EKI-2741F
10/100/1000Base-T to SFP
(mini-GBIC) Type Fiber
Optic Media Converter
EKI-2741SX
10/100/1000Base-T to
1000Base-SX SC Type
Fiber Optic Media
Converter
EKI-2741LX
10/100/1000Base-T to
1000Base-LX SC Type
Fiber Optic Media
Converter
User Manual

EKI-2741F-SX-LX User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2007 by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice. No part of
this manual may be reproduced, copied, translated or transmitted in any form or by any
means without the prior written permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no
responsibility for its use, nor for any infringements of the rights of third parties, which may
result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
1st Edition
May 2007
Part No.
Printed in China

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons
other than repair personnel authorized by Advantech, or which have been subject to misuse,
abuse, accident or improper installation. Advantech assumes no liability under the terms of
this warranty as a consequence of such events.
Because of Advantech′s high quality-control standards and rigorous testing, most of our
customers never need to use our repair service. If an Advantech product is defective, it will be
repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you
will be billed according to the cost of replacement materials, service time and freight. Please
consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU speed,
Advantech products used, other hardware and software used, etc.) Note anything
abnormal and list any onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return more
quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement Order
Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.

EKI-2741F-SX-LX User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions for
passing included the equipment being operated within an industrial enclosure. In order to
protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage,
we strongly recommend the use of CE-compliant industrial enclosure products.
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech’s customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, application software,
etc.)
- A complete description of the problem
- The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not
use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and
must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the user's
manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE
TEMPERATURE MAY GO BELOW -40℃(-40℉) OR ABOVE 85℃(185 ℉). THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.

EKI-2741F-SX-LX User Manual vi
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from damage.
1. To avoid electrical shock, always disconnect the power from your PC chassis before you
work on it. Don't touch any components on the CPU card or other cards while the PC is
on.
2. Disconnect power before making any configuration changes. The sudden rush of power
as you connect a jumper or install a card may damage sensitive electronic components.

vii Contents
Contents
Chapter 1 Overview...........................................2
1.1 Introduction ......................................................... 2
1.1.1 Fast Fiber Converters Module ................... 2
1.1.2 Dual Power Input ....................................... 2
1.1.3 Flexible Mounting ...................................... 2
1.1.4 Advanced Protection ................................. 2
1.1.5 Wide Operating Temperature .................... 2
1.1.6 Easy Troubleshooting................................ 2
1.2 Features.............................................................. 3
1.3 Specification ....................................................... 4
1.4 Packing List ........................................................ 6
1.5 Safety Precaution ............................................... 6
Chapter 2 Installation........................................8
2.1 LED Indicators .................................................... 8
Table 2.1: EKI-2741F/SX/LX LED Definition.............8
2.2 DIP-Switch .......................................................... 9
Table 2.2: EKI-2741series DIP-Switch Definition........9
2.3 Dimensions (units: mm) .................................... 10
Figure 2.1: Front View of EKI-2741 series.................10
Figure 2.2: Side View of EKI-2741 series ..................11
Figure 2.3: Rear View of EKI-2741 series ..................12
Figure 2.4: Top View of EKI-2741 series ...................13
2.4 Mounting ........................................................... 14
2.4.1 Wall mounting.......................................... 14
Figure 2.5: Combine the Metal Mounting Kit.............14
2.4.2 DIN-rail Mounting..................................... 15
Figure 2.6: Installation to DIN-rail Step 1...................15
Figure 2.7: Installation to DIN-rail Step 2...................16
2.5 Network Connection ......................................... 17
Figure 2.8: Transceiver to the SFP module .................17
Figure 2.9: Transceiver Inserted..................................17
Figure 2.10: LC connector to the transceiver ..............18
Figure 2.11: Remove LC connector ............................18
Figure 2.12: Pull out from the SFP module.................19
2.6 Power Connection ............................................ 20
Figure 2.13: Pin Assignment of the Power Connector 20
Chapter 3 Troubleshooting ............................22
Appendix A Pin Assignment & Wiring ...........24
Figure A.1: RJ-45 Pin Assignment..............................24
Figure A.2: EIA/TIA-568B .........................................24
Figure A.2: EIA/TIA-568A .........................................24

