OWNER'S MANUAL
Mobile Audio System
CS FMP200
PLL Synthesizer Stereo Radio
RDS (Radio Data System) Operation
Digital Compact Disc Player
Automatically Memory Storing
Mechanical Detachable Panel
Preset Equalization
+
022475

Contens
Installation------------------------------------ 3 Pausing playing------------------------------ 13
Take out screw before installation--- 3 Previewing all track------------------------- 13
DIN Front-Mount (MethodA)----------- 3 Repeating the same track----------------- 13
Installing the unit--------------------------- 3 Playing all track in random ---------------- 13
Removing the unit-------------------------- 4 Ejecting a disc-------------------------------- 13
DIN Rear-Mount (Method B)------------ 5 MP3 operation-------------------------------- 13
Using the detachable Front panel---- 6 Switch to CD (MP3) mode----------------- 13
Wiring Conection--------------------------- 7 Ejecting a disc --------------------------------- 14
Operation-------------------------------------- 8 Selecting tracks in single step----------- 14
Switching ON / OF the unit------------- 9 Selecting directory up / down------------ 14
Faceplate release-------------------------- 9 Pausing playing----------------------------- 14
Sound adjustment-------------------------- 9 Previewing all track------------------------- 14
Loudnes---------------------------------------- 10 Repeating the same track----------------- 14
Display----------------------------------------- 10 Playing all tracks in random-------------- 14
Equalization---------------------------------- 10 Selecting tracks by AMS / MP3 button 14
Liquid crystal display--------------------- 10 Display information-------------------------- 15
Reset function------------------------------- 11 Disc notes--------------------------------------- 15
Radio operation----------------------------- 11 Specification------------------------------------ 17
Switching to radio mode----------------- 11 Trouble shooting------------------------------- 18
Selecting the frequency band---------- 11 Warranty------------------------------------------ 19
Selecting station---------------------------- 11 EC Type-Approval certificate-------------- 19
Local / distand------------------------------- 11 Hotline----------------------------------------- 20
Automatic memory storing & Retraction of old devices------------------- 20
program scanning--------------------------- 11
Station storing-------------------------------- 11
RDS operation-------------------------------- 11
CD operation---------------------------------- 13
Switching to CD mode--------------------- 13
Selecting tracks------------------------------ 13
2

53mm
182mm
INSTALLATION
Choose the mounting location where
the unit will not interfere with the
normal driving function of the driver.
Before finally installing the unit,
connect the wiring temporarily and
make sure it is all connected up
properly and the unit and the system
Use only the parts included with the
unit to ensure proper installation. The
use of unauthorized parts can cause
Consult with your nearest dealer if
installation requires the drilling of
holes or other modifications of the
Install the unit where it does not get
in the driver's way and cannot injure
the passenger if there is a sudden
O
If installation angle exceeds 30 from
horizontal, the unit might not give its
Notes:
work properly.
vehicle.
malfunctions.
30
Avoid installing the unit where it would
be subject to high temperature, such
as from direct sunlight, or from hot air,
from the heater, or where it would be
subject to dust, dirt or excessive
vibration.
optimum performance.
stop,like an emergency stop.
DIN FRONT/REAR-MOUNT
This unit be can properly installed either
from "Front"(conventional DIN
Front-mount) or "Rear"(DIN Rear-mount
installation, utilizing threaded screw holes
at the sides of the unit chassis). For
details, refer to the following illustrated
installation methods.
TAKE OUT SCREW BEFORE
INSTALLATION
Before install the unit, please remove
the two screws .
Take out screw
before installation
DIN FRONT-MOUNT (Method A)
Installation Opening
This unit can be installed in any
dashboard having an opening as show
below:
Installing the unit
Be sure you test all connections first, and
then follow these steps to install the unit.
1.
3.
2.
4.
Make sure the ignition is turned off,
and then disconnect the cable from the
vehicle battery's negative (-) terminal.
Disconnect the wire harness and the
antenna.
Press the release button on the front
panel and remove the control panel
(see the steps of "removing the front
panel").
Lift the top of the outer trim ring then
pull it out to remove it.
The two supplied keys release tabs
inside the unit's sleeve so you can
remove it. Insert the keys as far as
they will go (with the notches facing
up) into the appropriate slots at the
5.
3

