Fabric OS 7.4.1a Release Notes v3.0 Page 1 of 142
Brocade Fabric OS v7.4.1a
Release Notes v3.0
February 24, 2016
Document History
Document Title Summary o Changes Publication Date
rocade Fabric OS v7.4.1a Release Notes v1.0 Initial Release December 18, 2015
rocade Fabric OS v7.4.1a Release Notes v2.0 Remove SmartOptics 16G DWDM
optics and add Finisar optics P/Ns
under the new support section
January 13, 2016
rocade Fabric OS v7.4.1a Release Notes v3.0 Updated DEFECT 000578406 info
in the Closed with Code Change in
Fabric OS v7.4.1.a. Add 6543 to
supported under rocade Analytic
Monitoring Platform section of
Important Notes
February 24, 2016

Fabric OS 7.4.1a Release Notes v3.0 Page 2 of 142
© 2016 rocade Communications Systems, Inc. All Rights Reserved.
ADX, AnyIO, rocade, rocade Assurance, the -wing symbol, DCX, Fabric OS, ICX, MLX, My rocade,
OpenScript, VCS, VDX, and Vyatta are registered trademarks, and HyperEdge, The Effortless Network, and The
On-Demand Data Center are trademarks of rocade Communications Systems, Inc., in the United States
and/or in other countries. Other brands, products, or service names mentioned may be trademarks of their
respective owners.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or
implied, concerning any equipment, equipment feature, or service offered or to be offered by rocade. rocade
reserves the right to make changes to this document at any time, without notice, and assumes no
responsibility for its use. This informational document describes features that may not be currently available.
Contact a rocade sales office for information on feature and product availability. Export of technical data
contained in this document may require an export license from the United States government.

Fabric OS 7.4.1a Release Notes v3.0 Page 3 of 142
Contents
Document History ....................................................................................................................................... 1
Overview ...................................................................................................................................................... 8
Enhancements and Resolution of Important Defects ........................................................................................... 8
FOS v7.4.1 Additional Hardware Platform Support ............................................................................................... 8
FOS v7.4.1 New Features & Support...................................................................................................................... 8
FOS v7.4 Obsoleted FOS Features............................................................................................................ 9
FOS v7.4 New Feature Descriptions ....................................................................................................... 10
New Hardware Support ......................................................................................................................................... 10
IP Extension features for rocade 7840 .............................................................................................................. 10
Support System Configuration for IP Extension ............................................................................................... 10
Support GE Port Configuration for IP Extension ............................................................................................... 10
Tunnel configuration for IP Extension ............................................................................................................... 10
Adaptive Rate Limiting (ARL) ............................................................................................................................. 10
TCP/IP Features ................................................................................................................................................. 10
Traffic Control List .............................................................................................................................................. 11
FCIP Enhancements to rocade 7840 ................................................................................................................. 11
ase Switch Support for 7840 ......................................................................................................................... 11
FCIP Hot Code Load (HCL) ................................................................................................................................. 11
Monitoring and Alerting Policy Suite (MAPS) Enhancements.............................................................................. 11
Monitoring without Fabric Vision license .......................................................................................................... 11
Monitor NPIV device login limits ....................................................................................................................... 11
Monitor backend ports ...................................................................................................................................... 11
Monitor FCIP circuit QoS .................................................................................................................................... 12
Monitor FCIP circuit RTT and jitter on 7800 and FX8-24 ................................................................................ 12
Fabric Performance Impact monitoring enhancement.................................................................................... 12
Slow drain device quarantine action for Fabric Performance Impact monitoring ......................................... 12
Port toggle action for Fabric Performance Impact monitoring ........................................................................ 12
FICON notification action ................................................................................................................................... 12
Alert quiet time support ..................................................................................................................................... 12
Usability enhancements .................................................................................................................................... 12
Flow Vision Enhancements ................................................................................................................................... 12
All F_Port Flow Monitoring ................................................................................................................................. 12
Scalability Improvement .................................................................................................................................... 13
Identify All Devices in a Flow ............................................................................................................................. 13
Fabric Flow Dashboard ...................................................................................................................................... 13
ClearLink Diagnostic (D_Port) Enhancements ..................................................................................................... 13
Link Power (d ) Loss Calculation...................................................................................................................... 13

