Advantech AIMB-506 User manual

User Manual
AIMB-506
Intel® /Core™ i7/i5/i3 /Pentium/
Celeron LGA1151 MicroATX with
VGA/DVI/DP/eDP (LVDS), 14
COM, Dual LAN, DDR4, PCIe x
16, PCIe x 1, PCI x 2 and SATAIII

AIMB-506 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.
Acknowledgements
IBM and PC are trademarks of International Business Machines Corporation
Intel® Core™ i7/i5/i3 Pentium/Celeron® is a trademark of Intel Corporation
All other product names or trademarks are properties of their respective owners
Part No.2006050600 Edition 1
Printed in China March 2020

iii AIMB-506 User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

AIMB-506 User Manual iv
Declaration of Conformity
FCC Class B
This device complies with the requirements in part 15 of the FCC rules:
Operation is subject to the following two conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that
may cause undesired operation
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this device in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his/her own expense. The
user is advised that any equipment changes or modifications not expressly approved
by the party responsible for compliance would void the compliance to FCC regula-
tions and therefore, the user's authority to operate the equipment.
CPU Compatibility
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
CPU Family Core Number Power Freq(GHz) Mfg-Tech Smart cach (L3) Package Type Result
Intel i7-9700E 8 65W 2.6G 14nm 12MB LGA1511 Pass
Intel i7-9700TE 8 35W 1.8G 14nm 12MB LGA1511 Pass
Intel i7-8700 6 65W 3.2G 14nm 12MB LGA1511 Pass
Intel i7-8700T 6 35W 2.4G 14nm 12MB LGA1511 Pass
Intel i5-9500E 6 65W 3.0G 14nm 9MB LGA1511 Pass
Intel i5-9500TE 6 35W 2.2G 14nm 9MB LGA1511 Pass
Intel i5-8500 6 65W 3.0G 14nm 9MB LGA1511 Pass
Intel i5-8500T 6 35W 2.1G 14nm 9MB LGA1511 Pass
Intel i3-9100E 4 65W 3.1G 14nm 6MB LGA1511 Pass
Intel i3-9100TE 4 35W 2.2G 14nm 6MB LGA1511 Pass
Intel i3-8100 4 65W 3.6G 14nm 6MB LGA1511 Pass
Intel i3-8100T 4 35W 3.1G 14nm 6MB LGA1511 Pass
Intel Pentium® Processor G5400 2 58W 3.7G 14nm 4MB LGA1511 Pass
Intel Pentium® Processor G5400T 2 35W 3.1G 14nm 4MB LGA1511 Pass
Intel Celeron® Processor G4900 2 54W 3.1G 14nm 2MB LGA1511 Pass
Intel Celeron® Processor G4900T 2 35W 2.9G 14nm 2MB LGA1511 Pass

v AIMB-506 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Ordering Information
*() BOM options available on MP version
Part Number PCH Memory VGA DVI DP eDP/
LVDS
USB
3.0/2.0 COM SATA LAN PCIe x16
PCI
x1
M.2 B-
Key
PCI
slot AMP
AIMB-506F-00A1E H310 Non ECC 1 1 1 1/(1) 8/12 14 3 2 1 11 21
AIMB-506G2-00A1E H310 Non ECC 1 1 1 (1)/(1) 4/8 10 3 2 1 11 21
AIMB-506GL-00A1E H310 Non ECC 1 1 (1) -/- 4/4 2 3 1 1 10 0(1)

AIMB-506 User Manual vi
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
1 x AIMB-506 Intel LGA 1151 Core i7/i5/i3 /Pentium/Celeron Micro ATX Mother-
board
2 x SATA HDD cable
1 x COM 1 to 2 cable
1 x COM 1 to 4 cable
1 x I/O port bracket
1 x Startup manual
1 x Warranty card
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the AIMB-506 mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. As you unpack the AIMB-506, check it for signs of ship-
ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or
it fails to meet the specifications, notify our service department or your local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.