INSTALLATION
Mount the sleeve by inserting the
sleeve into the opening of the
dashboard and bend open the tabs
located around the sleeve with a
screwdriver. Not all tabs will be able to
make contact, so examine which ones
will be most effective. Bending open
the appropriate tabs behind the
dashboard to secure the sleeve in
Reconnect the wire harness and the
antenna and be careful not to pinch
any wires or cables.
Slide the unit into the sleeve until it
Locks into place.
To further secure the unit, use the
supplied metal strap to secure the back
of the unit in place. Use the supplied
hardware (Hex Nut (5mm) and Spring
Washer) to attach one end of the strap
to the mounting bolt on the back of
the unit. If necessary, bend the metal
strap to fit your vehicle's mounting area.
Then use the supplied hardware
8.
9.
6.
7.
place.
Tabs
Screwdriver
Sleeve
Dashboard
any wires or cables.
(Tapping Screw (5x25mm) and Plain
Washer) to attach the other end of
metal strap to a solid metal part of the
vehicle under the dashboard. This
strap also helps ensure proper electrical
grounding of the unit.
Reconnect the cable to the vehicle
battery's negative (-) terminal. Then
replace the out trim ring and install
the unit's front panel (see the step of
"installing the front panel").
10.
Make sure the ignition is turned off,
then disconnect the cable from the
vehicle battery's negative (-) terminal.
Remove the metal strap attached the
back of the unit (if attached).
Press the release button to remove the
front panel.
Lift the top of the outer trim ring then
pull it out to remove it.
Insert both of the supplied keys into the
slots at the middle left and right sides of
the unit, then pull the unit out of the
dashboard.
1.
2.
3.
4.
Removing the unit
middle left and right sides of the unit.
Then slide the sleeve off the back of
the unit.
Outer Trim Ring
LKey
Sleeve
RKey
Front Panel
Mounting Bolt
Plain Washer
Tapping Screw
Metal Strap
Spring Washer Hex Nut
5.
4

Dashboard or Console
Screw
Hook
Factory Radio
Mounting Bracket
Side View showing
Screw Holes marked
T, N
Screw
INSTALLATION
If your vehicle is a Nissan, Toyota, follow
these mounting instructions.
Use the screw holes marked T (Toyota),
N (Nissan) located on both sides of the
unit to fasten the unit to the factory radio
mounting brackets supplied with your
vehicle.
2. Align the screw holes on the bracket
with the screw holes on the unit, and
then tighten the screws (5x5mm)on
each side.
Note: the outer trim ring, sleeve
and the metal strap are not used
for method B installation.
DIN REAR-MOUNT (Method B)
To fasten the unit to the factory radio
mounting brackets.
1. Use a screwdriver to loose the hook's
screws on the front left and right sides
of the unit and remove the hooks.
5

Front Panel
Protective Case
USING THE DETACHABLE FRONT PANEL
1. Press the release button (open) on
the front panel and pull of the front
panel.
INSTALLING THE FRONT PANEL
To install the front panel, insert the
panel into the housing and make
sure the panel is properly installed.
Otherwise, abnormality occurs on
the display or some keys will not
function properly
1. Do not drop the front panel.
2. Do not put pressure on the display
or control buttons when removing
or installing the front panel.
3. Do not touch the contacts on the
front panel or on the main unit body.
It may result in poor electrical contact.
4. If any dirt or foreign substances
adhered on the contacts, they can be
removed with a clean and dry cloth.
5. Do not expose the front panel to high
temperatures or direct sunlight in
anywhere.
6. Keep away any volatile agents (e.g.
benzene, thinner, or insecticides)
from touching the surface of the front
panel
7. Do not attempt to disassemble the
front panel.
Front Panel
REMOVING THE FRONT PANEL
2. Keep front panel into the case
Precautions when handling
Release Button
6

