Advantech ARK-5280 Series User manual

ARK-5280
Fanless, PC Board Expandable,
Embedded Box Computer
User Manual

ARK-5280 User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft
Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
All other product names or trademarks are properties of their respective
owners.
For more information on this and other Advantech products, please visit
our websites at: http://www.advantech.com
For technical support and service, please visit our support website at:
http://support.advantech.com
This manual is for the ARK-5280-100A1 and ARK-5280-200A1.
Part No. 2006528010 1st Edition
Printed in Taiwan May 2006

iii
Product Warranty (1 year)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for one year
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

ARK-5280 User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from Advantech. Please
contact your local supplier for ordering information. Test conditions for
passing included the equipment being operated within an industrial enclo-
sure. In order to protect the product from being damaged by ESD (Elec-
trostatic Discharge) and EMI leakage, we strongly recommend the use of
CE-compliant industrial enclosure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful inter-
ference in which case the user will be required to correct the interference
at his own expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, appli-
cation software, etc.)
- A complete description of the problem
- The exact wording of any error messages

v
ARK-5280 Series Model
There are two sub-models in ARK-5280 series as listed below:
ARK-5280-1S3A1 LV Celeron M 1.3 GHz Embedded Box Computer,
with VGA, Fast Ethernet, PS/2 (K/B & Mouse), 3 x RS-232, 1 x RS-232/
422/485, 2 x USB, DVI, Audio
ARK-5280-1S6A1 LV Pentium M 1.6GHz, Embedded Box Computer,
with VGA, Fast Ethernet, PS/2 (K/B & Mouse), 3 x RS-232, 1 x RS-232/
422/485, 2 x USB, DVI, Audio
Packing List
Before setting up the system, check that the items listed below are
included and in good condition. If any item does not accord with the
table, please contact your dealer immediately.
• 1 x ARK-5280 Unit
• 1 x PS2 Keyboard/Mouse Cable (P/N: 1700060202)
• 1 x Advantech library CD (P/N:2066000001)
• 1 x Utility CD (P/N:2066528000)
• 1 x Rear Mounting Bracket (P/N: 1960004453)
• 2 x Bottom Mounting Brackets (P/N: 1960004454)
• 1 x Power Cable, DIN-Jack to DC-Plug (P/N: 1700001861)
Note: 1 of 2 Bottom mounting brackets is made for
common usage for both table and wall mount

ARK-5280 User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Use a damp cloth. Do not use liquid or spray detergents for clean-
ing.
4. For plug-in equipment, the power outlet socket must be located
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Drop-
ping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before con-
necting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or elec-
trical shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE MAY GO BELOW -

vii
20° C (-4° F) OR ABOVE 60° C (140° F). THIS COULD DAM-
AGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES ACCORD-
ING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-
1:1982 is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.
CAUTION! THIS COMPUTER IS PROVIDED WITH A BAT-
TERY-POWERED REAL-TIME CLOCK CIRCUIT.
THERE IS A DANGER OF EXPLOSION IF
BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH SAME OR EQUIVLENT
TYPE RECOMMENDED BY THE
MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS.

ARK-5280 User Manual viii
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Ver-
wenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein
angefeuchtetes Tuch zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten.
Ein Kippen oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät
vor überhitzung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht
abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBw-
erte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber
fallen kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind
zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten
Sie es vom Stromnetz trennen. Somit wird im Falle einer Überspannung
eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder
Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw. elek-
trischen Schlag auslösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der ele-
ktrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet
werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz
zu trennen und von einer qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funk-
tioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.

ix
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der
Batterie. Ersatz nur durch densellben order einem vom Hersteller emp-
fohlene-mahnlichen Typ. Entsorgung gebrauchter Batterien navh Ang-
aben des Herstellers.
16. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf
nicht fach-männische Weise gewechselt wird. Verfangen Sie die Batterie
nur gleicher oder entsprechender Type, wie vom Hersteller empfohlen.
Entsorgen Sie Batterien nach Anweisung des Herstell-ers.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000
beträgt 70dB(A) oder weiger.
Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend
der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die
Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the
products from damage.
1. To avoid electrical shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.