Fabric OS 7.4.1a Release Notes v3.0 Page 4 of 142
Dynamic D_Port and On-demand D_Port with DWDM..................................................................................... 13
CLI Command Hierarchical Help Display .......................................................................................................... 13
Peer Zoning Support .............................................................................................................................................. 13
Target Driven Zoning support................................................................................................................................ 13
Lossless DLS enhancement .................................................................................................................................. 13
FCR enhancements ............................................................................................................................................... 14
Location Embedded LSAN zone ........................................................................................................................ 14
Increase Number of Imported Proxy Devices ................................................................................................... 14
Sort WWNs in lsanzoneshow CLI ...................................................................................................................... 14
Support Port Range for portcfgexport and portcfgvexport CLI ........................................................................ 14
Support Peer Zoning with FCR .......................................................................................................................... 14
Support New Domain ID Range for Front and Translate Phantom Domains ................................................. 14
Security Enhancements ........................................................................................................................................ 14
Obfuscation of RADIUS Shared Secrets ........................................................................................................... 14
Import/Export Syslog Server Certificates ......................................................................................................... 14
Password Policy Enhancement for Root Password Change ............................................................................ 14
secCryptoCfg CLI Command .............................................................................................................................. 14
Default Account Password Change................................................................................................................... 14
Time Server Enhancements .............................................................................................................................. 15
SNMP Enhancements............................................................................................................................................ 15
Log Messages for SNMPv3 Authentication ...................................................................................................... 15
SNMPv3 Individual Inform Tag.......................................................................................................................... 15
Disable SNMP Write Access .............................................................................................................................. 15
Obsoletes Fabric Watch and Advanced Performence Monitoring MI s ......................................................... 15
RDP Enhancements ............................................................................................................................................... 15
Firmware Download Enhancements ..................................................................................................................... 15
Staged Firmware Download .............................................................................................................................. 15
Firmware Clean Installation .............................................................................................................................. 15
Firmware Auto Sync Enhancement ................................................................................................................... 15
Firmware Integrity Check ................................................................................................................................... 16
Challenge-Response Authentication ................................................................................................................. 16
RAS Enhancements ............................................................................................................................................... 16
WWN Card Replacement Enhancements ......................................................................................................... 16
Show RASLOG Messages within a Timeframe ................................................................................................. 16
Audit Log Enhancements .................................................................................................................................. 16
Clihistory Identify Command Virtual Fabric FID ................................................................................................ 16
Zoning Enhancements........................................................................................................................................... 16
List Zones with Specific Alias ............................................................................................................................ 16

Fabric OS 7.4.1a Release Notes v3.0 Page 5 of 142
Sort zoneShow Command Output by WWN ...................................................................................................... 16
Indicate offline members in zoneShow output ................................................................................................ 16
Traffic Isolation (TI) Zoning Enforcement enhancement ................................................................................. 16
TI Failover Disabled Zone Message .................................................................................................................. 17
FICON Enhancements ........................................................................................................................................... 17
MAPS notification to FMS CUP .......................................................................................................................... 17
ConfigUpload and ConfigDownload of FMS Mode ........................................................................................... 17
D_Port Support in Port Descriptor .................................................................................................................... 17
Miscellaneous Enhancements .............................................................................................................................. 17
Login to Logical Switch IP .................................................................................................................................. 17
Dynamic Switch Port Names ............................................................................................................................. 17
Port Index Support for CLI Command portErrShow and portTestShow .......................................................... 17
Link Reset on Loss of Sync ............................................................................................................................... 17
Enhance switchShow CLI Output ...................................................................................................................... 17
portLoginShow Command with History Option ................................................................................................. 17
Port Peer eacon Support EX-Port .................................................................................................................... 17
ufOpMode for FC Gen5 lades ....................................................................................................................... 17
portStatsShow Command Display TXQ Latency ............................................................................................... 18
Support De-bouncing of Loss of Signal for Fixed Speed and Auto Negotiate Ports ....................................... 18
ackend Link Failure lade Fault Option ......................................................................................................... 18
DLS Support on Embedded Switches ............................................................................................................... 18
New portChannelShow CLI Command .............................................................................................................. 18
Support preserving port2area and area2port mappings with configUpload and configDownload .............. 18
Optionally Licensed Software.................................................................................................................. 19
Temporary License Support .................................................................................................................... 22
Supported Switches.................................................................................................................................. 23
Standards Compliance ............................................................................................................................. 23
Technical Support..................................................................................................................................... 24
FOS Migration Considerations ................................................................................................................ 25
FOS Upgrade and Downgrade Special Considerations ....................................................................................... 25
Recommended Migration Paths to FOS v7.4.1a ................................................................................................. 25
Important Notes......................................................................................................................................... 26
rocade Network Advisor Compatibility ............................................................................................................... 26
WebTools Compatibility ......................................................................................................................................... 26
SMI Compatibility ................................................................................................................................................... 26
Fabric OS Compatibility ......................................................................................................................................... 27
Supported Products and FOS Interoperability.................................................................................................. 27
Multi-Protocol Router Interoperability ............................................................................................................... 27
NOS (VDX Platform) Interoperability ................................................................................................................. 28

