Advance acoustic Warrior 28D User manual

Warrior™ST, Warrior™EcoFlex™
A-English
B-Español
1/10 revised 7/2016 Form No. 56041972 REV B
Instructions for Use
Advance Models: 56315036, 56307250(28D), 56315037(32D),
56315038(28C)
56315538(28D-C), 56315539(32D-C), 56315540(28C-C) 56315039(32C-C)
56381014(X28D-C), 56381015, 56381017(X32D-C), 56381024(X28C-C),
56381028(X32C-C)

A-2 / ENGLISH
A-2 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
TABLE OF CONTENTS
Page
Introduction..............................................................................A-3
Parts and Service ....................................................................A-3
Nameplate ...............................................................................A-3
Unpacking the Machine...........................................................A-3
Cautions and Warnings ...........................................................A-4
Consignes de prudence et de sécurité.....................................A5
Know Your Machine....................................................... A-6 – A-7
Control Panel – EcoFlex™ ......................................................A-8
Control Panel – Standard ........................................................A-9
Preparing the Machine for Use
Batteries ................................................................................A-10
Installing the Brushes ................................................ A-11 – A-12
Filling the Solution Tank.........................................................A-13
Squeegee Installation............................................................A-13
Detergent System (EcoFlex™)..................................A-14 – A-15
Operating the Machine
Wet Scrubbing...........................................................A-16 – A-17
Wet Vacuuming .........................................................A-16 – A-17
After Using the Machine ........................................................A-18
Maintenance Schedule..........................................................A-18
Servicing the Vacuum Motor..................................................A-18
Lubricating the Machine ........................................................A-18
Maintenance
Charging the Batteries (Wet).................................................A-19
Charging the Batteries (Gel)..................................................A-19
Servicing the Squeegee ........................................................A-20
Adjusting the Squeegee ........................................................A-20
Servicing the Recovery Tank Switches..................................A-21
Adjusting Disk Deck Skirt Height...........................................A-22
Troubleshooting
Circuit Breakers Tripping .......................................................A-23
Poor Water Pickup.................................................................A-23
Squeegee Streaks.................................................................A-23
Swirl Marks............................................................................A-23
No Solution Flow ...................................................................A-23
Scrub Deck Raises While Scrubbing (Cylindrical).................A-23
No Detergent Flow (EcoFlex™).............................................A-23
Technical Speci¿cations ........................................................A-24

ENGLISH / A-3
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-3
INTRODUCTION
This manual will help you get the most from your Advance™ automatic scrubber/dryer. Read it thoroughly before operating the machine.
Note: Bold numbers in parentheses indicate an item illustrated on pages 6-9 unless otherwise noted.
This product is intended for commercial use only.
PARTS AND SERVICE
Repairs, when required, should be performed by your Authorized Nil¿sk, Inc. Service Center, who employs factory trained service personnel, and
maintains an inventory of Advance original replacement parts and accessories.
Call Nil¿sk, Inc., for repair parts or service. Please specify the Model and Serial Number when discussing your machine.
MODIFICATIONS
Modi¿cations and additions to the cleaning machine which affect capacity and safe operation shall not be performed by the customer or user
without prior written approval from Nil¿sk, Inc. Unapproved modi¿cations will void the machine warranty and make the customer liable for any
resulting accidents.
NAMEPLATE
The Model and Serial Number of your machine are shown on the Nameplate in the battery compartment. This information is needed when
ordering repair parts for the machine. Use the space below to note the Model and Serial Number of your machine for future reference.
Model _________________________________________
Serial Number ___________________________________
UNPACKING THE MACHINE
When the machine is delivered, carefully inspect the shipping packaging and the machine for damage. If damage is evident, save the shipping
carton (if applicable) so that it can be inspected. Contact the Nil¿sk, Inc. Customer Service Department immediately to ¿le a freight damage claim.
Refer to the unpacking instruction sheet included with the machine to remove the machine from the pallet.
WARNING!
The Products sold with this Manual contain or may contain chemicals that are known to certain governments (such as the State of California, as
identi¿ed in its Proposition 65 Regulatory Warning Law) to cause cancer, birth defects or other reproductive harm. In certain locations (including
the State of California) purchasers of these Products that place them in service at an employment job site or a publicly accessible space are
required by regulation to make certain notices, warnings or disclosures regarding the chemicals that are or may be contained in the Products at
or about such work sites. It is the purchaser’s responsibility to know the content of, and to comply with, any laws and regulations relating to the
use of these Products in such environments. The Manufacturer disclaims any responsibility to advise purchasers of any speci¿c requirements that
may be applicable to the use of the Products in such environments.
revised 11/12

