Advantech FPM-3121 Series User manual

FPM-3121Series
Flat Panel Monitor with
12.1" Color TFT/LCD Display
User Manual

FPM-3121G Series User Manual ii
Copyright Notice
This document is copyrighted by Advantech Co., Ltd. All rights are
reserved. Advantech Co., Ltd. reserves the right to make improvements to
the products described in this manual at any time. Specifications are thus
subject to change without notice.
No part of this manual may be reproduced, copied, translated, or transmit-
ted in any form or by any means without the prior written permission of
Advantech Co., Ltd. Information provided in this manual is intended to
be accurate and reliable. However, Advantech Co., Ltd., assumes no
responsibility for its use, nor for any infringements upon the rights of
third parties which may result from its use.
All brand and product names mentioned herein are trademarks or regis-
tered trademarks of their respective holders.
This Manual Covers the Following Models
• FPM-3121G-X0AE
• FPM-3121G-R3AE
1st Edition
Printed in Taiwan December 2010

iii
Product Warranty (2 year)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for one year
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
All defective products under normal / standard operation will be serviced
by Advantech’s global RMA system. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty
period. For out-of-warranty repairs, you will be billed according to the
cost of replacement materials, service time and freight. Please consult
your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

FPM-3121G Series User Manual iv
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential environment. This
equipment generates, uses and can radiate radio frequency energy. If not
installed and used in accordance with this user's manual, it may cause
harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance
with this user’s manual, there is still no guarantee that interference will
not occur. If this equipment is believed to be causeing harmful interfer-
ence to radio or television reception, this can be determined by turning
the equipment on and off. If the interference is occurring, the user is
encouraged to try to correct the interference by one or more of the follow-
ing measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment to a power outlet on a circuit different from that
to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help

v
Packing List
Before installing your equipment, make sure that the following materials
have been received:
• FPM-3121G Series flat panel monitor
• Accessory pack, including:
- AC/DC adapter
- AC/DC power adapter bracket
- Video signal cable, 1.8m
- Fixed panel-mounted bracket x 8 pcs
- Screw Bags (M4x25 mm screws x 8 pcs)
- DC in Power Cord bracket x 1 piece
- RS-232 cable, 1.8m
- Driver/manual CD-ROM
If any of these items are missing or damaged, contact your distributor or
sales representative immediately.
Additional Information and Assistance
1. Visit the Advantech web site at www.advantech.com where you can
find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional assis-
tance. Please have the following information ready before you call:
• Product name and serial number
• Description of your peripheral attachments
• Description of your software (operating system, version, application
software, etc.)
• A complete description of the problem
• The exact wording of any error messages
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.

FPM-3121G Series User Manual vi
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping
it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connect-
ing the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electri-
cal shock.
13. Never open the equipment. For safety reasons, the equipment should
be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY
DAMAGE THE EQUIPMENT.
The sound pressure level at the operator's position according to IEC 704-
1:1982 is no more than 70dB(A).

vii
DISCLAIMER: This set of instructions is given according to IEC 704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Ver-
wenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein
angefeuchtetes Tuch zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein
Kippen oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor
überhitzung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht
abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen
kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu
beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten
Sie es vom Stromnetz trennen. Somit wird im Falle einer Überspan-
nung eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüs-
sigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw. elek-
trischen Schlag auslösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elek-
trischen Sicherheit nur von authorisiertem Servicepersonal geöffnet
werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu
trennen und von einer qualifizierten Servicestelle zu überprüfen:
a - Netzkabel oder Netzstecker sind beschädigt.

FPM-3121G Series User Manual viii
b - Flüssigkeit ist in das Gerät eingedrungen.
c - Das Gerät war Feuchtigkeit ausgesetzt.
d - Wenn das Gerät nicht der Bedienungsanleitung entsprech
end funktioniert oder Sie mit Hilfe dieser Anleitung keine
Verbesserung erzielen.
e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil
1000 beträgt 70dB(A) oder weiger.
15. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der Bat-
terie.Ersatz nur durch densellben order einem vom Hersteller empfohlen-
emahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des
Herstellers.
16. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf
nicht fachmännische Weise gewechselt wird. Verfangen Sie die Batterie
nur gleicher oder entsprechender Type, wie vom Hersteller empfohlen.
Entsorgen Sie Batterien nach Anweisung des Herstellers.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000
beträgt 70dB(A) oder weiger.
Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend
der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die
Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab.
DISCLAIMER: This set of instructions is given according to IEC704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.