WIRING CONNECTION
7
GREEN
GREEN/BLACK
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
MAIN UNIT
WHITE
WHITE/BLACK
FRONT Lch
SPEAKER
REAR Lch
SPEAKER
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
Rch RED
Lch WHITE
(GREY)
RCA CABLE
ANTENNA CONNECTOR
BLUE
POWER
ANTENNA
GROUND (B–)
MEMORY
BACK-UP (B+)
IGNITION
SWITCH (ACC+)
RED
YELLOW
BLACK
FUSE
FUSE

OPERATION
24
12
9710 5 8 16 13 4 17
19
6
1823
2221
20
321
11
14 15
+
8

OPERATION
SWITCHING ON/OFF THE UNIT
Switch on the unit by pressing any
button [except OPEN button (7) and
button (4)]. When system is on ,press
button (9) to turn off the unit.
Volume Bass Treble Balance Fader
FACEPLATE RELEASE
Press OPEN button (7) to detach the
removable faceplate.
SOUND ADJUSTMENT
Press SEL button (10) to select the
desired adjustment mode. The
adjustment mode will change in the
following order:
By pressing the volume up button (11)
or volume down button (12), it is
possible Press SEL button (10) for
several seconds, it is activated as
cyclical mode of following functions for
user’s selection.
TA SEEKorALARM PISO UND orMUTE
MASKDPIorALL RETUNE L orS
BEEP 2'nd orOFF
a) TA SEEK OR TA ALARM
- TA SEEK mode:
When newly tuned station does not
receive TP information for several
seconds, the radio retunes to next
station which has not the same
station (PI) as the last station, but
has the TP information.
When TP information gets lost at the
current station for retune time which
is set by RETUNE SHORT (30 sec.)
or RETUNE LONG (90 sec.), the
radio start to retune to next same PI
station. When same PI station does
not catch in 1 cyclic search, the
radio retunes to next station with TP
information.
- TA ALARM mode:
When this mode is selected, any
automatic retune mode is not
activated. Only double beep sound
(ALARM) is output.
When newly tuned station does not
have TP information for several
seconds, beeps come out.
When TP information gets lost at the
current station for retune time, the
beep sound is out-putted.
When newly tuned station has no
RDS signal, "PI SEEK" is
suppressed somewhat.
b) PI SOUND or PI MUTE
While AF switching is implemented in
C201 station, AF can switch to 100
MHz, which is non genuine AF (where,
different PI with same AF) in short
"DIP".
If a car cruises that critical area back
and forth, an oscillation
phenomenon can be occurred,
because the different PI code can be
received from 100 MHz with "XXX"PI.
The car radio has special procedure
to reduce even this kind of
unavoidable situation however there
is a limit to be escaped from this
serious case perfectly.
In that serious case, 2 mode is
selectable as follows:
100
100
PI:C 201 PI:XXX
98 90
- PI SOUND mode:
When above different PI sound (DIP)
is heard once in a while, the DIP's
sound will be heard for a short time.
- PI MUTE mode:
Under above same situation, a mute
sound will be heard for a short time.
c) RETUNE L or RETUNE S mode
The initial time of automatic TA search
or PI search modes is selected.
When PI information is not caught for
retune time, the radio starts to retune
to next same PI station.
When same PI station does not catch
1 cyclic search, the radio goes to last
station and waits for several minutes
until PI code is received.
9

