ADTRAN NetVanta 1224STR PWR Manual

NetVanta 1224STR DC
Hardware Installation Guide
1200590E1 NetVanta 1224STR DC
4200368L1 Enhanced Feature Pack (Hardware and Software) for IPSec VPN Upgrade
1200861L1 NetVanta 56K/64K Network Interface Module
1200862L2#NEBS NetVanta T1/FT1 NEBS Network Interface Module
1202862L1 NetVanta T1/FT1 Network Interface Module
1202863L1 NetVanta T1/FT1 + DSX-1 Network Interface Module
1200872L1 NetVanta Dual T1 Network Interface Module
1200868E1/L1 NetVanta E1/FE1 Network Interface Module
1200878E1/L1 NetVanta E1/FE1 + G.703 Drop Network Interface Module
1200866E1 NetVanta Serial Network Interface Module
1200936E1 NetVanta SHDSL Network Interface Module, Annex A
1200937E1 NetVanta SHDSL Network Interface Module, Annex B
1202869E1 NetVanta ADSL Network Interface Module, Annex A
1202889E1 NetVanta ADSL Network Interface Module, Annex B
1200864L1 NetVanta Analog Modem Dial Backup Interface Module
1200865L1 NetVanta ISDN BRI Dial Backup Interface Module
1200875L1 NetVanta ISDN S/T Dial Backup Interface Module
61200590E1-34B
March 2013

Trademarks NetVanta 1224STR DC Hardware Installation Guide
2 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or
trade names of their respective holders.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change
the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for
commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the
Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep
a copy of the software for backup purposes. This Agreement covers all software installed on the system, as
well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may
contain additional conditions for obtaining software upgrades.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2013 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

NetVanta 1224STR DC Hardware Installation Guide Conventions
61200590E1-34B Copyright © 2013 ADTRAN, Inc. 3
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to the
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Safety Instructions NetVanta 1224STR DC Hardware Installation Guide
4 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to reduce the risk of
fire, electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote
risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for special disposal instructions.
5. The socket-outlet shall be installed near the equipment and shall be easily accessible.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your qualified service personnel:
1. The power cable, extension cable, or plug is damaged.
2. An object has fallen into the product.
3. The product has been exposed to water.
4. The product has been dropped or damaged.
5. The product does not operate correctly when you follow the operating instructions.
Save These Important Safety Instructions
These units contain no user-serviceable parts. They should only be serviced by qualified
service personnel.
Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE),
are given in the document NetVanta Safety and Regulatory Information available online at
http://supportforums.adtran.com.

NetVanta 1224STR DC Hardware Installation Guide FCC-Required Information
61200590E1-34B Copyright © 2013 ADTRAN, Inc. 5
FCC-Required Information
FCC regulations require that the following information be provided in this manual:
1. This equipment complies with Part 68 of Federal Communications Commission (FCC) rules and
requirements adopted by America’s Carriers Telecommunications Association (ACTA). Each
registered interface has a label that contains, among other information, a product identifier in the
format US:AAAEQ##TXXXX. If requested, provide this information to the telephone company.
2. If this equipment causes harm to the telephone network, the telephone company may temporarily
discontinue service. If possible, advance notification is given; otherwise, notification is given as
soon as possible. The telephone company will advise the customer of the right to file a complaint
with the FCC.
3. The telephone company may make changes in its facilities, equipment, operations, or procedures
that could affect the proper operation of this equipment. Advance notification and the opportunity
to maintain uninterrupted service are given.
4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty
information. The telephone company may require this equipment to be disconnected from the
network until the problem is corrected, or it is certain the equipment is not malfunctioning.
5. This unit contains no user-serviceable parts.
6. This equipment is designed to connect to the telephone network or premises wiring using an
FCC-compatible modular jack, which is compliant with Part 68 and requirements adopted by
ACTA.
7. The following information may be required when applying to the local telephone company for
leased line facilities:
8. The ringer equivalency number (REN) is useful in determining the quantity of devices you may
connect to your telephone line and still have all of those devices ring when your number is called.
In most areas, the sum of the RENs of all devices should not exceed five. To be certain of the
number of devices you may connect to your line as determined by the REN, call your telephone
company to determine the maximum REN for your calling area.
9. This equipment may not be used on coin service provided by the telephone company. Connection
to party lines is subject to state tariffs. Contact your state public utility commission or corporation
commission for information.
Part Number Registration Number Service Type REN/SOC FIC USOC
1200861L1 US: HDCDENAN1200861L1 56 kbps Digital Interface
64 kbps Digital Interface 6.0F 04DU5-56
04DU5-64 RJ-48S
1202862L1 US: HDCDENAN1202863L1 1.544 Mbps - SF
1.544 Mbps - SF and B8ZS
1.544 Mbps - ESF
1.544 Mbps - ESF and B8ZS
6.0N
04DU9-BN
04DU9-DN
04DU9-1KN
04DU9-1SN
RJ-48C
1202863L1
1200872L1 US: HDCDENAN1200872L1
1200864L1 US: HDCMM04A1200864L1 Analog Loop Start 0.4A/9.0Y 02LS2 RJ-11C
1200865L1 US: HDCDENAN1200865L1 Basic Rate ISDN 6.0F 02LS5 RJ-49C
1202869E1 US: HDCDL01A1200869L1 ADSL Modem 0.1A Metallic RJ-11C

