1. PRODUCT INTRODUCTION
1.1. Product Brief
DVP-7637HE is a high-quality, high-performance capture device which is specially designed
for high-definition video capture applications. It supports up to 4 channel of high-definition,
1200p60 video from 4 x HDMI source. With hardware support, DVP-7637HE can record live
video from high-definition signal sources into H.264 files.
1.2. Specification
Model
DVP-7637HE
1920×1200p@60/50fps in →1920×1200p@60/50fps
Max. FPS
out
1920×1080p@60/50fps in →1920×1080p@60/50fps
out
Recording
Hardware Compression, Real-Time Mode
Mode
Product
Dimension
167.65×101.03 ( mm ) PCIe Full Height
Interface
PCIe×4 ( Gen2 )
Video Input
4×HDMI
Display
Video
YV12, NV12, YUY2, RGB24, RGB32
Format
1920×1200p@60/50fps
1920×1200p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
Video RAW
1280×720p@60/50fps
Data
1280×1024p@60fps
Resolution
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
3/6

4
720×480i@60fps
720×576i@50fps
Recording
Video
H.264 ( Hardware Compression )
Format
1920×1200p@60/50fps
1920×1200p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
Recording
1280×1024p@60fps
Video
1280×960p@60fps
Resolution
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Audio Input
4×HDMI Embedded Audio
PCB Audio Pin Input: 4×Stereo Audio
Audio
Stereo / 16-bit / 32000 ~ 48000Hz
Format
WatchDog
✓
Multiple
∞
Cards
Support API : DirectShow, V4L2, FFmpeg, Gstreamer
SDK
Support Language : C++, C#, .NET, Visual Basic, Qt,
Delphi
4/6

5
2. HARDWARE INSTALLATION
2.1. Package Contents
Item
Amount
DVP-7637HE
1
2.2. Connection Diagram
Figure below is the connection diagram for supported signal and interface.
Signal Connection diagram
2.3. Precaution
Before proceed, make sure touch a safely grounded object or metal object before touching
the device.
Wrist strap
Please follow below chapter for installation operations
5/6

6
2.4. PCI/PCIE
Turn off PC/notebook and remove power cord from AC plug/sockets on the wall.

Remove notebook battery.

After make sure the system is fully shut down, open the chassis.

Unpack the device package and make sure don’t touch any electrical and
semiconductor components on the device, especially ICs on board.

Install PCI/PCIE card to available motherboard PCI/PCIE slot and fasten the screw on the
device and back plate.

Close the chassis and connect signal source to the device.

Turn on the system.

3. SOFTWARE INSTALLATION
3.1. Support OS
Windows based system
Windows XP
Support
Windows Vista
Support
Windows 7
Support
Windows 8/8.1
Support
Windows 10
Support
Linux based system
Linux 2.6.14 or Higher
Support
3.2. Driver Installation
After install the device and reboot the PC/notebook, the “Windows Found New
Hardware Wizard” will appear and detect the device. Please click “Cancel” to exit the
Wizard, and implement installation program to install the device driver and application.
Please click on the driver and follow the instruction to start the installation.

While the installation is completed, user may check the device driver is installed
correctly by following steps

Start

Control Panel

System

Device Manager

And user can find device from the device manager dialog (see below figure, device
number will different by channel numbers).
DVP Series