A-4 / ENGLISH
A-4 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
CAUTIONS AND WARNINGS
SYMBOLS
Nil¿sk, Inc. uses the symbols below to signal potentially dangerous conditions. Read this information carefully and take the necessary steps to
protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
Read all instructions before using.
GENERAL SAFETY INSTRUCTIONS
Speci¿c Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
This machine is for commercial use, for example in hotels, schools, hospitals, factories, shops and of¿ces other than normal residential
housekeeping purposes.
WARNING!
*This machine should only be used by properly trained and authorized persons.
* This machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
* While on ramps or inclines, avoid sudden stops. Avoid abrupt sharp turns. Use low speed down ramps.
*Keep sparks, Àame and smoking materials away from batteries. Explosive gases are vented during normal operation.
*Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open Àame. Do
not smoke while charging the batteries.
*Remove all jewelry when working near electrical components.
*Turn the key switch off (O) and disconnect the batteries before servicing electrical components.
*Never work under a machine without safety blocks or stands to support the machine.
*Do not dispense Àammable cleaning agents, operate the machine on or near these agents, or operate in areas where Àammable liquids exist.
*Do not clean this machine with a pressure washer.
*Do not operate this machine on ramps or inclines of more than a 2 percent gradient.
*Only use the brushes provided with the appliance or those speci¿ed in the instruction manual. The use of other brushes may impair safety.
* Observe the Gross Vehicle Weight, GVW, of the machine when loading, driving, lifting or supporting the machine.
CAUTION!
*This machine is not approved for use on public paths or roads.
*This machine is not suitable for picking up hazardous dust.
*Use care when using scari¿er discs and grinding stones. Nil¿sk, Inc. will not be held responsible for any damage to Àoor surfaces caused by
scari¿ers or grinding stones.
*When operating this machine, ensure that third parties, particularly children, are not endangered.
*Before performing any service function, carefully read all instructions pertaining to that function.
*Do not leave the machine unattended without ¿rst turning the key switch off (O), removing the key and securing the machine.
* Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
*Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
* Use caution when moving this machine in below freezing temperature conditions. Any water in the solution, recovery or detergent tanks or in
the hose lines could freeze, causing damage to valves and ¿ttings. Flush with windshield washer Àuid.
* The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be safely done in
accordance with your local environmental regulations.
*Do not use on surfaces having a gradient exceeding that marked on the machine.
*All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
* Refer to the battery charger OEM product manual for additional speci¿c battery charger warnings.
SAVE THESE INSTRUCTIONS
revised 11/12

ENGLISH / A-5
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-5
CONSIGNES DE PRUDENCE ET DE SECURITE
SYMBOLES
Les symboles reproduits ci-dessous sont utilisés par Advance pour attirer l’attention de l’opérateur sur des situations potentiellement dangereuses.
Il est donc conseillé de lire attentivement ces indications et de prendre les mesures adéquates en vue de protéger le personnel et le matériel.
DANGER!
Ce symbole est utilisé pour mettre l’opérateur en garde contre les risques immédiats pouvant provoquer des dommages corporels graves, voire
entraîner la mort.
ATTENTION!
Ce symbole est utilisé pour attirer l’attention sur une situation susceptible d’entraîner des dommages corporels graves.
PRUDENCE!
Ce symbole est utilisé pour attirer l’attention de l’opérateur sur une situation qui pourrait entraîner des dommages corporels minimes, ou des
dommages à la machine ou à d’autres équipements.
Lire toutes les instructions avant d’utiliser l’appareil.
CONSIGNES GENERALES DE SECURITE
Les consignes spéci¿ques de prudence et de sécurité mentionnées ici ont pour but de vous informer de la survenance de tout risque de
dommages matériels ou corporels.
Cette machine est destinée à un usage commercial et peut, entre autres, être utilisée dans les hôtels, écoles, hôpitaux, usines et bureaux. Elle n’a
donc pas été conçue pour l’entretien ménager.
ATTENTION!
*Cette machine ne pourra être utilisée que par du personnel parfaitement entraîné et dûment autorisé.
* L’utilisation de cette machine n’est pas destinée aux personnes (notamment les enfants) qui souffrent de capacités physiques, sensorielles ou mentales
diminuées, ou d’un manque d’expérience et de connaissances.
* Évitez les arrêts soudains lorsque la machine se trouve sur des rampes ou des pentes. Évitez les virages serrés. Adoptez une vitesse réduite lorsque la
machine est en descente.
*Eloignez les batteries de toutes Àammes, étincelles ou substance fumigène. Les gaz explosifs sont ventilés pendant le fonctionnement normal.
*De plus, du gaz hydrogène explosif s’échappe des batteries lorsqu’elles sont en charge. Ne procédez au chargement des batteries que dans une zone bien
ventilée, loin de toute Àamme. Ne fumez pas à proximité des batteries lorsqu’elles sont en charge.
*Otez tous vos bijoux lorsque vous travaillez à proximité de composants électriques.
*Positionnez la clé de contact sur off (O) et déconnectez les batteries avant de procéder à l’entretien des composants électriques.
*Ne travaillez jamais sous une machine sans y avoir placé, au préalable, des blocs de sécurité ou des étais destinés à soutenir la machine
*Ne déversez pas d’agents nettoyants inÀammables, ne faites pas fonctionner la machine à proximité de ces agents ou d’autres liquides inÀammables.
*Ne nettoyez pas cette machine avec un nettoyeur à pression.
*Ne faites pas fonctionner la machine sur des rampes ou pentes de plus de 2 pour cent.
*Utilisez uniquement les brosses fournies avec l’appareil ou celles spéci¿ées dans le manuel d’instructions. L’utilisation d’autres brosses peut mettre la
sécurité en péril.
*Respectez le poids brut du véhicule (PBV) de la machine quand vous chargez, conduisez, levez ou supportez la machine.
PRUDENCE!
*Cette machine n’est pas conçue pour une utilisation sur les chemins ou voies publiques.
*Cette machine n’est pas conçue pour le ramassage des poussières dangereuses.
*Faites extrêmement attention lorsque vous utilisez des disques de scari¿cateur et des meules. Advance ne pourra, en aucun cas, être tenu pour
responsable des dommages occasionnés à vos sols par ce type d’équipement.
*Lors de l’utilisation de cette machine, assurez-vous que des tiers, et notamment des enfants, ne courent pas le moindre risque.
*Avant de procéder à toute opération d’entretien, veuillez lire attentivement toutes les instructions qui s’y rapportent.
*Ne laissez pas la machine sans surveillance sans avoir, au préalable, coupé le contact, enlevé la clé de contact (O) et tiré le frein à main.
* Positionnez la clé de contact sur off (O) avant de remplacer les brosses ou d’ouvrir tout panneau d’accès.
*Prenez toutes les mesures nécessaires pour éviter que les cheveux, les bijoux ou les vêtements amples ne soient entraînés dans les parties mobiles de la
machine.
* Faites attention lorsque vous déplacez cette machine dans un endroit où la température peut descendre sous 0°. L’eau contenue dans les réservoirs de
détergent, de récupération ou de solution ou dans les conduites risquerait de geler et par là même d’endommager les valves et raccords de la machine.
Rincez avec un liquide de lave-glace.
* Prenez soin d’enlever les batteries de la machine avant de mettre cette dernière au rebut. Pour ce qui est de l’élimination des batteries, conformez-vous aux
réglementations locales en matière d’environnement.
*N’utilisez pas sur des surfaces dont la pente dépasse celle mentionnée sur la machine.
*Toutes les portes et couvercles doivent être dans la position mentionnée dans le manuel d’instruction avant de mettre la machine en service.
* Consultez le manuel du fabricant du chargeur de batterie pour plus de consignes de sécurité spéci¿ques sur le chargeur de batterie.
CONSERVEZ SOIGNEUSEMENT CES INSTRUCTIONS
revised 11/12

