Advantech ROM-5720 User manual

User Manual
ROM-5720
Arm-Based SMARC 2.0 Module
with NXP i.MX8M Arm® Cortex®
A53 Processor

ROM-5720 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Arm is trademarks of Arm Corporation
NXP is trademarks of NXP Corporation
All other product names or trademarks are properties of their respective owners
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2006R57200 Edition 1
Printed in China February 2020

iii ROM-5720 User Manual
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Ordering Information
Packing List
Before installation, please ensure the following items have been shipped:
1 x ROM-5720
4 x Screws
1 x China ROHS
Part No. Description
ROM-5720CD-PEA1E ROM-5720 SMARC2.0 NXP i.MX8M Dual Core 1.5GHz
0~60°C
ROM-5720CQ-PEA1E ROM-5720 SMARC2.0 NXP i.MX8M Quad Core 1.5GHz
0~60°C
ROM-5720WD-OEA1E ROM-5720 SMARC2.0 NXP i.MX8M Dual Core 1.3GHz
-40~85°C
ROM-5720WQ-OEA1E ROM-5720 SMARC2.0 NXP i.MX8M Quad Core 1.3GHz
-40~85°C
ROM-DB5901-SWA1 Development carrier board for SMARC 2.0 module

ROM-5720 User Manual iv
Optional Accessories
Part No. Description
96PSA-A36W12R1 ADAPTER 100-240V 36W 12V 3A
1700001524 Power Cord 3P UL 10A 125V 180cm
170203183C Power Code 3P Europe (WS-010+WS-083)183cm
170203180A Power Cord 3P UK 2.5A/3A 250V 1.83M
1700008921 Power Cord 3P PSE 183cm
1700019076 USB OTG to Type A Female
1700019077 USB OTG to Type A Male
1701100300 D-SUB 9P(M) 30cm for COM Port
9696MEG510E Audio Daughter Board
9680015491 PCIe to Mini PCIe Adapter Card
ROM-EG56 MIPI-DSI to HDMI Board
SQF-ISDM1-16G-21C SQ Flash SD Card UHS-I MLC 16G (0~70°C)
SQF-ISDM1-16G-21E SQ Flash SD Card UHS-I MLC 16G (-40~85°C)
EWM-W163M201E 802.11a/b/g/n/ac,QCA6174A-5,2T2R,with BT4.2,full size Mini PCIe
1750008717-01 WiFi Dual Band Antenna (2.4Ghz and 5Ghz)
1750007965-01 Antenna Cable , SMA (M) to MHF4, 300mm
EWM-C117FL06E LTE/HSPA+/GPRS Module, w/ SIM Slot, TOBY-L280H, for Taiwan
1750007990-01 Antenna 4G/LTE Full Band L=11 cm 50 Ohm
1750006009 Antenna Cable SMA (F) to MHF 1.32 25cm
1970004440T001 Heat Spreader
1960063089N001 Semi Heat Sink
1930004835 Screw for Heat Spreader and Semi Heat Sink

v ROM-5720 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged
Liquid has penetrated into the equipment
The equipment has been exposed to moisture
The equipment does not work well, or you cannot get it to work according to
the user's manual
The equipment has been dropped and damaged
The equipment has obvious signs of breakage
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

ROM-5720 User Manual vi

vii ROM-5720 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 2
1.3 Mechanical Specifications......................................................................... 3
1.4 Electrical Specifications ............................................................................ 4
1.5 Environmental Specifications .................................................................... 4
Chapter 2 H/W Installation....................................5
2.1 Board Connectors ..................................................................................... 6
2.1.1 Connector List............................................................................... 6
2.2 Block Diagram........................................................................................... 7
Figure 2.1 ROM-5720 Block Diagram.......................................... 7
Chapter 3 Pin Definition .......................................9
3.1 Pin Definition ........................................................................................... 10
Chapter 4 Software Functionality ......................15
4.1 Test Tools ............................................................................................... 16
4.1.1 Display ........................................................................................ 16
4.1.2 Audio Test................................................................................... 18
4.1.3 4G Test ....................................................................................... 19
4.1.4 WIFI/BT Test............................................................................... 19
4.1.5 RS-232 test ................................................................................. 20
4.1.6 I2C test........................................................................................ 20
4.1.7 USB test...................................................................................... 21
4.1.8 RTC Test..................................................................................... 21
4.1.9 eMMC/SD/SPI flash test ............................................................. 22
4.1.10 Ethernet Test .............................................................................. 22
4.1.11 GPIO Test ................................................................................... 23
4.1.12 Watchdog Test............................................................................ 23
4.1.13 Camera Test ............................................................................... 24
Chapter 5 System Recovery...............................25
5.1 System Recovery .................................................................................... 26
5.1.1 Recovery by SD Card ................................................................. 26
5.1.2 Recovery by UUU Tool ............................................................... 26
Chapter 6 Advantech Services ..........................27
6.1 RISC Design-In Services ........................................................................ 28
6.2 Contact Information................................................................................. 31
6.3 Technical Support and Assistance.......................................................... 32
6.3.1 Warranty Policy........................................................................... 32
6.3.2 Repair Process ........................................................................... 33