vii AIMB-506 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Specifications ............................................................................................ 2
1.3.1 System .......................................................................................... 2
1.3.2 Memory ......................................................................................... 2
1.3.3 Input/Output .................................................................................. 3
1.3.4 Graphics........................................................................................ 3
1.3.5 Ethernet LAN ................................................................................ 3
1.3.6 Industrial features ......................................................................... 3
1.3.7 Mechanical and Environmental Specifications.............................. 4
1.4 Jumpers and Connectors .......................................................................... 4
Table 1.1: Jumpers...................................................................... 4
Table 1.2: Connectors ................................................................. 5
1.5 Board Layout: Jumper and Connector Locations...................................... 6
Figure 1.1 Jumper and Connector Locations............................... 6
Figure 1.2 I/O Connectors ........................................................... 6
1.6 AIMB-506 Board Diagram ......................................................................... 7
Figure 1.3 AIMB-506 Block Diagram ........................................... 7
1.7 Safety Precautions .................................................................................... 7
1.8 Jumper Settings ........................................................................................ 8
1.8.1 How to Set Jumpers...................................................................... 8
1.8.2 CMOS Clear (JCMOS1)................................................................ 8
Table 1.3: JCMOS1 ..................................................................... 8
1.8.3 JLVDS1: LVDS Panel Voltage 3.3V/ 5V/ 12V selection................ 9
Table 1.4: JLVDS1: LVDS Panel 3.3 V/5 V/ 12 V Selector ......... 9
1.8.4 PSON1: ATX, AT Mode Selector .................................................. 9
Table 1.5: PSON1: ATX, AT Mode Selector................................ 9
1.8.5 JWDT1+JOBS1: Watchdog Timer Output, OBS Alarm Option... 10
Table 1.6: JWDT1+JOBS1: Watchdog & Beep Pin Header ...... 10
1.8.6 JSETCOM3/7: COM3/7 RS232, RS422, RS485 Selection......... 11
Table 1.7: COM2 RS232, RS422, RS485 Selection ................. 11
1.8.7 LVDS VESA, JEIDA Format Selection Pin Header..................... 11
1.8.8 JCASEOP_SW1: Case Open Selection Pin Header .................. 12
Table 1.8: JCASEOP_SW1: Case Open Selection Pin Header 12
1.8.9 JSETCOM1_V1/JSETCOM2_V2: COM1/COM2_RI# Pin RI# / 5V /
12V.............................................................................................. 12
1.9 System Memory ...................................................................................... 12
1.10 Memory Installation Procedures.............................................................. 12
1.11 Cache Memory........................................................................................ 13
1.12 Processor Installation.............................................................................. 13
Chapter 2 Connecting Peripherals ....................15
2.1 Introduction ............................................................................................. 16
2.2 USB Ports (LAN1_USB12/ LAN2_USB34/ USB5678/ USB9101112/
USB13141516/ USB17181920) .............................................................. 16
Table 2.1: LAN LED Indicator.................................................... 16
2.3 VGA1/DVI-D Connector (VGA1+DVI 1) Connector................................. 17
2.4 Serial Ports (COM1~COM14) ................................................................. 18
2.5 Display Ports (DP1)................................................................................. 19
2.6 PS/2 Keyboard and Mouse Connector (KBMS1) .................................... 20
2.7 CPU Fan Connector (CPU_FAN1).......................................................... 20
2.8 System FAN Connector (SYSFAN1/2/3/4).............................................. 21

AIMB-506 User Manual viii
2.9 Front Panel Connectors (JFP1/JFP2)..................................................... 22
2.9.1 ATX Soft Power S.................................. witch (JFP1/PWR_SW)22
2.9.2 Reset (JFP1/RESET).................................................................. 22
2.9.3 HDD LED (JFP1/HDDLED) ........................................................ 22
2.9.4 External Speaker (JFP1/SPEAKER) .......................................... 22
2.9.5 Power LED and Keyboard Lock Connector (JFP2/PWR_LED &
KEY LOCK)................................................................................. 23
Table 2.2: ATX Power Supply LED Status (No Support for AT
Power) ...................................................................... 23
2.10 Line Out, Mic In Connector (AUDIO1) .................................................... 23
2.11 Serial ATA Interface (SATA1 ~ SATA3).................................................. 24
2.12 8-pin Alarm Board Connector (VOLT1)................................................... 25
2.13 ATX Power Connector (EATXPWR1, ATX12V2).................................... 26
2.14 General Purpose I/O Connector (GPIO1) ............................................... 27
2.15 eDP/LVDS Connector (eDP1/LVDS) ...................................................... 27
2.16 EDP Backlight Inverter(INV1) ................................................................. 28
2.17 Front Panel Audio Connector (FPAUD1) ................................................ 28
2.18 Digital Audio Connector (SPDIF1) .......................................................... 29
2.19 M.2 (B-Key/2242) (M2B1) ....................................................................... 29
2.20 SMBUS Header (SMBUS1) .................................................................... 30
Chapter 3 BIOS Operation ................................. 31
3.1 Introduction ............................................................................................. 32
3.2 BIOS Setup ............................................................................................. 32
3.2.1 Main Menu .................................................................................. 33
3.2.2 Advanced BIOS Features ........................................................... 34
3.3 Chipset Configuration Settings ............................................................... 58
3.3.1 System Agent (SA) Configuration............................................... 59
3.3.2 PCH-IO Configuration................................................................ 65
3.4 Security Settings ..................................................................................... 71
3.5 Boot Settings........................................................................................... 72
3.6 Save & Exit Configuration ....................................................................... 73
Chapter 4 Software Introduction & Services ... 75
4.1 Introduction ............................................................................................. 76
4.2 Value-Added Software Services ............................................................. 76
4.2.1 Software API............................................................................... 76
4.2.2 Software Utility............................................................................ 78
Chapter 5 Chipset Software Installation Utility 79
5.1 Before You Begin.................................................................................... 80
5.2 Introduction ............................................................................................. 80
5.3 Windows 10 Driver Setup ....................................................................... 81
Chapter 6 VGA Setup ......................................... 83
6.1 Introduction ............................................................................................. 84
6.2 Windows 10 VGA Driver Installation ....................................................... 84
Chapter 7 LAN Configuration ............................ 85
7.1 Introduction ............................................................................................. 86
7.2 Features.................................................................................................. 86