A-6 / ENGLISH
A-6 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
KNOW YOUR MACHINE
As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item
shown on these pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in
the text. NOTE: Refer to the service manual for detailed explanations of each item illustrated on the next 4 pages.
1 Solution Tank Fill
2 Operator Control Handle
3 Bottle Holders
4 Vacuum Motor Inlet Screen
5 Recovery Tank Cover
6 Detergent Cartridge Access Cover
6a Detergent Cartridge (EcoFlex models only)
7 Scrub Deck
8 Scrub Deck Skirt
9 Scrub Deck Bumper
10 Drive Wheel
11 Solution Filter
12 Solution Shut-Off Valve
13 Squeegee Assembly
14 Battery Pack Connector (onboard charger models only)
15 Onboard Battery Charger (Not found on all models)

ENGLISH / A-7
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-7
KNOW YOUR MACHINE
16 Solution Drain Hose / Level Indicator
17 Squeegee Raise / Lower Lever
18 Battery Pack Connector (non onboard charger models only)
19 Recovery Hose
20 Wheel Drive Circuit Breaker
21 Control Circuit Circuit Breaker
22 Squeegee Blade Tension Strap
23 Squeegee Blade Latch
24 Squeegee Blade Alignment Pins
25 Squeegee Mount Thumb Nut
26 Squeegee Adjustment Knob
27 Recovery Tank Drain Hose
28 Debris Hopper (Cylindrical Models Only)
29 Idler Assembly (Cylindrical Models Only)
30 Solution Manifold (Cylindrical Models Only)
31 Extended Scrub Filter (Optional)
32 Vacuum Shut Off Switch
33 Control Panel
34 Drive Paddle
35 Speed Limit Control Knob

A-8 / ENGLISH
A-8 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
Ø.4
!
!
max.2%
A
E
C
G
F
B
HI
D
D1
D2
D3 D4 D5
D6
D7
D8
D
CONTROL PANEL – ECOFLEX
A Key Switch (Main Power)
B Solution Switch
C Vacuum Switch
D Display Panel
D1 Solution Flow Indicator
D2 Fault Indicator
D3 Hour Meter
D4 Detergent Indicator
D5 Battery Indicator
D6 Scrub Pressure Indicator
D7 Recovery Tank FULL Indicator
D8 Battery Low Indicator
E Wand Switch (Dealer Installed Option)
F Detergent System (EcoFlex models only)
G EcoFlex Switch
H Scrub OFF
I Scrub ON
Regular Heavy Extreme Regular Heavy Extreme
Scrub Scrub Scrub Scrub Scrub Scrub
(press once) (press twice) (hold 5 sec.)