OPERATION
d) MASK DPI or MASK ALL mode
The AF frequency (which has different
PI or NO RDS signal with high field
strength) is masked during checking
PI when the unit searches AF. The
unit doesn't search this AF (DIP) for
few minutes. In the case of the AF
of NO RDS signal with high field
strength, if the real AF is wrongly
masked as DIP by some interference,
the unit hesitates to search real Afs.
For this reason, the unit has the user
option (MASK DPI) which doesn't
mask the AF of NO RDS signal with
high field strength. In MASK DPI
mode, the wrong sound or long mute
(according to PI SOUND or PI MUTE)
can be heard from the AF station
which has NO RDS signal and of
which the field strength is higher than
that of the currently tuning AF (station).
But, these phenomenons are rare and
the user will hardly hear the wrong
sound in whole Europe.
- MASK DPI mode:
Masked only the AF which has
different PI.
- MASK ALL mode:
Masked the AF which has different
PI and NO RDS signal with high
field strength.
e) BEEP 2'ND, BEEP ALL, BEEP
OFF mode
The situation of beep sound is
selected. The 3 mode is selected as
also by pressing the volume up
button (11) or volume down button
(12).
- BEEP 2'nd mode:
The beep is only generated when
all allowed double key is pressed
long (1 sec).
e.g.
When preset button (14) is pressed.
When BAD/LOU button (13) is
pressed.
- RETUNE L mode:
Selected as 90 seconds.
- RETUNE S mode:
Selected as 30 seconds.
When AMS button (18) is pressed.
- BEEP ALL mode:
The beep is generated when
every key is pressed.
- BEEP OFF mode:
The beep is disabled.
LOUDNESS
Press BND /LOU button (13) for several
seconds to reinforce the bass output.
Press it for several seconds again to
release this function.
DISPLAY
Press DSP button (15) to operate as the
conversion of each display mode as
follows:
- In case of receiving a RDS station
In radio mode:
->PS ->CT ->FREQ ->PTY ->
In CD mode:
->CD ->CT ->PS ->FREQ ->PTY ->
- In case of no receiving CT or PTY
information, the display shows as "NO
CLOCK" or "NO PTY".
- In case of receiving a non RDS station
In radio mode:
->"NO CLOCK" ->FREQ -> "NO PTY" ->
In CD mode:
-> CD -> CT -> FREQ -> "NO PTY" ->
Each displaying time is several seconds,
st
and come back to 1 position after
several seconds.
Notes:
- CT = clock time
- FREQ = frequency
EQUALIZATION
Press EQ button (19) to turn on
equalization function and to select
desired audio mode. There are five
kinds of mode as below:
FLAT CLASSICS POP M ROCK M DSP OFF
LIQUID CRYSTAL DISPLAY
Exhibit current frequency and activated
functions on the display (8).
10

RESET FUNCTION
RESET button (24) must be activated
with either a ballpoint pen or thin metal
object.
The RESET button is to be activated for
the following reasons:
- Initial installation of the unit when all
wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
Note: if press RESET button (24), the unit
can't work yet, please use a cotton swab
socked in isopropyl alcohol to clean the
socket on the front panel.
OPERATION
FM1 FM2 FM3
RADIO OPERATION
SWITCHING TO RADIO MODE
Press MOD button (6) shortly to select
radio mode, the radio mode appears
in the display together with the
memory band an frequency.
SELECTING THE FREQUENCY BAND
At radio mode, press BND/LOU button
(13) shortly to select the desired band.
The reception band will change in the
following order:
SELECTING STATION
Press button(17) or button
(16) shortly to activate automatic
seek function. Press for several
seconds until "MANUAL" appears on
the display, the manual tuning mode
is selected. If both buttons have not
been pressed for several seconds,
they will return to seek turning mode
and "AUTO" appears on the display.
AUTOMATIC MEMORY STORING &
PROGRAM SCANNING
- Automatic memory storing
Press AMS button (18) for several
seconds, the radio searches from
the current frequency and checks
the signal strength until one cycle
search is finished, And then 6
strongest stations are stored into
the corresponding preset number
button.
- Program scanning
Press AMS button (18) shortly to
scan preset station, When the
field strength level is more than
the threshold level of stop level,
the radio is holding at that preset
number for several seconds with
release mute, then searches
again.
STATION STORING
Press any one of the preset buttons
(14) (1 to 6) to select a station,
which had been stored in the
memory. Press this button for
several seconds (until 2ND beeps
come out), current station is stored
into the number button.
RDS (RADIO DATA SYSTEM)
OPERATION
- Setting RDS mode
Press AF button (3) and release
immediately to switch on or off
RDS mode.
Whenever RDS is switch on,
symbol “AF” appears on the
display.
Program name is displayed on
receiving a RDS station.
“AF” starts blinking if the
broadcasting signal getting worse.
“ALARM” will be displayed when
an emergency broadcasting is
received, meanwhile sound output
level will be adjusted to the preset
output level automatically when
the volume control is set at
minimum.
- Regional Program Operation
Press AF button (3) for several
seconds to switch on or off region
mode.
Some broadcasting stations
change their program from normal
broadcasting to regional
11

