Advantech FPM-40T User manual

FPM-40T/S
Flat Panel Monitor with
10.4" Color TFT/DSTN LCD
Display

ii
Copyright Notice
This document is copyrighted by Advantech Co., Ltd. All rights are
reserved. Advantech Co., Ltd. reserves the right to make
improvements to the products described in this manual at any time.
Specifications are thus subject to change without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advantech
Co., Ltd. assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from
its use.
All brand and product names mentioned herein are trademarks or
registered trademarks of their respective holders.
FCC Class A
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy. If not installed and used in accordance with this
user's manual, it may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
Part No. 2002040000
1st Edition Printed in Taiwan June 1998

iii
Packing List
Before installing your equipment, make sure that the following
materials have been received:
• FPM-40T/S
• Accessory pack, including:
- FPM-40T/S User's Manual
- PCA-6654 User's Manual
- PCA-6654 disks
- PCA-6654 video display card
- Component bag
- Screw bag
- 1.8 m shielding cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Additional Information and Assistance
1. Visit the Advantech web sites at www.advantech.com or
www.advantech.com.tw where you can find the latest
information about the product.
2. Contact your distributor, sales representative, or Advantech's
customer service center for technical support if you need
additional assistance. Please have the following information ready
before you call:
• Product name and serial number
• Description of your peripheral attachments
• Description of your software (operating system, version,
application software, etc.)
• A complete description of the problem
• The exact wording of any error messages

iv
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.
Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened
only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to
the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70dB(A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

v
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Verwenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient
ein angefeuchtetes Tuch zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und
leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein
Kippen oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät
vor überhitzung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht
abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber
fallen kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu
beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten
Sie es vom Stromnetz trennen. Somit wird im Falle einer Überspan-
nung eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder
Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw.
elektrischen Schlag auslösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der
elektrischen Sicherheit nur von authorisiertem Servicepersonal
geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu
trennen und von einer qualifizierten Servicestelle zu überprüfen:
a - Netzkabel oder Netzstecker sind beschädigt.
b - Flüssigkeit ist in das Gerät eingedrungen.
c - Das Gerät war Feuchtigkeit ausgesetzt.
d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend
funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesse-
rung erzielen.
e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt
70dB(A) oder weiger.
DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

vi
Contents
Chapter 1 Introduction..................................... 1
1.1 Introduction............................................................................2
1.2 Specifications..........................................................................3
1.3 Flat Panel Displays ................................................................5
1.4 Connectors..............................................................................6
1.5 Dimensions..............................................................................8
Chapter 2 System Setup.................................. 9
2.1 Wall Mounting .....................................................................10
2.2 Panel Mounting ....................................................................11
2.3 Exploded Diagram ...............................................................12
Appendix A
Touchscreen Driver Installation .................... 13
A.1 Introduction.........................................................................14
A.2 Windows 95..........................................................................15
A.3 Windows 3.1 and DOS........................................................18
A.4 Windows NT ........................................................................21
A.5 OS/2 (MonitorMouse).........................................................23

Introduction
This chapter includes:
• Introduction
• Specifications
• Flat Panel Displays
• Connectors
• Dimensions
CHAPTER
1

2 FPM-40T/S User's Manual
1.1 Introduction
Advantech's FPM-40T/S series flat panel monitors are state-of-the-art
alternatives to conventional CRT monitors. They offer the traditional
advantages of flat panel displays - small size, light weight and low
power consumption - with the added security of a rugged NEMA4/12
(IP52/56) compliant design.
The flat panel monitor package includes a PCI-bus video display card
and your choice of flat panel displays: color TFT or DSTN LCD. The
display card supports simultaneous use of LCD panels and analog
CRT monitors. A shielded 1.8 meter cable connects the FPM-40T/S
and the video display card, allowing remote operation. Add an
optional touchscreen to create the ultimate user interface. The
FPM-40T/S's compact size and extended range allow easy placement
in almost any location.

Chapter 1 Introduction 3
1.2 Specifications
General
• Construction: Plastic panel and steel chassis
• Front panel: NEMA 4/12 (IP 52/56)
• Control: One contrast adjustment knob on rear side (FPM-40S
only)
• I/O port keyboard connector
• Mounting: Panelmount or wallmount
• Dimensions (W x H x D): 342 x 265 x 32 mm (13.5" x 10.4" x 1.3")
• Weight: 2.6 kg (5.6 lb)
Video Display Card
• Model: PCA-6654
• Board: 32-bit PCI-bus, half-size
• Video chip: CHIPS 65550
• Memory: 2 MB on board, frame buffer 512 KB (optional)
• Max. resolution: 1024 x 768 for both flat panel and CRT displays
• Connectors: One MDR-26 connector for flat panel display
One DB-15 connector for CRT
• Simultaneous CRT/LCD display
• Power consumption: +5 V @ 1 A, max.
Touchscreen (Optional)
• Type: Analog resistive
• Resolution: Transmission @ 75%
• Controller: RS-232 interface
• Power consumption: +5 V @ 200 mA
• Software drivers: DOS, Windows 3.1/95/NT, and OS/2
• Life cycle: 35 million touches
• Surface: Meets ASTM-D-1044 standard (Taber Abrasion Test)