Fabric OS 7.4.1a Release Notes v3.0 Page 6 of 142
SNMP Support ....................................................................................................................................................... 28
Obtaining the MI s ............................................................................................................................................ 29
Blade Support............................................................................................................................................ 29
DCX/DCX-4S lade Support .............................................................................................................................. 29
DCX/DCX-4S lade Support Matrix................................................................................................................... 29
DCX 8510-8/DCX 8510-4 lade Support ........................................................................................................ 29
DCX 8510-8/DCX 8510-4 lade Support Matrix ............................................................................................. 29
Power Supply Requirements for lades in DCX/DCX-4S ................................................................................. 30
Typical Power Supply Requirements Guidelines for lades in DCX 8510-8 .................................................. 31
Typical Power Supply Requirements Guidelines for lades in DCX 8510-4 .................................................. 34
Scalability................................................................................................................................................... 34
Other Important Notes and Recommendations ..................................................................................... 34
Adaptive Networking/Flow- ased QoS Prioritization ........................................................................................... 34
Access Gateway ..................................................................................................................................................... 35
D_Port ..................................................................................................................................................................... 35
Edge Hold Time ...................................................................................................................................................... 35
Factory Installed Version of FOS ....................................................................................................................... 35
Default EHT Value .............................................................................................................................................. 35
Encryption ehavior for the rocade Encryption Switch ( ES) and FS8-18 ...................................................... 36
FCIP ( rocade 7800 and FX8-24) ........................................................................................................................ 37
Extension ( rocade 7840) .................................................................................................................................... 37
FCoE/DC /CEE (FCOE10-24) ............................................................................................................................... 38
FCR and Integrated Routing .................................................................................................................................. 39
Forward Error Correction (FEC) ............................................................................................................................. 39
FICON...................................................................................................................................................................... 40
FL_Port (Loop) Support ......................................................................................................................................... 40
Flow Vision ............................................................................................................................................................. 40
ICLs on DCX/DCX-4S ............................................................................................................................................. 40
Port Initialization .................................................................................................................................................... 40
Port Mirroring ......................................................................................................................................................... 41
Virtual Fabrics ........................................................................................................................................................ 41
WebTools ................................................................................................................................................................ 41
Zoning ..................................................................................................................................................................... 41
Read Diagnostics Parameters .............................................................................................................................. 41
Link Cable eaconing ............................................................................................................................................ 41
rocade Analytics Monitoring Platform ................................................................................................................ 42
Miscellaneous ........................................................................................................................................................ 42
Defects ....................................................................................................................................................... 44
Closed with Code Change in Fabric OS v7.4.1a................................................................................................... 44

Fabric OS 7.4.1a Release Notes v3.0 Page 7 of 142
Closed with Code Change in Fabric OS v7.4.1 ..................................................................................................... 51
Open Defects in Fabric OS v7.4.0 ........................................................................................................................ 80
Closed with Code Change in Fabric OS v7.4.0 ..................................................................................................... 95
Closed without Code Change in Fabric OS v7.4.0 ............................................................................................. 134