ARK-5280 User Manual x

xi Table of Contents
Contents
Chapter 1 Overview .......................................................... 2
1.1 Introduction ....................................................................... 2
1.2 Features ............................................................................. 2
1.2.1 Fanless Power Computing Performance ........................ 2
1.2.2 Compact, Extremely Robust Construction .................... 2
1.2.3 Highly Optimized Integration ........................................ 2
1.3 Hardware Specifications ................................................... 3
1.3.1 Processor System ........................................................... 3
1.3.2 Display ........................................................................... 3
1.3.3 Ethernet .......................................................................... 3
1.3.4 Audio ............................................................................. 4
1.3.5 Other .............................................................................. 4
1.3.6 Storage ........................................................................... 4
1.3.7 PC Board Expansion ...................................................... 4
1.3.8 Mechanical ..................................................................... 4
1.3.9 Internal DC-to-DC Power Supply Unit ......................... 5
1.3.10 Environment Specifications ........................................... 5
Figure 1.1:PCI Board Power Consumption Limit ......... 6
1.4 Chassis Dimensions........................................................... 7
Figure 1.2:ARK-5280 Dimensions ................................ 7
Chapter 2 Hardware Functionality ............................... 10
2.1 Introduction of External I/O Connectors......................... 10
Figure 2.1:Front Panel External I/O Connectors ......... 10
2.2 Front Panel External I/O Connectors .............................. 10
2.2.1 Power ON/OFF Button ................................................ 10
2.2.2 LED Indicators ............................................................. 10
2.2.3 Power Input Connector ................................................ 11
Figure 2.2:4-pole, DC DIN-Jack .................................. 11
Table 2.1:Power Connector Pin Assignments ............. 11
2.2.4 COM2 Connector ......................................................... 11
Figure 2.3:COM 2 Connector ...................................... 11
Table 2.2:COM1 Serial Port Pin Assignments ............ 11
2.2.5 COM1, COM3, and COM4 Connector ........................ 12
Figure 2.4:COM1, COM3 and COM 4 Connector ...... 12
Table 2.3:COM2~4 Serial Port Pin Assignments ........ 12
2.2.6 Audio Connector .......................................................... 13
2.2.7 DVI Connector ............................................................. 13
Figure 2.5:DVI Connector ........................................... 13
Table 2.4:DVI Port Pin Assignments .......................... 13
2.2.8 Ethernet Connector (LAN) .......................................... 14
Figure 2.6:RJ-45 Connector ......................................... 14
Table 2.5:RJ-45 Connector pin assignments ............... 14
2.2.9 PS2 Keyboard/Mouse Connector ................................ 15

ARK-5280 User Manual xii
Figure 2.7:PS/2 Mouse Connector ............................... 15
Table 2.6:PS2 Keyboard and PS2 Mouse Connector .. 15
2.2.10 VGA Connector ........................................................... 16
Figure 2.8:VGA Connector .......................................... 16
Table 2.7:Table 2.10: VGA port pin assignments ...... 16
2.2.11 USB Connector ............................................................ 16
Figure 2.9:USB Connector .......................................... 17
Table 2.8:USB Connector ............................................ 17
Chapter 3 Hardware Installation & Upgrade .............. 20
3.1 Jumpers and Connectors.................................................. 20
3.2 Setting Jumpers ............................................................... 20
3.3 Jumper Location.............................................................. 21
Table 3.1:Jumpers ........................................................ 21
Figure 3.1:Jumper Location of Internal SBC Board .... 21
3.4 COM2 RS-232/422/485 Jumper setting (JP1) ................ 22
Table 3.2:COM2 RS-232/422/485 Jumper Selection .. 22
3.5 CMOS Clearance (JP2) ................................................... 22
Table 3.3:Clear CMOS Jumper (JP3) .......................... 22
3.6 PCl Card Power Selection............................................... 23
Table 3.4:PCl Card Power Selection ........................... 23
3.7 Connecting Power .......................................................... 23
3.8 Installing the DDR SDRAM Memory Module............... 23
Figure 3.2:Disconnect the Power Cord ........................ 23
Figure 3.3:Unscrew the Top Cover Screws ................. 24
Figure 3.4:Remove the Top Cover and PCI Cover ...... 24
Figure 3.5:Insert the SODIMM Module ...................... 25
3.9 Install a Compact Flash Card .......................................... 25
Figure 3.6:Install the CF Card ..................................... 26
3.10 Installing the 2.5" Hard Disk Drive (HDD) ................... 26
Figure 3.7:Remove the HDD cover frame ................... 27
Figure 3.8:Connect the HDD and IDE Cable .............. 27
Figure 3.9:Install the HDD into the HDD Housing ..... 28
3.11 Installing the PCI card..................................................... 28
Figure 3.10:Remove the PCI dummy bracket ............. 29
Figure 3.11:Insert the PCI Card and Fasten ................. 30
Figure 3.12:Adjust the Depressed Rubber Height ....... 30
Chapter 4 Award BIOS Setup........................................ 32
4.1 Introduction ..................................................................... 32
4.1.1 CMOS RAM Auto-backup and Restore ...................... 32
4.2 Entering Setup................................................................. 32
Figure 4.1:Award BIOS Setup ..................................... 33
4.3 Standard CMOS Setup .................................................... 33
Figure 4.2:Standard CMOS Features ........................... 34
4.4 Advanced BIOS Features................................................ 34
Figure 4.3:Advanced BIOS Features ........................... 35
4.4.1 Virus Warning .............................................................. 35
4.4.2 L1 & L2 Cache ............................................................ 35