ENGLISH / A-9
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-9
>2%
A
B
C
E
H
I
J
J1 J2
1
2
3
D1
CONTROL PANEL – STANDARD
A Key Switch (Main Power)
B Solution Switch
C Vacuum Switch
D1 Solution Flow Indicator
E Wand Switch (Dealer Installed Option)
H Scrub OFF
I Scrub ON
J Display
J1 Battery Indicator
J2 Hour Meter / Scrub Pressure Indicator / Fault Code Display / Recovery
Tank FULL Indicator
Extreme Scrub
Heavy Scrub
Regular Scrub
Extreme Scrub
Heavy Scrub
Regular Scrub

A-10 / ENGLISH
A-10 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
BATTERIES
If your machine shipped with batteries installed do the following:
x Check that the batteries are connected to the machine (14 or 18).
x Turn ON the Key Switch (A) and check the Battery Indicator (D or J1). If the gauge is completely ¿lled or the green light is ON, the batteries are ready for
use. If the gauge is less than full or the green light is OFF, the batteries should be charged before use. See the “Charging The Batteries” section.
x IMPORTANT!: IF YOUR MACHINE HAS AN ONBOARD BATTERY CHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
If your machine shipped without batteries installed do the following:
x Consult your Authorized Nil¿sk, Inc. dealer for recommended batteries.
x Install the batteries by following the instructions below.
x DO NOT install three 12 volt batteries in your machine. This affects the stability of the machine.
x IMPORTANT!: IF YOUR MACHINE HAS AN ONBOARD BATTERY CHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
WARNING!
Use extreme caution when working with batteries. Sulfuric acid in batteries can cause severe injury if allowed to contact the skin
or eyes. Explosive hydrogen gas is vented from the batteries through openings in the battery caps. This gas can be ignited by
any electrical arc, spark or Àame. Do not install any lead-acid battery in a sealed container or enclosure. Hydrogen gas from
overcharging must be allowed to escape.
When Servicing Batteries...
*Remove all jewelry
*Do not smoke
*Wear safety glasses, rubber gloves and a rubber apron
*Work in a well-ventilated area
*Do not allow tools to touch more than one battery terminal at a time
* ALWAYS disconnect the negative (ground) cable ¿rst when replacing batteries to prevent sparks.
* ALWAYS connect the negative cable last when installing batteries.
CAUTION!
Electrical components in this machine can be severely damaged if the
batteries are not installed and connected properly. Nil¿sk, Inc., a quali¿ed
electrician, or the battery manufacturer should install batteries.
1 Remove the batteries from their shipping crate and carefully inspect them for cracks or
other damage. If damage is evident, contact the carrier that delivered them or the battery
manufacturer to ¿le a damage claim.
2 Turn the Master Key Switch (A) OFF and remove the key.
3 Tip the recovery tank to the side, locked position. Remove the battery cables from inside
the battery compartment.
4 Your machine comes from the factory with enough battery cables to install six 6 volt
batteries. Carefully lift the batteries into the battery compartment and arrange them
exactly as shown in FIGURE 1. Secure the batteries as close to the back of the machine
as possible.
5 Install the battery cables as shown. Position the cables so the battery caps can be easily
removed for battery service.
6 Carefully tighten the nut in each battery terminal until the terminal will not turn. Do not
over-tighten the terminals, or they will be very dif¿cult to remove for future service.
7 Coat the terminals with spray-on battery terminal coating (available at most auto parts
stores).
8 Put one of the black rubber boots over each of the terminals and connect the Battery
Pack Connector (14 or 18).
When changing batteries or the charger, please contact your local authorized
service center for correct battery, charger and machine settings to prevent
battery damage.
FIGURE 1
revised 11/12

ENGLISH / A-11
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-11
INSTALLING THE BRUSHES (DISC SYSTEM)
CAUTION!
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
1 Make sure the Brush Deck (7) is in the RAISED position. Make sure the Key Switch (A) is off (O).
2 If using pads, install the pads on the pad holders.
3 See Figure 2. To mount the Brushes (AA) (or pad holders) align the Lugs (BB) on the brush with the holes on the mounting plate and turn to
lock in place (turn the outside edge of brush towards the rear of machine as shown (CC)).
FIGURE 2

A-12 / ENGLISH
A-12 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
INSTALL THE BRUSHES (CYLINDRICAL SYSTEM)
CAUTION!
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
1 Make sure the Brush Deck is in the RAISED position. Make sure the Key Switch (A) is off (O).
2 See Figure 3. To access the brushes loosen the black knobs (one on each side) on top of the idler assemblies (29) and remove the idler
assemblies. Slide the brush into the housing, lift slightly, push and turn until it seats. Re-install the idler assemblies.
FIGURE 3