Fabric OS 7.4.1a Release Notes v3.0 Page 8 of 142
Overview
FOS v7.4.1a is a patch release based on FOS v7.4.1. All hardware platforms and features supported in FOS
v7.4.1 are also supported in FOS v7.4.1a. This release contains fixes for defects.
Enhancements and Resolution o Important De ects
•DEFECT000576282 - rocade switches hareboot due to Out of Memory (OOM) condition.
•DEFECT000567733 - After an upgrade to Fabric OS v7.4.x, MAPS may stop working. And on a rocade
director switch, HA Sync may be lost.
•DEFECT000578406 - Host is unable to access storage after the host reboots following an upgrade to
FOS7.4.1
In addition to defect fixes listed at the end of this document, FOS v7.4.1a also includes the following
enhancements:
•Support certificate signing request (CSR) generated with SHA-256 signature through secCertUtil CLI
command with “-hash sha256” option.
•Support QSFP Part Number: 57-1000294-02 to be used on rocade FC16-64 port blade and on rocade
DCX8510 core blades for Inter Chassis Link (ICL).
•Support following new optics part numbers:
oFinisar 16G DWDM 40km SFP+ (FTLX3670SCCxx 16)
oFinisar 8G DWDM 40km SFP+ (FTLX3670SCC** 08)
oFinisar 8G CWDM 70km SFP+ (FTLX2870SCC** 08)
oFinisar 8G CWDM 40km SFP+ (FTLX2670SCC** 08)
oFinisar 4G DWDM 80km SFP+ (FWLF1634RL** 04)
oFinisar 4G CWDM 80km SFP (FWLF1625P2L** 04)
oFinisar 4G ELWL 50km SFP (FWLF1524P2L55 03)
oFinisar 4G ELWL 100km SFP (FWLF1625P2L55 03)
•Support Low QoS zone configuration to co-exist with vTap on fabric switches monitored by the rocade
Analytics Monitoring Platform.
FOS v7.4.1 Additional Hardware Plat orm Support
FOS v7.4.1 merges in the support for the following embedded platforms, in addition to all hardware platforms
supported in FOS v7.4.0b.
•rocade 6543 (embedded switch)
FOS v7.4.1 New Features & Support
In addition to fixes for defects, FOS v7.4.1 includes following enhancements:
• Support POSIX style regular expression for <alias_pattern> parameter in the zoneShow --alias
<alias_pattern> CLI.
• SNMP enhancement to MI object ifOperStatus to report port online/offline state independently from the
value of ifAdminStatus.
• Support SCP/SFTP protocol for SNMP MI objects hwinfospsaveSet and hwUpdateFile for initiating
firmwareDownload and supportSave through SNMP.
FOS v7.4.1 also includes the following features introduced in FOS v7.4.0b that enable rocade Gen 5 fabric
switches as source switches to be monitored by the rocade Analytics Monitoring Platform:
•Support for virtual tap (vTap)
ovTap is a rocade Gen 5 Flow Vision capability enabled on a fabric switch to mirror selected
frames to Analytics Monitoring Platform for analysis. A new pre-defined flow named
“sys_analytics_vtap” supports vTap.