xiii Table of Contents
4.4.3 Quick Power On Self Test ........................................... 35
4.4.4 First/Second/Third/Other Boot Device ........................ 35
4.4.5 Swap Floppy Drive ...................................................... 35
4.4.6 Boot UP Floppy Seek .................................................. 36
4.4.7 Boot Up NumLock Status ............................................ 36
4.4.8 Gate A20 Option .......................................................... 36
4.4.9 Typematic Rate Setting ................................................ 36
4.4.10 Typematic Rate (Chars/Sec) ........................................ 36
4.4.11 Typematic Delay (msec) .............................................. 36
4.4.12 Security Option ............................................................ 36
4.4.13 APIC Mode .................................................................. 37
4.4.14 MPS Version Control For OS ...................................... 37
4.5 Advanced Chipset Features............................................. 37
Figure 4.4:Advanced Chipset Features Setup .............. 37
4.5.1 DRAM Timing Selectable ........................................... 37
4.5.2 CAS Latency Time ...................................................... 37
4.5.3 Active to Precharge Delay ........................................... 38
4.5.4 DRAM RAS# to CAS# Delay ..................................... 38
4.5.5 DRAM RAS# Precharge .............................................. 38
4.5.6 DRAM Data Integrity Mode ........................................ 38
4.5.7 MGM Core Frequency ................................................. 38
4.5.8 System BIOS Cacheable .............................................. 38
4.5.9 Video BIOS Cacheable ................................................ 38
4.5.10 Memory Hole At 15M-16M ........................................ 38
4.5.11 Delayed Transaction .................................................... 39
4.5.12 Delay Prior to Thermal ................................................ 39
4.5.13 AGP Aperture Size (MB) ............................................ 39
Figure 4.5:**ON Chip VGA Setting** Screen ........... 39
4.5.14 On-Chip VGA .............................................................. 39
4.5.15 On-Chip Frame Buffer Size ......................................... 39
4.5.16 Boot Display ................................................................ 40
4.5.17 Panel Scaling ................................................................ 40
4.5.18 Panel Resolution .......................................................... 40
Figure 4.6:“Boot Display” Selection ........................... 40
Figure 4.7:“Panel Number” (Resolution) Selection .... 41
4.6 Integrated Peripherals...................................................... 41
Figure 4.8:Integrated peripherals ................................. 41
4.6.1 IDE Master/Slave PIO/UDMA Mode, ......................... 42
4.6.2 On-Chip Primary/Secondary PCI IDE ......................... 42
Figure 4.9:On-Chip IDE Device .................................. 42
4.6.3 IDE HDD Block Mode ................................................ 42
Figure 4.10:Onboard Device ........................................ 43
4.6.4 USB Controller ............................................................ 43
4.6.5 USB 2.0 Controller ...................................................... 43
4.6.6 USB Keyboard/Mouse Support ................................... 43
4.6.7 AC97 Audio ................................................................. 43