FCC Radio Frequency Interference Statement NetVanta 1224STR DC Hardware Installation Guide
6 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Electromagnetic Compatibility (EMC) Table
NetVanta Module P/N and Name NetVanta 1224STR DC
1200861L1 56K/64K NIM FCC Part 15 Class A
EN 55022 Class A
1200862L2#NEBS T1/FT1 NEBS NIM FCC Part 15 Class A,
EN 55022 Class A
GR-1089-CORE,
Sections 2 and 3
1202862L1
1202863L1
1200872L1
T1/FT1 NIM
T1/FT1 + DSX-1 NIM
Dual T1 NIM
FCC Part 15 Class A
EN 55022 Class A
1200868E1/L1
1200878E1/L1 E1/FE1 NIM E1/FE1 + G.703 Drop NIM FCC Part 15 Class A EN 55022 Class A
EN 55024
1200866E1 Serial NIM FCC Part 15 Class A
EN 55022 Class A
EN 55024
1200936E1
1200937E1 SHDSL NIM, Annex A SHDSL NIM, Annex B FCC Part 15 Class A EN 55022 Class A
EN 55024
1202869E1
1202889E1 ADSL NIM, Annex A ADSL NIM, Annex B FCC Part 15 Class A EN 55022 Class A
EN 55024
1200864L1
1200865L1
1200875L1
Analog Modem DIM
ISDN BRI DIM
ISDN S/T DIM
FCC Part 15 Class A
EN 55022 Class A
EN 55024
1202368L1 VPN Accelerator Card (included in P/N
4200368L1) FCC Part 15 Class A EN 55022 Class A
EN 55024
EN 61000-3-2
EN 61000-3-3

NetVanta 1224STR DC Hardware Installation Guide Industry Canada Compliance Information
61200590E1-34B Copyright © 2013 ADTRAN, Inc. 7
Industry Canada Compliance Information
Notice: The Industry Canada label applied to the product (identified by the Industry Canada logo or the
“IC:” in front of the certification/registration number) signifies that the Industry Canada technical
specifications were met.
Notice: The REN for this terminal equipment is supplied in the documentation or on the product labeling/
markings. The REN assigned to each terminal device indicates the maximum number of terminals that can
be connected to a telephone interface. The termination on an interface may consist of any combination of
devices subject only to the requirement that the sum of the RENs of all the devices should not exceed five
(5).
Canadian Emissions Requirements
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus
as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques
de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee
par le ministre des Communications.

Toll Fraud Liability NetVanta 1224STR DC Hardware Installation Guide
8 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
Toll Fraud Liability
Be advised that certain security risks are inherent in the use of any telecommunications or networking
equipment, including but not limited to, toll fraud, Denial of Service (DoS) attacks, loss or theft of data,
and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER
EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE
OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER
USE OF ADTRAN EQUIPMENT OR SOFTWARE. THEREFORE, ADTRAN IS NOT LIABLE FOR
ANY LOSSES OR DAMAGES RESULTING FROM SUCH FRAUD, ATTACK, OR IMPROPER USE,
INCLUDING, BUT NOT LIMITED TO, HUMAN AND DATA PRIVACY, INTELLECTUAL
PROPERTY, MATERIAL ASSETS, FINANCIAL RESOURCES, LABOR AND LEGAL COSTS.
Ultimately, the responsibility for securing your telecommunication and networking equipment rests with
you, and you are encouraged to review documentation regarding available security measures, their
configuration and implementation, and to test such features as is necessary for your network.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the Support section of the
ADTRAN website at http://www.adtran.com.

