61200307L1-19B T1 Network Interface Module Installation Instructions 1 of 1
Installation Instructions
T1 Network Interface Module
P/N 1200307L1
Installing the T1 Network Interface Module
Figure 1 represents the actions required for proper placement of the T1 Network Interface Module. Perform
the following steps to install the network module:
1. RemovethecoverplatefromtheappropriateNetworkslot.
2. Slide the T1 Network Interface Module into the ATLAS 550 chassis until the module is firmly seated
in the ATLAS 550 unit.
3. Fasten the thumbscrews at both edges of the network module. Tighten with a screwdriver.
4. Connect the cable to the associated device.
5. Complete the installation of any remaining modules and the Base Unit as specified in the Installation
chapter of the ATLAS 550 User Manual.
Figure 1. Installing the T1 Network Interface Module
See the ATLAS 550 User Manual for operation, configuration, and detailed specifications on the T1 Network
Interface Module (ADTRAN P/N 1200307L1).
WARNING: Option modules are intended to be serviced by qualified service personnel only.
NETWORK 2
24
ETHERNET
CONTROL
IN OUT
RELAY ALARM
OI
FUSE RATING:2A/250V SLO-BLO
90-240VAC, 2A, 50/60Hz
NC NO
COMGND
ALLEMPTYSLOTSMUSTBE
COVEREDWITHBLANKPANELS
CAUTION:FORCONTINUEDPROTECTION
AGAINSTRISKOFFIRE,REPLACEONLY
WITHSAMETYPEANDRATINGOFFUSE.
MON
Remove Cover Plate
IO
NETWORK
IN
OUT
IN
OUT
NETWORKMON
T1 NETWORKMODULE TEST
500 Series
Install Module
NETWORK 1
April 2000
61200307L1-19B
