Advantech B+B SmartWorx IE-ModeConverter User manual

IE-ModeConverter
Fiber Mode Conversion - SFP Module/s
USER MANUAL

IE-ModeConverter - SFP
ii
Advantech B+B SmartWorx - Americas
707 Dayton Road
Ottawa, IL 61350 USA
Phone [phone]
Fax [phone]
Advantech B+B SmartWorx - Europe
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone [phone]
Fax [phone]
www.advantech-bb.com
[e-mail]

IE-ModeConverter - SFP
ii
CONTENTS
About The IE-iMcV-MediaLinX & -iMcV-MediaLinX.................................... 4
Overview .....................................................................................................................4
Features ....................................................................................................................... 4
Applications ................................................................................................................. 5
Installing the IE-ModeConverter ................................................................ 5
SFP Port Requirements ................................................................................................ 5
DIN Rail Mounting....................................................................................................... 5
DIN Rail - Cascading DC Power .................................................................................. 6
Powering the IE-ModeConverter ................................................................ 6
Power Input Specifications........................................................................................... 6
DC Terminal Block Option .......................................................................................... 7
DC Power Supply Precautions ..................................................................................... 7
LED Operation ......................................................................................... 8
Specifications........................................................................................... 9
B+B SmartWorx Technical Support.......................................................... 10
Statements, Guidelines, Precautions, Regulatory ..................................... 10
FCC Radio Frequency Interference Statement....................................................... 10
Fiber Optic Cleaning Guidelines......................................................................... 11
Electrostatic Discharge Precautions............................................................................ 12
Regulatory, Standards, Compliances ..........................................................................13

IE-ModeConverter - SFP
4
ABOUT THE IE-IMCV-MEDIALINX & -IMCV-MEDIALINX
OVERVIEW
The IE-ModeConverter is a pure mode converter that converts any fiber optics
type to any other fiber optics type. This product is a protocol independent
converter and is not intended for applications that require retiming or any
Layer 2 functions. The IE-ModeConverter supports extended temperature
operation.
The IE-ModeConverter requires two small form-factor (SFP) modules (sold
separately and available from B+B SmartWorx), which provide greater fiber
flexibility in the network environment. The hot-swappable nature of SFPs and
the numerous fiber modes and types available in SFPs allow for easy
configuration and future upgrading as network demands evolve. The SFP
modules must be MSA-compliant and support the same speed range.
•The IE-ModeConverter operates as a mode converter only; and not as a rate
converter.
•The IE-ModeConverter does not provide support for copper (TX) SFPs.
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.
FEATURES
The IE-ModeConverter provides the ability to change optical transport
characteristics using easy-to-install SFP devices. This mix-and-match
functionality is only limited by available B+B SmartWorx’ SFP units.
Key Features:
• Uses Miniature Media Converter Form Factor.
• Supports 7 to 50 VDC terminal block option with cascading power.
• Supports external 5 VDC power option (not extended temperature).
• Allows extended temperature range from -25 to +85 °C (-13 to +185 °F).
• Uses all standard MSA-complaint SFP devices (excluding copper SFPs).
• Provides extensive diagnostic LED functions.
• Supports DIN rail mounting.

IE-ModeConverter - SFP
5
APPLICATIONS
The standard application is the conversion of a short-range, multi-mode fiber
interface to a long-range, single-mode fiber line. In addition, CWDM, DWDM
or single-strand fiber can be supported with the appropriate SFP. This allows
you to purchase low-cost, multi-mode fiber blade cards for your network
equipment and support long-distance, single-mode fiber links.
INSTALLING THE IE-MODECONVERTER
The IE-ModeConverter installs anywhere as a standalone, table-top device, or
on a DIN rail.
As a standalone device, install it in locations with limited space.
If multiple connections are required, use an IE-PowerTray/18 enclosure, (sold
separately, available from B+B SmartWorx). The tray allows for 18
conversions in a 1.5 rack unit of space. The units can also be powered by
daisy-chaining DC power (see Cascading DC Power).
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.
SFP PORT REQUIREMENTS
The IE-ModeConverter requires two SFP modules of the same speed: either two
fast Ethernet (100Mbps) modules, or two Gigabit Ethernet (1000Mbps) modules.
NOTE: Both SFPs must operate at the same speed.
DIN RAIL MOUNTING
The IE-ModeConverter can be mounted with two
DIN rail clips (hardware option, available from B+B
SmartWorx). The DIN rail clips include screws to
allow the installation on a DIN rail. Install the screws
into DIN rail clips, which should be mounted
perpendicular to the DIN rail. Snap the converter
onto the clips. To remove the converter from the DIN
rail, place a flat-head screwdriver into the slot to
gently pry the converter from the rail.
Note: DIN rail clips are designed for use on DIN-35 rail.

