SIMB-M01 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x Intel D525 mini-ITX Main board
• 1 x CD ROM per carton, which contains the followings:
- User’s Manual in PDF file
- Drivers
• 1 x SATA cable kit (SATA/Power)
• 1 x I/O Shield
• 1 x Startup Manual per carton
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file. Acrobat
Reader can be downloaded at: www. adobe.com/Prodindex/
acrobat/readstep.html (Acrobat is a trademark of Adobe).
SIMB-M01
Intel® Atom D525 Mini-ITX Motherboard
Startup Manual
System
• CPU:Onboard Intel® Atom D525 DC 1.8GHz Processor
• BIOS:AMI 8Mb SPI
• SystemChipset:Intel® NM10
• I/OChipset:FINTEK F71869ED
• Memory:Two 204-pin SO-DIMM sockets support up to
4GB Single Channel DDR3 800 MHz SDRAM
• H/WStatusMonitor:Monitoring temperature, voltage
and cooling fan status. Auto throttling control when CPU
overheats
• ExpansionSlots:1 PCI-E x 1
• PowerState:S1, S3, S4, S5
• WakeuponLANorRing:LAN (WOL) and Ring (WO)
• SmartFanControl:Ye s
Display
• Chipset:Integrated Intel® GMA Gen3.5 DX9, 400 MHz
• DisplayMemory:Shared Memory Max 224MB
• DualDisplay:VGA + HDMI
• VGA:Onboard, supports max resolution 2048 x 1536
(@60Hz)
• HDMI:Onboard HDMI 1.3, supports max resolution 1920
x 1080
Audio
• AudioCodec:Realtek ALC662, 5.1 CH. HD Audio
• AudioInterface:Line-in, Line-out, Mic.-in, S/PDIF, Front
Audio Header
Ethernet
• LAN1:Realtek 8111E Gigabit Ethernet
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SIMB-M01 series Rev. A1.
Part No. 20060M0110
Printed in China
1st Edition
July 2011

2 SIMB-M01 Startup Manual
Connectors
Label Function Note
CPU_FAN1 CPU Fan Connector
SYS_FAN1 System Fan Connector
Serial_B Serial Port Connector
F_PANEL Intel Front Panel connector
F_AUDIO Audio Mic.-In & Line-Out Connector
SPDIF_OUT SPDIF OUT
TPM TPM Connector
Connectors and Jumpers

SIMB-M01 Startup Manual 3
F_USB1
F_USB2
USB 2.0
Connector
Jumpers
Label Function Note
JCMOS1 Clear CMOS
Norrnal* Clear CMOS
Connectors and Jumpers

4 SIMB-M01 Startup Manual
The manufacturer reserves the right to make changes, with-
out notice, to any product, including circuits and/or software
described or contained in this manual in order to improve
design and/or performance. The manufacturer assumes
no responsibility or liability for the use of the described
product(s), conveys no license or title under any patent,
copyright, or masks work rights to these products, and
makes no representations or warranties that these products
are free from patent, copyright, or mask work right infringe-
ment, unless otherwise specified. For the detail product
information, please refer to user’s manual.
Safety Declaration
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Board Diagram
Disclaimer and Notice
