Advance acoustic Micromatic M17B User manual

Micromatic™ M17B
INSTRUCTION FOR USE
Advance model: 908 7057 020 ENGLISH
INSTRUCTIONS D’UTILISATION
Modèle Advance: 908 7057 020 FRANÇAIS
INSTRUCCIONES DE USO
Modelo Advance: 908 7057 020 ESPAÑOL
INSTRUÇÕES DE USO
Modelo Advance: 908 7057 020 PORTUGUÊS
909 5853 000(3)2008-11

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 1
TABLE OF CONTENTS
INTRODUCTION.............................................................................................................................................................. 2
MANUAL PURPOSE AND CONTENTS .......................................................................................................................................... 2
TARGET........................................................................................................................................................................................... 2
HOW TO KEEP THIS MANUAL....................................................................................................................................................... 2
IDENTIFICATION DATA................................................................................................................................................................... 2
OTHER REFERENCE MANUALS................................................................................................................................................... 2
SPARE PARTS AND MAINTENANCE............................................................................................................................................. 2
CHANGES AND IMPROVEMENTS ................................................................................................................................................ 2
OPERATION CAPABILITIES ........................................................................................................................................................... 2
CONVENTIONS .............................................................................................................................................................................. 2
UNPACKING/DELIVERY ................................................................................................................................................. 3
SAFETY ........................................................................................................................................................................... 3
SYMBOLS ....................................................................................................................................................................................... 3
GENERAL INSTRUCTIONS............................................................................................................................................................ 3
MACHINE DESCRIPTION ............................................................................................................................................... 5
MACHINE STRUCTURE ................................................................................................................................................................. 5
CONTROL PANEL........................................................................................................................................................................... 7
ACCESSORIES/OPTIONS.............................................................................................................................................................. 7
TECHNICAL DATA........................................................................................................................................................................... 8
WIRING DIAGRAM.......................................................................................................................................................................... 9
USE ................................................................................................................................................................................ 10
BATTERY CHECK/SETTING ON A NEW MACHINE.................................................................................................................... 10
GEL BATTERY SETTING, INSTALLATION AND CHARGING ...................................................................................................... 10
BEFORE MACHINE START-UP.....................................................................................................................................................11
MACHINE START AND STOP....................................................................................................................................................... 12
MACHINE OPERATION (SCRUBBING/DRYING)......................................................................................................................... 13
MACHINE TRANSPORT/PARKING .............................................................................................................................................. 14
TANK EMPTYING.......................................................................................................................................................................... 14
AFTER USING THE MACHINE..................................................................................................................................................... 14
RECOVERY TANK REMOVAL ...................................................................................................................................................... 15
MACHINE LONG INACTIVITY ...................................................................................................................................................... 15
FIRST PERIOD OF USE ............................................................................................................................................................... 15
MAINTENANCE............................................................................................................................................................. 16
SCHEDULED MAINTENANCE TABLE ......................................................................................................................................... 16
SQUEEGEE CLEANING ............................................................................................................................................................... 17
SQUEEGEE BLADE CHECK AND REPLACEMENT.................................................................................................................... 17
BRUSH CLEANING....................................................................................................................................................................... 18
TANK AND VACUUM GRID CLEANING ....................................................................................................................................... 18
SOLUTION FILTER CLEANING.................................................................................................................................................... 19
MACHINE SPEED ADJUSTMENT ................................................................................................................................................ 19
BATTERY CHARGING .................................................................................................................................................................. 20
FUSE CHECK/REPLACEMENT.................................................................................................................................................... 21
TROUBLESHOOTING................................................................................................................................................... 22
SCRAPPING .................................................................................................................................................................. 22