OPERATION
broadcasting for a certain time
period. When region is on, the
current listening program remains
unchanged. When region is off, it
allows the reception moves to the
regional station.
- Using PTY to Select Program
PTY button (1) is operated as
follows:
PTY MUSIC group PTY SPEECH group PTY off
While selecting PTY engagement,
its selection is implemented by
preset buttons as described in notes.
When PTY is selected, the radio
starts to search corresponding PTY
information, and stops if the
corresponding PTY information is
detected.
If corresponding PTY information is
not existed any more, PTY engaging
is automatically exit to normal mode.
Notes:
When PTY mode is engaged, the
PTY switch is shared as follows:
According to above 2 allotted group,
the preset number is used for PTY
selection as follows:
PTY MUSIC group PTY SPEECH group PTY off
MUSIC group
* POP M, ROCK M
*EASY M, LIGHT M
*CLASSICS, OTHER M
*JAZZ, COUNTRY
*NATION M, OLDIES
*FOLK M SPEECH group
*NEWS, AFFAIRS, INFO
*SPORT, EDUCATE, DRAMA
*CULTURE, SCIENCE, VARIED
*WEATHER, FINANCE, CHILDREN
*SOCIAL, RELIGION, PHONE IN
*TRAVEL, LEISURE, DOCUMENT
- Listening to Traffic Announcement
TA button (2) is operated as follows:
When pressed short, it is engaging
whether TA mode on or off.
When TA mode is on and a traffic
announcement is transmitted:
When the unit was in CD (MP3), it
will switch temporarily to radio
mode.
Temporary switch over to an EON
linked station when EON detects a
traffic announcement on that other
program.
If the volume level was under the
threshold point it will be raised to
the threshold point. But the user
changed the volume level, which
was more than the threshold point
(min. TA volume level), it will be set
to the last level.
When TA mode is on, TA of
individual segment is turned on.
When a TP station is received, TP
of individual segment is turned on.
TA interruption function
The current traffic announcement is
cancelled by pressing this key.
But the TA mode will not be off.
When pressed long, it is selected
EON TA LOCAL/EON TA
DISTANCE mode.
The purpose of this key is to reduce
unwanted EON TA switching, which
EON TA information was received
from current station and the radio
switched to that EON linked station,
but no information could not be
received because the EON linked
station is located too far from that
area. So the radio is switched back
to current station again. In above
operation, a customer listens to a
wrong program or mute sound for a
while.
EON TA LOCAL mode
When the filed strength level of
EON linked is less than threshold
level, the radio does not switch that
station, and a customer can hardly
listen to any disturbances.
When EON TA LOCAL mode is
selected, “EON TA LO” on numeric
display is indicated for a few
seconds.
EON TA DISTANCE mode
EON TA switch is tried to
implemented by the information of
current station.
12