4 FPM-40T/S User's Manual
1.3 Flat Panel Displays
FPM-40T FPM-40S
Display Type TFT color LCD DSTN LCD
Size (Diagonal) 10.4" 10.4"
Max. Resolution 640 x 480 640 x 480
Max. Colors 256 K colors 4096 colors
Viewing Angle 90° 90°
Dot Size (mm) 0.33 x 0.33 0.33 x 0.33
Luminance (cd/m2)250 130
LCD Model Toshiba
LTM10C029A
or compatibles
Kyocera
KCB6448BSTT-X5
or compatibles
Temperature 0 ~ 50° C 0 ~ 45° C
VR Controls N/A Contrast
Simultaneous Mode Yes Yes
LCD MTBF 50,000 hours 50,000 hours
Backlight MTBF 20,000 hours 25,000 hours

Chapter 1 Introduction 5
1.4 Connectors
The following connectors are situated on the left side of the
FPM-40T/S:
Video I/O Port (MDR-26)
This connector links the FPM-40T/S to the PCA-6654 display card.
Figure 1-1 shows how to make the connection.
Note: The display card provides power to the FPM-40T/S;
no external power is required.
Warning: Make sure that your display card corresponds with
your choice of display!
Touchscreen Connector (DB-9) (Optional)
This connector will be present only if a touchscreen is installed. It
must be connected to the RS-232 port of the PC. The touchscreen
cable is included with all orders which include the touchscreen option.
External Keyboard Connector
The FPM-40T/S provides an external keyboard connector to let you
attach a PC/AT standard keyboard. Figure 1-1 shows the correct
wiring method. Be sure that the internal keyboard connector between
the PCA-6654 (EXT.KBD) and the CPU card (KBD) has been
connected.

6 FPM-40T/S User's Manual
Figure 1-1: Connectors

Chapter 1 Introduction 7
1.5 Dimensions
Figure 1-2: Dimensions
Unit: mm
FPM-40T/S (10.4")
Cutout Dimensions: 305 mm x 230 mm

8 FPM-40T/S User's Manual

System Setup
• Wall Mounting
• Panel Mounting
• Exploded Diagram
CHAPTER
2

10 FPM-40T/S User's Manual
2.1 Wall Mounting
When the FPM-40T/S assembly is complete, the unit may be mounted
in a panel or wall. Mounting brackets and fixing brackets are supplied
for convenient wall mounting. The screw holes are used to secure the
large mounting bracket to the wall. Connect the FPM-40T/S to the
bracket using the three screws included. After attaching the
FPM-40T/S to the bracket, use the fix bracket to stabilize the unit.
Figure 2-1: Wall mounting

Chapter 2 System Setup 11
2.2 Panel Mounting
A cutout can be made to accommodate panel mounting. Four
panel-mount brackets are included with the FPM-40T/S. Slide the unit
backwards into the panel opening. Attach the four mounting brackets
by inserting the screws into the keyhole slots on the flat panel monitor
cover. Use the screws to secure the brackets to the cover. Tighten the
screws to secure the front panel monitor against the back panel.
Figure 2-2: Panel mounting

12 FPM-40T/S User's Manual
2.3 Exploded Diagram
Remove the six screws as shown, then lift the rear panel from the unit.
The internal components are as shown below:
Figure 2-3: Exploded diagram

Touchscreen Driver
Installation
• Introduction
• Windows 95
• Windows 3.1 and DOS
• Windows NT
• OS/2 (MonitorMouse)
APPENDIX
A

14 FPM-40T/S User's Manual
A.1 Introduction
Before you attempt to install the touchscreen driver, you should
carefully read the instructions in the relevant "read me" file stored in
the installation CD-ROM. The file path for the instructions in the
CD-ROM is:
D:\monmouse\
This is where you will find instructions for Win 95, DOS 3.1, Win
NT, and OS/2.
Note 1: The touchscreen driver must be installed from the
CD-ROM supplied.The CD-ROM drive is designated
as "D" throughout this chapter.
Note 2: The installation instructions assume that the
touchscreen is connected to COM1, and that the
mouse is connected to and set for COM2. Both of
these configurations are factory pre-settings.
Note 3: The following illustrations of windows are examples
only.You must follow this manual's flowchart
instructions, and pay attention to the instructions
which then appear on your screen.