ENGLISH INSTRUCTIONS FOR USE
2909 5853 000(3)2008-11 Micromatic™ M17B
INTRODUCTION
NOTE
The numbers in brackets refer to the components shown in Machine Description chapter.
MANUAL PURPOSE AND CONTENTS
The purpose of this Manual is to provide the operator with all necessary information to use the machine properly, in a safe and
autonomous way. It contains information about technical data, operation, machine inactivity, maintenance, spare parts and safety
conditions.
Before carrying out any procedure on the machine, the operators and qualified technicians must read this Manual carefully.
Contact an authorized Advance Service Center in case of doubts regarding the interpretation of the instructions and for any further
information.
TARGET
This Manual is intended for operators and technicians qualified to perform the machine maintenance.
The operators must not perform procedures reserved for qualified technicians. Advance will not be answerable for damages coming
from the non-observance of this prohibition.
HOW TO KEEP THIS MANUAL
The Instructions for Use Manual must be kept near the machine, inside an adequate case, away from liquids and other substances
that can cause damage to it.
IDENTIFICATION DATA
The machine model and serial number are marked on the label and can be read from the outside (1).
The machine model year is shown after the Date Code on the serial plate (A08 means January 2008).
This information is useful when requiring machine spare parts. Use the following table to write down the machine identification data
for any further reference.
MACHINE model ...............................................................................
MACHINE serial number ...................................................................
OTHER REFERENCE MANUALS
Electronic Battery Charger Manual, which is to be considered as integral part of this Manual.–
Spare Parts List (supplied with the machine)–
Service Manual (that can be consulted at Advance Service Centers)–
SPARE PARTS AND MAINTENANCE
All necessary operating, maintenance and repair procedures must be carried out by qualified personnel or by Advance Service
Centers. Only original spare parts and accessories must be used.
Call Advance for service or to order spare parts and accessories, specifying the machine model and serial number.
CHANGES AND IMPROVEMENTS
Advance constantly improves its products and reserves the right to make changes and improvements at its discretion without being
obliged to apply such benefits to the machines previously sold.
Any change and/or addition of accessories must be approved and performed by Advance.
OPERATION CAPABILITIES
These scrubber-dryers are used to clean (scrubbing and drying) smooth and solid floors, in civil or industrial environment, under
safe operation conditions by a qualified operator.
The scrubber-dryers cannot be used for moquette and carpet cleaning.
CONVENTIONS
Forward, backward, front, rear, left or right are intended with reference to the operator position, that is to say with the hands on the
handlebar (2).

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 3
UNPACKING/DELIVERY
To unpack the machine, carefully follow the instructions on the packing.
When the machine is delivered, check that the packing and the machine were not damaged during transportation.
In case of visible damages, keep the packing and have it checked by the carrier that delivered it. Call the carrier immediately to fill
in a damage claim.
Please check that the following items have been supplied with the machine:
Technical documents:–
Scrubber-dryer Instructions for Use•
Electronic Battery Charger Manual•
Scrubber-dryer Spare Parts List•
No. 1 40 A lamellar fuse–
No. 4 clamps–
No. 4 battery terminal caps–
SAFETY
The following symbols indicate potentially dangerous situations. Always read this information carefully and take all necessary
precautions to safeguard people and property.
The operator’s cooperation is essential in order to prevent injury. No accident prevention program is effective without the total
cooperation of the person responsible for the machine operation. Most of the accidents that may occur in a factory, while working
or moving around, are caused by failure to comply with the simplest rules for exercising prudence. A careful and prudent operator is
the best guarantee against accidents and is essential for successful completion of any prevention program.
SYMBOLS
DANGER!
It indicates a dangerous situation with risk of death for the operator.
WARNING!
It indicates a potential risk of injury for people.
CAUTION!
It indicates a caution or a remark related to important or useful functions.
Pay careful attention to the paragraphs marked by this symbol.
NOTE
It indicates a remark related to important or useful functions.
CONSULTATION
It indicates the necessity to refer to the Instructions for Use before performing any procedure.
GENERAL INSTRUCTIONS
Specific warnings and cautions to inform about potential damages to people and machine are shown below.
DANGER!
Before performing any maintenance, repair, cleaning or replacement procedure, turn the main switch to “0”–
and, if necessary, disconnect the battery.
This machine must be used by properly trained operators only. Children or disabled people cannot use this–
machine.
Do not wear jewelry when working near electrical components.–
Do not operate the machine near toxic, dangerous, flammable and/or explosive powders, liquids or vapors:–
This machine is not suitable for collecting dangerous powders.
During battery charging, remove the recovery tank and perform this procedure in well-ventilated areas and–
away from bare flames.

