium®/Celeron®
Processor Only), Windows 8.1 64-bit, Linux 32/64-bit, Win10 64-bit
Extended Support (BSP) WES7, Linux, VxWorks (TBD)

AmITX-SL-G
Specifications 9
2.15. Functional Block Diagram
TPM
Atmel
(optional)
USB Header
USB Vertical
DP
DP
DP
USB3.0
USB3.0
PS/2
SPI0/1 Header
DisplayPort A
BMC
Intel® Q170/H110
Chipset
Super I/O
ITE
IT8783
Intel® Core™
i7/i5/i3 Processor
LGA 1151 Socket
USB3.0
USB3.0
3x SATA 6Gb/s port 1/2/3
GPIO
LPC
FDI
DMI
Vertical SODIMM (Channel A)
DDR4 (non ECC)
Front Panel
SMBu s
Sensor
LM73
CPU FAN
Feature Connector
System Signals
SPI 0/1 SPI0 SPI1 Socket
Failsafe
switch
SYS FAN1
3x SATA
System Signals
PCIe x1 port 2PCIe x1 slot
DisplayPort C
USB3.0 port 3/4
USB 3.0 port 1/2
USB2.0
USB2.0
DisplayPort B
GbE
i219LM/V
RJ-45
10/100/1000
(top)
PCIe port 6
RJ45
10/100/1000
(bottom)
GbE
i211AT PCIe port 5
HDA
Codec
ALC886
Center Line In
Surround L/R Line Out
S/PDIF Out Mic In
Audio Header
COM1 Header
COM2 Header
COM3 Header
COM4 Header
1x RS-232/422/485
mSATA/
Mini PCIe
full size (bottom)
Mini PCIe
half size
(top side)
USB 2.0 port 9
Switch
1x SATA 6Gb/s port 4
Q170: 2x USB 3.0 port 5/6
H110: 2x USB 2.0 port 7/8
US B
Hub
x4
1x USB 2.0 port 10
PCIe x1 port 3
PCIe x1 port 4
SYS FAN2
PCIe x16 PCIe x16 slot
3x RS-232
USB2.0
USB2.0
4x USB 2.0
Vertical SODIMM (Channel B)
DDR4 (non ECC)
eDP to
LVDS
eDP
4 lanes
LVDS
Singl e/Dual Channel 18/24-bit
(optional eDP)
DDC
LVDS Dat/Cl k
eDP (optional)
LVDS AUX
Connector
Q170: 1x USB 3.0 port 7
H110: 1x USB 2.0 port 5
LVDS Control
Brightness
MIC2-In / Lin2-Out
USB 2.0 port 6
Figure 1: AmITX-SL-G Functional Block Diagram

10 Specifications
This page intentionally left blank.

AmITX-SL-G
Mechanical Layout 11
3. Mechanical Layout
3.1. Connector Locations
3.1.1. Rear I/O Connectors
DP USB 3.0 USB 3.0 USB 2.0 LAN Audio
DP DP LAN
Figure 2: AmITX-SL-G Rear I/O
3.1.2. Component-Side Connectors
Front Panel Connector
2x DDR4 SODIMM
ATX/AT Power
Feature Connector
LVDS/eDP
Mini PCIe
USB Vertical Connector
SATA Connectors
Audio Header
PCIe x1
3x RS-232�
1x RS-232/422/485
PCIe x16
SPI Header
USB3.0 for Q170
USB2.0 for H110
SPI Socket
DB40 Connector
PS/2 KB/MS
LVDS AUX
CPU Fan
Figure 3: AmITX-SL-G Component-Side Connectors

12 Mechanical Layout
3.2. Mechanical Dimensions
Top View
4
8
0
0 10.16 154.94 159.84 138.23 120.69 85.78 52.9
39.64
114.64
22.86
35.34
59.54
36.41
157.48
154.94
61.09
28.21
157.48
74.24
149.24
74.24
Side View
27.58
35.33
1.6
Dimensions: mm
Figure 4: AmITX-SL-G Mechanical Dimensions

AmITX-SL-G
Mechanical Layout 13
3.3. Thermal Solutions
LGA1150 CPU Cooler, H=30.0mm, 45W
Standard Temp.: 0°C to
60°C P/N: 32-20513-0000
LGA1150 CPU Cooler, H=46.05mm,
45W
Standard Temp.: 0°C to
60°C P/N: 32-20512-0000
LGA1150 CPU Cooler, H=50.2mm, 95W
Standard Temp.: 0°C to
60°C P/N: 32-20113-3000
LGA1150 CPU Cooler, H=61.4mm, 95W
Standard Temp.: 0°C to
60°C P/N: 32-20495-0000

14 Mechanical Layout
This page intentionally left blank.