ix AIMB-506 User Manual
7.3 Installation ............................................................................................... 86
7.4 Windows® 10 Driver Setup (Realtek 8111G).......................................... 87
Appendix A Programming the Watchdog Timer..89
A.1 Programming the Watchdog Timer ......................................................... 90
A.1.1 Watchdog Timer Overview.......................................................... 90
A.1.2 Programming the Watchdog Timer ............................................. 90
Table A.1: Watchdog Timer Registers ....................................... 92
A.1.3 Example Program ....................................................................... 93
Appendix B Pin Assignments ...............................97
B.1 HD Audio Interface (AUDIO1) ................................................................. 98
B.2 LAN & USB3.0 Connector (LAN2_USB34) ............................................. 98
B.3 LAN & USB3.0 Connector (LAN1_USB12) ............................................. 99
B.4 USB2.0 Connector (USB5678) ............................................................. 100
B.5 USB3.0 Connector (USB9101112) ....................................................... 100
B.6 Display Port Connector (DP1)............................................................... 101
B.7 VGA & DVI Connector (VGA1+DVI1).................................................... 101
B.8 ATX 4/8 Pin Main Power Connector (ATX12V1 / ATX12V2) ................ 102
B.9 CPU Socket LGA 1151 H4 (CPU1)....................................................... 103
B.10 SMBUS Header (JSMB2)...................................................................... 103
B.11 CPU FAN Header (CPUFAN1) ............................................................. 103
B.12 SYSTEM FAN Header (SYSFAN1)....................................................... 104
B.13 SYSTEM FAN Header (SYSFAN2)....................................................... 104
B.14 DDR4 DIMM Socket (DIMMA1) ............................................................ 104
B.15 DDR4 DIMM Socket (DIMMB1) ............................................................ 104
B.16 Case Open Switch Pin Header (JCASEOP_SW1) ............................... 104
B.17 Case Open Pin Header (JCASE1) ........................................................ 105
B.18 Keyboard Mouse Pin Header (KBMS1) ................................................ 105
B.19 SYSTEM FAN Header (SYSFAN3)....................................................... 105
B.20 SYSTEM FAN Header (SYSFAN4)....................................................... 105
B.21 COM Port Pin Header (COM12) ........................................................... 106
B.22 LPC Pin Header (LPC1)........................................................................ 106
B.23 COM3456 Setting Pin Header (JSETCOM3) ........................................ 107
B.24 General Purpose I/O Pin Header (GPIO1)............................................ 107
B.25 COM Port Pin Header (COM3456) ....................................................... 108
B.26 Battery Holder (BAT1)........................................................................... 108
B.27 AT/ATX Mode Selection Header (PSON1) ........................................... 109
B.28 Alarm Board/CMM Power Pin Header (VOLT1).................................... 109
B.29 ATX Power Header (EATXPWR1) ........................................................ 109
B.30 COM Port Pin Header (COM11121314) ............................................... 110
B.31 SIM Card Holder (SIM1)........................................................................ 110
B.32 M.2 B Key Socket (M2B1)..................................................................... 111
B.33 SATA Connector (SATA1) .................................................................... 112
B.34 SATA Connector (SATA2) .................................................................... 112
B.35 USB2.0 Pin Header (USB1920) ............................................................ 112
B.36 USB2.0 Pin Header (USB1718) ............................................................ 113
B.37 Front Panel Header (JFP1) ................................................................... 113
B.38 Watchdog & Beep Pin Header (JWDT1+JOBS1) ................................. 113
B.39 Speaker (SP1)....................................................................................... 114
B.40 PLED Pin Header (JFP2) ...................................................................... 114
B.41 SPI Programming Pin Header (SPI_CN1) ............................................ 114
B.42 SATA Connector (SATA3) .................................................................... 115
B.43 SPI ROM Socket (SPI1)........................................................................ 115
B.44 Clear CMOS Pin Header (JCMOS1)..................................................... 115
B.45 SMbus Pin Header (SMBUS1).............................................................. 116
B.46 USB2.0 Pin Header (USB1516) ............................................................ 116