ENGLISH INSTRUCTIONS FOR USE
4909 5853 000(3)2008-11 Micromatic™ M17B
WARNING!
Before using the battery charger, ensure that frequency and voltage values, indicated on the machine serial–number plate, match the electrical mains voltage.
Do not pull or carry the machine by the battery charger cable and never use the battery charger cable as–a handle. Do not close a door on the battery charger cable, or pull the battery charger cable around sharp
edges or corners. Do not run the machine on the battery charger cable. Keep the battery charger cable away
from heated surfaces.
Do not charge the batteries if the battery charger cable or the plug are damaged. If the machine is not–working as it should, has been damaged, left outdoors or dropped into water, return it to the Service Center.
To reduce the risk of fire, electric shock, or injury, do not leave the machine unattended when it is plugged–in. Before performing any maintenance procedure, disconnect the battery charger cable from the electrical
mains.
Do not smoke while charging the batteries.–Do not leave the machine unattended without being sure that it cannot move independently.–Always protect the machine against the sun, rain and bad weather, both under operation and inactivity–condition. Store the machine indoors, in a dry place: This machine must be used in dry conditions, it must
not be used or kept outdoors in wet conditions.
Before using the machine, close all doors and/or covers.–Do not allow to be used as a toy. Close attention is necessary when used near children.–Use only as shown in this Manual. Use only Advance recommended accessories.–Take all necessary precautions to prevent hair, jewelry and loose clothes from being caught by the machine–moving parts.
Do not leave the machine unattended without being sure that it cannot move independently.–Do not use the machine on slopes with a gradient exceeding the specifications.–While using this machine, take care not to cause damage to people or objects.–Do not bump into shelves or scaffoldings, especially where there is a risk of falling objects.–Do not put any can containing fluids on the machine.–The machine working temperature must be between 0°C and +40°C.–The machine storage temperature must be between 0°C and +40°C.–The humidity must be between 30% and 95%.–Do not use the machine as a means of transport.–Do not use the machine on slopes with a gradient exceeding the specifications.–Do not allow the brushes to operate while the machine is stationary to avoid damaging the floor.–In case of fire, use a powder fire extinguisher, not a water one.–Do not tamper with the machine safety guards and follow the ordinary maintenance instructions–scrupulously.
Do not allow any object to enter into the openings. Do not use the machine if the openings are clogged.–Always keep the openings free from dust, hairs and any other foreign material which could reduce the air
flow.
Do not remove or modify the plates affixed to the machine.–This machine cannot be used on roads or public streets.–Pay attention during machine transportation when temperature is below freezing point. The water in the
–recovery tank or in the hoses could freeze and seriously damage the machine.
Use the brushes and pads supplied with the machine and those specified in the Instructions for Use Manual.–Using other brushes or pads could reduce safety.
In case of machine malfunctions, ensure that these are not due to lack of maintenance. Otherwise, request–assistance from the authorized personnel or from an authorized Service Center.
If parts must be replaced, require ORIGINAL spare parts from an Otherwise Dealer or Retailer.–To ensure machine proper and safe operation, the scheduled maintenance shown in the relevant chapter of–this Manual, must be performed by the authorized personnel or by an authorized Service Center.
Carefully read all the instructions before performing any maintenance/repair procedure.–Do not wash the machine with direct or pressurized water jets, or with corrosive substances.–The machine must be disposed of properly, because of the presence of toxic-harmful materials (batteries,–etc.), which are subject to standards that require disposal in special centers (see Scrapping chapter).

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 5
42
32 01 98
81
02
31 41 71151
4
5
1
22 21
51
52
92
12
62 72
71
3
91
33
6
13
03
23
2
a32 b32
31
41
82
61
S310261
MACHINE DESCRIPTION
MACHINE STRUCTURE
Serial number plate/technical data1.
Handlebar2.
Handlebar inclination adjusting knob3.
Solution flow control lever4.
Solution flow control lever in Smart solution position (water5.
“economy” usage, for a washing autonomy set to 70-80
minutes)
Recovery water tank cover6.
Rear support wheel for transport/parking7.
Central wheels on fixed axle8.
Brush/pad9.
Brush/pad cover10.
Squeegee11.
Squeegee mounting handwheels12.
Front squeegee blade13.
Rear squeegee blade14.
Squeegee blade mounting springs15.
Recovery water drain hose16.
Recovery water drain hose bracket17.
Solution drain valve18.
Squeegee lifting/lowering lever19.
Solution filter20.
Battery charger-electrical mains connecting cable21.
Squeegee vacuum hose22.
Transport/parking device23.
Transport/parking device (engaged)23a.
Transport/parking device (disengaged)23b.
Transport/parking device positioning pin24.
Electrical component box25.
Battery charger26.
Battery charger warning lights27.
Danger label28.
Squeegee bumper wheel29.
Brush/pad support30.
Recovery tank31.
Solution tank32.
Compensation hole33.