ROM-5720 User Manual viii

Chapter 1
1General Introduction
This chapter briefly introduces the
ROM-5720 platform
Sections include:
Introduction
Specifications

ROM-5720 User Manual 2
1.1 Introduction
ROM-5720 SMARC2.0 Module integrates the NXP i.MX8M Arm Cortex-A53 high
performance processor that supports a Vivante GC7000 Lite 3D Graphics engine and
4Kp60 HEVC decoding with HDR.
ROM-5720 comes with Advantech ROM-DB5901 Evaluation Carrier Board for easy
integration and design reference; we also offer referenced schematics and layout
checklists for carrier board development. Additionally, Linux BSP, test utilities, HW
design utilities and reference codes are ready for application development and
device integration.
ROM-5720 is suitable for following applications:
Computing Vision
Medical
Robotic
Infotainment
Portable Devices
1.2 Product Features
Compatible
Module SMARC 2.0
Processor
System CPU NXP Arm Cortex-A53 i.MX8M Dual/Quad, up to 1.5GHz
Memory
Technology LPDDR4 1866 MHz
Capacity On-board 2 GB
Flash 16 GB eMMC for O.S. and 8 MB NOR Flash
Graphic
H/W Video
Decode
HEVC/H.265(4Kp60), VP9(4Kp60), H.264(4Kp30), MPEG-
2, MPEG-4p2, VC-1, VP8, RV9, AVS, MJPEG, H.263
HDMI 4096 x 2160 at 60 Hz
MIPI-DSI 1x 4-lane MIPI DSI, up to 1920 x 1080 @ 60Hz
Camera Input MIPI-CSI 1 x 4-lane MIPI CSI, 1 x 2-lane MIPI CSI
Ethernet Transceiver NXP i.MX8M GbE controller Integrated RGMII
1 x RTL8119I-CG Giga LAN controller
Speed 2 x 10/100/1000 Mbps
Watch Dog
Timer HW WDT MSP430 (time out: 0.1~6553.5s, power on/off 4s)
I/O
USB 2 x USB3.0, 4 x USB2.0 Host, 1 x USB 2.0 OTG,
I2S 2
SDIO 1
UART 1 x UART w/ 4wires, 3 x UART w/ 2wires,
SPI 1
GPIO 12
I2C 4
PCIE 1 x PCIe2.0 1-lane
O.S Linux Yocto
Dimensions W x D 82 x 50mm
Power DC-In Fixed 5V DC source and allow 3.3 V ~ 5.25 V operates
directly from single level Lithium Ion cells

3 ROM-5720 User Manual
Chapter 1 General Introduction
1.3 Mechanical Specifications
Dimensions: SMARC form factor size, 82mm (D) x 50 mm(W)
Height on Top: Under 3.0 mm base on SPEC definition (without heat sink)
Height on Bottom: Under 1.3 mm base on SPEC definition
Environment
Operational
Temperature 0 ~ 60 °C/ -40 ~ 85 °C
Operating
Humidity 0% ~ 90% relative humidity, non-condensing
Certifications Level CE / FCC Class B

ROM-5720 User Manual 4
1.4 Electrical Specifications
Power Supply Voltage:
–Voltage requirements: +5 V
Power Supply Current:
Test Conditions:
1. Test temperature: room temperature
2. Test voltage: rated voltage AC 110V/60Hz
3. Test loading:
3.1 Maximum load mode: Running programs.
3.2 Idle mode: DUT power management off and no running any program.
4. OS: Yocto 2.5
5. Test software: gst-launch-1.0, gpu test , cpu burning
1.5 Environmental Specifications
Operating Temperature: 0 ~ 60° C/ -40 ~ 85° C
The operating temperature refers to the environmental temperature for the
model.
Operating Humidity: 5% ~ 95% relative humidity, non-condensing
Storage Temperature: -40~85° C
Storage Humidity:
–Relative humidity: 95% @ 60° C
Model Kernel idle Maximum mode
ROM-5720 3 W 5.3 W