IE-ModeConverter - SFP
6
DIN RAIL - CASCADING DC POWER
If installing multiple IE-ModeConverters on
DIN rail, you can use one DC input source
and then cascade from one DC terminal block
to the next, until reaching the maximum
electrical current available.
POWERING THE IE-MODECONVERTER
The IE-ModeConverter requires an external DC power source and has three
powering options:
•Universal AC power adapter w/ country specific clip (not included with module only version).
•User supplied LPS DC power via a four-position DC power block.
•Power from an IE- PowerTray/18 (optional, available from B+B SmartWorx)
•Double-USB power cable (optional, available only from B+B SmartWorx).
•IE-Power/5V DIN rail mount power supply, extended temperature (optional, from B+B)
For extended temperature operation, the DC terminal block must be used
because the supplied AC to DC converter is not rated for extended
temperature operation. The power source used with the DC terminal block
should be a Limited Power Source (LPS).
POWER INPUT SPECIFICATIONS
Power Input Specifications Table
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A maximum
DC Terminal
+7 to +50 VDC @ 2.5 Watts. Actual current consumption may
vary depending on the type of SFP modules installed. When
not using the supplied AC/DC converter, the externally
supplied DC power must be provided from an LPS source.
DC Jack
5 VDC
Double-USB Power
Cable
Spec 500mA
NOTE : that the laptop or PC USB ports must be 2.0 or greater to provide sufficient
power to the unit.
Power Tray 18-Slot
AC for Miniature
Converters
125W, 20A @ 5V

IE-ModeConverter - SFP
7
DC TERMINAL BLOCK OPTION
The IE-ModeConverter DC power option
includes a 7 to 50 VDC terminal block and a
standard +5 VDC mini-jack. The DC terminal
block has multiple DC inputs intended for
cascading DC power to an adjacent unit.
Connect the power source to any one positive
and one negative terminal on the IE-
ModeConverter.
NOTE: When using stranded wire, the leads must be tinned. The chassis is not protected against mis-wiring;
if mis-wired the chassis will not function. The chassis is internally connected to the negative power terminal.
DC POWER SUPPLY PRECAUTIONS
The following precautions must be observed when installing the chassis model with an
internal DC power supply.
1. Check nameplate ratings to ensure there is no overloading of supply circuits that
could affect overcurrent protection and supply wiring.
2. In addition, the following must be observed:
a. Connect the equipment to a 35 to 50 VDC power source that is electrically isolated from
the alternating current source. The 35 to 50 VDC power source is connected to a SELV
DC source.
b. Route input wiring to terminal block and secure in such a manner that it is protected from
damage and stress. Do not route wiring past sharp edges or moving parts.
c. Incorporate a readily accessible disconnect device, with a 3mm minimum contact gap in
the fixed wiring.
Reliable Earthing of this equipment must be maintained. Particular attention should be
given to supply connections when connecting to power strips, rather than direct
connections to the branch circuit.

IE-ModeConverter - SFP
8
LED OPERATION
The IE-ModeConverter has four status
LED indicators. Each LED is dual color
and has three states: Off, red, or
green. A loss of signal on one SFP
causes the TX of the other SFP to turn
Off. This action does not activate the
red TX Fault LED.
LED COLOR OR STATE
PWR
Red
Off
Green
Card does not pass the self-test. Unit does not
have power.
Power is applied to the card.
All internal self-test functions
must pass before the PWR
LED is green.
SD I
SD 2
LED transmitter has an active fault. No active fault
on transmitter.
LOS indication
on receiver.
Valid signal is detected by the
SFP and LED transmitter is not
in fault.
MSA LEDs
One or both SFPs are not installed or
not detected. The TX inhibit must not
be active if a SFP is missing.* Or, both
SFPs are installed, but their speed
settings are different. This condition
disables both SFPs.
N/A Indicates that both SFPs with
the same speed are securely
installed.
*To help in troubleshooting, the Link Loss (LL) feature is always ON. That is, if a LOS is detected on an
incoming SFP port, the optical transmitter on the other SFP port is turned OFF. This provides a Link Loss
carry forward function to alert the device downstream of the existing problem. This function is "ON" in
both directions at the same time. The LL function is inhibited if either SFP is not installed.