ENGLISH INSTRUCTIONS FOR USE
6909 5853 000(3)2008-11 Micromatic™ M17B
MACHINE STRUCTURE (Continues)
Recovery water tank cover (open)41.
Recovery water tank cover gasket42.
Brush/pad support43.
Recovery tank compartment44.
Solution tank filler neck45.
Vacuum grid with automatic shut-off float46.
Recovery water drain hole47.
Vacuum system motor48.
Brush/pad motor49.
Batteries50.
Battery installation diagram51.
Deck with brush/pad-holder coupling pin52.
Machine speed adjustment screw53.
Brush54.
Pad-holder55.
Pad56.
Screw57.
Brush/pad-holder engagement rotation direction58.
Foam filter59.
41
42
46
44
47
45
43
52
57
53
50
48
49
59
58
51
54 55
56
S310235

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 7
CONTROL PANEL
Control panel61.
Charged battery warning light (green)62.
Semi-discharged battery warning light (yellow)63.
Discharged battery warning light (red)64.
Brush/pad switch65.
Vacuum switch66.
62
63
64
61 65 66
S310227
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according the
machine specific use:
Brushes/pads of different materials–
Curved squeegee–
For further information concerning the optional accessories, contact an authorized Retailer.

ENGLISH INSTRUCTIONS FOR USE
8909 5853 000(3)2008-11 Micromatic™ M17B
TECHNICAL DATA
General Values
Machine length 39.2 in (997 mm)
Machine width with squeegee 28.3 in (720 mm)
Machine width without squeegee 22.4 in (570 mm)
Min/max machine height with adjustable handlebar 28.7 - 32.9 in (730 - 836 mm)
Total machine weight 138.6 lbs (63 kg)
Minimum turning radius 29.5 in (750 mm)
Cleaning width 16.9 in (430 mm)
Battery compartment size 13.7x13.7x10.2 in (350x350x260 mm)
Central (fixed axle) wheel diameter 9.8 in (250 mm)
Brush diameter 16.9 - 17 in (430 - 432 mm)
Rear wheel pressure on the floor 145 psi (1.0 N/mm2)
Front wheel pressure on the floor 275.5 psi (1.9 N/mm2)
Brush/pad pressure on the floor 50.6 lbs (23 kg)
Performance Values
Vacuuming 41.5 inH2O (1,055 mmH2O)
Brush/pad-holder motor speed 135 rpm
Sound pressure level at workstation (ISO 11201, ISO 4871) (LpA) 65 dB(A) ± 3dB(A)
Machine sound pressure level (ISO 3744, ISO 4871) (LwA) 89 dB(A)
Vibration level at the operator’s arms (ISO 5349-1) < 2.5 m/s2
Vacuum system motor power 0.4 HP (300 W)
Brush/pad motor power 0.7 HP (520 W)
Gradeability 2%
Battery voltage 24 V
Standard batteries 12 V, 87 Ah (GEL)
Clean water tank capacity 6.0 gal (23 liters)
Dirty water tank capacity 5.5 gal (21 liters)