AIMB-506 User Manual x
B.47 USB2.0 Pin Header (USB1314)............................................................ 116
B.48 COM Port Pin Header (COM78910) ..................................................... 117
B.49 PCIe x16 Slot (PCIEX16_1).................................................................. 118
B.50 PCI Slot (PCI1) ..................................................................................... 119
B.51 PCI Slot (PCI2) ..................................................................................... 121
B.52 COM78910 Setting Pin Header (JSETCOM7)...................................... 122
B.53 LVDS/eDP Backlight Inverter Power Header (INV1) ............................ 123
B.54 LVDS Panel Voltage Selection Header (JLVDS1) ................................ 123
B.55 PCIe x1 Slot (PCIEX1_1)...................................................................... 124
B.56 LVDS/eDP Panel Header (LVDS_EDP1) ............................................. 125
B.57 LVDS VESA, JEIDA Format Selection Pin Header (JLVDS_VCON1).. 126
B.58 SPDIF Pin Header (SPDIF1) ................................................................ 126
B.59 Audio Amplifier Pin Header (AMP1)...................................................... 127
B.60 Front Audio Pin H........................................................eader (FPAUD1)127
B.61 LAN Active LED Pin Header (LANLED1).............................................. 127
B.62 COM1 RI# Selection Pin Header(JSETCOM1_V1) .............................. 128
B.63 COM2 RI# Selection Pin Header(JSETCOM2_V2) .............................. 128

Chapter 1
1General Information

AIMB-506 User Manual 2
1.1 Introduction
AIMB-506 is designed with the Intel H310 for industrial applications that require both
high-performance computing and enhanced power management capabilities. The
motherboard supports 8th /9th Intel® Core™ i7/i5/i3 embedded processors up to 8
MB L3 cache and DDR4 2666 MHz up to 64GB, per slot up to 32GB. Multiple I/O
connectivity of 14 serial ports, 12 USB 2.0, 8 USB 3.0, dual GbE LAN, and 3 SATA III
ports are offered.
1.2 Features
Multiple I/O connectivity: Dual GbE LAN via PCIe x1 bus, 1 x PCIe x16 slot
(Gen 3), 1 x PCIe x1 slot (Gen 2), 1 x PCI, 12 x USB 2.0 ports and 8 x USB 3.0
ports.
Standard Micro ATX form factor with industrial features: The AIMB-506 is a
full-featured Micro ATX motherboard with balanced expendability and perfor-
mance.
Wide selection of storage devices: SATAIII HDD, customers benefit from the
flexibility of using the most suitable storage device for larger capacity.
Optimized integrated graphics solution: With Intel® Flexible Display Inter-
face, it supports versatile display options and 32-bit 3D graphics engine.
1.3 Specifications
1.3.1 System
CPU: Intel 8th/9th generation Core i7/i5/i3 /Pentium/Celeron processor
BIOS: AMI EFI 128 Mbit SPI BIOS
System chipset: Intel® H310
SATA hard disk drive interface: Three on-board SATA connectors with data
transmission rates up to 600 MB
1.3.2 Memory
RAM: Up to 64 GB in 2 slots 288-pin DIMM sockets. Supports dual-channel
DDR4 2666 MHz SDRAM.
–AIMB-506G2 & AIMB-506L supports non-ECC unbuffered DIMMs and do not
support any memory configuration that mixes non-ECC with ECC unbuffered
DIMMs.
Note! A 32-bit OS may not fully detect 4GB of RAM when 4 GB is installed.