OPERATION
When EON TA DISTANCE mode is
selected, “EON TA DX” on numeric
display is indicated for a few
seconds.
The RDS data used are the PI, PS,
AF, TP, TA, EON and PTY data.
PI: Program Identification code
Code for identifying programs
PS: Program Service Name
Broadcast station name data
expressed in alphanumerically
characters
AF: Alternative Frequencies
Frequency list of broadcasting
stations transmitting the same
program
TP: Traffic Program Identification
Identification data for traffic
information-broadcasting
station
TA: Traffic Announcement
Identification
Identification data showing
traffic
information is being transmitted
or not
EON: Enhanced Other Networks
Information
Broadcasting information on PI,
AF, TP, TA, etc, relating to
networks other than the
network used for current
reception
PTY: Program Type Code
Contents of programs such as
news, light music, sports etc.
CD OPERATION
SWITCHING TO CD MODE
If there is no CD inserted in the driver:
Gently insert the CD with the printed
side uppermost into the CD
compartment until you feel some
resistance,. The CD is drawn into the
driver automatically , CD playback
begins.
If a CD is already inserted in the driver:
Keep pressing MOD button (6) shortly
until the CD mode display appears.
SELECTING TRACKS
Press button (16) or button
(17) to move to the previous track or
the following track. Track number
shows on display.
Hold button (16) or button
(17) to fast reverse of fast forward,
CD play starts from when you release
the button.
PAUSING PLAYING
Press PAU button (20) to pause CD
player, Press it again to resume play.
PREVIEWING ALL TRACKS
Press SCN button (21) to play first
several seconds of each track on the
current disc. Press again to stop intro
and listen to track.
REPEATING THE SAME TRACK
Press RPT button (22) to continuously
repeat the same track. Press it again to
stop repeat.
PLAYING ALL TRACKS IN RANDOM
Press SHF button (23) to play all tracks
on CD in random order. Press again to
cancel the function.
MP3 OPERATION
SWITCHING TO CD (MP3) MODE
If there is no MP3 disc inserted in the
driver:
Gently insert the MP3 disc with the
printed side uppermost into the disc
slot (5) until you feel some resistance.
The MP3 disc is drawn into the driver
automatically. The MP3 playback
begins.
If a MP3 disc is already inserted in
the driver:
Keep pressing MOD button (6) shortly
until the CD (MP3) mode display
appears.
EJECTING A DISC
Press button (4) to stop CD playing
and eject the disc from the disc slot (5).
13

OPERATION
EJECTING A DISC
Press button (4) to stop MP3
playing and eject the disc from the
disc slot (5)
EJECTING TRACKS IN SINGLE
STEP
Press button(16) or button
(17) to move to the previous track or
the following track, Track number
shows on display.
PAUSING PLAYING
Press PAU button (20) to pause MP3
player, Press it again to resume play.
PREVIEWING ALL TRACKS
Press SCN button (21) to play first
several seconds of each track on the
current disc. Press again to stop intro
and listen to track.
PREVIEWING THE SAME TRACK
Press RPT button (22) to continuously
repeat the same track, Press it again
to stop repeat.
PLAYING ALL TRACK IN RANDOM
Press SHF button (23) to play all
tracks on MP3 disc in random order.
Press again to cancel the function.
SELECTING TRACK BY AMS/MP3
BUTTON
AMS button is assigned as Digital
Audio Mode selection button in MP3
operation. When pressed, it is
activated as selecting each mode of
Digital Audio. “Searching track
directly” => “Searching Directory or
File Name”=> “Navigation” from root
by MANU/SKIP UP/DOWN buttons
=> “Navigation” from current directory
by MANU/SKIP UP/DOWN buttons.
Searching Track Directly
Press AMS(MP3) button for one
time. It enters into "Searching track
directly" in Digital Audio CD.
The unit searches the track
selected by following direct numeric
buttons:
M1-M6, MOD (7), MANU/SKIP
DOWN(8), MANU/SKIP UP (9),
DSP(0).
If selected three digits, the unit
searches the track at once. if
selected one or two digits, the unit
wait for ENTER (BND/LOU) button
for seconds. The unit searches the
track after few seconds, even if the
enter button is not pressed.
Searching Directory or file Name
Press AMS (MP3) button for two
times. It enters into "Searching
Directory or File Name" in Digital
Audio CD.
The unit searches files and
directories that have the same
character which is inputted by the
user pressing the corresponding
buttons listed on the Table 1 below.
Explain as follows:
- Use the corresponding buttons to
select the characters A to Z, blank,
0-9, _ , - , + .
- Press SEL button to confirm entry
of each characters.
- Press BND /LOU (ENTER)
button to start the title search,
In case the selected title is a
directory name, display will show(' '),
then
- Use the MANU/SKIP UP/DOWN
button to list all songs under
this directory and select the title.
- Press BND/LOU (ENTER)
button to confirm and start the play.
- Repeat the above steps if the
newly selected title is again a
directory.
Searching From Root Directory
Press AMS (MP3) button for three
times. The unit searches fire or
directory from root by MANU/SKIP
UP/DOWN buttons (D-DIR icon
14