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 9
F3
CH1
BK RD BN
V-
IS1
F2
YE
CFBA430
BKBU BN RD
BK
EB1
PKWHOGBNBU GY
EB2
SW1
SW2
RD
ES1
BU
ES2
F1
YE
BN M2
BU M1
RD
RD
OR WH
EV1
Pb/Gel
SWITCH
RD GY
BK
RD
RD
BK
909 5604 000
Rev. A
+
-
+
-
CT
1
BL
S-
BT VT S+ V- BL
V+
8
CH
1
SC LRSVSB LY LG KY
LC
8
Ch
NO Ch
W-
W+
Gel
Pb
S310228
WIRING DIAGRAM
Key
CH1 Battery charger
C1 Battery charger connector
EB1 Electronic board (CF BA430)
EB2 Electronic board led (CF BALED)
ES1 Brush/pad switch
ES2 Vacuum switch
EV1 Water solenoid valve
F1 Brush fuse (40 A)
F2 Vacuum system fuse (40 A)
F3 Solenoid valve and electronic board fuse (5 A)
IS1 Negative insulator
M1 Brush/pad motor
M2 Vacuum system motor
SW1 Brush/pad switch
SW2 Vacuum switch
Color codes
BK Black
BU Blue
BN Brown
GN Green
GY Grey
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow

ENGLISH INSTRUCTIONS FOR USE
10 909 5853 000(3)2008-11 Micromatic™ M17B
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER–
WARNING–
CAUTION–
CONSULTATION–
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason, in case of damage replace them immediately.
BATTERY CHECK/SETTING ON A NEW MACHINE
WARNING!
The electric components of the machine can be seriously damaged if the batteries are either improperly installed
or connected. The batteries must be installed by qualified personnel only. Check the batteries for damage before
installation. Handle the batteries with great care. Install the battery terminal caps supplied with the machine.
The machine requires two 12V batteries, connected according to the diagram (51).
The machine can be supplied in one of the following modes:
GEL batteries already installed on the machine
Start the machine by pressing the brush/pad-holder and vacuum system switches (65 and 66). If the green warning light (62)–
turns on, the batteries are ready to be used.
If the yellow or red warning light (63 or 64) turns on, it is necessary to charge the batteries before using the machine (see–
procedure in Maintenance chapter).
Without batteries
Buy appropriate batteries [See the Technical Data paragraph and the diagram (51)]. For the battery choice and installation,–
apply to qualified battery retailers.
Set the machine for GEL batteries, then install the batteries on the machine and charge them, as shown in the next paragraph.–
GEL BATTERY SETTING, INSTALLATION AND
CHARGING
The electronic board of the machine is to be set according to
the type of batteries chosen, gel (GEL) batteries. Proceed as
follows.
Machine setting
The machine factory setting is for GEL batteries; if this1.
setting corresponds to the type of batteries supplied, go to
step 4. Otherwise, carry out steps 2, and 3 too.
Remove the screws (A, Fig. 1), then remove the electrical2.
component box cover (B).
WARNING!
Do not move/set the adjacent switch (D).
Reinstall the electric component box cover (B) and tighten3.
the screws (A).
B
A
A
C
D
Figure 1
S310234B

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 11
Battery installation
Disconnect the vacuum hose (22) from the squeegee (11).4.
Disconnect the recovery water drain hose (16) from the5.
bracket (17).
Open the cover (6).6.
Grasp the recovery tank (A, Fig. 2) in the area (B) and7.
slightly raise it.
Disconnect the vacuum hose (C) from the tank, then8.
remove the tank (A) with the hoses (D) and (E).
Install the batteries on the machine according to the9.
diagram (28).
Install the tank (A, Fig. 2) by performing steps 6 to 10 in10.
the reverse order.
Battery charging
Charge the batteries (see the relevant procedure in11.
Maintenance chapter).
A
B
C
D
E
Figure 2
S310233 A
BEFORE MACHINE START-UP
Brush or pad-holder installation
NOTE
Use either the brush (54) or the pad-holder (55) according to the type of floor to be cleaned.
Insert the positioning pin (24) and deactivate the transport/parking device (23b).1.
Lift the brush/pad cover (10) by prying the handlebar (2).2.
Place the brush (14) or the pad-holder (15) under the deck.3.
Lower the deck (10,) by means of the handlebar (2).4.
Engage the brush/pad-holder by pressing the brush/pad switch (65) for a few seconds. If the procedure is difficult, manually5.
turn the brush/pad-holder counter-clockwise (58).
Brush/pad application guide (suggestions only)
Types of brushes available Midlite Grit 180 Midgrit 240 Prolite Union Mix
General cleaning
Concrete
Terrazzo floor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing
Rubber tiles
Marble
Vinyl tiles

