NetVanta Series
(with SHDSL Network Interface Module)
Quick Configuration Guide 64200867L1-42B November 2004
• Category 5 - UTP cable for connecting the system to the existing network.
• VT100 terminal or PC with VT100 emulation software.
• DB-9 (male) to DB-9 (female) straight-through serial cable for configuring the unit.
Connection Diagram
The NetVanta may be initially accessed and managed either via a console session or through a
Telnet session. See Initiate a Console Session on page 2 for instructions. Initiating a Telnet
session requires using a hub and two Ethernet cables (one for the PC and one for the unit). The
default Ethernet IP address is 10.10.10.1. Refer to Configure a Telnet Session on page 4 to
change Telnet session settings.
Equipment Required
This quick configuration guide provides step-by-step instructions for configuring
your application. The configuration scripts are available on the ADTRAN OS
Documentation CD.
The configuration parameters used in the example outlined in this document are for
instructional purposes only. Please replace all underlined entries (example) with your
specific parameters to configure your application.
Network Diagram
Configure the Unit
Branch Office Corporate HQ
NetVanta
LAN IP: 10.10.10.1/24
WAN IP: 192.168.72.2/30
eth 0/1
LAN IP: 10.10.20.7/24
PWR STAT TD
VPN
RD TD RD TD RD
WAN LAN
PWR STAT TD
VPN
RD TD RD
NetVanta3200
WAN LAN
DLCI 16
Annex D Signaling
192.168.72.1/30
FR 1
DS0s 1-10 Data,
21-24 Voice
PBX
t1 1/2 t1 1/1

2 Technical Support 1-888-4ADTRAN (1-888-423-8726) 64200867L1-42B
1. Connect a VT100 terminal (or PC with VT100 emulation software) to the NetVanta
CONSOLE port using a DB-9 (male) to DB-9 (female) straight-through serial cable.
2. Configure the COM port with the following parameters:
Data Rate: 9600
Data Bits: 8
Parity Bits: None
Stop Bits: 1
Flow Control: None
3. Open a VT100 terminal session. (Please refer to the appropriate VT100 terminal software
documentation for detailed instructions.)
4. Press the <Enter> key.
5. Enter enable at the >prompt.
6. Enter the password when prompted. The default password is password.
7. You are now at the #prompt. At the # prompt, enter config terminal to enter the Global
Configuration mode.
Typically you will have a master unit at the campus location, and a slave unit at a remote location.
The following sections describe how to set up and configure both the master and slave units.
1. At the (config)# prompt, enter interface eth 0/1 to access the configuration parameters for
the Ethernet port located on the rear panel of the unit.
2. Enter ip address 10.10.20.7 255.255.255.0 to assign an IP address to the Ethernet port
using a 24-bit subnet mask.
3. Enter no shutdown to activate the interface to pass data.
4. Enter exit to exit the Ethernet interface commands and return to the Global Configuration
mode.
Initiate a Console Session
Configure the Ethernet Port Parameters
If you are accessing the NetVanta via Telnet, once you change this IP address, you will
lose connection to the NetVanta. You must change the IP address of your PC before you
can proceed.
ADTRAN recommends that you set the Ethernet speed and duplex to match the switch or
hub into which it is plugged.
For example: (config-eth 0/1)#speed 10
(config-eth 0/1)#half-duplex
The NetVanta Network Interface Modules (NIMs) use a slot/port notation for interface
identification. All non-modular interfaces built into the base unit (e.g., the Ethernet port) are
identified using 0as the slot number.

64200867L1-42B Technical Support 1-888-4ADTRAN (1-888-423-8726) 3
For the Master Unit:
1. At the (config)# prompt, enter interface shdsl 1/1 to activate the interface configuration
mode for the SHDSL network interface.
2. Enter equipment-type co to configure the unit to source timing into the SHDSL network
connection. Use this option in a campus environment when operating two SHDSL network
interface modules (NIMs) back-to-back.
3. Enter linerate 2312 to define the line rate for the SHDSL interface for the CO side.
4. Enter no shutdown to activate the SHDSL interface.
5. Enter exit to return to the Global Configuration mode.
For the Slave Unit:
1. At the (config)# prompt, enter interface shdsl 1/1 to activate the interface configuration
mode for the SHDSL network interface.
2. Enter equipment-type cpe. Use this option when interfacing directly with your service
provider or when acting as the slave NIM in a campus environment.
3. Enter no shutdown to activate the SHDSL interface.
4. Enter exit to return to the Global Configuration mode.
The following steps show how to configure a PPP virtual interface to the corporate router for the
master unit.Enter interface fr 1 to create a Frame Relay virtual interface labeled 1.
1. At the (config)# prompt, enter interface ppp 1 to create a PPP virtual interface labeled 1.
2. Assign an IP address to the PPP endpoint using a 30-bit mask.
• Master: Enter ip address 192.168.72.2 255.255.255.252
•Slave:Enterip address 192.168.72.1 255.255.255.252
3. Enter no shutdown to activate the PPP interface.
4. Enter exit to return to the Global Configuration mode.
For both the master and slave units, enter cross-connect 1 shdsl 1/1 ppp 1 to connect the
SHDSL network connection (shdsl 1/1) to the virtual PPP interface (ppp 1).
Depending on your network setup, configure your unit’s static route to the far side/Internet
access at the local site beginning at the (config)# prompt.
Set up the default route (i.e., address of internet router).
• Master: ip route 10.10.20.0 255.255.255.0 192.168.72.1
• Slave: ip route 0.0.0.0 0.0.0.0 192.168.72.2
Configure the SHDSL Network Interface
Configure the Virtual PPP Interface
Create the Cross-Connect
Configure the Routes

4 Technical Support 1-888-4ADTRAN (1-888-423-8726) 64200867L1-42B
The following steps show how to access the Telnet configuration parameters and change the
password. The default password for initializing a Telnet session is password (all lowercase). For
security purposes, change the password to something unique. For this example, replace the
underlined word with a password of your choosing. The NetVanta supports five Telnet sessions
(0 through 4).
1. Verify that the prompt of your unit displays (config)#.
2. Enter line telnet 0 4 to change the configuration parameters for the Telnet session.
3. Enter password word to change the login password for the Telnet session.
4. Enter exit to return to the Global Configuration mode.
1. Verify that the prompt of your unit displays (config)#.
2. Enter enable password word to set the Enable Security mode password.
or
3. Enter enable password md5 word to encrypt the enable password using MD5 encryption.
1. Verify that the prompt of your unit displays (config)#.
2. Enter exit to leave configuration mode.
3. Enter copy running-config startup-config to save the current configuration to memory. This
command may be abbreviated as copy run start.
4. Enter exit to close the configuration session.
The NetVanta is now configured and operational. Complete the installation by connecting the
appropriate cables to the networks. Please refer to the NetVanta Hardware Installation Guide for
details on pinouts and cabling.
Configure a Telnet Session
An enable security mode password must be defined before configured Telnet sessions are
activated. See Set the Enable Security Mode Password for information on password
configuration.
Set the Enable Security Mode Password
The Enable Security mode passwords are case sensitive.
Save the Configuration
Complete the Installation