ENGLISH / A-13
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-13
FILLING THE SOLUTION TANK
Fill the solution tank with a maximum of 30 gallons (113.5 Liters) of cleaning solution. Do not ¿ll the solution tank above 7.5 cm (3 inches) from the
bottom of the Solution Fill (1). The solution should be a mixture of water and the proper cleaning chemical for the job. Always follow the dilution
instructions on the chemical container label. NOTE: EcoFlex machines can either be used conventionally with detergent mixed in the tank or the
detergent dispensing system can be used. When using the detergent dispensing do not mix detergent in the tank, plain water should be used.
CAUTION!
Use only low-foaming, non-Àammable liquid detergents intended for machine application. Water temperature should not exceed 130
degrees fahrenheit (54.4 degrees celsius)
SQUEEGEE INSTALLATION
1 See Figure 4. Slide the Squeegee Assembly (13) onto the squeegee mount bracket and tighten the Squeegee Mount Thumb Nuts (25).
2 Connect the Recovery Hose (19) to the squeegee inlet.
3 Lower the squeegee, move the machine ahead slightly and adjust the squeegee tilt using the Squeegee Adjustment Knob (26) so that the
rear squeegee blade touches the Àoor evenly across its entire width and is bent over slightly as shown.
FIGURE 4

A-14 / ENGLISH
A-14 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
DETERGENT SYSTEM PREPARATION AND USE (ECOFLEX MODELS ONLY)
COMMON INSTRUCTIONS:
Pressing and releasing the Detergent Switch (F) while the solution system is active will cause the detergent system to alternately turn on and off.
The system should be purged of previous detergent when switching to a different detergent. SERVICE NOTE: Move machine over Àoor drain
before purging because a small amount of detergent will be dispensed in the process.
To Purge When Changing Chemicals:
1 Disconnect and remove the detergent cartridge.
2 Turn the Key Switch (A) ON. Press and hold the Solution Switch (B) and the Detergent Switch (F) down for 2 seconds. NOTE: Once
activated the purge process takes 10 seconds. See illustration on next page for Detergent System indicators. Normally one purge cycle is
adequate to purge the system.
To Purge Weekly:
1 Disconnect and remove the detergent cartridge. Install and connect a Cartridge ¿lled with clean water
2 Turn the Key Switch (A) ON. Press and hold the Solution Switch (B) and the Detergent Switch (F) down for 2 seconds. NOTE: Once
activated the purge process takes 10 seconds. See illustration on next page for Detergent System indicators. Normally one purge cycle is
adequate to purge the system.
When the Detergent Cartridge is almost empty a Display Panel (D) indicator will come on. This “Low Detergent” indicator will remain on until you
reset the system. Once this indicator comes on you should be able to simply pour an entire gallon bottle of detergent into the Cartridge to re¿ll
without worrying about measuring. NOTE: Only reset the system when the cartridge is full. When switching cartridges, the “Low Detergent”
indicator is only accurate if the replacement cartridge is at the same level as the cartridge being replaced.
To Reset:
1 Turn the Key Switch (A) ON. Press and hold the Detergent Switch (F) and the EcoFlex Switch (G) down for 2 seconds. See illustration on
next page for Detergent System indicators.
Detergent Ratio:
1 The detergent ratio is locked at 1:400, except while overriding the EcoFlex cleaning mode. The pre-programmed ratio that is used during
EcoFlex override can be adjusted. With the detergent system OFF, press and hold the Detergent ON/OFF Switch (F) for 2 seconds. The
detergent indicator will Àash and each press of the switch will cycle through the available ratios (1:32, 1:50, 1:64, 1:100, 1:128, 1:150, 1:200,
1:256, 1:300, 1:400). Once the desired ratio is displayed on the screen (D4), stop and it will lock in after 5 seconds.
CARTRIDGE SPECIFIC INSTRUCTIONS:
Fill the detergent cartridge with a maximum of 1.25 gallons (4.73 Liters) of detergent. SERVICE NOTE: Remove the detergent cartridge from the
detergent box prior to ¿lling to avoid spilling detergent on the machine.
It is recommended that a separate cartridge be used for each detergent you plan to use. The detergent cartridges have a white decal on them so
you can write the detergent name on each cartridge to avoid mixing them up. When installing a new cartridge, remove the Cap (AA) and place the
cartridge in the detergent box. Install the Dry Break Cap (BB) as shown.

ENGLISH / A-15
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-15
Ø.4
Ø.4
Ø.4
A
F
D
B
max.2%
G
DETERGENT SYSTEM PREPARATION AND USE (ECOFLEX MODELS ONLY)
Press (F) & (G) for 2
seconds to reset. Press (F) & (B) for 2
seconds to purge.
FULL (RESET)
DETERGENT LOW
PURGE