ENGLISH INSTRUCTIONS FOR USE
12 909 5853 000(3)2008-11 Micromatic™ M17B
Squeegee installation
Install the squeegee (11) and fasten it with the handwheels (12), then connect the vacuum hose (22) to the squeegee.6.
Solution tank filling
Use the filler neck (45) to fill the tank (32) with a solution suitable for the work to be performed. Do not fill the solution tank7.
completely, leave few inches from the edge. Always follow the dilution instructions on the label of the chemical product used to
prepare the solution. The solution temperature must not exceed 40°C.
CAUTION!
Use only low-foam and non-flammable detergents, intended for automatic scrubber applications.
Adjustments
Using the knob (3), adjust the handlebar (2) to the most comfortable position.8.
MACHINE START AND STOP
Starting the machine
Prepare the machine as shown in the previous paragraph.1.
Lower the squeegee (11) with the lever (19).2.
Turn the solution flow control lever (4) to one of the following positions, according to the type of cleaning to be performed:3.
Smart solutions: when the lever (4) is turned to Smart solutions (5), the machine works in a special condition of•
programmed water economy usage; as the water flow is set and constant, the machine can work with a washing autonomy
of 70-80 minutes (0.3 liters/min average).
Variable system: when the lever is turned to the left (variable flow) the flow rate can increase up to 1 liters/min.•
In no case it is possible to close completely the water flow to the brushes during operation.•
While keeping the hand on the handlebar (2), start the machine by turning the brush/pad-holder switch and the vacuum system4.
switch (65 and 66) to “I”.
NOTE
If the green warning light (62) turns on, the batteries are ready to be used. If the yellow or red warning light (63 or 64)
turns on, it is necessary to charge the battery (see the procedure in Maintenance chapter).
Stopping the machine
Turn the brush/pad-holder switch and the vacuum system switch (65 and 66) to “0”.5.
Lift the squeegee with the lever (19).6.
Insert the positioning pin (24) and lift the brush/pad-holder by activating the transport/parking device (23a).7.

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 13
MACHINE OPERATION (SCRUBBING/DRYING)
Start the machine as shown in the previous paragraph.1.
While keeping both hands on the handlebar (2), move the machine and start scrubbing/drying the floor.2.
If necessary, adjust the solution quantity by using the lever (4).3.
CAUTION!
To avoid damaging the floor surface, do not use the brushes without the solution and, when the machine is not
operating, stop the brush/pad-holder by pressing the switch (65).
CAUTION!
Before lifting the brush/pad, turn it off by pressing the switch (65).
NOTE
For correct scrubbing/drying of floors at the sides of the walls, Advance suggests to go near the walls with the right side
of the machine as shown in figure 3.
A
B
Figure 3
P100160
CAUTION!
In case of brush/pad-holder motor overload, due to foreign bodies which prevent them from turning, or to
excessively aggressive floors/brushes, the safety system stops the brush/pad-holder after about one minute of
continuous overload.
The overload is shown by the three warning lights (62, 63, 64) flashing simultaneously.
To start scrubbing again after a brush/pad-holder stop due to overload, stop the machine by turning the brush/
pad-holder switch and the vacuum system switch (65 and 66) to “0”. Turn on the machine by turning the brush/
pad-holder switch and the vacuum system switch (65 and 66) to “I”.
Battery discharge during operation
Until the green warning light (62) stays on, the batteries allow the machine to work normally. When the green warning light4.
(62) turns off and the yellow (63) and red (64) warning lights turn on in sequence, it is necessary to charge the battery as the
machine residual autonomy is at the minimum level.
CAUTION!
Do not use the machine with discharged batteries, to avoid damaging the batteries and reducing their life.
Machine speed adjustment
The machine speed varies according to the type of floor to be cleaned and the choice of using the brush or the pad. If5.
necessary, it is possible to adjust the machine speed by following the relevant procedure in the Maintenance chapter.

