ASMB-822I Intel® Xeon® E5-2600/E5-2600 v2 series LGA 2011
Socket ATX Server Board with 6 PCIe & 1 PCI Expansion Slots
Startup Manual
Standard SBC Functions
• CPU: LGA2011 Intel ® Xeon® E5-2600/E5-2600 v2
series
• BIOS: AMI 64 Mb SPI BIOS
• Chipset: Intel® C602J
• System memory: 6* DDR3 REG/ECC/Non-ECC
1066/1333/1600 unbuffered DIMM, Max. 96 GB
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 96 GB RAM
when 96 GB RAM is installed.
• SATA Interface: 4 SATA2 3 Gb/s ports, 2 SATA3 6Gb/s,
supports Intel Matrix Storage (for Windows only) software
RAID 0, 1, 10 & 5.
• Serial ports: Two serial ports, only support RS-232
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB ports: Supports up to twelve USB 2.0 (2* Type-A)
and two USB3.0 ports
VGA Interface
• Chipset: Aspeed AST2300
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate
Ethernet interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel I210; LAN2: Intel 82579LM; LAN3:
Realtek 8201EL(10/100Mbps for IPMI,ASMB-822I sku
only)
Mechanical and Environmental
• Dmensions (L x W): 304 x 244 mm (12” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption(Main board only, excluded IO
device): Max. load: +3.3 V @ 13.69 A, +5 V@ 7.777 A,
+12 V @ 11.48 A, +12 V(8P) @ 22 A, +5 Vsb@ 2 A
• Operating temperature: 0 ~ 60° C (depending on CPU)
• Weight: 1 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the ASMB-822I series Rev. A1
Part No. 2002822I10
Print in China
1st Edition,
Sep 2012

2 ASMB-822I Startup Manual
Jumper list
Label Function
JCMOS1 CMOS clear
JME1 ME update
JCMOS1/JME1: CMOS clear/ME update function
Closed pins
Result
1-2 Keep CMOS data/Disable ME update*
2-3
Clear CMOS data/Enable ME update
*: Default
Installation Note
JFP1
Pin.1 #PWR_SW
Pin.3 GND
Pin.2 #RST_SW
Pin.4 GND
*Power button pin is located in Pin 1 & 3 of front panel
connector
Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update
1 2 3
1 2 3
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each jumper and connector.
Connector list
Label Function
ATX24P_P1 ATX 24 Pin main power con-
nector
ATX8P_P0 Processor power connector(for
CPU0)
SATA0~SATA5 Serial ATA0~5
USB4_5,USB6_7
USB8_9
USB2.0 port 4,5,6,7,8,9
(Header)
USB0_1,USB2_3
USB10,USB11
USB2.0 port 0,1,2,3,10 &
11(type A)
USB30_1 USB3.0 port 0, 1
DIMMA0 ~ DIMMD0 DDR3 memory slot
CPUFAN0 CPU FAN connector
SYSFAN0,SYSFAN1,
SYSFAN2,SYSFAN3 System FAN connector
LAN1,LAN2 LAN connector
IPMI LAN1 LAN connector for IPMI
VGA_COM1 VGA+COM connector
KBMS1 Keyboard and mouse connector
KBMS2 External keyboard and mouse
connector(6 pin)
BIOS_SKT1 BIOS SPI ROM
LANLED1 LAN LED extension connector
SMBUS1 Front panel SMBus header
IPMI1 IPMI header
SATA_SGPIO_1 SATA SGPIO header
AUDIO1 Audio header
COM2 Serial port: RS-232
JFP1 Front panel header
Jumpers and Connectors Jumpers and Connectors

ASMB-822I Startup Manual 3