Fabric OS 7.4.1a Release Notes v3.0 Page 9 of 142
ovTap supports automatic discovery of Analytic F_Port (AF_Port) when a rocade Analytics
Monitoring Platform is attached to the fabric. An AF_Port is a mirror port on the Analytics
Monitoring Platform designated as the destination of information sent from vTap-enabled ports on
a fabric switch.
•Support for Analytics E_Port (AE_Port) connectivity between fabric switches and the rocade Analytics
Monitoring Platform through Analytics Switch Link (ASL)
oASLs are Gen 5 Fibre Channel links dedicated for carrying information from vTap-enabled ports on
fabric switches to rocade Analytics Monitoring Platform.
oASLs do not carry normal data traffic unless they are the only paths from hosts to targets.
•Enhancement to MAPS for monitoring AE_Port and vTap
oAdd Fabric Performance Impact (FPI) monitoring for latency and congestion monitoring on AE_Port
oAdd FPI monitoring for back-end ports with active vTap on a fabric switch
oAdd Switch Resource monitoring for vTap traffic IOPS with active vTap on a fabric switch
FOS v7.4 Obsoleted FOS Features
The following features supported in FOS v7.3 and earlier releases are obsolete beginning with FOS v7.4:
•Fabric Watch
•Advanced Performance Monitoring (APM)
Users running Fabric Watch for switch monitoring in FOS v7.3 are advised to convert to MAPS monitoring
before upgrading to FOS v7.4. Converting Fabric Watch to MAPS before upgrading to FOS v7.4 can preserve
Fabric Watch threshold configurations. If users choose to upgrade to FOS v7.4 without converting to MAPS,
Fabric Watch will stop functioning after the firmware upgrade and the Fabric Watch thresholds cannot be
automatically migrated for use by MAPS. Please refer to the Fabric OS MAPS Administrator’s Guide for step-by-
step migration instructions.
Users running APM in FOS v7.3 are required to remove all monitors before upgrading to FOS v7.4 by using the
following commands:
1. Enter perfdeleemonitor to remove all End-to-end monitors.
2. Enter perfcfgsave to save this change.
3. Enter fmmonitor --delmonitor to remove all filter monitors.
4. Enter fmmonitor --delete frametype to remove the specified user-defined frametype.
5. Enter perfttmon --delete to remove all switch level Top Talker monitors.
6. Enter perfttmon --delete fabricmode to remove fabric mode Top Talker monitors.
After upgrading to FOS v7.4, the APM monitors will stop functioning. Users can use the Flow Vision features as
part of Fabric Vision for performance monitoring. Please refer to the Fabric OS Flow Vision Administrator’s
Guide for detailed instructions on removing APM monitors and Flow Vision feature configurations.
rocade Fabric Vision licenses are required for MAPS and Flow Vision. The combination of rocade Fabric
Watch license and rocade APM license enables the MAPS and Flow Vision features. For switches with only
Fabric Watch licenses or only APM licenses, users can acquire and install the missing license to acquire MAPS
and Flow Vision features.

Fabric OS 7.4.1a Release Notes v3.0 Page 10 of 142
FOS v7.4 New Feature Descriptions
New Hardware Support
FOS v7.4 adds support for the following new hardware:
•rocade-branded 4G external US flash drive
IP Extension eatures or Brocade 7840
FOS v7.4 introduces IP Extension support for the rocade 7840. Users can use this capability to extend IP
storage for replication and disaster recovery in much the same way as Fibre Channel storage while taking
advantage of the compression, encryption, QoS, and trunking features available in the rocade 7840.
A rocade 7840 running FOS v7.4 can support both FCIP Extension and IP Extension at the same time. IP
Extension includes the following:
•Support for system configuration for IP Extension
•Support for GbE port configuration for IP Extension
•Tunnel configuration for IP Extension
•Adaptive Rate Limiting
•TCP/IP Features
•Traffic Control List
Support System Con iguration or IP Extension
FOS v7.4 supports users configuring rocade 7840 for both FCIP Extension and IP Extension (hybrid mode). y
default, rocade 7840 supports FCIP Extension only. Changing a rocade 7840 between FCIP-only and hybrid
mode requires a switch reboot.
Support GE Port Con iguration or IP Extension
FOS v7.4 supports users configuring the front end 1/10 GbE ports as LAN ports on a rocade 7840 for hybrid
mode. These ports are used to connect to IP storage devices on the LAN side. FOS v7.4 supports static Link
Aggregation Group (LAG) configuration so that multiple LAN ports can be assigned to the same LAG group.
Tunnel con iguration or IP Extension
FOS v7.4 supports user configuration of IP tunnels on a rocade 7840 in the same way as FC tunnels are
configured. IP tunnels and FC tunnels are all represented under virtual E-port (VE). Each VE is configured as a
FC-only tunnel or as both FC and IP tunnels. Trunking, QoS, and compression are supported on IP tunnels as
they are for FC tunnels.
Adaptive Rate Limiting (ARL)
FOS v7.4 supports all ARL features available on the FCIP Extension for IP Extension. The static distribution of
unused bandwidth is hierarchical.
TCP/IP Features
FOS v7.4 supports the following TCP/IP features for IP Extension.
•LAN side jumbo frames
•IPv4 and IPv6 for LAN side
•Maximum 512 TCP connections per Data Processor (DP)
•Maximum 512 TCP open requests per second per DP
•Maximum 64 UDP flows per DP
•DSCP/VLAN L2CoS marking
•Segment Preservation
•Each LAN TCP window will be 64K by default. If TCP window scaling is requested, the maximum advertised
window is 256K. The maximum window per connection is 2M irrespective of the advertised window.