ENGLISH INSTRUCTIONS FOR USE
14 909 5853 000(3)2008-11 Micromatic™ M17B
MACHINE TRANSPORT/PARKING
To transport/park the machine, proceed as follows.
Turn the brush/pad-holder switch and the vacuum system switch (65 and 66) to “0”.1.
Lift the squeegee with the lever (19).2.
Grasp the handlebar (2) and slightly lower it until the rear wheel (7) comes into contact with the floor (Fig. 4). While holding the3.
machine in this position, push it to the transport/parking area.
In order not to drag the brush/pad on the floor and leave wet marks, when finishing working, remove the brush/pad-holder from4.
the deck by using the release device (see the procedure in After Using The Machine paragraph), then place it on the support
(43).
Figure 4
S310229A
TANK EMPTYING
An automatic float shut-off system (46) turns off the vacuum system when the recovery tank (31) is full.
The vacuum system shutdown, due to the recovery tank filling, is signalled by an increase in the vacuum system motor noise,
moreover the floor is not dried.
CAUTION!
If the vacuum system turns off accidentally (for example, when the float is activated because of a sudden
machine movement), to resume the operation: turn off the vacuum system by pressing the switch (66), then
open the cover (6) and check that the float inside the grid (46) has gone down to the water level. Then close the
cover (6) and turn on the vacuum system by pressing the switch (66).
When the recovery tank (31) is full, empty it according to the following procedure.
Recovery tank emptying
Start the machine by pressing the brush/pad-holder and vacuum system switches (65 and 66).1.
Lift the squeegee with the lever (19).2.
Drive the machine to the appointed disposal area.3.
Insert the positioning pin (24) and lift the brush/pad-holder by activating the transport/parking device (23a).4.
Empty the recovery tank with the drain hose (16). Then, rinse the tank with clean water.5.
Solution tank emptying
Perform steps 1 to 4.6.
Empty the solution tank by using the drain valve (18). Then, rinse the tank with clean water.7.
AFTER USING THE MACHINE
After working, before leaving the machine:
Remove the brush/pad-holder as follows:1.
With the brush/pad-holder lifted, turn the brush/pad-holder switch (65) to “I” and, after a few seconds, back to “0”, thus•
releasing the brush/pad-holder.
Empty the tanks (31 and 32) as shown in the previous paragraph.2.
Perform the daily maintenance procedures (see the Maintenance chapter).3.
Store the machine in a clean and dry place, with the brush/pad and the squeegee lifted or removed.4.

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 15
RECOVERY TANK REMOVAL
To check the batteries, or to perform other procedures, it may be necessary to remove the recovery tank (31) as shown below.
Empty the recovery tank (31) as shown in the relevant paragraph.1.
Drive the machine on a level floor.2.
Make sure that the switches (65 and 66) are turned to “0”.3.
Disconnect the vacuum hose (22) from the squeegee (11).4.
Disconnect the recovery water drain hose (16) from the bracket (17).5.
Open the cover (6).6.
Grasp the recovery tank (A, Fig. 5) in the area (B) and slightly raise it.7.
Disconnect the vacuum hose (C) from the tank, then remove the tank (A) with the hoses (D) and (E).8.
A
B
C
D
E
Figure 5
S310233A
MACHINE LONG INACTIVITY
If the machine is not going to be used for more than 30 days, proceed as follows:
Perform the operations described in the After Using The Machine paragraph.1.
Remove the recovery tank (31) according to the procedure shown in the previous paragraph, then disconnect the battery2.
negative terminals (50).
Install the recovery tank (A).3.
Store the machine in a clean and dry place.4.
FIRST PERIOD OF USE
After the first period of use (first 8 hours) it is necessary to check the fixing and connecting parts of the machine for proper
tightening. Check the visible parts for integrity and leakage.

ENGLISH INSTRUCTIONS FOR USE
16 909 5853 000(3)2008-11 Micromatic™ M17B
MAINTENANCE
The lifespan of the machine and its operating safety are ensured by correct and regular maintenance. The following chart provides
the scheduled maintenance. The intervals shown may vary according to particular working conditions, which are to be defined by
the person in charge of the maintenance.
WARNING!
Maintenance operations must be carried out with the machine switched off and the batteries/battery charger
cable disconnected.
Moreover, carefully read the instructions in Safety chapter.
All scheduled or extraordinary maintenance procedures must be performed by qualified personnel, or by an authorized Service
Center. This manual describes only the easier and most common maintenance procedures.
NOTE
For other maintenance procedures contained in the scheduled maintenance chart, refer to the Service Manual that can
be consulted at any Service Center.
SCHEDULED MAINTENANCE TABLE
Procedure Daily or after us-
ing the machine Weekly Every six months Yearly
Squeegee cleaning
Brush cleaning
Tank and vacuum grid cleaning
Squeegee blade check and replacement
Solution filter cleaning
Battery charger
Screw and nut tightening check (1)
Brush motor carbon brush check or replacement (2)
Vacuum system motor carbon brush check or replacement (2)
And after the first 8 working hours(1)
This maintenance operation must be performed by Advance authorized Service Center.(2)