ix Table of Contents
Contents
Chapter 1 Introduction ..................................................... 2
1.1 Introduction ....................................................................... 2
1.2 Specifications .................................................................... 2
1.3 LCD Specifications ........................................................... 3
1.4 Power Adapter Specifications ........................................... 4
1.5 Connectors......................................................................... 4
1.6 Dimensions........................................................................ 6
Figure 1.1:FPM-3121G-UA Chassis Dimensions ......... 6
Chapter 2 System Setup.................................................... 8
2.1 Mounting FPM-3121G-UA Series .................................... 8
2.1.1 Wall Mounting ............................................................... 8
Figure 2.1:Wall Mounting ............................................. 8
2.1.2 Panel Mounting .............................................................. 9
Figure 2.2:Panel Mounting ............................................ 9
Figure 2.3:Panel Mounting ............................................ 9
2.2 Desktop, Swing-ARM for FPM-3121G-UA Series ........ 10
2.2.1 Desktop Stand .............................................................. 10
Figure 2.4:Desktop Stand: FPM-3121G-UA Series .... 10
2.2.2 VESA ARM Mounting ................................................ 11
Figure 2.5:Swing-ARM: FPM-3121G-UA series ........ 11
2.2.3 Power Adapter ............................................................. 12
Appendix A Display Timing Mode & OSD ...................... 14
A.1 Supported Input Timing Modes ...................................... 14
Table A.1:Supported Input Formats ............................ 14
A.2 Keypad Interface ............................................................. 15
A.3 Power Indicator LED Status............................................ 15
A.4 OSD Function.................................................................. 16
Appendix B Touchscreen ................................................... 18
B.1 Introduction ..................................................................... 18
B.2 Touchscreen Specifications............................................. 18
B.3 Installing Driver for Windows 2000/XP ......................... 19
B.4 Configuring PenMount Windows 2000/XP Driver......... 24
B.4.1 PenMount Control Panel ............................................. 24
B.4.2 PenMount Monitor Menu Icon .................................... 34
B.4.3 PenMount Rotating Functions ..................................... 35
B.5 Uninstall the PenMount Windows 2000/XP driver......... 36

FPM-3121G Series User Manual x

2
CHAPTER
1
Introduction
This chapter includes:
• Introduction
• Specifications
• LCD Specification
• Power Consumption
• Connectors
• Dimensions

FPM-3121G Series User Manual 2
Chapter 1 Introduction
1.1 Introduction
Advantech's FPM-3121G series consists of 12.1" color TFT LCD flat
panel monitors built specifically for industrial applications. With the
optional touchscreen, the FPM-3121G-RA series offers user-friendly sys-
tem control interfaces.
In addition to its usual application as an LCD panel monitor, the FPM-
3121G Series comes standard with Direct VGA control signal input,
making it compatible with industrial PCs and workstations.
The OSD (On Screen Display) function allows you to adjust the display
and turn the backlight on and off, a function that is highly appreciated
among experienced users of industrial flat panel monitors.
The whole chassis is made of durable stainless steel, and the front panel is
of aluminum with NEMA4/IP65 compliance.
For applications in harsh environments, FPM-3121G can work at -20
~ 6 -4 ~ 140 °F )
Products in the FPM-3121G Series can also be provided in touch
be immediately transformed into a re
applications.
1.2 Specifications
General
• Construction: Heavy-duty stainless steel chassis
• Front Panel:
• Control: OSD (On Screen Display) control pad on front side
• Mounting: Panel, wallmount, desktop or VESA Arm
screen
versions (FPM-3121G-R) With an 5-wire resistive type touchscreen, this
monitor can mote control system.
The Advantech FPM-3121G series is the ultimate HMI solution for your
industrial
Aluminum
0° C (

