Advantech PCM-2610B Installation and operation manual

PCM-261X Startup Manual 1
Before installation, please make sure that you have:
1. mPCIe card with controller x 1
2. Wired cable x 1
3. DB37 to DB9(4 ports) cable x 1
4. Startup manual x 1
5. Warranty card x 1
6. DB37 IO plate with bracket x 1
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
The driver can be downloaded from the product website.
* Supports Windows XP/7/8/10, and Linux
PCM-2610B
PCM-2612B
4-Ports Non-Isolated RS-232 mPCIe, DB37
4-Ports Non-Isolated RS-422/485 mPCIe, DB37
Startup Manual
You can set the terminator resistor via jumper setting if
necessary to match impedance.
PCM-2612B Jumper switch setting as below.
Master/Slave Settings
COM
Port Switch Pin Setting Description
COM 1
SW1
1
ON RS-422 Master
OFF RS-485/RS-422
Slave (Default)
COM 2 2
ON RS-422 Master
OFF RS-485/RS-422
Slave (Default)
COM 3 3
ON RS-422 Master
OFF RS-485/RS-422
Slave (Default)
COM 4 4
ON RS-422 Master
OFF RS-485/RS-422
Slave (Default)
SW1 SW2
SW3
CN1
CN2
Packing List
For more information on this and other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This manual is for PCM-2610B-AE/PCM-2612B-AE.
Part No. 2001261000
Printed in China
1st Edition
March 2018
Jumper Settings
Documentation/Software Support Guide

2 PCM-261X Startup Manual
Terminal Resistor Settings
COM Port Switch Pin Setting RS-422 Description RS-485 Description
COM 1
SW2
1ON 120 Ohm between Tx+/Tx- 120 Ohm between Data+/Data-
OFF Open (Default)
2ON 120 Ohm between Rx+/Rx- Invalid
OFF Open (Default)
COM 2
3ON 120 Ohm between Tx+/Tx- 120 Ohm between Data+/Data-
OFF Open (Default)
4ON 120 Ohm between Rx+/Rx- Invalid
OFF Open (Default)
COM 3
SW3
1ON 120 Ohm between Tx+/Tx- 120 Ohm between Data+/Data-
OFF Open (Default)
2ON 120 Ohm between Rx+/Rx- Invalid
OFF Open (Default)
COM 4
3ON 120 Ohm between Tx+/Tx- 120 Ohm between Data+/Data-
OFF Open (Default)
4ON 120 Ohm between Rx+/Rx- Invalid
OFF Open (Default)
Board ID Setting
The comm. cards feature a built-in DIP switch for defining the card’s board ID. When multiple cards are installed, the board ID
switch is useful for identifying the device number of each card.
Board ID Setting
SW Position 3 Position 2 Position 1 Position 0
BoardID BID3 BID2 BID1 BID0
0 ON ON ON ON
1 ON ON ON OFF
2 ON ON OFF ON
3 ON ON OFF OFF
4 ON OFF ON ON
5 ON OFF ON OFF
6 ON OFF OFF ON
Jumper Settings (Cont.)

PCM-261X Startup Manual 3
7 ON OFF OFF OFF
8 OFF ON ON ON
9 OFF ON ON OFF
10 OFF ON OFF ON
11 OFF ON OFF OFF
12 OFF OFF ON ON
13 OFF OFF ON OFF
14 OFF OFF OFF ON
15 OFF OFF OFF OFF
The following tables and figures show the pin assignments of 1 connector on the bracket to the modular card. if you see two
ports or above, it will use the same pin-definition of this one.
PCM-2610B Female DB37 on bracket PCM-2612B Female DB37 on bracket
PIN RS-232 PIN RS-232 PIN RS-422 RS-485 PIN RS-422 RS-485
1 - 20 3_RI 1 - - 20 - -
2 3_DCD 21 3_DTR 2 3_TxD- 3_Data- 21 3_RxD- -
3 3_GND 22 3_DSR 3 3_GND 3_GND 22 - -
4 3_CTS 23 3_RTS 4 - -- 23 - -
5 3_RxD 24 3_TxD 5 3_TxD+ 3_Data+ 24 3_RxD+ -
6 4_RI 25 4_DCD 6 - - 25 4_TxD- 4_Data-
7 4_DTR 26 4_GND 7 4_RxD- - 26 4_GND 4_GND
8 4_DSR 27 4_CTS 8 - - 27 - -
9 4_RTS 28 4_RxD 9 - - 28 4_TxD+ 4_Data+
10 4_TxD 29 2_RI 10 4_RxD+ - 29 - -
11 2_DCD 30 2_DTR 11 2_TxD- 2_Data- 30 2_RxD- -
12 2_GND 31 2_DSR 12 2_GND 2_GND 31 - -
13 2_CTS 32 2_RTS 13 - - 32 - -
14 2_RxD 33 2_TxD 14 2_TxD+ 2_Data+ 33 2_RxD+ -
15 1_RI 34 1_DCD 15 - - 34 1_TxD- 1_Data-
16 1_DTR 35 1_GND 16 1_RxD- - 35 1_GND 1_GND
17 1_DSR 36 1_CTS 17 - - 36 - -
18 1_RTS 37 1_RxD 18 - - 37 1_TxD+ 1_Data+
19 1_TxD 19 1_RxD+ -
19 1
37 20
Jumper Settings (Cont.)
PIN Assignment

4 PCM-261X Startup Manual
1. Remove the screws from the backplate and lift it off.
2. Unscrew to remove the blank expansion plate.
3. Instert the PCM Module through the blanking plate slot.
4. Insert the PCM IO plate through the blank plate hole
and lock the screws.
5. Insert the mPCIe card and lock the screws
6. Connect IO plate to mPCIe card with the FFC cables.
TPC Embedded Panel Computer Installation
PCM Module with iDoor technology supports following iAutomation Computing Platforms:
Standard Mount UNO-2000
DIN-Rail Mount UNO-1000
Wall Mount UNO-3000
4:3 Panel Mount TPC-xx51T/xx82, TPC-2000/5000
16:9 Panel Mount TPC-xx51WP/xx81WP, TPC-2000/5000
See the following page for installation in TPC Embedded Panel Computers and UNO Embedded Computers.
Installation

PCM-261X Startup Manual 5
UNO Embedded Computer Installation
1. Remove the screws from the base plate and lift to
remove.
2. Insert the mPCIe card and lock the screws.
3. Unscrew to remove the blank expansion plate.
4. Insert the PCM IO plate through the blank plate hole
and lock the screws. Connect IO plate to mPCIe card
with the FFC cables.