ARK-5280 User Manual xiv
4.6.8 Init Display First .......................................................... 43
Figure 4.11:Super IO Device ....................................... 44
4.6.9 Onboard FDC Controller ............................................. 44
4.6.10 Onboard Serial Port ..................................................... 44
4.6.11 UART Mode Select ..................................................... 44
4.6.12 RxD, TxD Active ......................................................... 44
4.6.13 IR Transmission Delay ................................................ 44
4.6.14 UR2 Duplex Mode ....................................................... 45
4.6.15 Onboard Parallel Port ................................................... 45
4.6.16 Parallel Port Mode ....................................................... 45
4.6.17 EPP Mode Select ......................................................... 45
4.6.18 ECP Mode Use DMA .................................................. 45
4.6.19 PWRON After PWR-Fail ............................................ 45
4.7 Power Management Setup............................................... 46
4.7.1 ACPI function .............................................................. 46
4.7.2 ACPI Suspend Type ..................................................... 46
4.7.3 Power Management ..................................................... 46
Figure 4.12:Power Management Setup ........................ 47
4.7.4 Video Off In Method ................................................... 47
4.7.5 Video Off In Suspend .................................................. 47
4.7.6 Suspend type ................................................................ 47
4.7.7 Modem Use IRQ .......................................................... 47
4.7.8 Suspend Mode .............................................................. 47
4.7.9 HDD Power Down ....................................................... 48
4.7.10 Soft-Off by PWR-BTTN ............................................. 48
4.7.11 CPU THRM-Throttling ................................................ 48
4.7.12 Wake-up By PCI card .................................................. 48
4.7.13 Power On By Ring ....................................................... 48
4.7.14 Resume By Alarm ........................................................ 48
4.7.15 Primary IDE 0 (1) and Secondary IDE 0 (1) ............... 49
4.7.16 FDD, COM, LPT PORT .............................................. 49
4.7.17 PCI PIRQ [A-D]# ........................................................ 49
4.8 PnP/PCI Configurations .................................................. 49
Figure 4.13:PnP/PCI Configurations ........................... 49
4.8.1 Reset Configuration Data ............................................. 50
4.8.2 Resources controlled by: .............................................. 50
4.8.3 PCI/VGA Palette Snoop .............................................. 50
4.9 PC Health Status.............................................................. 50
Figure 4.14:PC Health Status ....................................... 50
4.9.1 CPU Warning Temperature ......................................... 51
4.9.2 Temperatures/Voltages ................................................ 51
4.9.3 Shutdown Temperature ................................................ 51
4.10 Frequency/Voltage Control ............................................. 51
Figure 4.15:Frequency/Voltage Control ..................... 51
4.11 Password Setting ............................................................. 52
4.12 Save & Exit Setup ........................................................... 52

xv Table of Contents
4.13 Exit Without Saving........................................................ 52
Chapter 5 PCI SVGA Setup ........................................... 54
5.1 Introduction ..................................................................... 54
5.1.1 Chipset ......................................................................... 54
5.1.2 Display memory ........................................................... 54
5.1.3 Display types ................................................................ 54
5.2 Installation of the SVGA Driver ..................................... 54
5.2.1 Installation for Windows 2000/XP .............................. 54
Figure 5.1:Directory of VGA Driver ........................... 55
Figure 5.2:VGA Driver Installation Setup Screen ....... 56
Figure 5.3:Intel Extreme Graphics 2 Installer ............. 56
Figure 5.4:License Agreement ..................................... 57
Figure 5.5:Installation Complete ................................. 57
5.3 Further information ......................................................... 58
Chapter 6 PCI Bus Ethernet Interface.......................... 60
6.1 Introduction ..................................................................... 60
6.2 Installation of Ethernet driver ......................................... 60
6.2.1 Installation for Windows XP ....................................... 61
Figure 6.1:Device Manager ......................................... 61
Figure 6.2:Update Driver ............................................. 62
Figure 6.3:Hardware Update Wizard ........................... 62
Figure 6.4:Choose Automatic Installation ................... 63
Figure 6.5:Hardware Installation ................................. 63
Figure 6.6:Completing the Hardware Update Wizard . 64
Chapter 7 Audio Setup.................................................... 66
7.1 Introduction ..................................................................... 66
7.2 Driver Installation ........................................................... 66
7.2.1 Before you begin .......................................................... 66
7.2.2 Windows XP driver ..................................................... 66
Figure 7.1:Audio Driver Directory .............................. 67
Figure 7.2:Realtek AC’97 Audio Setup ....................... 68
Figure 7.3:Software Installation Screen ....................... 68
Figure 7.4:Install Shield Wizard Complete ................. 69
Appendix A Watchdog Timer............................................ 72
A.1 Watchdog Programming ................................................ 72

ARK-5280 User Manual xvi

2
CHAPTER
1
Overview
This chapter gives background infor-
mation on the ARK-5280, including an
overview and specifications.
Sections include:
• Introduction
• Features
• Hardware Specifications
• Chassis Dimension