OPERATION
Searching From Current Directory
Press AMS (MP3) button for four
times. The unit searches fire or
directory from current directory by
MANU/SKIP UP/DOWN buttons.
(D-DIR icon turns on if the name is
directory). The current directory
name is displayed for a second and
the currently playing file name is
displayed (selected). The user can
select the directory or file in the
directory by MANU/SKIP UP/DOWN
buttons. The selected file can be
played by pressing BND/LOU
(ENTER) button.
"MP3" icon turns on when MP3 disc
is played and blinks when it is in
navigation mode.
DISPLAY INFORMATION
Press DSP button to show the
following information, such as the
clock, ID3 TAG (if available: song title
directory name, artist name, other
contents...) and other information.
turns on if the name is directory).
Display will list all available
directories and songs. Select the
desired directory/songs by using
MANU/SKIP UP/ DOWN button
and BND/LOU (ENTER) button to
confirm. If the selected title is a
song, it starts to play.
If the selected title is a directory
name, display will show (' '), then
- Use the MANU/SKIP UP/DOWN
buttons to list all songs under this
directory and select the title.
- Press BND/LOU (ENTER) button
to confirm and start the play.
- Repeat the above steps if the
newly selected title is again a
directory.
KEY Assigned IN Searching mode (Table 1)
AMS Mode Select
BND/LOU ENTER
M1 A, B, C, 1
M2 D, E, F, 2
M3 G, H, I, 3
M4 J, K, L, 4
M, N, O, 5/Directoty
DOWN
M5
M6 P, Q, R, 6/Directory UP
MOD S, T, U, 7
MANU/SKIP DOWN V, W, X, 8
MANU/SKIP UP Y, Z, SPACE, 9
SEL CHARACTER SHIFT
RIGHT
DSP _,-,+,0
VOLUME UP
/DOWN
VOLUME UP/DOWN & MANU/SKIP UP
/DOWN buttons:
Searching file and directory during
Navigation.
DISC NOTES
A. Notes on discs:
1. Attempting to use non-standard
shape discs (e.g. square, start, heart)
may damage the unit. Be sure to use
round shape CD discs only for this
unit.
2. Do not stick paper or tape, etc, onto
the label side or the recording side
of any discs, as it may cause a
malfunction.
3. Dirt, dust, scratches and warping
discs will cause misoperation.
CHARACTER SELECT
(A, B~8,9,0)
15

OPERATION
B. Notes on CD-Rs (recordable
CDs)/CD-RWs (rewritable CDs):
1. Be sure to use discs with following
marks only for the unit to play:
Recordable Rewritable
2. The unit cannot play a CD-R and
CD-RW that is not finalized. (Please
refer to the manual of your
CD-R/CD-RW recorder or
CD-R/CD-RW software for more
information on finalization process).
3. Depending on the recording status,
conditions of the disc and the
equipment used for the recording,
some CD-Rs/CD-RWs may not be
played on this unit. (see *1)
*1: To have more reliable play back,
please see following
recommendations:
a: Use CD-RWs with speed 1x to 4x
and write with speed 1x to 2x.
b. Use CD-Rs with speed 1x to 8x
and write with speed 1x to 2x.
c. Do not play a CD-RW which has
been written for more than 5
times.
C. Notes on MP3 files (MP3 Version
Only):
1. The disc must be in the ISO9660 level
1or level 2 format, or Joliet or Romeo
in the expansion format.
2. When naming a MP3 file, be sure the
file name extension is ".MP3".
3. For a non-MP3 file, even though the file
name extension is ".MP3", the unit
cannot recognize it.
16