Chapter 2
2H/W Installation
This chapter gives mechanical
and connector information on the
ROM-5720 CPU Computer on
Module
Sections include:
Connector Information
Mechanical Drawing

ROM-5720 User Manual 6
2.1 Board Connectors
The board has one switch that allows you to configure your system
2.1.1 Connector List
External I/O Connector
SW1 (UART & Debug Port Selection)
SW1 (AT/ATX Mode Selection)
Position Description
SW1(1-2) UART & Debug Port selection
AT & ATX mode selection
Setting Function
1-On UART
1-Off Debug (Default)
Setting Function
2-On AT Mode (Default)
2- Off ATX Mode

7 ROM-5720 User Manual
Chapter 2 H/W Installation
2.2 Block Diagram
Figure 2.1 ROM-5720 Block Diagram

ROM-5720 User Manual 8

Chapter 3
3Pin Definition
This chapter details the pin defini-
tions of ROM-5720

ROM-5720 User Manual 10
3.1 Pin Definition
Here is the 314 Pin MXM connector pin define as below:
P-Pin Primary (Top) Side
SMARC2.0 ROM-5720 A101-4 S-Pin
Secondary (Bot-
tom) Side
SAMRC2.0
ROM-5720 A101-4
S1 I2C_CAM1_CK I2C_CAM1_CK
P1 SMB_ALERT_1V8# SMB_ALERT_1V8# S2 I2C_CAM1_DAT I2C_CAM1_DAT
P2 GND GND S3 GND GND
P3 CSI1_CK+ CSI1_CK+ S4 RSVD N/A
P4 CSI1_CK- CSI1_CK- S5 I2C_CAM0_CK I2C_CAM0_CK
P5 GBE1_SDP N/A S6 CAM_MCK CAM_MCK
P6 GBE0_SDP N/A S7 I2C_CAM0_DAT I2C_CAM0_DAT
P7 CSI1_RX0+ CSI1_RX0+ S8 CSI0_CK+ CSI0_CK+
P8 CSI1_RX0- CSI1_RX0- S9 CSI0_CK- CSI0_CK-
P9 GND GND S10 GND GND
P10 CSI1_RX1+ CSI1_RX1+ S11 CSI0_RX0+ CSI0_RX0+
P11 CSI1_RX1- CSI1_RX1- S12 CSI0_RX0- CSI0_RX0-
P12 GND GND S13 GND GND
P13 CSI1_RX2+ CSI1_RX2+ S14 CSI0_RX1+ CSI0_RX1+
P14 CSI1_RX2- CSI1_RX2- S15 CSI0_RX1- CSI0_RX1-
P15 GND GND S16 GND GND
P16 CSI1_RX3+ CSI1_RX3+ S17 GBE1_MDI0+ GBE1_MDI0+
P17 CSI1_RX3- CSI1_RX3- S18 GBE1_MDI0- GBE1_MDI0-
P18 GND GND S19 GBE1_LINK100# GBE1_LINK100#
P19 GBE0_MDI3- GBE0_MDI3- S20 GBE1_MDI1+ GBE1_MDI1+
P20 GBE0_MDI3+ GBE0_MDI3+ S21 GBE1_MDI1- GBE1_MDI1-
P21 GBE0_LINK100# GBE0_LINK100# S22 GBE1_LINK1000# GBE1_LINK1000#
P22 GBE0_LINK1000# GBE0_LINK1000# S23 GBE1_MDI2+ GBE1_MDI2+
P23 GBE0_MDI2- GBE0_MDI2- S24 GBE1_MDI2- GBE1_MDI2-
P24 GBE0_MDI2+ GBE0_MDI2+ S25 GND GND
P25 GBE0_LINK_ACT# GBE0_LINK_ACT# S26 GBE1_MDI3+ GBE1_MDI3+
P26 GBE0_MDI1- GBE0_MDI1- S27 GBE1_MDI3- GBE1_MDI3-
P27 GBE0_MDI1+ GBE0_MDI1+ S28 GBE1_CTREF N/A
P28 GBE0_CTREF N/A S29 PCIE_D_TX+ N/A
P29 GBE_MDI0- GBE_MDI0- S30 PCIE_D_TX- N/A
P30 GBE_MDI0+ GBE_MDI0+ S31 GBE1_LINK_ACT# GBE1_LINK_ACT#
P31 SPI0_CS1# N/A S32 PCIE_D_RX+ N/A
P32 GND GND S33 PCIE_D_RX- N/A
P33 SDIO_WP SDIO_WP S34 GND GND
P34 SDIO_CMD SDIO_CMD S35 USB4+ USB4+
P35 SDIO_CD# SDIO_CD# S36 USB4- USB4-
P36 SDIO_CK SDIO_CK S37 USB3_VBUS_DET N/A
P37 SDIO_PWR_EN SDIO_PWR_EN S38 AUDIO_MCK AUDIO_MCK
P38 GND GND S39 I2S0_LRCK I2S0_LRCK
P39 SDIO_D0 SDIO_D0 S40 I2S0_SDOUT I2S0_SDOUT
P40 SDIO_D1 SDIO_D1 S41 I2S0_SDIN I2S0_SDIN
P41 SDIO_D2 SDIO_D2 S42 I2S0_CK I2S0_CK
P42 SDIO_D3 SDIO_D3 S43 ESPI_ALERT0# N/A
P43 SPI0_CS0# SPI0_CS0# S44 ESPI_ALERT1# N/A
P44 SPI0_CK SPI0_CK S45 RSVD N/A