A-16 / ENGLISH
A-16 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
WET SCRUBBING
WARNING!
Be sure you understand the operator controls and their functions. While on ramps or inclines, avoid sudden stops when loaded.
Avoid abrupt sharp turns. Use low speed down hills. Clean only while ascending (driving up) the ramp.
1 Follow the instructions in the Preparing The Machine For Use section of this manual.
2 Turn the Master Key Switch (A) ON (I). This will display the control panel indicator lights, reference the Battery Indicator and Hour Meter on the Display (D or J).
3 To transport the machine to the work area, push the Drive Paddle (34) forward to go forward or pull the Drive Paddle (34) backward to move the machine in reverse. Vary the
pressure on the Drive Paddle (34) to obtain the desired speed.
NOTE: Speed Control Knob (35) is used to control the maximum speed in either forward or reverse.
4 Press and hold the Solution Switch (B) for 5 seconds to pre-wet the Àoor. NOTE: This must be done prior to pressing the Scrub ON Switch (I).
5 Press the Scrub ON Switch (I) once for Regular Scrub or twice for Heavy Scrub mode. Hold this switch for 5 seconds for Extreme Scrub mode. Both the solution system
and detergent system have 3 Àow rate presets that coincide with the 3 scrub modes (see Control Panel). NOTE: There is a solution Àow rate over ride function if you wish
to increase solution Àow without increasing scrub pressure. Hold the Solution Switch (B) for 3 seconds (solution indicator will start Àashing) and then let go. You then have 3
seconds to set a different Àow rate by simply pressing the Solution Switch (B) repeatedly until the Solution Flow Rate Indicator (D1) shows the rate you desire (Regular, Heavy or
Extreme / see Control Panel). Any subsequent scrub pressure adjustments will reset the solution Àow rate to default.
NOTE: The solution, vacuum and detergent (EcoFlex models) systems are automatically activated when the Scrub ON Switch (I) is pressed. No further action is required other
than lowering the squeegee (17). Any individual system can be turned OFF or back ON by simply pressing its switch at any time during scrubbing.
6 Lower the squeegee with the Squeegee Raise / Lower Lever (17).
7 When the Drive Paddle (34) is in the neutral position, the scrub, vacuum, solution and detergent (EcoFlex models) systems are activated but not running. Grip the Operator
Control Handle (2) and push the Drive Paddle (34) forward to start the scrub, vacuum, solution and detergent (EcoFlex models), and to move the machine forward. For best
results, move the machine at a slow walking speed. Press the Solution Switch (B) once to turn OFF while making sharp turns. Pull the Drive Paddle (34) backward to move the
machine in reverse. The brushes will run while moving the machine in reverse, but solution and chemical will not be dispensed.
CAUTION!
To avoid damaging the Àoor, keep the machine moving while the brushes are turning.
8 When scrubbing, check behind the machine occasionally to see that all of the waste water is being picked up. If there is water trailing the machine, you may be dispensing too
much solution, the recovery tank may be full, or the squeegee tool may require adjustment.
9 EcoFlex models only: The machine defaults to the EcoFlex cleaning mode (EcoFlex Switch Indicator is lit GREEN) conserving solution and detergent. Press the EcoFlex
Switch (G) to override the EcoFlex cleaning mode and temporarily increase scrub pressure, solution Àow and the detergent ratio. This will cause the indicator to Àash green for
one minute, solution Àow rate will increase to the next level, scrub pressure will increase to the next level and the detergent ratio will increase to the pre-programmed ratio. The
pre-programmed ratio that is used during EcoFlex override can be adjusted. With the detergent system OFF, press and hold the Detergent ON/OFF Switch (F) for 2 seconds.
The detergent indicator will Àash and each press of the switch will cycle through the available ratios (1:32, 1:50, 1:64, 1:100, 1:128, 1:150, 1:200, 1:256, 1:300, 1:400).
Once the desired ratio is displayed on the screen (D4), stop and it will lock in after 5 seconds.
NOTE: Pressing and holding the EcoFlex Switch (G) for 2 seconds disables the EcoFlex system. The only way to re-enable is to push the EcoFlex Switch (G) again. Cycling
the Key Switch (A) does not re-enable the system. The EcoFlex system will only function if the Scrub System (I) has been enabled.
10 For extremely dirty Àoors, a one-pass scrubbing operation may not be satisfactory and a “double-scrub” operation may be required. This operation is the same as a one-pass
scrubbing except on the ¿rst pass the squeegee is in the up position. This allows the cleaning solution to remain on the Àoor to work longer. The ¿nal pass is made over the
same area, with the squeegee lowered to pick up the accumulated solution.
11 The recovery tank has an automatic shut-off switch that turns ALL systems OFF except the drive system when the recovery tank is full. When this switch is activated, the
recovery tank must be emptied. The machine will not pick up water or scrub with the switch activated.
NOTE: All other indicators vanish and a “Recovery Tank FULL” Indicator (D7) turns on in the Display Panel when the switch is activated on “EcoFlex” models. The Hour Meter
(J2) momentarily Àashes each letter of the word FULL over and over on “Standard” models.
12 When the operator wants to stop scrubbing or the recovery tank is full, press the Scrub OFF Switch (H) once. This will automatically stop the scrub brushes and solution Àow and
the scrub deck will raise UP. NOTE: The vacuum will stop after a 10 second delay. This is to allow any remaining water to be picked up without turning the vacuum back on.
13 Raise the squeegee and drive the machine to a designated wastewater “DISPOSAL SITE” and empty the recovery tank. To empty, pull the Recovery Tank Drain Hose (27) from
its hanger and open the cap (hold the end of the hose above the water level in the tank to avoid sudden, uncontrolled Àow of waste water). The Recovery Tank Drain Hose (27)
can be squeezed to regulate the Àow. Re¿ll the solution tank and continue scrubbing.
NOTE: Make sure the Recovery Tank Cover (5) and the Recovery Tank Drain Hose (27) cap is properly seated or the machine will not pick-up water correctly.
When the batteries require recharging the Battery LOW Indicator (D8) will come on (EcoFlex models) or the Battery Indicator (J1) will Àash red (Standard models)
and the vacuum motor will shut off after 30 seconds. Transport the machine to a service area and recharge the batteries according to the instructions in the Battery
section of this manual.
WET VACUUMING
Fit the machine with optional attachments for wet vacuuming.
1 Disconnect the Recovery Hose (19) from the Squeegee (13).
2 Attach suitable wet pick-up tools to the hose (Available from Nil¿sk, Inc.).
3 Turn the Master Key Switch (A) ON.
4 Press the Wand Switch (E) once to turn ON the vacuum motor.
SERVICE NOTE: Refer to the service manual for detailed functional descriptions of all controls and optional programmability.