SPECIFICATION
GENERAL
Power Supply Requirements : DC 12 Volts, Negative Ground
Chassis Dimensions : 178 (W) x 160 (D) x 50 (H)
RADIO
FM
Frequency Coverage : 87.5 to 108 Mhz
I.F. : 10.7 Mhz
Sensitivity (S/N=30dB) : 4 V
Stereo Separation : >25 dB
Tone Controls
- Bass (at 100 Hz) : 10 dB
- Treble (at 10 kHz) : 10 dB
Maximum Output Power : 4x50 watts
Current Drain : 5 ampere (max.)
CD PLAYER
Signal to Noise Ratio : More than 55 dB
Channel Separation : More than 45 dB
Frequency Response : 40Hz - 18 kHz
17

TROUBLE SHOOTING
Before going through the checklist, check wiring connection. If any of the problems
persist after checklist has been made, consult your nearest service dealer.
Symptom Cause Solution
No power. The car ignition switch is If the power supply is properly
not on. connected to the car accessory
circuits, but the engine is not
running, switch the ignition key
to "ACC"
The fuse is blown. Replace the fuse.
Disc cannot be Presence of CD disc inside Remove the disc in the player,
loaded or ejected. the player. then put a new one.
Insert the compact disc with
the label facing upward.
Compact disc is extremely Clean the disc or try to play a
dirty or defective disc. new one.
Temperature inside the car Cool off or until the ambient
is too high. temperature returns to normal.
Condensation. Leave the player off for an hour
or so, then try again.
No sound. Volume is in minimum.
Adjust volume to a desired level.
Wiring is not properly Check wiring connection.
connected.
Sound skips. The installation angle is Adjust the installation angle less
more than 30 degrees. than 30 degrees.
The disc is extremely dirty Clean the compact disc, or try
or defective disc. to play a new one.
The operation keys The built-in microcomputer Press the RESET button.
do not work. is not operating properly
due to noise.
The radio does not The antenna cable is not Insert the antenna cable firmly.
work. The radio connected.
station automatic
selection does not The signals are too weak. Select a station manually.
work.
Inserting the disc in reverse
direction.
88-C2000-21
Front panel is not properly fix
into its place.
18

Warranty
This device is covered by a 24-month warranty. The warranty starts with
the date of purchase. In order to proof the date of purchase, we advise to
keep the receipt. If articles are returned without receipt, repairs can only be
executed on payment of additional costs. This arrangement also applies for
inadequately packed articles.
Within the warranty period, all imperfections which are due to defective
material or production procedures will be remedied free of charge. Within
the warranty period the device will be repaired or replaced on discretion of
the Service or ITM Technology AG.
Replaced parts/devices which are replaced become property of ITM
Technology AG. The replacement of the device does not automatically
renew or extend the warranty. The primal warranty period of the original
device remains same and ends after 24 month. Damages which are due to
improper use, wear, tear interference of a third party or circumstances
beyond our control are not covered by the warranty. Consumables such as
batteries, packing material etc. and imperfections which hardly reduce the
value or serviceability of the device are not covered by the warranty. Claims
for damages which are not based on a deliberate act or a grossly
negligence of the producer, are exempted. Our customer service naturally
remains at your disposal after the period of warranty. After expiration of the
warranty or in case of damages for which we can not accept warranty you
will not receive an estimate.
EC Type-Approval Certificate
Communication concering the e1 type-approval of a type of component with
regard to Directive 72/245/EEC, as last amended by Directive 95/94/EC.
19
.

Hotline
*Hotline number: 01805 880606 (0,12€ / Minute)
*Valid for Germany only
Business hours:Monday to Thursday from 08:00 am to 05:00 pm
Friday from 08:00 am to 04:00 pm
We offer you qualified advice, should you encounter problems during
the installation or the operation of your unit.
* This hotline number is valid for the federal republic of Germany only
Retraction of old devices
Waste electrical products must not be
disposed of with household waste.
This equipment should betaken to
your local recycling centre for
safe treatment.
20