EKI-2741F-SX-LX User Manual viii

1 Chapter1
Overview
Sections include:
zIntroduction
zFeatures
zSpecifications
zPacking List
zSafety Precaution
CHAPTER

EKI-2741F-SX-LX User Manual 2
Chapter 1 Overview
1.1 Introduction
The EKI-2741 is designed to convert Gigabit Ethernet networks to Gigabit fiber
networks by transparently converting Ethernet signals to optic signals. The advantages
of fiber optics are wide bandwidth, EMI immunity and long-distance transmission
capability. Therefore, EKI-2741 is an ideal solution for “fiber to building” applications at
central offices or local sites. EKI-2741 supports MDI/MDIX auto detection, so you don’t
need to use crossover wires. Furthermore, the EKI-2741 can work normally from -10 ~
60o C and accepts a wide voltage range from +12 ~ 48 VDC. Besides, it also provides
3,000 VDC surge (EFT) protection against over-voltage, so it is suitable for harsh
operating environments.
1.1.1 Fast Fiber Converters Module
The EKI-2741F/SX/LX provides you with one Fiber connector for your fiber optic cable
and one Ethernet RJ-45 port (Auto MDI/MDIX) for your 1000Base-TX copper cable
connection. There are two DIP-switches to set the operation mode for UTP, Fiber ports
and link loss forwarding function.
1.1.2 Dual Power Input
To reduce the risk of power failure, the EKI-2741F/SX/LX provide +12 ~ 48 VDC dual
power inputs. If there is power failure, EKI-2741F/SX/LX will automatically switch to the
secondary power input.
1.1.3 Flexible Mounting
EKI-2741F/SX/LX are extremely compact and can be mounted on a DIN-rail or a panel,
so it is suitable for any space-constrained environment.
1.1.4 Advanced Protection
The power line of EKI-2741F/SX/LX supports up to 3,000 VDC EFT protection, which
secure equipment against unregulated voltage and make systems safer and more
reliable. Meanwhile, 4,000 VDC ESD protections for Ethernet ports make EKI-
2741F/SX/LX more suitable for harsh environments.
1.1.5 Wide Operating Temperature
The operating temperature of the EKI-2741F/SX/LX is between -40 ~ 75 ℃(wide
operating temperature model) or -10 ~ 60 ℃(standard model). With such a wide range,
you can use the EKI-2741F/SX/LX in some of the harshest industrial environments that
exist.
1.1.6 Easy Troubleshooting
LED indicators make troubleshooting quick and easy. The 10/100/1000 Base-TX port
has 2 LEDs that display the link status, transmission speed and collision status. Also
the three power indicators P1, P2 and P-Fail help you diagnose immediately.

3 Chapter1
1.2 Features
•Provides 1 x SFP (mini-GBIC) type connector (EKI-2741F)
•Provides 1 x 1000Base-SX or 1000Base-LX SC type connector (EKI-2741SX/LX)
•Provides 1 x 10/100/1000Mbps Ethernet ports with RJ-45 connector
•Supports full/half duplex flow control
•Supports MDI/MDI-X auto-crossover
•Supports surge (EFT) protection 3,000 VDC for power line
•Supports 4,000 VDC Ethernet ESD protection
•Embedded with a switch controller, supports auto-negotiation
•Supports store & forward transmission
•Supports redundant +12 ~ 48 VDC power input
•Provides flexible mounting: DIN-rail, Wall Mounting
•Supports operating temperatures from -40 ~ 75 ℃(wide operating temperature
model) or -10 ~ 60 ℃(standard model)

EKI-2741F-SX-LX User Manual 4
1.3 Specification
Communications
Standard IEEE 802.3, 802.3ab, 802.3u, 802.3x,
802.3z
LAN 10/100/1000Base-TX, 1000Base-SX,
1000Base-LX
Transmission Distance Multi-Mode Fiber: 550m (EKI-2741SX)
Single-Mode Fiber: 10km (EKI-2741LX) or
SFP (mini-GBIC) Fiber: Up to 110km (EKI-2741F)
Ethernet: Up to 100 meters (STP or UTP)
Transmission Speed Up to 1000 Mbps
Interface
Connectors Fiber : 1 x SFP(mini-GBIC) fiber connector
(EKI-2741F)
1 x SC type fiber connector (EKI-2741SX/LX)
1 x RJ-45
6-pin removable screw terminal (power & relay)
LED Indicators TX port: 10/100/1000M, Link/Active
Fiber port: LNK/ACT
Port Alarm, LFP
Power
Power Consumption 5.28 W (EKI-2741F)
5.18 W (EKI-2741SX)
5.30 W (EKI-2741LX)
Power Input 2 x Unregulated +12 ~ 48 VDC
Fault Output 1 Relay Output
Mechanism
Dimensions (WxDxH) 37 x 95 x 140 mm
Enclosure IP30, Metal shell with solid mounting kits
Mounting DIN-rail, wall
Protection
ESD (Ethernet) 4,000 VDC
Surge (EFT for power) 3,000 VDC
Reverse Polarity Yes
Overload 0.9A@12VDC (25 ℃)