INSTRUCTIONS FOR USE ENGLISH
Micromatic™ M17B 909 5853 000(3)2008-11 17
SQUEEGEE CLEANING
NOTE
The squeegee must be clean and its blades must be in good conditions in order to get a good drying.
WARNING!
It is advisable to wear protective gloves when cleaning the squeegee because there may be sharp debris.
Drive the machine on a level floor.1.
Make sure that the switches (65 and 66) are turned to “0”.2.
Lower the squeegee with the lever (19).3.
Disconnect the vacuum hose (22) from the squeegee.4.
Loosen the handwheels (12) and remove the squeegee (11).5.
Wash and clean the squeegee; in particular, clean the compartments (A, Fig. 6) and the vacuum hole (B) from dirt and debris.6.
Check the front blade (C) and the rear blade (D) for integrity, cuts and tears; if necessary replace them (see the procedure in7.
the following paragraph).
Assemble in the reverse order of disassembly.8.
SQUEEGEE BLADE CHECK AND REPLACEMENT
Clean the squeegee as shown in the previous paragraph.1.
Check that the edges of the front blade (E, Fig. 6) and of the rear blade (I) lay down on the same level, along all their length;2.
otherwise adjust their height as shown below:
Remove the fixing springs (F) and adjust the front blade (C) and the rear blade (D).•
Install the mounting springs on the front and rear blades.•
Check the front blade (C) and rear blade (D) for integrity, cuts and tears; otherwise replace them according to the following3.
procedure. Also check the front corner (H) of the rear blade for wear; if it is worn, overturn the blade to replace the worn corner
with the other one (I), if it is integral. If the other corner is worn too, replace the blade according to the following procedure:
Remove the fixing springs (F) and replace (or overturn) the rear blade (D).•
Install the mounting springs on the front and rear blades.•
Install the squeegee (11) and screw down the handwheels (12).4.
Connect the vacuum hose (22) to the squeegee (11).5.
IG
A
EH
B
A
F
F
D
C
Figure 6
S310230A

ENGLISH INSTRUCTIONS FOR USE
18 909 5853 000(3)2008-11 Micromatic™ M17B
BRUSH CLEANING
NOTE
It is advisable to wear protective gloves when cleaning the brush because there may be sharp debris.
Remove the brush, as shown in the Use chapter.1.
Clean and wash the brush with water and detergent.2.
Check the brush bristles for integrity and wear; if necessary, replace the brush.3.
TANK AND VACUUM GRID CLEANING
Drive the machine to the appointed disposal area.1.
Make sure that the switches (65 and 66) are turned to “0”.2.
Open the cover (6), then clean and wash the cover, the tanks (31 and 32) and the vacuum grid (46) with clean water. Drain the3.
water from the tanks with the drain hose (16) and the valve (18).
If necessary, release the retainers (B, Fig. 7), open the vacuum grid (A), remove the float (C), carefully clean and reinstall4.
them.
Check the recovery tank cover sealing gasket (D) for integrity.5.
NOTE
The gasket (D) creates vacuum in the tank that is necessary for the vacuuming of recovery water.
If necessary, replace the gasket (D) after removing it from its housing (E). When reassembling the new gasket, install the joint (F) in
the central area as shown in the figure.
Check the bearing surface (D) of the gasket (G) for integrity and sealing capabilities.6.
Check the compensation hole (33) for clogging.7.
NOTE
The hole (33) compensates the air in the cover air gap, thus allowing the creation of vacuum in the recovery tank.
Close the recovery tank cover (6).8.
A
B
B
C
D
E
F
G
Figure 7
S310231B