ENGLISH / A-17
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-17
34
35
17
27
19
2
13
A
E
I
D
H
G
5
B
WET SCRUBBING

A-18 / ENGLISH
A-18 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
AFTER USE
1 Raise the brushes (or pads) and raise the squeegee. Move the machine to a service area.
2 Turn the Master Key Switch (A) OFF and remove the key.
3 To empty the solution tank, pull the Solution Drain Hose (16) off the elbow. Direct the hose to a Àoor drain or bucket. Rinse the tank with clean water.
Inspect the solution hoses; replace if kinked or damaged.
4 To empty the recovery tank, remove the Recovery Tank Drain Hose (27) from its hanger and remove the cap (hold the end of the hose above the water level
in the tank to avoid sudden, uncontrolled Àow of waste water). The Recovery Tank Drain Hose (27) can be squeezed to regulate the Àow. Rinse the tank
and recovery tank switch(es) (32) with clean water. Inspect the recovery and vacuum hoses; replace if kinked or damaged. SERVICE NOTE: Make sure
you do not get any water down the Vacuum Motor Inlet Screen (4) while cleaning.
5 Remove the brushes or pad holders. Rinse the brushes or pads with warm water and hang up to dry. Allow buf¿ng pads to dry completely before using
again. NOTE: You can either remove the brushes manually or automatically by pressing and holding the Scrub OFF Switch (H) for 5 seconds (EcoFlex disk
models only).
6 Remove the squeegee, rinse it with warm water and hang it up to dry.
7 Check the maintenance schedule below and perform any required maintenance before storage.
MAINTENANCE SCHEDULE
MAINTENANCE ITEM Daily Weekly Monthly Yearly
Charge Batteries X
Check/Clean Tanks & Hoses (clean recovery tank switches & vacuum inlet screen) X
Check/Clean/Rotate the Brushes/Pads X
Check/Clean the Squeegee X
Clean Hopper on Cylindrical System X
Check Each Battery Cell(s) Water Level (does not apply to gel cell batteries) X
Inspect Scrub Housing Skirts X
Inspect and clean Solution Filter X
Clean Solution Manifolds on Cylindrical System X
Purge Detergent System (EcoFlex only) X
Lubricate the Machine X
* Check Carbon Brushes X
* Have Nil¿sk, Inc. check the vacuum motor carbon motor brushes once a year or after 300 operating hours. The brush and drive motor carbon brushes check
every 500 hours or once a year.
NOTE: Refer to the Service Manual for more detail on maintenance and service repairs.
8 Store the machine in a clean, dry place.
9 Turn the Master Key Switch (A) OFF (O) and remove the key.
SERVICING THE VACUUM MOTOR
Have your Advance Dealer check the carbon motor brushes once a year or after 300 operating hours.
IMPORTANT!
Motor damage resulting from failure to service
the carbon brushes is not covered under
warranty. See the Limited Warranty Statement.
LUBRICATING THE MACHINE
Once a month, apply light machine oil to lubricate the:
• General Pivot Points For the Squeegee Linkage (A).
• Squeegee mount angle adjustment knob threads (B).
• Squeegee Tool end wheels (C).
• General Pivot Points For the Brush Linkage (D).
• Scrub deck bumper wheels.
Once per quarter, Grease the following
• Rear Caster Wheel Swivels (E).
revised 11/12