11 ROM-5720 User Manual
Chapter 3 Pin Definition
P45 SPI0_DIN SPI0_DIN S46 RSVD N/A
P46 SPI0_DO SPI0_DO S47 GND GND
P47 GND GND S48 I2C_GP_CK I2C_GP_CK
P48 SATA_TX+ N/A S49 I2C_GP_DAT I2C_GP_DAT
P49 SATA_TX- N/A S50 I2S2_LRCK I2S2_LRCK
P50 GND GND S51 I2S2_SDOUT I2S2_SDOUT
P51 SATA_RX+ N/A S52 I2S2_SDIN I2S2_SDIN
P52 SATA_RX- N/A S53 I2S2_CK I2S2_CK
P53 GND GND S54 SATA_ACT# N/A
P54 ESPI_CS0# N/A S55 USB5_EN_OC# N/A
P55 ESPI_CS1# N/A S56 ESPI_IO_2 N/A
P56 ESPI_CK N/A S57 ESPI_IO_3 N/A
P57 ESPI_IO_0 N/A S58 ESPI_RESET# N/A
P58 ESPI_IO_1 N/A S59 USB5+ N/A
P59 GND GND S60 USB5- N/A
P60 USB0+ USB0+ S61 GND GND
P61 USB0- USB0- S62 USB3_SSTX+ USB3_SSTX+
P62 USB0_EN_OC# USB0_EN_OC# S63 USB3_SSTX- USB3_SSTX-
P63 USB0_VBUS_DET USB0_VBUS_DET S64 GND GND
P64 USB0_OTG_ID USB0_OTG_ID S65 USB3_SSRX+ USB3_SSRX+
P65 USB1+ USB1+ S66 USB3_SSRX- USB3_SSRX-
P66 USB1- USB1- S67 GND GND
P67 USB1_EN_OC# USB1_EN_OC# S68 USB3+ USB3+
P68 GND GND S69 USB3- USB3-
P69 USB2+ USB2+ S70 GND GND
P70 USB2- USB2- S71 USB2_SSTX+ USB2_SSTX+
P71 USB2_EN_OC# USB2_EN_OC# S72 USB2_SSTX- USB2_SSTX-
P72 RSVD N/A S73 GND GND
P73 RSVD N/A S74 USB2_SSRX+ USB2_SSRX+
P74 USB3_EN_OC# USB3_EN_OC# S75 USB2_SSRX- USB2_SSRX-
<Key> <Key>
P75 PCIE_A_RST# PCIE_A_RST# S76 PCIE_B_RST# PCIE_B_RST#
P76 USB4_EN_OC# USB4_EN_OC# S77 PCIE_C_RST# N/A
P77 RSVD N/A S78 PCIE_C_RX+ N/A
P78 RSVD N/A S79 PCIE_C_RX- N/A
P79 GND GND S80 GND GND
P80 PCIE_C_REFCK+ N/A S81 PCIE_C_TX+ N/A
P81 PCIE_C_REFCK- N/A S82 PCIE_C_TX- N/A
P82 GND GND S83 GND GND
P83 PCIE_A_REFCK+ PCIE_A_REFCK+ S84 PCIE_B_REFCK+ PCIE_B_REFCK+
P84 PCIE_A_REFCK- PCIE_A_REFCK- S85 PCIE_B_REFCK- PCIE_B_REFCK-
P85 GND GND S86 GND GND
P86 PCIE_A_RX+ PCIE_A_RX+ S87 PCIE_B_RX+ PCIE_B_RX+
P87 PCIE_A_RX- PCIE_A_RX- S88 PCIE_B_RX- PCIE_B_RX-
P88 GND GND S89 GND GND
P89 PCIE_A_TX+ PCIE_A_TX+ S90 PCIE_B_TX+ PCIE_B_TX+
P90 PCIE_A_TX- PCIE_A_TX- S91 PCIE_B_TX- PCIE_B_TX-
P91 GND GND S92 GND GND
P92 HDMI_D2+ HDMI_D2+ S93 DP0_LANE0+ N/A
P93 HDMI_D2- HDMI_D2- S94 DP0_LANE0- N/A
P94 GND GND S95 DP0_AUX_SEL N/A
P95 HDMI_D1+ HDMI_D1+ S96 DP0_LANE1+ N/A