5 Chapter1
Environment
Operating Temperature -10 ~ 60 ℃ (14~140℉)
Wide temp. model: -40 ~ 75 ℃ (-40 ~ 167℉)
Storage Temperature -40 ~ 85 ℃(-40 ~ 185℉)
Operating Humidity 5 ~ 95% (non-condensing)
Storage Humidity 0 ~ 95% (non-condensing)
Certifications
Safety UL, 60950-1, CAN/CSA-C22.2 No.60950
EMC U.S.A.: FCC Part 15 CISPR 22
EU: EN55011, EN61000-6-4
EN55022, Class A,
EN61000-3-2/3
EN55024
IEC61000-4-2/3/4/5/6/8/11/12
EN61000-6-2
Free Fall IEC60068-2-32
Shock IEC60068-2-27
Vibration IEC60068-2-6

EKI-2741F-SX-LX User Manual 6
1.4 Packing List
•1 x EKI-2741F or EKI-2741SX or EKI-2741LX Industrial Ethernet Switch
•1 x eAutomation Industrial Communication CD-ROM with software, and User manual
•2 x Wall Mounting Bracket and Screws
•1 x DIN-rail Mounting Bracket and Screws
•1 x EKI-2741F/SX/LX Startup Manual
•1 x DC Jack Cable φ2.0/150mm
1.5 Safety Precaution
Attention IF DC voltage is supplied by an external circuit, please use a protection device
on the power supply input.

7 Chapter2
Installation
Sections include:
zLED Indicators
zDimensions
zMounting
zNetwork Connection
zPower Connection
CHAPTER

EKI-2741F-SX-LX User Manual 8
Chapter 2 Installation
In this chapter, you will be given an overview of the EKI-2741F/SX/LX hardware
installation procedures.
2.1 LED Indicators
There are few LEDs display the power status and network status located on the front
panel of EKI-2741F/SX/LX, each of them has its own specific meaning as the table
below.
Table 2.1: EKI-2741F/SX/LX LED Definition
LED Color Description
On Power input 1 is active
P1 Green
Off Power input 1 is inactive
On Power input 2 is active
P2 Green
Off Power input 2 is inactive
On Power input 1 or 2 has failed
P-Fail Red
Off Power input 1 and 2 are both functional, or no power input
On Connected to network
Flashing Networking is active
LNK/ACT (fiber port) Green
Off Not connected to network
On Link to 1000M bps network
1000M
(RJ-45) Yellow
Off Not connected to network
On Connected to network
Flashing Networking is active
LNK/ACT (RJ-45) Green
Off Not connected to network

9 Chapter2
2.2 DIP-Switch
The DIP-Switch is used to configure operation mode for LFP (Link Fault Pass-
Through) and operation mode for UTP/Fiber port. The default value of DIP-switch is
OFF.
Table 2.2: EKI-2741series DIP-Switch Definition
S/W No Status Description
ON Enables Port/Power Alarm
1
OFF Disable Port/Power Alarm
ON Enables LFP
2
OFF Disables LFP
Link Fault Pass-Through (DIP-Switch 2): When LFP is enabled, it allows UTP link
failures to be reported to the fiber side and also allows Fiber link failures to be reported
to the UTP side. Therefore, a link loss forwarding feature is provided in both UTP and
Fiber side.
Note Please don’t change the DIP-switch setting when UTP or fiber port is
transmitting or receiving data. It may cause some data error. Besides, if you
change the DIP-switch setting, please power off the converter and power on
again to make the setting effective.

EKI-2741F-SX-LX User Manual 10
2.3 Dimensions (units: mm)
Figure 2.1: Front View of EKI-2741 series

11 Chapter2
Figure 2.2: Side View of EKI-2741 series