3 Chapter1
• Dimensions (W x H x D):
• Panel Mount Cut out Dimension (WxH): 301.5x227.5 mm
• Weight: 3.0 kg (6.6 lb)
• Vibration (operating): 5 ~ 500 Hz, Random, 1 Grms
• CE, FCC, BSMI, CCC certified
• Power Consumption: +12V @ 4.75 A / +24V @ 2.62 A
Touchscreen (Optional)
• Type: 5 wire, analog resistive
• Resolution: 1024 x 1024
• Light Transmission: 75% (Gouge Hardness is greater than 4H per
ASTM D3363-92 for HCC01, HCG10 and HCG12)
• Controller: RS-232 interface
• Power Consumption:
FPM-3121G-RA: +5 V @ 200 mA
• OS Support: Windows 2000/XP
• Life Span: 1,000,000 activations (typical) at a single point with a 5/8"
diameter silicone finger with a 350g load at 2 touches per second
1.3 LCD Specifications
• Display Type: SXGA
• Display Size: 12.1"
• Max. Colors: 262 k
• Max. Resolution: 800*600
• Viewing Angle (H/V): 140 ° / 120 °
• Luminance: 450 cd/m2
• Operating Temperature: -20 ~ 60 °C (-4 ~ 140 °F )
• Contrast Ratio: 700 : 1 (typ)
• Lamp Life Time: 50,000 hrs.
312 x 244 x 60 mm

FPM-3121G Series User Manual 4
1.4 Power Adapter Specifications
• Max Output Power: 42 W
• AC input voltage: 100 - 240 V AC
• Output voltage: + 12 V @ 3.5 A
• Safety Standards: UL/CE/CCC/TUV/CB
1.5 Connectors
The following connectors are on the bottom of the FPM-3121G Series:
VGA Port (DB15)
This DB-15 connector can be connected to the system via the external 15-pin
DB-15 connector locatd on the left side of the system unit.
RS-232 Touchscreen Connector (DB9) (with FPM-3121G-R)
This connector will only be present if a touchscreen is installed. It must be
connected to the RS-232 port of the PC. The touchscreen cable is included
with all orders that include the touchscreen option.
DC 12V or DC 24V Power In
This connector connects to the DC 12V / 24V Switching Power Supply.

5 Chapter1
Warning:
Before you connect a VGA cable between the monitor and a PC, please
note the following issues.
1. If you have installed a operating system in the PC, make sure the ver-
tical frequency is within the acceptable range. (Refer to Appendix B)
2. If you have not installed a operating system, you have to adjust the
vertical frequency to fall within the range.

Figure 1.1: FPM-3121G Dimensions
FPM-3121G Series User Manual 6
1.6 Dimensions

2
CHAPTER
2
System Setup
• Mounting the Monitor
• Wall / Panel Mounting
• Desktop / Swing-Arm Mounting

M-3121G Series
2. Place the FPM-3121G series in the bracket.
3121G series on a wall. The wall mounting kit is optional. (P/N: FPM-
FPM-3121G Series User Manual 8
Chapter 2 System Setup
2.1 Mounting FP
Monitors in the FPM-3121G series can be flexibly mounted. The versatil-
ity of the FPM-3121G series mounts enable them to be mounted on your
desk or almost anywhere else.
2.1.1 Wall Mounting
Please refer to figure 2.1 and follow the steps below to install FPM-
2150DESK-MT)
1. Screw the hook and wall-mounted brackets on the wall.
Figure 2.1: Wall Mounting
Wall-mounting Bracket

4. Mount the FPM-3121G series’ monitor on the panel by the screws
1. Insert the FPM-3121G series’ into the cutout hole of the panel.
9 Chapter2
2.1.2 Panel Mounting
Refer to figure 2.2 and follow the instructions below to install in a panel.
(The dimensions of the cutout is 303.5 x 229.5 mm )
2. Place eight panel-mounting brackets on FPM-3121G series’ (2 on
the top, 2 on the bottom, 2 on the left, and 2 on the right).
3. Fasten the eight panel-mounting brackets with screws.
on the ten panel-mounted brackets.
Figure 2.2: Panel Mounting
Figure 2.3: Panel Mounting

FPM-3121G Series User Manual 10
2.2 Desktop, Swing-ARM for FPM-3121G Series
The FPM-3121G series’ monitors can also be mounted in other ways.
You can use the desktop stand for desktop use or attach it on a swing-arm
bracket.
2.2.1 Desktop Stand
Refer to figure 2.4. The desktop stand bracket is attached to the rear of
FPM-3121G series’. Simply attach the small bracket at the rear side of the
monitor by screwing the two screws. The bracket now becomes the desk-
top stand bracket.
The desktop stand kit is optional. (P/N: FPM-2150DESK-MT)
Figure 2.4: Desktop Stand: FPM-3121G Series
2.2.2 VESA ARM Mounting