IE-ModeConverter - SFP
9
SPECIFICATIONS
Operating Temperature:
-25 to +85 °C (-13 to +185 °F) - DC configuration
-20 to +70 °C (-4 to +158 °F) - DIN rail mount power supply
-10 to +50 °C (+14 to +122 °F) - with AC wall adapter
Storage Temperature:
-45 to +85 °C (-49 to +185 °F)
Shipping Weight:
0.11 kg (0.25 lb)
Dimensions:
2.11H x 4.57W x 8.51D cm (0.83H x 1.80W x 3.35D in)

IE-ModeConverter - SFP
10
B+B SMARTWORX TECHNICAL SUPPORT
USA/Canada: 1 [phone] (Ottawa IL USA)
Europe: [phone] (Ireland / Europe)
Email: [e-mail]
Web: www.advantech-bb.com
STATEMENTS, GUIDELINES, PRECAUTIONS, REGULATORY
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class A computing device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which the user will be
required to correct the interference at his own expense.
Any changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC
RFI limits. This digital apparatus does not exceed the Class A limits for radio
noise emission from digital apparatus set out in the Radio Interference
Regulation of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de classe A
prescrites dans le Règlement sur le brouillage radioélectrique publié par le
ministère des Communications du Canada.

IE-ModeConverter - SFP
11
FIBER OPTIC CLEANING GUIDELINES
Fiber Optic transmitters and receivers are extremely susceptible to
contamination by particles of dirt or dust, which can obstruct the optic path and
cause performance degradation. Good system performance requires clean
optics and connector ferrules.
1. Use fiber patch cords (or connectors, if you terminate your own fiber)
only from a reputable supplier; low-quality components can cause many
hard-to-diagnose problems in an installation.
2. Dust caps are installed at the factory to ensure factory-clean optical
devices. These protective caps should not be removed until the moment
of connecting the fiber cable to the device. Should it be necessary to
disconnect the fiber device, reinstall the protective dust caps.
3. Store spare caps in a dust-free environment such as a sealed plastic
bag or box so that, when reinstalled, they do not introduce any
contamination to the optics.
4. If you suspect that the optics have been contaminated, alternate
between blasting with clean, dry, compressed air and flushing with
methanol to remove particles of dirt.

IE-ModeConverter - SFP
12
ELECTROSTATIC DISCHARGE PRECAUTIONS
Electrostatic discharge (ESD) can cause damage to any product, add-in
modules or standalone units, containing electronic components. Always
observe the following precautions when installing or handling these kinds of
products:
1. Do not remove unit from its protective packaging until ready to install.
2. Wear an ESD wrist grounding strap before handling any module or
component. If a wrist strap is not available, maintain grounded
contact with the system unit throughout any procedure requiring ESD
protection.
3. Hold the units by the edges; do not touch the electronic components
or gold connectors.
4. After removal, always place the boards on a grounded, static-free
surface, ESD pad or in a proper ESD bag. Do not slide the modules
or standalone units over any surface.
WARNING! Integrated circuits and fiber optic components are
extremely susceptible to
electrostatic discharge damage. Do
not handle
these components directly unless you are a qualified
service technician and use tools and techniques that conform to
accepted industry practices.

IE-ModeConverter - SFP
13
REGULATORY, STANDARDS, COMPLIANCES
•SFP-MSA SFP standard (September 14, 2000)
•SFF-8472 DDMI standard (Revision 1.0)
•All SFPs used in this product should be certified to IEC 60825-1
UL/cUL: Listed to Safety of Information Technology Equipment, including Electrical
Business Equipment.
CE: The products described herein comply with the Council Directive on
Electromagnetic Compatibility (2004/108/EC) and the Council Directive on Electrical
Equipment Designed for use within Certain Voltage Limits (2006/95/EC). Certified to
Safety of Information Technology Equipment, Including Electrical Business Equipment.
For further details, contact B+B SmartWorx.
The products described herein comply with the Council Directive on Electromagnetic
Compatibility (2004/108/EC).
European Directive 2002/96/EC (WEEE) requires that any equipment that bears this
symbol on product or packaging must not be disposed of with unsorted municipal waste.
This symbol indicates that the equipment should be disposed of separately from regular
household waste. It is the consumer’s responsibility to dispose of this and all equipment
so marked through designated collection facilities appointed by government or local
authorities. Following these steps through proper disposal and recycling will help
prevent potential negative consequences to the environment and human health. For
more detailed information about proper disposal, please contact local authorities, waste
disposal services, or the point of purchase for this equipment.
© 2018 B+B SmartWorx – powered by Advantech. All rights reserved. The information in this document is subject to
change without notice. B+B SmartWorx assumes no responsibility for any errors that may appear in this document.
IE-ModeConverter is a trademark of B+B SmartWorx. Other brands or product names may be trademarks and are
the property of their respective companies.
Documentation Number: IE-ModeConverter_4618m
Class 1 Laser product, Luokan 1 Laserlaite,
Laser Klasse 1, Appareil A’Laser de Classe 1