ENGLISH / A-19
FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™- A-19
CHARGING WET BATTERIES
EcoFlex - Charge the batteries each time the machine is used or when the Battery Indicator (D5) is reading less than full.
Standard - Charge the batteries each time the machine is used or when the Battery Indicator (J1) is Àashing RED.
WARNING!
Do not ¿ll the batteries before charging.
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
*Remove all jewelry
*Do not smoke
*Wear safety glasses, rubber gloves and a rubber apron
*Work in a well-ventilated area
*Do not allow tools to touch more than one battery terminal at a time
* ALWAYS disconnect the negative (ground) cable ¿rst when replacing batteries to prevent sparks.
* ALWAYS connect the negative cable last when installing batteries.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Unwind the electrical cord from the side of the onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more
detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector (18). Follow the instructions on the battery charger. SERVICE
NOTE: Make sure you plug the battery charger into the connector with the handle attached to it.
CAUTION!
To avoid damage to Àoor surfaces, wipe water and acid from the top of the batteries after charging.
CHECKING THE BATTERY WATER LEVEL
Check the water level of the batteries at least once a week.
After charging the batteries, remove the vent caps and check the water level in each battery cell. Use distilled or demineralized water in a battery
¿lling dispenser (available at most auto parts stores) to ¿ll each cell to the level indicator (or to 10 mm over the top of the separators). DO NOT
over-¿ll the batteries!
CAUTION!
Acid can spill onto the Àoor if the batteries are over¿lled.
Tighten the vent caps. Wash the tops of the batteries with a solution of baking soda and water (2 tablespoons of baking soda to 1 liter of water).
CHARGING GEL (VRLA) BATTERIES
EcoFlex - Charge the batteries each time the machine is used or when the Battery Indicator (D5) is reading less than full.
Standard - Charge the batteries each time the machine is used or when the Battery Indicator (J1) is Àashing RED.
WARNING!
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
*Remove all jewelry
*Do not smoke
*Wear safety glasses, rubber gloves and a rubber apron
*Work in a well-ventilated area
*Do not allow tools to touch more than one battery terminal at a time
* ALWAYS disconnect the negative (ground) cable ¿rst when replacing batteries to prevent sparks.
* ALWAYS connect the negative cable last when installing batteries.
CAUTION!
Your voltage regulated lead acid (VRLA) battery will deliver superior performance and life ONLY IF IT RECHARGED PROPERLY! Under or
overcharging will shorten battery life and limit performance. Be sure to FOLLOW PROPER CHARGING INSTRUCTIONS! DO NOT ATTEMPT
TO OPEN THIS BATTERY! If a VRLA battery is opened, it loses its pressure and the plates become oxygen contaminated. THE WARRANTY
WILL BE VOIDED IF THE BATTERY IS OPENED.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Unwind the electrical cord from the side of the onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more
detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector (18). Follow the instructions on the battery charger. SERVICE
NOTE: Make sure you plug the battery charger into the connector with the handle attached to it.
IMPORTANT: Make sure you have an appropriate charger for use on Gel cell batteries. Use only “voltage-regulated” or “voltage-limited” chargers. Standard constant
current or taper current chargers MUST NOT be used. A temperature-sensing charger is recommended, as manual adjustments are never accurate and will damage any
VRLA battery.

A-20 / ENGLISH
A-20 - FORM NO. - 56041972 - Warrior™ST, Warrior™EcoFlex™
SERVICING THE SQUEEGEE
If the squeegee leaves narrow streaks or water, the blades may be dirty or damaged. Remove the squeegee, rinse it under warm water and
inspect the blades. Reverse or replace the blades if they are cut, torn, wavy or worn.
To Reverse or Replace the Rear Squeegee Wiping Blade...
1 See Figure 5. Raise the squeegee tool off the Àoor, and then unsnap the Center Latch (23) on the squeegee tool.
2 Remove the Tension Straps (22).
3 Slip the rear blade off the Alignment Pins (24).
4 The squeegee blade has 4 working edges. Turn the blade so a clean, undamaged edge points toward the front of the machine. Replace the
blade if all 4 edges are nicked, torn or worn to a large radius.
5 Install the blade, following the steps in reverse order and adjust the squeegee tilt.
To Reverse or Replace the Front Squeegee Blade...
1 Raise the squeegee tool off the Àoor, loosen the (2) Thumb Nuts (25), disconnect the Recovery Hose (19) and remove the Squeegee
Assembly (13) from the mount.
2 Remove both rear Tension Straps (22) ¿rst.
3 Remove all the wing nuts that hold the front blade in place, then remove the tension strap and blade.
4 The squeegee blade has 4 working edges. Turn the blade so a clean, undamaged edge points toward the front of the machine. Replace the
blade if all 4 edges are nicked, torn or worn to a large radius.
5 Install the blade, following the steps in reverse order and adjust the squeegee tilt.
ADJUSTING THE SQUEEGEE
Adjust the squeegee angle whenever a blade is reversed or replaced, or if the squeegee is not wiping the Àoor dry.
To Adjust the Squeegee Angle...
1 Park the machine on a Àat, even surface and lower the squeegee.
2 While moving the machine forward slowly, turn the Squeegee Adjustment Knob (26) until the rear squeegee blade folds over evenly across
the entire width of the squeegee as shown below.
FIGURE 5