3 AIMB-506 User Manual
Chapter 1 General Information
1.3.3 Input/Output
PCIe slot: 1 PCIe x16 expansion slot, 1 PCIe x 1 expansion slot, 2 PCI
Serial port: Fourteen serial ports, COM3 and COM7 are RS-232/422/485 with
hardware auto-flow control and the rest are RS-232.
Keyboard and PS/2 mouse connector: Two 6-pin mini-DIN connectors are
located on the mounting bracket for easy connection to PS/2 keyboard and
mouse.
USB port: Supports up to 12 USB 2.0 ports with transmission rates up to 480
Mbps and 8 USB 3.0 ports with transmission rates up to 5 Gbps.
GPIO: AIMB-506 supports 16-bit GPIO from super I/O for general purpose con-
trol applications.
1.3.4 Graphics
Controller: Intel® HD Graphics
Display memory: 1 GB maximum shared memory with 2GB and above system
memory installed
DVI: Supports DVI up to resolution 1920 x 1200 @ 60Hz refresh rate
VGA: Supports VGA up to resolution 1920 x 1200 @ 60Hz refresh rate
Display Port: Supports max resolution 4096 x 2304 @60Hz
eDP: Supports max resolution 3840 x 2160 @ 60Hz
LVDS (BOM option eDP): Support max resolution 1920 x 1200
Dual Display: VGA+eDP/LVDS, VGA+DVI, eDP/LVDS+ DVI, LVDS + DP, DP+
DVI, eDP/LVDS+DP
1.3.5 Ethernet LAN
Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus
which provides 500 MB/s data transmission rate
Controller: LAN1: Realtek 8111G; LAN2:Intel Realtek 8111G
1.3.6 Industrial features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels)

AIMB-506 User Manual 4
1.3.7 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU)
Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
Humidity: 5 ~ 95% non-condensing
Power supply voltage: +3.3 V, +5 V, +12 V, -12 V, 5 Vsb, 12V_4P
Power consumption:
LAG1151 Core i7-9700E 2.6 GHz, 12MB L3 Cache, 2pcs 16GB DDR4
2666MHz memory
+5 V 3.3 V 12V_4P 5 Vsb -12 V 12V
0.7A 0.78A 3.462A 0.53A 0 A 0.303A
Measure the maximum current value with system under maximum load (CPU:
Top speed, RAM & Graphic: Full loading)
Board size: 244 mm x 244 mm (9.6" x 9.6")
Board weight: 0.365 kg
1.4 Jumpers and Connectors
Connectors on the AIMB-506 motherboard link it to devices such as hard disk drives
and a keyboard. In addition, the board has a number of jumpers used to configure
your system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumpers
Label Function
JFP1
(Keyboard
Lock and
Power LED)
Power LED
S3/S4: Fast flash / Slow flash (ATX)
System On: ON (ATX/ AT)
System Off: OFF (AT)
System Off: Slow flash (ATX)
JSETCOM3/7 Serial port: RS232/RS422/RS485
jumper setting
JCMOS1 eDP1 and LVDS power jumper
JLVDS1 Case open connector
JWDT1+JOBS1 Watch dog & beep pin header
JCASEOP_SW1 Case open switch pin header
JLVDS_VCON1 LVDS VESA, JEIDA format selection pin header
JSETCOM1_V1 COM1 voltage selection
JSETCOM2_V2 COM2 voltage selection
PSON1 AT(1-2) / ATX(2-3) (Default 2-3)

5 AIMB-506 User Manual
Chapter 1 General Information
Table 1.2: Connectors
Label Function
LANLED1 Front panel LAN indicator connector
COM12 Serial port 1/2 (RS-232)
COM3/4/5/6
Serial port: COM 3/4/5/6, box header 2 x 20 p
Serial port COM3 support
RS232/422/485
COM7/8/9/10
Serial port: COM 7/8/9/10, box header 2 x 20 p
Serial port COM7 support
RS232/422/485
COM11/12/13/14 Serial port: COM 11/12/13/14, box header 2 x 20 p
KBMS1 On board external keyboard and mouse connector
LAN1_USB12 LAN1 & USB12 connector
LAN2_USB34 LAN2 & USB34 connector
USB 5/6/7/8 USB port 5-8
USB 9/10/11/12 USB port 9-12
USB 13/14/15/16/17/18/
19/20
USB port 13/14/15/16/17/18/19/20 (internal 2 x 10 pin header on
board) (optional)
AUDIO1 Line out, Mic IN connector
FPAUDIO1 Front panel audio connector
SPI_CN1 SPI flash programming connector
SATA1-3 Serial III ATA connector
GPIO1 GPIO pin header(SMD pitch=2.0 mm)
ATX12V1
ATX12V2 ATX 12V 4/8 pin Auxiliary power connector
EATXPWR1 ATX power connector
CPUFAN1 CPU FAN connector (4 pin)
SYSFAN1/2/3/4 System FAN power connector (4 pin)
LVDS_EDP1 LVDS/eDP panel header
INV1 EDP/LVDS inverter
VOLT1 Voltage display connector
SPDIF1 Digital audio connector
4 x 1 header pitch =2.54mm
SMBUS1 SMBUS expansion pin header 1 x 4 p
SIM1 SIM card connector
LPC1 Low pin count interface (2x7 pin header)
M2B1 M.2 (B Key /2242)
SP1 Buzzer
SPI1 SPI BIOS flash socket
AMP1 Audio amplifier output connector
JSMB2 SMBus header
JFP2 Power switch/ reset/ external speaker/ SATA HDD LED / SMBus
connector
JCASE1 Case open connector