ARK-5280 User Manual 2
Chapter 1 Overview
1.1 Introduction
ARK-5280 is a powerful, robust and fanless Embedded Box Computer.
The high performance ARK-5280 is equipped with socket 479 that sup-
ports Intel Celeron-M and Pentium-M processors, which is highly suit-
able for embedded and industrial PC applications requiring high
processor performance within a limited space. Featuring two PCI slots for
application expansion and system integration, ARK-5280 also carries
four USB 2.0 and four serial port communication I/O interfaces. It can
support up to 2 GB DDR SDRAM of main memory and has dual inde-
pendent display support from the built-in CRT/VGA and DVI interfaces
that gives ARK-5280 great flexibility within space critical environments.
ARK-5280 is ideal for embedded system applications such as machine
automation, and industrial plant and cabinet integration.
1.2 Features
1.2.1 Fanless Power Computing Performance
• Fanless operation in sealed construction utilizing low thermal emission
processors
• Supports Socket 479 type Intel Pentium M and Celeron M processors
1.2.2 Compact, Extremely Robust Construction
• Robust sealed Aluminum casting construction using a modularized
design to offer maximize space efficiency
• Rubber anti-vibration card-holder for PC expansion boards and anti-
vibration HDD to ensure maximum reliability
1.2.3 Highly Optimized Integration
• Simple and modularized service-friendly design
• Quick installation, easy expansion and maintenance
• Systems are supplied “Ready-to-Run”
• Access wide-range of 9 ~ 32 VDC power input source with ATX sup-
port; offers flexibility for various automation environments
• Long life cycle support for product continuity to secure investment

3 Chapter1
1.3 Hardware Specifications
1.3.1 Processor System
Processor Support
Supports uFCPGA2, 478 pin embedded Intel Pentium M or Celeron M
processors, and supports up to Intel Pentium M processor 745 at 1.8 GHz
• Celeron M 1.3 GHz (ARK-5280-1S3A1)
• Pentium M 1.6 GHz (ARK-3380-1S6A1)
System Chipset
• Intel 855GME Graphics Memory Controller Hub (GMCH) Chipset
• Intel FW82801DB I/O Controller Hub 4 (ICH4) Chipset
• 400 MHz FSB
BIOS:
4 Mbit Flash BIOS, supports Plug & Play, APM 1.2 ACPI Supported
Second level cache
• Celeron M processor: 512 KB or 1 MB
• Pentium M processor 1 MB or 2 MB
System Memory
• Dual-200 pin SO-DIMM sockets
• Supports ECC DDR200/266/333 SDRAM Up to 2GB
1.3.2 Display
Chipset
Intel 855GME GMCH, utilizing Intel Extreme Graphics 2 technology
Display Memory
Dynamic video memory allocation up to 64 MB
Display Interface support
• CRT Interface
• DVI interface, compliant with DVI specification 1.0.
• Resolution up to 2048X1536@24bpp (75 Hz)
1.3.3 Ethernet
Ethernet Controller:
Intel 82551ER Ethernet Controller

ARK-5280 User Manual 4
Ethernet Interface
Built-in Dual RJ45 ports as LAN 1 and LAN 2
1.3.4 Audio
Audio Interface
• Audio controller on the ICH4 chip.
• Realtek ACL202 AC97 Codec
• AC97 3D surround stereo sound, Dual 2.2 W Amplifier
• Supports Line_In, Speaker_Out, and Microphone_In connectors on the
front side.
1.3.5 Other
Watchdog Timer:
255 levels timer interval, setup by software
Series Port:
One RS-232/422/485 port (COM2) and 3*RS-232 port (COM1,COM3,
and COM4) on the front side.
Keyboard/Mouse:
One PS/2 Port to support PS/2 Mouse and PS/2 Keyboard
USB:
• ARK-5280 Support up to 4*USB 2.0 compliant universal series bus
ports.
• ARK-5280 default supports 2*USB 2.0 compliant universal series bus
ports.
• Additional 2*USB 2.0 compliant universal series bus ports can be sup-
ported optionally by Dual-USB Cable-Bracket (Part # 1700001934)
1.3.6 Storage
• Supports one drive bay space for 2.5’’ HDD
• Supports one Compact Flash socket for Type I/II Compact Flash
1.3.7 PC Board Expansion
• Built-in 2*PCI expansion slots
• Supports maximum length of 185 mm of PCB boards expansion
1.3.8 Mechanical
Construction: Aluminum housing
Mounting: Desktop mounting and wall mounting