61200590E1-34B Copyright © 2013 ADTRAN, Inc. 9
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Features and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Module Network Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SFP Module Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Front Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Rear Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Option Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Network Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dial Backup Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Installing Dial Backup and Network Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) . . . . . . . . . . . . . . . . . . 41
Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Table of Contents NetVanta 1224STR DC Hardware Installation Guide
10 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B

61200590E1-34B Copyright © 2013 ADTRAN, Inc. 11
List of Figures
Figure 1. Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 2. Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 3. NetVanta 56K/64K NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 4. NetVanta T1/FT1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 5. NetVanta T1/FT1 NEBS NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 6. NetVanta T1/FT1 + DSX-1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 7. NetVanta Dual T1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 8. NetVanta E1/FE1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 9. NetVanta E1/FE1 + G.703 Drop NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 10. NetVanta Serial NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 11. NetVanta SHDSL NIM, Annex A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 12. NetVanta SHDSL NIM, Annex B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 13. NetVanta ADSL NIM, Annex A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 14. NetVanta ADSL NIM, Annex B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 15. Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 16. Grounding the NetVanta 1224STR DC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 17. Installing DIMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 18. NIM and DIM Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 19. NetVanta VPN Accelerator Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

List of Figures NetVanta 1224STR DC Hardware Installation Guide
12 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B

61200590E1-34B Copyright © 2013 ADTRAN, Inc. 13
List of Tables
Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table A-1. CONSOLE Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-2. SFP Slot Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-3. 10/100Base-T Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table A-4. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table A-5. WAN-DDS Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table A-6. WAN-T1 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table A-7. WAN-E1 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table A-8. DSX-1 Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table A-9. G.703 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table A-10. WAN-SHDSL Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table A-11. WAN-ADSL Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Table A-12. Serial to Cable Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Table A-13. Analog Modem and ISDN BRI DBU Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table A-14. ISDN S/T DBU Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

List of Tables NetVanta 1224STR DC Hardware Installation Guide
14 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B

61200590E1-34B Copyright © 2013 ADTRAN, Inc. 15
1. INTRODUCTION
This hardware installation guide describes the NetVanta 1224STR DC unit’s physical characteristics, lists
its features and specifications, introduces basic functionality, and provides installation instructions.
For information on switch configuration for a specific application, refer to the configuration guides provided on
the ADTRAN Support Community. For details on the command line interface (CLI), refer to the AOS
Command Reference Guide. All other related documents are also available online at
http://supportforums.adtran.com.
2. PHYSICAL DESCRIPTION
The NetVanta 1224STR DC is a managed switch housed in a 1U-high rack-mountable metal enclosure that
includes a DC power supply. The front panel contains 24 10/100Base-T Ethernet interfaces (RJ-45), one Gigabit
Ethernet interface that provides one fixed RJ-45 connector, and one standard small form-factor pluggable (SFP)
slot for fiber connectivity.
This section includes a list of features and specifications, a list of shipping contents, and a description of the
unit’s front and rear panel designs. For additional information, refer to the following sections:
•Mounting Options on page 36
•Supplying Power to the Unit on page 38
•Installing Dial Backup and Network Interface Modules on page 39
•Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1) on page 41
Features and Specifications
• Physical Interfaces
• 24 10/100Base-T Ethernet interfaces on the front panel
• One 1000Base-T Gigabit Ethernet interfaces on the front panel (SFP slots for fiber
connectivity/RJ-45 connectors for copper connectivity)
• Integrated DB-9, EIA-232 console port (DCE) on the rear panel
• Modular network interface on the rear panel
• Stacking
• Spanning Tree Support (802.1D and 802.1w)
• Link Aggregation (802.3ad)
• VLAN Support (802.1Q), up to 255 active VLANs
• Priority QoS (802.1p)
• Management
•Console
•TelnetCLI
•SSHCLI
• SNMP V2
• Port mirroring
• DC Power: 24 to 48 VDC
• Mechanical Specifications
• Housing: 1U-high metal enclosure (1.72-inch H x 17.22-inch W x 7.8-inch D)