ROM-5720 User Manual 12
P96 HDMI_D1- HDMI_D1- S97 DP0_LANE1- N/A
P97 GND GND S98 DP0_HPD N/A
P98 HDMI_D0+ HDMI_D0+ S99 DP0_LANE2+ N/A
P99 HDMI_D0- HDMI_D0- S100 DP0_LANE2- N/A
P100 GND GND S101 GND GND
P101 HDMI_CK+ HDMI_CK+ S102 DP0_LANE3+ N/A
P102 HDMI_CK- HDMI_CK- S103 DP0_LANE3- N/A
P103 GND GND S104 USB3_OTG_ID N/A
P104 HDMI_HPD HDMI_HPD S105 DP0_AUX+ N/A
P105 HDMI_CTRL_CK HDMI_CTRL_CK S106 DP0_AUX- N/A
P106 HDMI_CTRL_DAT HDMI_CTRL_DAT S107 LCD1_BKLT_EN N/A
P107 DP1_AUX_SEL N/A S108
LVDS1_CK+ /
eDP1_AUX+ /
DSI1_CLK+
N/A
P108 GPIO0/
CAM0_PWR#
GPIO0/
CAM0_PWR# S109
LVDS1_CK- /
eDP1_AUX- /
DSI1_CLK-
N/A
P109 GPIO1/
CAM1_PWR#
GPIO1/
CAM1_PWR# S110 GND GND
P110 GPIO2/
CAM0_RST#
GPIO2/
CAM0_RST# S111
LVDS1_0+ /
eDP1_TX0+ /
DSI1_D0+
N/A
P111 GPIO3/
CAM1_RST#
GPIO3/
CAM1_RST# S112
LVDS1_0- /
eDP1_TX0- /
DSI1_D0-
N/A
P112 GPIO4 GPIO4 S113 eDP1_HPD N/A
P113 GPIO5 GPIO5 S114
LVDS1_1+ /
eDP1_TX1+ /
DSI1_D1+
N/A
P114 GPIO6 GPIO6 S115
LVDS1_1- /
eDP1_TX1- /
DSI1_D1-
N/A
P115 GPIO7 GPIO7 S116 LCD1_VDD_EN N/A
P116 GPIO8 GPIO8 S117
LVDS1_2+ /
eDP1_TX2+ /
DSI1_D2+
N/A
P117 GPIO9 GPIO9 S118
LVDS1_2- /
eDP1_TX2- /
DSI1_D2-
N/A
P118 GPIO10 GPIO10 S119 GND GND
P119 GPIO11 GPIO11 S120
LVDS1_3+ /
eDP1_TX3+ /
DSI1_D3+
N/A
P120 GND GND S121
LVDS1_3- /
eDP1_TX3- /
DSI1_D3-
N/A
P121 I2C_PM_CK I2C_PM_CK S122 LCD1_BKLT_PWM N/A
P122 I2C_PM_DAT I2C_PM_DAT S123 RSVD N/A
P123 BOOT_SEL0# BOOT_SEL0# S124 GND GND
P124 BOOT_SEL1# BOOT_SEL1# S125 DSI0_D0+ DSI0_D0+
P125 BOOT_SEL2# BOOT_SEL2# S126 DSI0_D0- DSI0_D0-
P126 RESET_OUT# RESET_OUT# S127 LCD0_BKLT_EN LCD0_BKLT_EN
P127 RESET_IN# RESET_IN# S128 DSI0_D1+ DSI0_D1+
P128 POWER_BTN# POWER_BTN# S129 DSI0_D1- DSI0_D1-
P129 SER0_TX SER0_TX S130 GND GND
P130 SER0_RX SER0_RX S131 DSI0_D2+ DSI0_D2+