AIMB-506 User Manual 6
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Jumper and Connector Locations
Figure 1.2 I/O Connectors

7 AIMB-506 User Manual
Chapter 1 General Information
1.6 AIMB-506 Board Diagram
Figure 1.3 AIMB-506 Block Diagram
1.7 Safety Precautions
Warning! Always completely disconnect the power cord from chassis whenever
you work with the hardware. Do not make connections while the power
is on. Sensitive electronic components can be damaged by sudden
power surges. Only experienced electronics personnel should open the
PC chassis.
Caution! Always ground yourself to remove any static charge before touching the
motherboard. Modern electronic devices are very sensitive to electro-
static discharges. As a safety precaution, use a grounding wrist strap at
all times. Place all electronic components on a static-dissipative surface
or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacturer.
Discard used batteries according to manufacturer's instructions.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer’s
instructions.

AIMB-506 User Manual 8
1.8 Jumper Settings
This section provides instructions on how to configure your motherboard by setting
the jumpers. It also includes the motherboards's default settings and your options for
each jumper.
1.8.1 How to Set Jumpers
You can configure your motherboard to match the needs of your application by set-
ting the jumpers. A jumper is a metal bridge that closes an electrical circuit. It consists
of two metal pins and a small metal clip (often protected by a plastic cover) that slides
over the pins to connect them. To “close” (or turn ON) a jumper, you connect the pins
with the clip. To “open” (or turn OFF) a jumper, you remove the clip. Sometimes a
jumper consists of a set of three pins, labeled 1, 2, and 3. In this case you connect
either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set-
ting jumpers.
1.8.2 CMOS Clear (JCMOS1)
The AIMB-506 motherboard contains a jumper that can erase CMOS data and reset
the system BIOS information. Normally this jumper should be set with pins 1-2
closed. If you want to reset the CMOS data, set JCMOS1 to 2-3 closed for just a few
seconds, and then move the jumper back to 1-2 closed. This procedure will reset the
CMOS to its default setting.
* Default
Table 1.3: JCMOS1
Function Jumper Settings
*Keep CMOS data
Clear CMOS data
1-2 closed
2-3 closed

9 AIMB-506 User Manual
Chapter 1 General Information
1.8.3 JLVDS1: LVDS Panel Voltage 3.3V/ 5V/ 12V selection
*Default
1.8.4 PSON1: ATX, AT Mode Selector
*Default 1 1
Table 1.4: JLVDS1: LVDS Panel 3.3 V/5 V/ 12 V Selector
Closed Pins Result
*JEDP1, 4-6 Jumper for +3.3 V
EDP1, 2-4 Jumper for +5 V
JEDP1, 3-4 Jumper for +12 V
Jumper position for +3.3V (Default)
Jumper position for +5V
Jumper position for +12V
Table 1.5: PSON1: ATX, AT Mode Selector
Closed Pins Result
1-2 AT Mode
2-3* ATX Mode
AT Mode
1-2 closed
ATX Mode
2-3 closed

AIMB-506 User Manual 10
1.8.5 JWDT1+JOBS1: Watchdog Timer Output, OBS Alarm Option
Table 1.6: JWDT1+JOBS1: Watchdog & Beep Pin Header
Pin Pin Name
1NC
2 Watchdog Reset# output
3 System Reset input#
4 SIO Warning Beep output
5 SP1 Buzzer Beep input
Watchdog Timer Output (2-3) (Default)
OBS BEEP (4-5) (Default)
Watchdog Timer Disable (1-2)
OSB BEEP (4-5) (Default)