Physical Description NetVanta 1224STR DC Hardware Installation Guide
16 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
• 10/100Base-T Ethernet: 24 ganged RJ-45 jacks
• 10/100/1000Base-T Ethernet: SFP slots/standard RJ-45 jacks
• Console Port: DB-9, female
• Environmental Specifications
• DC Input Power: 24 to 48 VDC at 2.5 A
• Storage Temperature: -20C to 70C
• Operating Temperature: 0C to 50C
• Relative Humidity: Up to 95 percent, noncondensing
Module Network Interface
The NetVanta 1224STR DC contains a module network interface that support the following network interface
modules (NIMs) and dial backup interface modules (DIMs):
• 1200861L1 56K/64K NIM
• 1202862L1 T1/FT1 NIM
• 1200862L2#NEBS T1/FT1 NEBS NIM
• 1202863L1 T1/FT1 + DSX-1 NIM
• 1200872L1 Dual T1 NIM
• 1200868E1/L1 E1/FE1 NIM
• 1200878E1/L1 E1/FE1 + G.703 Drop NIM
• 1200866E1 Serial NIM
• 1200936E1 SHDSL NIM, Annex A
• 1200937E1 SHDSL NIM, Annex B
• 1202869E1 ADSL NIM, Annex A
• 1202889E1 ADSL NIM, Annex B
• 1200864L1 Analog Modem DIM
• 1200865L1 ISDN BRI DIM
• 1200875L1 ISDN S/T DIM
SFP Module Slots
The NetVanta 1224STR DC supports one SFP slot. It accepts a number of industry standard SFP modules. The
SFP modules provide Gigabit Ethernet fiber connectivity for high-speed uplinks or switch stacking. For a list of
supported SFP modules, visit the ADTRAN website at http://www.adtran.com.
Shipping Contents
Each NetVanta 1224STR DC unit is shipped in their own cardboard shipping carton. Open the carton carefully,
and avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Repair and
Replacement section of the Support page on the ADTRAN website at http://www.adtran.com/support).

NetVanta 1224STR DC Hardware Installation Guide Physical Description
61200590E1-34B Copyright © 2013 ADTRAN, Inc. 17
Domestic shipments of the NetVanta 1224STR DC include the following items:
• NetVanta 1224STR DC base unit
• Quick start guide
• A detachable power cable with a grounded, three-prong plug
International shipments of the NetVanta 1224STR DC include the following items:
• NetVanta 1224STR DC base unit
• Quick start guide
• All necessary power cords
Front Panel Design
The NetVanta 1224STR DC front panel is shown below. Table 1 on page 18 describes all of the LEDs, and
Appendix A on page 43 shows the connector pinouts.
NetVanta 1224STR DC Front Panel Features
Status LEDs
The status LEDs are located to the lower left of RJ-45 port 1. The WAN LED reflects the status of an
installed NIM. The DBU LED reflects the status of an installed DIM. The STAT LED indicates the
unit’s status.
10/100Base-T Ethernet Interfaces
The NetVanta 1224STR DCs contain 24 10/100Base-T Ethernet interfaces (RJ-45). These interfaces
are consecutively numbered 1 through 24, from left to right, with the numbers screened directly above
each port. Status LEDs for each of these interfaces are located directly over these numbers.
Gigabit Ethernet Interfaces/SFP Slots
The NetVanta 1224STR DC front panel contains one Gigabit Ethernet interface that provides one fixed
RJ-45 connector and one standard SFP slot for fiber connectivity. (Use either the RJ-45 connector or
the SFP slot. The fiber slot has precedence.) This interface is labeled G1, and the status LED is located
to the left of RJ-45 port 1, above the STAT LED.
Figure 1. Front Panel Layout
Rear Panel Design
The NetVanta 1224STR DC rear panel is shown below. Refer to Appendix A on page 43 for pinouts.
Figure 2. Rear Panel Layout
-48V....., 1.2A
+24V....., 2.5A
USE COPPER
CONDUCTORS ONLY
WAN-T1

Physical Description NetVanta 1224STR DC Hardware Installation Guide
18 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
NetVanta 1224STR DC Rear Panel Features
NIM Option Slot
The NIM option slot accepts a variety of NIM option modules (refer to Option Modules on page 19 ).
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) that provides for local management and
configuration (via a DB-9 female connector).
Power Connection
The NetVanta 1224STR DC connects to a centralized DC power source via a four-position power
connector. Please refer to Supplying Power to the Unit on page 38 for connection details.
Connection directly to an external modem requires a cross-over cable.
Table 1. Front Panel LED Descriptions
LED Color Indication
STAT Off Unit is not receiving power.
Green (solid) Power is on and self-test passed.
Green (flashing) On power-up, the STAT LED flashes rapidly for five
seconds, during which time the user may escape to boot
mode from the CONSOLE port.
Red (solid) Power is on, but the self-test failed or the boot code could
not be booted.
DBU Off No DIM is installed.
Green (solid) DIM is ready. For the ISDN BRI DIM, green solid indicates
that the negotiation with the switch is complete.
Green (flashing) Unit is in dial backup.
Amber (solid) Unit is in test.
Red (solid) Alarm condition is occurring on the DBU interface, or there
is a self-test failure.
WAN Off No NIM is installed, or interface is administratively down.
Green (solid) NIM is up and everything is operational.
Green (flashing) Port has activity (transmit or receive).
Amber (solid) Unit is in test.
Red (solid) Alarm condition is occurring on the WAN interface, or there
is a self-test failure.
Port LEDs
(1through 24 and G1)Off Port is administratively disabled or does not have a
connection.
Green (solid) Port is enabled and has a connection.
Amber (flashing) Port has activity (transmit or receive).

NetVanta 1224STR DC Hardware Installation Guide Option Modules
61200590E1-34B Copyright © 2013 ADTRAN, Inc. 19
3. OPTION MODULES
The NetVanta 1224STR DC supports several option modules designed to meet a variety of networking
requirements. The option modules include plug-in NIMs and plug-on DIMs.
NIMs are cards that plug directly into the option module slot located on the rear of the base unit. These cards
provide the following types of interfaces:
•NetVanta 56K/64K NIM (P/N 1200861L1) on page 20
•NetVanta T1/FT1 NIM (P/N 1202862L1) on page 21
•NetVanta T1/FT1 NEBS NIM (P/N 1200862L2#NEBS) on page 22
•NetVanta T1/FT1 + DSX-1 NIM (P/N 1202863L1) on page 23
•NetVanta Dual T1 NIM (P/N 1200872L1) on page 24
•NetVanta E1/FE1 NIM (P/N 1200868E1/L1) on page 25
•NetVanta E1/FE1 + G.703 Drop NIM (P/N 1200878E1/L1) on page 26
•NetVanta Serial NIM (P/N 1200866E1) on page 27
•NetVanta SHDSL NIM, Annex A (P/N 1200936E1) on page 28
•NetVanta SHDSL NIM, Annex B (P/N 1200937E1) on page 29
•NetVanta ADSL NIM, Annex A (P/N 1202869E1) on page 30
•NetVanta ADSL NIM, Annex B (P/N 1202889E1) on page 31
DIMs are plug-on cards that plug directly on to the NIM prior to installation into the base unit. A DIM must be
plugged on to a NIM in order for the interfaces on the NIM to be active. The NetVanta supports the following
DIMs:
•NetVanta Analog Modem DIM (P/N 1200864L1) on page 32
•NetVanta ISDN BRI DIM (P/N 1200865L1) on page 33
•NetVanta ISDN S/T DIM (P/N 1200875L1) on page 34
This section describes each module, providing individual card specifications and features. Refer to Connector
Pin Definitions on page 43 for pinout information. Installing Dial Backup and Network Interface Modules on
page 39 provides information on card installation.

Option Modules NetVanta 1224STR DC Hardware Installation Guide
20 Copyright © 2013 ADTRAN, Inc. 61200590E1-34B
Network Interface Modules
NetVanta 56K/64K NIM (P/N 1200861L1)
The 56K/64K NIM (shown in Figure 3) provides a DDS WAN interface for the NetVanta. This module provides
a single 56K or 64K DDS network interface. See Table A-5 on page 45 for the WAN-DDS connector pinouts,
and Table A-13 on page 48 for the DBU connector pinouts. An optional DIM is required for dial backup
applications.
Figure 3. NetVanta 56K/64K NIM
Features and Specifications
Operating Modes
• Dedicated DDS (leased line)
DDS Interface
• Supported Standards: AT&T TR 62310
• 4-wire, full-duplex
• Receiver Sensitivity: -45 dB, all rates
• Data Rates: 56K, 64K, and auto
• Connector: RJ-48S
Clock Source
•Network
•Internal
Diagnostics
• CSU and DSU Loopbacks
Compliance
• EMC - see Electromagnetic Compatibility
(EMC) Table on page 6 .
• ACTA/FCC Part 68
• IC CS-03
• UL/CUL 60950
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent,
noncondensing
Physical
• Dimensions: 2.75-inch W x 4.25-inch D
